INSTRUCTION MANUAL
INSTR-SF-TR12-000
STREAMFLO
®
MINI

1Responsibilites
Contents
1. Responsibilities
4. Technical Specifications
5. Assembling The System
6. Controller Settings
7. Operating Your Streamflo® Mini System
8. Charging The Battery
9. Troubleshooting
3. About Your System
2. Safety Regulations
10. Service & Maintenance
11. Why Streamline®?
12. Warranty Information
General Responsibilities
Manufactures Responsibilities
Personnel Responsibilities
System Safety
Safety Precautions
Personnel Safety
3
4
3
4
3
5
3
7
8
9
10
10
11
6
4
12
13
14
Responsibilities
General Responsibilities
Manufacturer Responsibilities
Personnel Responsibilities
These operating instructions allows you to use the Streamflo® Mini system safely and eciently. The
instructional booklet must be read before setting up, starting or using your
Streamline®equipment. It is an integral part of the product itself.
Varitech Systems Ltd, the manufacturer of Streamflo®, holds 12-months warranty on all
machines and equipment from the date of purchased (see Warranty section 2)
Varitech Systems Ltd, the manufacturer of Streamline®, is in no case responsible for failures
or errors caused by modifications to the unit by customer or other persons.
The Streamflo® Mini equipment is designed and manufactured to be operated in
industrial applications. It is important that the operator(s) of the Streamflo® Mini equipment have
read through these operating instructions thoroughly, and understand all safety instructions and
regulations.
The Streamflo® Mini system is not intended for use by children, adolescents,
persons under the influence of alcohol / drugs or simply lacking experience and knowledge.
These operating instructions are designed to educate the user, informing the operator how to carry
out the task at hand successfully, whilst avoiding potential dangers that might occur.
Please keep this booklet in a safe place near your Streamflo® Mini system for future consultation.
Your Streamflo® Mini system is constructed according to current safety standard and regulations. The
latest and current edition is illustrated in this manual.
The contents of this booklet should be bought to the attention of all users.
Please read the warning and instructions contained in this booklet carefully.
They provide important information on the safe use and maintenance of the
equipment. Pay particular attention to general safety instructions.
Important
If needed, training videos can be found on the Streamline®website: www.streamline.systems
Weekly Inspection
Disposal Of Machine
Personnel Responsibilities
Low Water Pressure
Controller Error Codes
Pump wont start
12
11
12
11
12
11
2W: www.streamline.systems E: [e-mail] T: [phone] W: www.streamline.systems E: [e-mail] T: [phone]

2Saftey Regulations
Safety Regulations
4W: www.streamline.systems E: [e-mail] T: [phone] W: www.streamline.systems E: [e-mail] T: [phone]
• If the powerful booster pump overheats on the Streamflo® Mini filtration
system, an activation switch is triggered and the system will
automatically switch o.
• As the Streamflo® Mini trolley system is powered by an electrical source,
never use the equipment in the rain, snow or strong winds.
• Never use the filtration system to clean people and/or animals.
• Before each use, undertake a visual check on all electrical cables for
damage. Never use the filtration system with a damaged cable.
• To avoid all mechanical hazards, place the Streamflo® Mini
trolley system on an even surface only, and ensure
sucient stability.
Over Heating
Electrical Hazards
Mechanical Hazards
The Streamflo® Mini filtration trolley is manufactured with the safety of the operator in mind,
including some key features such as result in serious personal injury.
• If the water pressure in the Streamflo® Mini trolley system is above the
standard 10bar pressure, the pressure relief valve opens on the pump
allowing a greater flow through the waste water outlet, reducing the
pressure in the system and through the pure water outlet.
System Safety
Over Pressure
Use only original accessories that come with the
Streamflo® Mini trolley system, oering
maximum quality and security. Failure to use
original accessories absolves Varitech
Systems Ltd, the manufacturer from
all liability.
Personal Safety
Stay alert, watch what you are doing and use common sense when operating the Streamflo® Mini
trolley system. Do not use the Streamflo® Mini system while you are tired or under the
influence of alcohol, drugs or medication. A moment of inattention while operating the filtration
trolley may result in serious personal injury.
Additional protective equipment such as a dust mask, non-skid safety shoes, hard hat or hearing
protection may be required depending on the safety regulations in the operator surroundings.
Additional protective equipment such as a dust mask, non-skid safety shoes, hard hat
or hearing protection may be required depending on the safety regulations in the
operator surroundings.
Use personal protective equipment to avoid personal injury:
Protective Footware
Protective Gloves

Technical Specifications
2 4
About Your System Technical Specifications
6W: www.streamline.systems E: [e-mail] T: [phone] W: www.streamline.systems E: [e-mail] T: [phone]
Specifications Data
SF-TR12-000 (Streamflo® Mini)
Country Of Origin Great Britan
Maximum Height 1005mm Extended
551mm Compresssed
Maximum Length 141mm
Maximum Width 243mm
Dry Weight 6kg
Wet Weight 18.5kg
Inlet Pressure Requirement N/A
Inlet Water Flow Requirment N/A
Optimum Operating Pressure 6.9Bar / 100Psi
Standard Water Inlet Connection (Male hose lock) Container
Waste Water Outlet Connection (Male hose lock) N/A
Pure Water Outlet Connection (Male hose lock) Q21
Electrical Power Supply 12v
Minimum Operating Temperature 5°C
Maximum Operating Temperature 40°C
Optimum Water Quality N/A
Water Quality Range (MINI l/h - Maxi l/h) n/a
Water Flow (Optimum Output) 3.8lpm
Operating Time Up to 90mins
Charging Time 180mins
1x Controller
1x Telescopic handle
1x Carry handle
1x Tank lid
1x 12Ltr tank
1x Q21 pure
water oitlet
connection
1x Charging
point
1x Streamflo®
4.5Lpm 100psi
6.9bar pump

5 6
Assembling The System Controller Settings
Assembling The System Controller Settings
8W: www.streamline.systems E: [e-mail] T: [phone] W: www.streamline.systems E: [e-mail] T: [phone]
1. Ensure your unit is on a stable floor and dry location. 1. When in position, press the power button on
the flow controller and hold for 2 seconds
2. Remove the container lid and riser tube
and fill container with pure water
2. Now you can adjust the speed of the water
flow through the 100psi multi-speed pump
by pressing and holding the button on the
flow controller untill you reach the
desired setting
3. Connect Outlet pipe to accessory
(Window Cleaning telecopic pole/Lance)
3. To check voltage of battery, press the
controller button twice, voltage of battery will
display. It is recommend any battery lower
than 10.5v requires charging.
4. To switch o the controller, press the power button and hold for 2 seconds
Turning On Your Controller

5
6
Operating Your Streamflo® Mini System
Charging The Battery
Operating Your Streamflo® Mini System
Charging The Battery
8Troubleshooting
10 W: www.streamline.systems E: [e-mail] T: [phone] W: www.streamline.systems E: [e-mail] T: [phone]
1. Fill the tank system with Pure Water
2. Switch on controller to desired flow (See page 9 - section 2)
3. Switch on controller, allow this to run for 2-3 mins to bleed any air our of the system
4. Apply pure water to area and clean
1. Plug the charger into mains electrical socket
2. Locate the charging port on the trolley unit
3. Red and green light on the charger will indicate battery charging completion
4. Always store batteries fully charged
Troubleshooting
Low water pressure or poor water production
Controller Error Codes
Pump will not start
1. Check water supply in is good and consistant
2. Air has not bled from system.
3. Controller calibration set to low.
1. Check for blockages in set up
2. Raise calibration on the controller
3 Controller calibration set to low
1. Check Battery Voltage, controller flashing B constantly, charge battery.
2. Check controller is functioing.
3. Check battery connection secure.
P
(Pressure Switch Activated)
D
(Dead end detected)
B
(Battery Voltage
/ low charge)

9Service & Maintenance 7Why Streamline®?
Why Streamline®?
Flexibility
Quality
Service
• Streamline® systems can be built according to customers’ exact requirements
• For non-standard systems, the user’s needs or specifications are listened to and turned
into reality.
• Whilst price is important, quality is remembered long after price is forgotten
• We insist on sourcing brand name products from around the world, only of a reputable quality,
and bring them together under the Streamline® name
• All Streamline® products carry a full one year’s warranty, according to the manufacturers’
standard terms and conditions of sale.
• We have an in-house technical helpline able to answer most of your questions relating to the
capabilities and functionalities of all Streamline® products
• If we get it wrong, we will put it right. If you are sent a wrong item, we will immediately attend
to sending you the correct item and arrange a collection of the wrong item without
any quibbles
• Streamline® is backed by a comprehensive range with massive stocks providing you with a
‘one stop shop’ for all your requirements.
Manufatured
in the
United Kingdom
Checked & tested
by quality control
12 W: www.streamline.systems E: [e-mail] T: [phone] W: www.streamline.systems E: [e-mail] T: [phone]
Service & Maintenance
Weekly Inspection
Disposal of components and machine
1. Check Streamflo® Mini System is kept clean and chemical free.
2. Check the battery is holding charge.
3. Check all connections are leak free.
The Streamflo® Mini System is classified as special waste. It must be taken apart and divided into
uniform sections which should be disposed of according to current legislation.
Do not use the components removed as spare parts.
Care and maintenance of your Streamflo® Mini System will ensure it is well looked after and running
smoothly every time.
It is recommended to run a weekly examination on the Streamflo Mini system to ensure the components
and connections are adequate and eective for producing constant water flow.
Rinse the full trolley set up after every use. To do this, insert sution tube into clean water and rinse line
with approx 5ltrs of clean water.
Routine maintenance once a year, will add to the life of your Streamflo® Mini system and we recommend
charger, pump and battery are inspected and replaced accordingly to ensure proper rinse clean.
All parts are available from Streamline® for this service.
If water is spilled onto the device, wipe it clean with a dry, lint free, non-abrasive cloth to prolong life.

7Warranty Information Notes
14 W: www.streamline.systems E: [e-mail] T: [phone] W: www.streamline.systems E: [e-mail] T: [phone]
Warranty Information
Streamline® Warranty
The warranty on all Machines and Equipment is
for 1 year (12-months) from RECORDED DATE
OF PURCHASE.
THIS WARRANTY EXCLUDES NORMAL
MAINTENANCE ITEMS, including but not limited
to HOSES, FILTERS, O-RINGS,
DIAPHRAGMS, VALVES, GASKETS,
CARBON BRUSHES and damage to motors
and other components as a result of failure to
replace normal maintenance items. THIS LIST
IS NOT EXHAUSTIVE.
If Streamline® receives notice of such defects
during the warranty period, Streamline®
will either, at its opinion, repair or replace
components which prove to be defective.
Replacement parts will only be supplied under
warranty, upon the inspection and approval of
the defective parts by Streamline®
Should it be necessary to supply replacement
parts before the opportunity to inspect, these
will be charged at current prices and credit will
only be issued upon subsequent inspection and
warranty approval by Streamline®
The customer is responsible for the cost of
return of the defective part. If warranty is
approved, Streamline® will pay for the cost
of the repaired or replacement part.
This warranty excludes the following conditions
and circumstances which are at the discretion
of Streamline®
Wear and tear, misuse, abuse improper
maintenance, frost damage, the use of chemicals
other than those supplied or approved by
Streamline®, improper installation or repair,
unauthorised modification, incidental or
consequential costs, loss or damage, service,
labour or third party charges, the cost of
returning defective parts to Streamline®.
This warranty constitutes the exclusive remedy
of any purchaser of a Streamline® unit and is in
lieu of all other warranties, express or implied,
including without limitation any implied
warranty of merchantability or fitness for use, to
the fullest extent permitted by law. In no event
shall any implied warranty of merchantability or
fitness for use exceed the term of the applicable
warranty stated above and Streamline® shall
have no other obligation or liability.
Important
Unfortunately these rights cannot be
transferred to a third party.

INSTR-SF-TR12-000
STREAMFLO
Instruction Manual
®
MINI
