Sunjoy A106001000 User manual

CountryofOr
igin:China ProductionNumber:xxxxxxxx
RETRACTABLE SHADE PERGOLA
ASSEMBLY INSTRUCTION
ITEM#：A106001000
Ifyouhaveanyissueswiththeproduct,donotreturn
theproductbacktothestore
Foranyquestionsorissuesaboutourproduct
CallSunjoyCustomerService
1-866-578-6569
at anytime, 24 hours / 7 days a week
Forfurtherassistance,pleasewritetous at
[e-mail]

2 /21
CountryofOrigin:China
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
SAFETY INFORMATION ：
Please read and understand this entire manual before attempting to assemble or install the
product.
WARNING:
1. Keep all children and pets away from assembly area. Children and pets should be
supervised while gazebo is being assembled.
2. The assembled gazebo should be located at least 6 feet from any obstruction such as
fence, garage, house, overhanging branches, laundry lines or electrical wires.
3. Some parts may contain sharp edges. Wear protective gloves if necessary, during
assembly.
4. This unit is heavy. For safety, do not assemble this item alone. Three to four people are
recommended for safe assembly.
5. Keep all flame and heat sources away from the tent fabric. This tent is made with fabric
that meets CPAI-84 specifications for flame resistance. It is not fire proof. The fabric will
burn if left in continuous contact with any flame source. The application of any foreign
substance to the tent fabric may render the flame-resistant properties ineffective.
6. Check all nuts and bolts periodically for tightness and, when required, tighten them again.
7. While this gazebo is manufactured to withstand winds through only the supplied ground
stakes, in areas subject to frequent severe weather, securing the gazebo to a deck,
concrete patio or footings should be considered.
8. Do not use ladder leaning against the gazebo or climbing onto the roof.
9. Do not use or enter the gazebo if there exists any of the following or of similar conditions:
a. Visible movement of support members, roofing panels or sagging roofline.
b. Creaks or audible noise from the gazebo.
c. Cracks, fractures or malformation of support members or roof panels.
d. Damaged or missing fasteners.
CAUTION
•Install the gazebo on level ground. Stakes are provided to secure the gazebo to the ground.
Do not assemble the gazebo on sandy, muddy or loose soil, as stakes do not have enough
anchorage in these types of soil. If you wish to secure the gazebo to a wood deck or
concrete surface, use anchors suited to these surfaces. Snow must be cleared off regularly
during snowy days. Remove the snow at the roof top when it is thicker than 2 inches. In
order to avoid damage, use a plastic snow rake to remove excessive snow and ice buildup
from roof and keep away from falling debris. Any assembly or maintenance of the product
must be carried out by adults only. Please check your state and local regulations prior to
purchasing. Some jurisdictions may require permits for installation and use. Some special
procedures may be valid in your area.
•For outdoor use only.
•If any scratch paint, please touch up to prevent rusting.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents
list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.

CountryofOrigin:China
3 /21
TOOLS NEEDED
IMPORTANT
How many people needed for the installation work
Provided in hardware pack
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
4 /21

EXPLODED DRAWING
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
5 /21
Parts List
LabelPart NumberDescription Qty Part Image
A P000600916 Top Beam 1 7
B P000600917 Top Beam 2 7
C P000400628 Beam 1
（Long Side） 2
D P000400627 Beam 2
（Long Side） 2
E P000400629 Beam 1
（Short Side） 2
F P000400630 Beam 2
（Short Side） 2
G1 P000500747 Corner 1 2
G2 P000500748 Corner 2 2
G3 P005600175 Angle Sleeve 4
H P000200295 Post 4
J P000100179 Base 4
K P006100114 Base Cover 4
L P005000252 Arc support 1 4
M P005000253 Arc support 2 4
N1 P005700270 Pipe For Pull
Cloth 1 7
N2 P005700271 Pipe For Pull
Cloth 2 7
N3 P005700272 Pipe For Pull
Cloth 3 2
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
6 /21
N4 P005700273 Pipe For Pull
Cloth 4 2
P P005800117 Hook 4
Q1 P005700268 Guide Tube 1 1
Q2 P005700266 Guide Tube 2 1
Q3 P005700269 Guide Tube 3 1
Q4 P005700267 Guide Tube 4 1
R P003300024 Pulley 14
S P006400011 Small Canopy 1
T P006400012 Big Canopy 1
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
7 /21
Hardware Pack
LabelPart NumberDescription Qty Add Part Image
AA H010020011 Bolt M6*15 122 13
BB H050030001 Flat washer
M6 168 18
CC H010110018 Bolt M6*45 14 2
DD H010110009 Bolt M6*15 32 4
EE H070010003 Stake
Φ8*180 8 0
FF H090010017 Wrench M6 1 0
Actual Size
Actual Size
Actual Size
Actual Size
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
GG H050020017 24 2
Spring
WasherM6

CountryofOrigin:China
8 /21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
2x
8x
2x 4x
8x
1

CountryofOrigin:China
9 /21
2x
2x
8x
2x
2x
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
2
8x 8x

CountryofOrigin:China
10 /21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
3
8x 8x 8x
2x

CountryofOrigin:China
11 /21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
4
8x
4x
4x 4x
8x

CountryofOrigin:China
12 /21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
5
8x8x

CountryofOrigin:China
13 /21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
6
2x
4x
16x 16x 16x

CountryofOrigin:China
14 /21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
7
4x 4x
32x 32x

CountryofOrigin:China
15 /21
7x 7x
18x
2x 2x
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
8
18x

Country of Origin: China
16 / 21
14x
1x 7x
2x 14x
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
9
14x

Country of Origin: China
17/21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
10
1x
1x
1x
1x
12x 12x

Country of Origin: China
18/21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
14x
7x
7x
14x
11

Country of Origin: China
19/21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
12
1x 7x
14x 14x

CountryofOrigin:China
20 /21
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
13
8x
