Sunjoy A101012300 User manual

Country of Origin: China Production Number: xxxxxxxxxx



ITEM NO.：A101012300
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com 
1-(866)-578-6569
[email protected]

2/ 8
Country of Origin: China
DescriptionLabelPart#Qty Image
PostA1 P000200454 4
Longscreen B1 P0004008864
Shortscreen C1 P000400887 4
Midbeam
connector D3P000501164 4
Hook E1 P0058000011
Slantingbeam
upperbar F1 P000601329 4
Slantingbeam
lowerbar F2 P000601331 4
Middlebeam G1 P0006013304
Bigtop
connector H1 P000501163 1
Adjustabletube IP00570065212
Small top
slanting bar J1 P000601328 4
Small top
connector K1 P000501162 1
Stake plate L P000100324 4
Stake cover M1 P006100168 4
Netting bar N1 P005700653 8
Arc support O1 P005000413 8
Small canopy P1 P001100534 1
Mid canopy Q1 P001100535 1
Large Canopy R1 P001100536 1
Curtain S P001300104 1
Parts List

3/ 8
Country of Origin: China









Mosquito
netting T P001200207 1
Hardware Pack 1
Label Description Part# Qty Image
AA M6X20 Bolt H010020012 32PCS
BB M6 Flat washer H050010057 72PCS
CC M6X30 bolt H010020023 40 PCS
Fig.1：Putstakecover(M1)through
Post(A1) and lift up stake cover,
thenattachstakeslate(L)to
bottomofpost(A1)byusing
bolt(AA)、washer(BB).
Fig.2‐1：Attachshort
screen （C1 ）tolong
screen（B1）.
Fig.2‐2：Attach middle
beam lower connector(D3)
to long screen(B1) and
short screen(C1), by using
bolt(AA)、washer(BB).
Z1 M6 wrench H090010002 2 PC

4/ 8
Country of Origin: China


Fig.3‐1：Inserttheassembled
screen(B1/C1)topost（A1）.
Fig.3‐2：thenfixassemble
screen（B1、C1）topost
（A1）byusingbolt(CC)、
washer(BB).
Fig.4：attach netting bar(N1)to
longsidescreenand(B1)andshort
sidescreen(C1),byusingbolt
(AA)、washer(BB).
Hardware Pack 2
Label Description Part# Qty Image
BB M6 flat washer H050010057 16 PCS
EE M6X35 bolt H010020013 8 PCS
DD M6 nut H040010003 8 PCS
Fig.5：Attacharcsupport（O1）to
post（A1）andacrossscreen（B1、
C1）；byusingbolt(CC)、Washer(BB)

5/ 8
Country of Origin: China



Fig.10：Byusingbolt(EE)、
washer 片(BB)、nut (DD),attach
middle beam(G1) to
middle beamconnector(D3)；
Fig.11：Insertsmalltopslantingbar
(J1)intosmalltopconnector(K1)。
Fig.12：Putlargecanopy
(R1) ，middle
canopy(Q1)on top in
turn，donotspreadout。
Then insert assembled
smalltopslantingbar(J1)
intobig top slanting
upperbar（F1）.
Fig.8：Byusingbolt(EE)、washer(BB)、
nut(DD), attach slanting beam lower
bar(F2)topost(A1)；
Fig.6 ：Insertslanting beam
lowerbar（F2）intoslanting
beamupperbar（F1）
Fig.7 ：Insert slanting beam(F)
intobigtopconnector（H1）；
Fig.13‐1、Fig.13‐2：attachedtheadjustabletube（I）tobottom
ofbigtopslantingbeamupperbar（F1）andbottomofbig
top slanting lower bar（F2），and bottom of small top
slantingbar（J1），adjustthelengthshortest。

Fig.9：Insert middle beam

(G1) to big top connector

(H1).Thenscrewthehook

(E1) to big top connector
(
H1)。

6/ 8
Country of Origin: China
Hardware Pack 3
Label Description Part# Qty Image
FF Φ6*230 floor stake H070010008 8 PCS
GG Ring R079990135 112PCS
Fig.13：Fix small canopyfour
corner(P1) to
adjustabletube（I），
then adjust length till
canopytight.
Fig.14：Fixmiddlecanlpy
four corner (Q1) to big
top slanting beam upper
bar （F1 ）,then adjust
middle top end tube till
middlecanopytight。
Fig.15 ：Fix big canopyfour
corner(Q1) to big top slanting
lowerbar（F2），thenadjustbig
topendtubetillcanopytight.

7/ 8
Country of Origin: China






Fig.16：B
yusingring(GG)
hang mosquitonetting(T)
onnettingbar（N1）; by
usingring(GG)hangcurtain
(S) on screen lower tube
（B1、C1）。
Fig.17 ：Byusing
stake(FF)fixassembled
gazeboonground.

8/ 8
Country of Origin: China
 Oursteelcomponentsforgardenaccessoriesandfurniturearetreatedwithrustinhibitingpaint
thatprotectsitfromrusting.However,duetothenatureofsteel,surfaceoxidation(rusting)will
occuroncetheseprotectivecoatingsarescratched.Thisisnotadefectandthusnotcoveredby
thewarranty.
 Tominimizethiscondition,werecommendcarewhenassembling&handlingtheproductto
preventscratchingthepaint.Shouldanyscratchingordamageoccur,werecommendimmediate
touch‐upwithrustinhibitingpaint.
 Surfacerustcanalsobeeasilyremovedwithaverylightapplicationofcommoncookingoil.If
surfaceoxidation(rusting)occursandifnomeasureistakentopreventthis,theoxidationmay
startdrippingontodeckorpatioandcauseddamagingstains,whichmaybedifficulttoremove.
Thiscanbepreventediftheabove‐mentionedmeasuresaretakentokeeptheproductfrom
oxidizing.
 Usedampclothtowipeoffthestainsasquicklyaspossible.
 Ifnecessary,washwithamildsolutionofsoapandwater;rinsethoroughlyanddrycompletely.
 Periodicallycheckandensurethatallboltsarewell‐tightenduringuse
SunjoyGroupwarrantstotheoriginalpurchaserthatthisitem isfree fromdefects inworkmanship
andmaterialsforaperiodof  1yearfromthedateofpurchase,providedtheitemwasfactory‐sealed
atthetimeofpurchaseandismaintainedwithcareandusedonlyforpersonal,residentialpurposes.
Shouldanymanufacturingdefectarisewithinthiswarrantyperiod,SunjoyGroupwillreplace(atour
option) any defective merchandise or parts upon proof of purchase;however,transportation and
deliverycosts,aswellas paymentstoathirdpartyforassemblyordisassemblyofthe item,remain
theresponsibilityofthepurchaser.Apurchaserofan"openbox,"previously‐returned,or"clearance"
item, aswell as original purchasers outside of the warranty period, may obtain replacementparts
fromSunjoyGroupforproductsincurrentproduction,atnominalcost.
Itemsusedforcommercial,contract,orothernon‐residentialpurposes,oritemsdamagedduetoactsof
nature,vandalism,misuse,orimproperassemblyarenotcovered.Corrosionorrustingofhardwareisnot
covered.Proofofpurchase(datedregisterreceipt)isrequiredforwarrantyclaims.Warrantyistotheoriginal
purchaserandisnon‐transferable.Anyreplacementofwarranteditemswillbeintheoriginalstyleand
color,orasimilarstyleandcoloriftheoriginalisunavailableorhasbeendiscontinued.Assomestatesdonot
allowexclusionsorlimitationsonanimpliedwarranty,theaboveexclusionsandlimitationsmaynotapply.
Thiswarranty givesyouspecificrights,andyoumayalsohaveotherrights,whichvaryfromstatetostate. 
Care and Maintenance
Limited Manufacturer’s Warranty
Exclusions:
