Sunjoy L-GZ407PST-KD User manual

ASSEMBLY INSTRUCTIONS
ITEM#L-GZ407PST-KD
10’x10’ Gazebo with one side privacy panel
IMPORTANT:
Please read and follow all safety statements, warnings, assembly instructions, use & care directions before attempting to
assemble.
1. When installing and assembling your gazebo, it is recommended that 2 or more adults are involved.
2. Do not use the unit during an electrical storm, as there is a remote chance of getting struck by lightening.
3. Do not climb on top of the gazebo. Falling off the gazebo can result in serious injury, possibly even death.
4. Do not leave the gazebo assembled when there is a risk of high wind, as possible damage will occur to the structure.
5. Never barbecue under this gazebo or use lanterns that contain naked flames.
6. This package contains small items and plastic bags that should be kept away from children.
7. Ensure that all connectors & poles are firmly secured in position fully. It is important to do so before use so as to avoid
collapsing or damage to the item, which could result in injury.
8. WARNING: Keep flame and heat sources away from the gazebo fabric. The fabric may burn if it is exposed to prolonged
contact with a source of heat. The application of any foreign substance to the gazebo fabric may render the flame-resistant
properties ineffective.
9. WARNING: Please take down the gazebo during strong wind. The manufacturer or retailer is not liable for any loss of the
product or other items due to the failure to take down the gazebo during strong wind.
Tools required: Ladder, Hammer Screwdriver (not included)

Hardware Pack
Parts List
AA M6*15mm Screw 36PCS
BB M6mm Washer 52PCS
CC M6*32mm Screw 16PCS
DD M6mm Wrench 1PC
FF Φ6*180mm Peg 16PCS
A1 Panel 1 4
A2 Panel 2 4
B1 Panel 3 4
B2 Panel 4 4
C Side pole 1 4
D Side pole 2 12
E Corner bottom beam 4
F Corner upper beam 4
G Support pole 1 4
H Support pole 2 4
I Top connector 1
J Hook 1
K Panel connector 16
L Shelf 4
M Big canopy 1
N Small canopy 1
P Privacy panel 1

Step 1:
Connect Panel A1 (A2) and Panel connector (K) by Screw (AA) and Washer (BB).
Connect Panel B1 (B2) and Panel connector (K) by Screw (AA) and Washer (BB).

Step 2:
Connect Panel A1 (A2) and Panel B1 (B2) by Screw (CC) and Washer (BB).

Step 3:
Fig. 5: Insert Side pole 2(D) into Side pole 1(C).
Fig. 6: Insert Side pole 2(D) into Panel B1 (A1).

Step 4:
Fig. 7: Insert Corner bottom beam (E) into Side pole 2(D).
Fig. 8: Insert Side pole 2(D) into F.
Fig. 9: Insert Support pole 2(H) into Support pole 1(G).
Fig. 10: Insert Corner upper beam (F) and Support pole 1(G) into Top connector (I).
Fig. 11: Insert Corner bottom beam (E) into A1 (B1).
Fig. 12: Connect Support pole 2(H) and Side pole 1(D) by Screw (AA) and Washer (BB).

Step 5:
Fig. 13: Put Shelf (L) onto the frame.
Fig. 14: First put the Big canopy (M) onto the top of the gazebo (Do not fully spread). Put the Small canopy (N) onto the frame,
then fix the big canopy. Hanging the Privacy panel (P) to either side if needed.
Fig. 15: Secure gazebo to the ground with Pegs (FF).
