Steelcase Vertical Processor Sling CPRSLFO User manual

Vertical Processor Sling, Fixed Mount
Compatible with c:scape®, Frameone®, and Ology™worksurfaces
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE(888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©2015 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
Tools Required:
®
Page 1 of 7
21078501 Rev D
#2 Phillips
Power Drill
7/16"
CPRSLFO
c:scape and Frameone Worksurfaces Ology Worksurfaces

Page 2 of 7
21078501 Rev D
®
c:scape and Frameone Worksurfaces
2
BOLT
NUT
2
Insert one (1) bolt through sling support bracket and
loosely install the nut on the opposite side.
STRAP
3
Thread straps through sling support bracket and place
assembly onto the CPU.
3
1
Place base bracket on underside of worksurface with
slot towards the rear of the desk and base bracket no
more than 1/4" from the cantilever to allow maximum
clearance between CPU and desk leg. Install with
four (4) 5/8" long screws (included).
SCREW
BASE
BRACKET SLOT
Setback the base bracket, as shown,
to allow the CPU to be flush with the
front edge of the worksurface. For
example: Setback 6-3/4" when using
an 18" deep CPU.
CANTILEVER
1

6
7
5
4
LONG SIDE
OF SLING
SUPPORT
BRACKET
BOLT
6
NUT
Orient sling support bracket on center of CPU
and tighten straps.
NOTE: Long side of sling support bracket
should be placed nearest the side of the desk.
4
5
Insert second bolt through the empty hole in the sling
support bracket.
Tighten both bolts.
Align the mounted bolt with the slot in the base bracket
and slide up and to the rear into position.
Page 3 of 7
21078501 Rev D
®
c:scape and Frameone Worksurfaces

2
BOLT
NUT
2
Insert one (1) bolt through sling support bracket and
loosely install the nut on the opposite side.
STRAP
3
Thread straps through sling support bracket and place
assembly onto the CPU.
3
SLOT
SCREW
CANTILEVER
BASE
BRACKET
Setback the base bracket, as shown,
to allow the CPU to be flush with the
front edge of the worksurface.For
example: Setback 6-3/4" when using
an 18" deep CPU.
1
1
Place base bracket on underside of worksurface with
slot towards the rear of the desk and base bracket no
more than 1/4" from the cantilever to allow maximum
clearance between CPU and desk leg. Install with
four (4) 5/8" long screws (included).
Page 4 of 7
21078501 Rev D
®
Ology Worksurfaces without Overhang

Orient sling support bracket on center of CPU
and tighten straps.
NOTE: Long side of sling support bracket
should be placed nearest the side of the desk.
4
5
Align the mounted bolt with the slot in the base bracket
and slide up and to the rear into position.
5
6
7
BOLT
NUT
Insert second bolt through the empty hole in the sling
support bracket.
Tighten both bolts.
LONG SIDE
OF SLING
SUPPORT
BRACKET
6
4
Page 5 of 7
21078501 Rev D
®
Ology Worksurfaces without Overhang

2
BOLT
NUT
2
Insert one (1) bolt through sling support bracket and
loosely install the nut on the opposite side.
STRAP
3
Thread straps through sling support bracket and place
assembly onto the CPU.
3
SLOT
SCREW
CANTILEVER
1
Place base bracket on underside of worksurface with
slot towards the rear of the desk and base bracket no
more than 1/4" from the cantilever to allow maximum
clearance between CPU and desk leg. Do not place
the base bracket over the worksurface reinforcing
brackets. Install with four (4) 5/8" long screws (included).
1
BASE
BRACKET
WORKSURFACE
REINFORCING
BRACKETS
Setback the base bracket, as shown, to allow
the CPU to be flush with the front edge of the
worksurface. For example: Setback 6-3/4” when
using an 18” deep CPU. Note that when mounting
on Ology worksurfaces with overhang, it may not
be possible to mount the CPU flush with the front
of the worksurface.
Page 6 of 7
21078501 Rev D
®
Ology Worksurfaces with Overhang

Orient sling support bracket on center of CPU
and tighten straps.
NOTE: Long side of sling support bracket
should be placed nearest the side of the desk.
4
5
Align the mounted bolt with the slot in the base bracket
and slide up and to the rear into position.
6
7
BOLT
NUT
Insert second bolt through the empty hole in the sling
support bracket.
Tighten both bolts.
LONG SIDE
OF SLING
SUPPORT
BRACKET
6
4
5
Page 7 of 7
21078501 Rev D
®
Ology Worksurfaces with Overhang
