Sunjoy Sheridan L-GG040PST User manual

1
Congratulations on your purchase of our SUNJOY Sheridan Grill Gazebo. Our clear, easy to
follow, step-by-step instructions will guide you through the assembly process from start to
finish.
WARNING:
zThis unit is heavy. Do not assemble this item alone. 4 people are recommended for safe assembly.
zKeep all children and pets away from assembly area. Children and pets should be supervised when
they are in the area of the Gazebo construction.
zKeep assembly area at least 6ft/1.8m from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
zSome parts may contain sharp edges. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of personal injury and damage to the product.
Please read all instructions before assembly and use.
zAssemble on level ground.
zCheck all bolts for tightness before use, and periodically check and tighten bolts as necessary.
zFor outdoor use only
Sheridan Grill Gazebo
Item# L-GG040PST
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for safe and
easy operation. Keep this manual for future reference.
For technical assistance on assembly or replacement parts, call Sunjoy Industries at
1-866-578-6569 from 8:30AM to 5:30PM EST, or email us at [email protected], or visit
www.sunjoydirect.com for assistance.

2
No. Description Qty Pic.
A Post Screen 1 2
B Post Screen 2 2
C Long Side Screen 2
D Short Side Screen 2
E Slate Table Top 2
F Shelf 2
G Oblique Beam 4
H Big Top Connector 1
I Small Top Oblique
Beam 4
J Small Top Connector 1
K Finial 1
L Hook 1
M Small Canopy 1
N Big Canopy 1
O Screw 24
Parts List

3

4
`
Fig.3: Insert Long Side Screen (C)
into the buckle of Post Screen 1&2
(A&B), and fix them by Screw (O).
(Do the same steps for Short Side
Screen (D) assembly.)
Fig.2: Insert Slate Table Top
(E) into the buckle of Post
Screen 1&2 (A&B), and fix
them by Screw (O). Repeat Fig.
1 & 2 for the other side.
Fig.1: Insert Shelf (F) into the
buckle of Post Screen 1&2
(A&B), and fix them by Screw
(O).

5
Fig.5: Insert the bottom of Oblique Beam
(G) into Post Screen 1&2 (A&B), then put
Big Canopy (N) on the big top. Do not
extend it now.
Fig.4: Insert Oblique Beam (G) into Big Top
Connector (H), then attach Hook (L) to Big
top Connector (H).
Fig.7: Insert Small Top Oblique Beam
(I) into Oblique Beam (G).
Fig.6: Insert Small Top Oblique Beam (I)
into Small Top Connector (J).

6
g
HH Stake 8x180mm 8 PCS
Hardware Pack
Fig.8: Put Small Canopy (M) onto the Small
Top and extend it to Small Top Oblique Beam
(I), attach Finial (K) to Small Top Connector (J).
Fig.9: Cover Oblique Beam (G) by
Big Canopy (N).
Fig.10: Fix the assembled gazebo to floor
by Stake (HH).
Now your gazebo is ready for use.

7
Care & Maintenance
Steel components of garden accessories and furniture are treated with rust inhibiting paint. However, due to
the nature of steel, surface oxidation (rusting) will occur if this protective coating is scratched.
To minimize this condition, it is recommended that care be taken when assembling and handling the product,
in order to prevent the paint from being scratched.
Limited Warranty:
Sunjoy Industries warrants to the original purchaser that this item is free from defects in workmanship and
materials for a period of 1 year from the date of purchase, provided the item was factory-sealed at the time of
purchase and is maintained with care and used only for personal, residential purposes. Should any
manufacturing defect arise within this warranty period, Sunjoy Industries will repair or replace (at our option)
any defective merchandise upon proof of purchase; however, transportation and delivery costs, as well as
payments to a third party for assembly or disassembly of the item, remain the responsibility of the purchaser.
A purchaser of an "open box," previously-returned, or "clearance" item, as well as original purchasers outside
of the warranty period, may obtain replacement parts from Sunjoy Industries for products in current production,
at nominal cost.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of
nature, vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not
covered. Proof of purchase (dated register receipt) is required for warranty claims. Warranty is to the original
purchaser and is non-transferable. Any replacement of warranted items will be in the original style and color,
or a similar style and color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not apply. This
warranty gives you specific rights, and you may also have other rights, which vary from state to state.

1
Felicitaciones por su compra de nuestro Gazebo Parrilla Sheridan de SUNJOY. Nuestras
instrucciones clareas y fáciles de seguir, le guiaran paso por paso por el montaje del principio al
final.
AVISO:
zEsta unidad es muy pesada. No la monte a solas. Recomendamos la ayuda de 4 personas para un
montaje sano y salvo.
zMantenga niños y animales fuera de la zona de montaje. Los niños y los animales deben estar siempre
bajo vigilancia mientras estén en la zona de construcción del Gazebo o Glorieta.
zMantenga la zona de montaje a por lo menos 2m (6 pies) de cualquier obstrucción como vallas, garaje,
casa, ramas colgantes, cuerda para tender o cables eléctricos.
zAlgunas piezas pueden tener bordes afilados. Cuando este montando y utilizando este producto, tendrá
que seguir las precauciones fundamentales de seguridad para reducir el riesgo de lesiones personales y de
danos al producto.
zPor favor, léase las instrucciones antes de montar y emplear.
zMonte sobre una superficie a nivel.
zVerifique todos los tornillos para asegurarse que están apretados antes de emplear y periódicamente y
apriételos si es necesario.
zPara empleo al exterior únicamente.
Gazebo Parrilla Sheridan
Articulo No. L-GG040PST
IMPORTANTE
Léase, por favor, estas instrucciones detenidamente y completamente y sigua cada etapa con
cuidado para una operación fácil y segura. Guarde esta manual para futura consulta.
Para asistencia técnica sobre el montaje o piezas de recambio, llame a Sunjoy Industries al
1-866-578-6569 de 8h30 a 17h30, hora del Este, o por correo electrónico a
[email protected], o visite www.sunjoydirect.com para asistencia.
1

2
No. Descripción Cantidad Diagrama
A Fachada del Poste 1 2
B Fachada del Poste 2 2
C Fachada del Lado
Largo 2
D Fachada del Lado
Corto 2
E Mesa de Pizarra 2
F Estante 2
G Viga Arqueada 4
H Conexión del Techo
Grande 1
I
Conexión de la Viga
Inclinada del Techo
Pequeño
4
J Conexión del Techo
Pequeño 1
K Florón 1
L Gancho 1
M Toldo Pequeño 1
N Toldo Grande 1
O Tornillo 24
Lista de Piezas

3
