Sunjoy L-GZ288PST-4D User manual

IMPORTANT:
Please read and follow all safety statements, warnings, assembly instructions, use & care directions, before
attempting to assemble.
WARNINGS:
1. Assembly Instructions must be followed.
2. Pegs supplied must be used to hold this gazebo in place when upright.
3. Warranty does not cover damage due to extreme weather conditions.
4. Do not use candles, matches or open flames of any kind in or near a tent.
5. Do not cook inside the tent.
6. Build campfires downwind and several meters away from a tent and be sure to fully extinguish campfires
before leaving a campsite or before retiring for the night.
Assembly Instruction
ITEM# L-GZ288PST-4D
Classic Scroll Gazebo

7. Exercise extreme caution when using fuel-powered lanterns or heaters inside a tent and use
battery-operated lanterns whenever possible.
8. Do not refuel lamps, heaters or stoves inside a tent.
9. Extinguish or turn off all lanterns before going to sleep.
10. Do not smoke in a tent.
11. Do not store flammable liquids inside a tent.
12. KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC. This tent is made of
flame-resistant fabric. It is not fireproof. The fabric will burn if left in continuous contact with a flame source.
Panel A 4
Panel B 4
Short side support pole C 2
Long side support pole
1D 2
Long side support pole
2E 2
Pole F 4
Pole G 2
Pole H 2
Pole I 4
Center Connector J 1
Center Connector K 1
Top Hook L 1
Corner Connector 1 M 2
Corner Connector 2 N 2
Center Finial O 1
Corner Finial P 4
Big Canopy Q 1
Small Canopy R 1
Parts List

Hardware Pack usedin Step 1
AA M6X15 Bolt 8PCS
BB M6X32 Bolt 28PCS
CC M6 Flat Washer 52PCS
DD M6 Wrench 2PCS
HH M6 Nut 16PCS

Fig.1
：
Use Bolt (BB) and Flat Washer (CC) tofix Panel (B) and Panel (A).
Fig.2
：
Insert Long side support pole (D) into pole (E), attach pole (D) and (E) by using Bolt (AA) and Flat Washer
(CC).
Fig.3
：
Attach Pole C&D&E to Panel (A) and Panel (B) by using Bolt (BB) and Flat Washer (CC).
Hardware Pack usedin Step 2
AA M6X15 Bolt 4 PCS
BB M6X32 Bolt 4PCS
CC M6 Flat Washer 12PCS
HH M6 Nut 4 PCS
Fig.4
：
Insert Corner connector (M&N) into panel (A) and (B).
Fig.5
：
Insert Pole (F) into Center Connector (J). (Notes: put the pole end with hole upwards as Fig 5-1 )
Fig.6
：
Insert end of Pole (F) into Corner Connector (M&N).

Fig.7
：
Insert Pole (G&H) into Center connector (J).
Fig.8
：
Fix Pole (G) to Short side Support Pole (C) and Fix Pole (H) to Long side Support Poles (D&E). Put
Big Canopy (Q) onto the Big Top, do not fully spread.
Fig.9
：
Insert Pole (I) into Center Connector (K).
Fig.10
：
Fix Pole (I) to Pole (F) by using by Bolt (BB), Flat Washer (CC) and Nut (HH)
Hardware Pack usedin Step 3
EE ￠6*180“7”Stake 16 PCS

USE & CARE:
1. This gazebo is not a permanent structure and should be disassembled & stored away after use.
2. Do not repack your gazebo until completely dry.
3. This gazebo must be assembled by two adults or more.
4. This gazebo must not be left erect in windy conditions.
5. Loading limit of the hook is 33 lbs.
6. Loading limit of the ring is 25 lbs.
7. Steel components for garden accessories and furniture are treated with rust inhibiting paint that protects
them from rust. However, due to the nature of steel, surface oxidation (rusting) will occur if this protective
coating is scratched. This is a natural process. To minimize this condition, it is recommended that care be
taken when assembling and handling the product in order to prevent the paint from being scratched. If
scratching or damage occurs, it is recommended that the area be touched-up immediately with rust inhibiting
paint, which is convenient to purchase from your local shop. Surface rust can be removed easily using a very
light application of common cooking oil. If surface oxidation (rusting) occurs and no measures are taken to
correct it, the oxidation may start dripping onto the deck or patio, which may cause damaging stains that may
be difficult to remove.
Fig.11
：
Put Small Canopy (R) to small top, put Centre Finial (O) to small top connector. Put fully spread Big
Canopy (Q) to the big top, screw Corner Finial (P) into four corner on the big top.
Fig.12：Fix the completely assembled gazebo by Stake (EE).
