Sunjoy A101010800 User manual

Country of Origin: China Production Number: xxxxxxxxxx
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
1-(866)-578-6569
[email protected]
ITEM No.:A101010800

2/ 7
∙
Country of Origin: China
A P000200450 Post 4
B P000100317 Base plate 4
C P000400864 Across beam 1 4
D P000400865 Across beam 2 4
E P000601307 Middle beam 4
F P000601306 Slanting beam 4
AA H06015C11 M6 * 15 Bolt 8PCS
BB H06030C11 M6 * 30 Bolt 8PCS
CC H19002C11 M6 Flat Washer 16 PCS
DD H14001C11 M6 Nut 8 PCS
EE P90804B07016 M6*20 8 PCS
FF P90804B07016 M6*15 16PC
GG P12401B01001 Stake 8PCS
HH P90701A07001 Mosquito Netting Hook 32PCS
II H00002C12 M6 Wrench 1 PCS
JJ H00001C12 M6 Wrench 1 PCS
Parts List
Hardware Pack

3/ 7
∙
Country of Origin: China
G P000501135 Middle beam
bottom connector 4
H P000501136 Big top connector 1
I P005700645 Netting rod 8
J P005700643 Big top adjustable
tube 8
K P005700644 Small top
adjustable tube 4
L P005700606 Mosquito netting 1
M P001100509 Small canopy 1
N P001100508 Big top canopy 1
Ste
p
1
A
Fig.2
B
C
D
E
F
H
Fig.3
Fig.6
Fig.5
Fig.7
Fig.4
Fig.8
Fig.1

4/ 7
∙
Fig.1-1:Insert across beam 1（C）into across beam 2（D）.
Fig.1-2: Attach netting rod（I）、middle beam bottom connector（G）to across beam 1/2（C/
D）and fix by using bolt (FF).
Fig. 2：Attach base plate(B) to bottom post（A）fix by using bolt（DD）and flat washer（CC）.
Fig.3:Insert across beam1/2（C/D）into groove of post（A），then connect across beam 1/2（C/D）
to post（A）by using bolt（EE）.
Fig.4: Insert middle beam（E）、slanting beam（F） into big top connector（H）.
Fig.5：Insert big top adjustable tube（J）inmost hole to middle beam（E）and slanting beam longer
end（F）.
Fig.6: Insert small top adjustable tube inmost hole（K）to slanting beam short end（F）.
Fig.7：Attach slanting beam (F) to Post (A) by using bolt（BB）、flat washer（CC）and Nut（DD）.
Fig.8：Connect middle beam(E) to middle beam bottom connector, by using bolt（BB）、Flat washer
（CC）and washer（DD）.
Country of Origin: China
Fig.1-1
A
B
Fig.1-2 Fig.2
D
C
C D
G
I
I FF
CC
DD CC DD
Fig.6
Fig.3
EE EE
A H
F
EF
E
E/F
J
K
FF
A
CC
DD
BB
BB
DD
CC
E
G
Fig.4 Fig.5
Fig.7 Fig.8

5/ 7
∙
Country of Origin: China
Fig.8：Place small canopy four corner（M）to small top adjust tube（K）.
Fig.9: Place big canopy four corner（N）to big top adjustable tube（J）.
Ste
p
2
Fig.9
M
Fig.10
Fig.1
N
Fig.9
M
K
N
J

6/ 7
∙
Country of Origin: China
Fig.10-1: Put ring（HH）through mosquito netting loop（L），hang mosquito netting to
mosquito rod（I）.
Fig.10-2: Fix mosquito netting bandage（L） to post（A）.
Fig.11: Put the stake（GG）through base plate（B）and fix on ground.
Ste
p
3
Fig.10-1
Fig.11
L
Fig.10-2
Fig.10-2 Fig.11
L
I
L
A
B
B
HH
GG
GG

7/ 7
∙
Country of Origin: China

Oursteelcomponentsforgardenaccessoriesandfurniturearetreatedwithrustinhibitingpaintthatprotectsitfrom
rusting.However,duetothenatureofsteel,surfaceoxidation(rusting)willoccuroncetheseprotectivecoatingsare
scratched.Thisisnotadefectandthusnotcoveredbythewarranty.
Tominimizethiscondition,werecommendcarewhenassembling&handlingtheproducttopreventscratchingthepaint.
Shouldanyscratchingordamageoccur,werecommendimmediatetouch‐upwithrustinhibitingpaint.
Surfacerustcanalsobeeasilyremovedwithaverylightapplicationofcommoncookingoil.Ifsurfaceoxidation(rusting)
occursandifnomeasureistakentopreventthis,theoxidationmaystartdrippingontodeckorpatioandcauseddamaging
stains,whichmaybedifficulttoremove.Thiscanbepreventediftheabove‐mentionedmeasuresaretakentokeepthe
productfromoxidizing.
Usedampclothtowipeoffthestainsasquicklyaspossible.
Ifnecessary,washwithamildsolutionofsoapandwater;rinsethoroughlyanddrycompletely.
Periodicallycheckandensurethatallboltsarewell‐tightenduringuse
SunjoyGroupwarrantstotheoriginalpurchaserthatthisitemisfreefromdefectsinworkmanshipandmaterialsforaperiodof
6monthsfromthedateofpurchase,providedtheitemwasfactory‐sealedatthetimeofpurchaseandismaintainedwithcare
and used only for personal, residential purposes. Should any manufacturing defect arise within this warranty period, Sunjoy
Group will replace (at our option) any defective merchandise or parts upon proof of purchase; however, transportation and
delivery costs, as well as payments to a third partyfor assembly or disassembly of the item, remain the responsibility of the
purchaser.Apurchaserofan"openbox,"previously‐returned,or"clearance"item,aswellasoriginalpurchasersoutsideofthe
warrantyperiod,mayobtainreplacementpartsfromSunjoyGroupforproductsincurrentproduction,atnominalcost.
Items used for commercial, contract, or other non‐residential purposes, or items damaged due to acts of nature,
vandalism, misuse,orimproperassemblyarenotcovered.Corrosionorrustingofhardwareisnotcovered.Proofofpurchase
(datedregisterreceipt) is required for warranty claims. Warranty is to the original purchaser and is non‐transferable. Any
replacement of warranteditemswillbeintheoriginalstyleandcolor,orasimilarstyleandcoloriftheoriginalisunavailableor
hasbeendiscontinued.Assomestatesdonotallowexclusionsorlimitationsonanimpliedwarranty,
theaboveexclusionsandlimitationsmaynotapply.This warranty gives you specific rights, and you may also have other
rights,whichvaryfromstatetostate. 
Care and Maintenance
Limited Manufacturer’s Warranty
Exclusions:
