STONEX SC2000 User manual

www.stonex.it
STONEX SC2000
GNSS Receiver
User Manual
NEX S800A
GNSS Receiver
User Manual
(November 2017)-Ver.1-Rev.0 –Firmware Version: 0.22.170401

SC2000 GNSS Receiver –User Manual 1
Statement
Please read carefully:
The final interpretation of this user manual belongs to STONEX.
This user manual is only for your reference. If your receiver does not match the
case in user manual, the actual situation of the receiver shall prevail.
Information in this document is subject to change without notice; STONEX
reserves the right to change or improve its products and to make changes in
the content without obligation to notify any person or organization of such
changes or improvements. If you have any questions, please contact customer
service center, or contact our authorized dealers.
Please carefully read the notes and instructions in User Manual. In order to
avoid unexpected damage, you should only use original supplied parts. If you
do not use the system with the correct procedure or connect incompatible
accessories, cause the equipment damage and may even endanger other
person and your safety. In this regard, the Company does not assume any
responsibility.

SC2000 GNSS Receiver –User Manual 2
Contents
Statement.......................................................................................................... 1
1. Technical Specification........................................................................ 4
1.1 Overview..........................................................................................................................4
1.2 Main features.................................................................................................................4
1.3 Technical Specifications ............................................................................................4
1.3.1 Physical.........................................................................................................................4
1.3.2 Environmental............................................................................................................4
1.3.3 Electrical .......................................................................................................................4
1.3.4 GNSS..............................................................................................................................5
1.3.5 Ports...............................................................................................................................6
1.3.6 Data and Storage .....................................................................................................6
2. Hardware Structure ............................................................................. 7
2.1 Receiver appearance ..................................................................................................7
2.1.1 Front panel..................................................................................................................7
2.1.2 Back panel ...................................................................................................................9
2.2 Structural drawings / mounting dimensions.................................................10
3. WEB UI................................................................................................. 11
3.1 Summary ......................................................................................................................12
3.2 System Information.................................................................................................. 13
3.2.1 System Information.............................................................................................. 13
3.2.2 GPS Status................................................................................................................14
3.2.3 Satellites.................................................................................................................... 14
3.2.4 Data Transmission.................................................................................................15
3.2.5 Data Recording ......................................................................................................16
3.3 Configuration .............................................................................................................17
3.3.1 Reference Station.................................................................................................. 17
3.3.2 GNSS configuration.............................................................................................. 18
3.3.3 Tracking satellites.................................................................................................. 19
3.3.4 Network..................................................................................................................... 20
3.3.5 Ntrip Server.............................................................................................................. 22
3.3.6 Recording .................................................................................................................23
3.3.7 Port Configuration................................................................................................ 25
3.3.7.1 Bluetooth............................................................................................................... 26
3.3.7.2 COM1...................................................................................................................... 27
3.3.7.3 SOCKET .................................................................................................................. 28
3.3.8 Alerts........................................................................................................................... 29

SC2000 GNSS Receiver –User Manual 3
3.3.9 Registration.............................................................................................................. 29
3.4 Download..................................................................................................................... 30
3.5 System Management .............................................................................................. 31
3.6 Help ................................................................................................................................ 31
4. Operation ............................................................................................ 32
4.1 Power on ......................................................................................................................32
4.2 Quick setting............................................................................................................... 33
5. Accessories .......................................................................................... 38

SC2000 GNSS Receiver –User Manual 4
1. Technical Specification
1.1 Overview
SC2000 is a high-precision CORS reference station receiver. LINUX system as
its development platform, and it supports for secondary development. It has
powerful and stable function, and can be used in many fields.
1.2 Main features
555 channels with Multi-constellation GNSS support.
Superior carrier phase observations of less than 1mm accuracy
Internal battery for more than 20 hours operation.
4G LTE and Bluetooth / WLAN datalink support.
Easy configuration from webUI and remote server.
NTRIP server/caster support.
1.3 Technical Specifications
1.3.1 Physical
Weight：2KG
Dimension：222mm*164mm*79mm
1.3.2 Environmental
Operating temperature：-40℃-65℃
Storage temperature：-40℃-80℃
Humidity：0%-100% non-condensing
1.3.3 Electrical
Input：9-28V
Power：2.8W

SC2000 GNSS Receiver –User Manual 5
1.3.4 GNSS
（1）Channels：555
（2）Tracking signals:
GPS：L1 C/A, L1C, L2C, L2P, L5
GLONASS：L1 C/A, L2C, L2P, L3, L5
BeiDou：B1, B2, B3
Galileo：E1, E5 AltBOC, E5a, E5b, E6
IRNSS：L5
SBAS：L1, L5
QZSS：L1 C/A, L1C, L2C, L5, L6
L-Band up to 5 channels
（3）Positioning accuracy
Table 1-1 Positioning accuracy
Positioning mode
Accuracy
Horizontal
Vertical
static
3mm + 0.1ppm
3.5mm + 0.4ppm
RTK
8mm + 1ppm
15mm + 1ppm
（4）initialization time：＜10s
（5）initialization reliability：＞99.9%

SC2000 GNSS Receiver –User Manual 6
1.3.5 Ports
3 RS232 serial ports(DB9 and 2 LEMO 5pin).
1 RJ45 Ethernet port.
1 power port.
1 USB port.
1 4G LTE antenna port.
1 UHF antenna port.(Optional)
1 EVENT port.
1 1PPS port.
1 SIM card slot.
1 GNSS antenna port.
1.3.6 Data and Storage
Output data format: NMEA-0183，binary，RINEX, RTCM2.x,
RTCM3.x
Internal memory：32G
External storage：32G

SC2000 GNSS Receiver –User Manual 7
2. Hardware Structure
2.1 Receiver appearance
Figure 2-1
2.1.1 Front panel
The front panel of SC2000 receiver includes seven buttons, four LED indicators,
and one OLED display.
Figure 2-2

SC2000 GNSS Receiver –User Manual 8
After switching on SC2000 receiver, current time information and GPS status
are displayed in the main interface. The default language is English, and you
can press the left and right arrow keys to obtain the current IP information.
Table 2-1 Function table
Name
Function
F1
Save the current setup and return to the previous
menu
F2
Enter the main menu
Move the cursor up and down, modify parameters
when entering modify items
Move the cursor left and right
Power key
Switch on/off the receiver and confirmation key
Bluetooth
indicator
It will be light blue when SC2000 is connected via
Bluetooth
Differential
transmission
indicator
When the differential data output, the differential
indicator blinks evenly at 1-second interval
Static recording
indicator
When start static recording, static recording indicator
blinks evenly at 1-second interval
Power indicator
After switching on SC2000 receiver, the power light is
on

SC2000 GNSS Receiver –User Manual 9
2.1.2 Back panel
SC2000 receiver provides a variety of communication interfaces to facilitate
users in different application scenarios.
Figure 2-3 Back panel
Table 2-2 Interface function table
No.
Name
Function
1
PWR
Receiver power supply interface, input voltage
DC 9V-28V.
2
USB
USB interface
3
COM1
RS232 serial port
4
COM2
RS232 serial port（Optional RS485 serial port）
5
COM3
DB9 serial port
6
LTE
GPRS antenna interface
7
1PPS
1 Pulse Per Second output
8
EVENT
EVENT input
9
SIM
Standard size SIM card interface
10
RJ45
Wired Ethernet port
11
GNSS
GNSS External receiver antenna connector
12
UHF
UHF External receiver antenna connector
Note:
The UHF interface is replaced by the OSC interface in the SC2000N.

SC2000 GNSS Receiver –User Manual 10
2.2 Structural drawings / mounting dimensions
(Dimensions in mm)
Figure 2-4

SC2000 GNSS Receiver –User Manual 11
3. WEB UI
There are two ways to login into the WEB interface, which are Ethernet port
login and WIFI login. The WEB interface content of the two login modes is
same.
（1）Ethernet port login: Connect the RJ45 network port with the computer
host and enter the IP address in the browser. Enter user name and password
in the pop-up dialog box; the default username is admin and the default
password is password.
（2）WIFI login: when SC2000 WIFI hotspot is enable, the user can log in into
the WEB interface by connecting to its WIFI network. The hotspot name is the
serial number of the receiver. Enter the IP address: 192.168.10.1, a window will
pop up, the default username is admin and the default password is password.

SC2000 GNSS Receiver –User Manual 12
3.1 Summary
After a succesful authentication to the WEB interface of SC2000, the main page
contents: Reference information, device version, system version, network
parameters, memory status and so on. It is shown as below:
Figure 3-1
Note: The effect of different browsers display may be slightly different,
recommend using Google Chrome or IE.

SC2000 GNSS Receiver –User Manual 13
3.2 System Information
3.2.1 System Information
The system information screen will display the station name, device model,
device serial number, system version, application version information, built-in
OEM board model and network parameter information.
Figure 3-2

SC2000 GNSS Receiver –User Manual 14
3.2.2 GPS Status
The GPS Status page displays the current SC2000 positioning, the base station
coordinates and antenna type.
Figure 3-3
3.2.3 Satellites
This page shows the current satellite signal-to-noise ratio, elevation mask
angle, azimuth and other information. The information of GPS, BEIDOU,
GLONASS and GALILEO are displayed separately.
Figure 3-4

SC2000 GNSS Receiver –User Manual 15
3.2.4 Data Transmission
After setting up the data transmission, the user can see the current data
transfer status on the page as shown in figure 3-5. Click [Edit] to directly jump
to [Ntrip Server].
Figure 3-5

SC2000 GNSS Receiver –User Manual 16
3.2.5 Data Recording
In this page, the user can see the specific data recording information as shown
in figure 3-6. Click [Edit], the user could modify the parameters like path type,
file name, interval, duration time, etc. as shown in figure 3-7.
Figure 3-6
Figure 3-7

SC2000 GNSS Receiver –User Manual 17
3.3 Configuration
3.3.1 Reference Station
On this page the user mainly can set the reference station, antenna, coordinate
system and station coordinates, as shown in figure 3-8.
Figure 3-8
Reference station coordinates: If you do not need known coordinates to
start the reference station, then click on "Load Current Position" to get the
reference station coordinates approximately. However, if you need known
coordinates, please input them according to to the appropriate format.
The web access port is 80. After setting mapping in the router device, then you
can access the SC2000 by Internet, enter the ip address and the port, e.g.
113.109.179.180:80

SC2000 GNSS Receiver –User Manual 18
3.3.2 GNSS configuration
This menu is mainly for the satellite systems and the cutoff angle settings, as
shown in figure 3-10.
Figure 3-10

SC2000 GNSS Receiver –User Manual 19
3.3.3 Tracking satellites
In this page, the user can select the satellites they want to track, as shown in
figure 3-11.
Figure 3-11
