• If the pump overheats on the
Dragonfly®4
kit, an activation switch is
triggered and the system will automatically switch o.
• Do not use the Dragonfly®4 kit in the vicinity of power lines, junction
boxes, power sockets
• If the Dragonfly®4 kit is used to clean illuminated signs, remember to
switch o the power supply first
• Never direct the jet towards people, animals or electrical equipment
• Before each use, undertake a visual check on all electrical cables for
damage. Never use the Dragonfly®4 kit with a damaged cable.
• When using the
Dragonfly®4 kit
do not place it on the ground or use it
as a support element.
Over Heating
Electrical Hazards
Mechanical Hazards
The Dragonfly®4 Internal Window Cleaning Kit is manufactured with the safety of the operator in
mind, including some key features such as; result in serious personal injury.
This applies to all Dragonfly®4 Window Cleaning Kits.
Electrical connections must be carried out in respect of current legislation (in compliance with the
provisions of the IEC 60364-1 standard) and in accordance with the manufacturer’s instructions.
Varitech Systems Ltd, the manufactures of Steamline®, declines all liability for damage caused by
faulty earthing of the appliance
- Varitech Systems Ltd, the manufacture of Steamline®declines all liability for dam
age to persons, animals or things caused by faulty or incorrect connection
- Before connecting the equipment, check that the specification given on the rating plate
corresponds to that of the mains electrical supply
- If the equipment is connected via an extension, use cables with an adequate cross section,
never less than 1,5 mmq. The plug and socket must be watertight
- The electrical safety of the equipment is guaranteed only when correctly and eciently
earthed as specified in current electrical safety legislation (in compliance with the
provisions of the IEC 60364-1 standard). This fundamental safety requisite should be
verified. If in doubt, ask a professionally qualified electrician to check the system
thoroughly. It is recommended that the electric supply to this machine should include a
residual current device that will interrupt the supply if the leakage current to earth
exceeds 30 mA for 30ms or a device that will prove the earth circuit
- The equipment can be disconnected from the mains only by unplugging the plug
from the mains socket.
- When using any electrical appliance, certain fundamental rules should be respected:
• Do not touch the appliance with wet hands or feet
• Do not touch the appliance with bare feet or unsuitable clothing
• Do not pull the power cable or appliance itself to unplug the plug
from the mains
Use only original accessories that come with the Dragonfly®4 Internal Window Cleaning Kit, oering
maximum quality and security. Failure to use original accessories absolves Varitech Systems Ltd, the
manufacturer from all liability.
• If the water pressure in the Dragonfly®4 kit is above the
standard 2.8bar / 40Psi pressure, the pressure switch is activated
to stop the pump over pressurizing
• It is important to never open the Dragonfly®4 pump during
operation or whilst under pressure.
Over Pressure
System Safety Electrical Specifications and Safety
