Sunrise Medical STERLING ELITE2 Mini User manual

1
Elite2Mini XS Plus Rev.B
Instrucons for Use
ELITE2Mini
ELITE2XS
ELITE2Plus
000691026.UK Mobility Scooter

2
ENGLISH
Elite2Mini XS Plus Rev.B
03
UK
Scooter Components
We at SUNRISE MEDICAL have been awarded the ISO-13485 cercate, which arms the quality of our products at every stage,
from R & D to producon. These products meet the requirements in accordance with EC regulaons. Opons or accessories shown
are available at extra cost.
EN
Dealer signature and stamp
If you have any queries about the use, maintenance or
safety of your product, please contact your local approved
Sunrise Medical service agent. If you do not know of an
approved dealer in your area or have any other quesons,
please write or telephone:
Sunrise Medical
Thorns Road
Brierley Hill
West Midlands
DY5 2LD
England
Phone: [phone]
Fax: [phone]
www.SunriseMedical.co.uk

3
ENGLISH
Elite2Mini XS Plus Rev.B
Contents
1.0 User informaon ................................................... 4
1.1 This user manual ��������������������������������������������������������������4
1.2 For further informaon ����������������������������������������������������4
1.3 Symbols used in this manual ��������������������������������������������5
2.0 Safety ................................................................... 6
2.1 Symbols and labels used on the product �������������������������6
2.2 Safety: Temperature ���������������������������������������������������������6
2.3 Safety: Moving parts ��������������������������������������������������������7
2.4 Safety: Electromagnec radiaon ������������������������������������7
2.6 Safety: Choking hazard �����������������������������������������������������8
2.7 Ramps for transporng scooter ���������������������������������������8
2.8 Safety: Liing the scooter ������������������������������������������������8
3.0 Intended use of the scooter .................................. 9
3.1 Area of applicaon: The user �������������������������������������������9
3.2 Area of applicaon: The user environment �������������������10
4.0 Seng up the scooter ..........................................11
4.1 Seat height ����������������������������������������������������������������������11
4.2 Handlebar Adjustment ���������������������������������������������������11
4�3 Elite2 plus ller height adjustment ���������������������������������11
4.4 Tiller Adjustment (executed by the user) ����������������������11
4.5 Back angle (executed by the user) ���������������������������������12
4.6 Lumbar support (executed by the user) ������������������������12
4.7 Seat posion (executed by the user) �����������������������������12
4.8 Armrest angle (executed by the user) ���������������������������12
4.9 Control system programme �������������������������������������������12
4.10 Lap strap / seang posioning belt �����������������������������13
4.11 An Tips ������������������������������������������������������������������������15
4.12 Available OPTIONS �������������������������������������������������������15
4.12.1 Foot Control ���������������������������������������������������������15
4.12.2 Twist Grip Throle ������������������������������������������������15
4.12.3 Crutch holder ��������������������������������������������������������15
4.12.4 Raised Foot Plaorm ��������������������������������������������16
4.12.5 Angle Adjustable Foot Support ����������������������������16
4.12.6 Walker - Rollator Mount ����������������������������������������16
4.12.7 Oxygen Bole Holder �������������������������������������������16
5.0 Using the scooter .................................................17
5.1 Checking scooter before use ������������������������������������������17
5.2 Making a transfer �����������������������������������������������������������18
5.3 Driving the scooter ���������������������������������������������������������19
5.4 Curves �����������������������������������������������������������������������������20
5.5 Braking & Emergency stop ���������������������������������������������20
5.6 Driving on a slope �����������������������������������������������������������20
5.7 Obstacles & kerbs �����������������������������������������������������������21
5.8 Pushing the scooter �������������������������������������������������������22
5.9 Using Near Water �����������������������������������������������������������22
6.0 Control Panel .......................................................23
6.1 Denions ����������������������������������������������������������������������24
6.1.1 On/O Key Switch ���������������������������������������������������27
6.1.2 Control Lever (Wig wag Control) ����������������������������27
6.2 Braking ����������������������������������������������������������������������������29
6.2.1 Emergency Braking using the Hand brake �������������29
6.2.2 Emergency Braking using the keyswitch ����������������29
6.3 Throle select switch �����������������������������������������������������30
6.4 Direconal switch �����������������������������������������������������������30
7.0 Baeries, charging and range ...............................31
7.1 Baeries �������������������������������������������������������������������������31
7.2 Charging baeries: ���������������������������������������������������������32
7.2.1 Charging Socket: �����������������������������������������������������32
7.3 The range of your vehicle: ����������������������������������������������34
7.4 Baery warranty: �����������������������������������������������������������34
7.5 Baery Removal: ������������������������������������������������������������34
7.6 Disconnecng baeries for air transport �����������������������34
8.0 Transport .............................................................36
8.1 Transportaon in vehicles: ���������������������������������������������36
8.2 Using your scooter on the train: ������������������������������������36
8.3 Other Transport requirements: ��������������������������������������36
9.0 Maintenance & cleaning ......................................37
9.1 Maintenance ������������������������������������������������������������������37
9.2 Tyre maintenance and pressures �����������������������������������38
9.2.1 Tyre pressure ����������������������������������������������������������38
9.2.2 Tyre wear ����������������������������������������������������������������38
9.3 Wheel Removal ��������������������������������������������������������������39
9�3�1 Elite2 XS RS 3-Wheel Front Wheel Removal �����������39
9�3�2 Elite2 Plus 3-Wheel Front Wheel Removal �������������40
9�3�3 Elite2 XS RS Rear Wheel Removal ���������������������������40
9�3�4 Elite2 Plus Rear Wheel Removal �����������������������������41
9.4 Changing the Inner Tube (All) ����������������������������������������41
9.5 Lighng maintenance: ����������������������������������������������������43
9.6 Cleaning and disinfecon �����������������������������������������������43
9.7 Medium to long term storage ����������������������������������������43
9.8 Storage temperature & humidity �����������������������������������43
10.0 Troubleshoong .................................................44
10�1 Elite2 Plus display ����������������������������������������������������������44
10�2 Elite2 XS Display ������������������������������������������������������������44
10.3 Fault Codes and Possible Causes ���������������������������������45
11.0 Disposal .............................................................46
12.0 Specicaon Sheets (EN 12184 & ISO 7176-15) ...47
13.0 Warranty ............................................................51
14.0 Name Plate ........................................................52

4
ENGLISH
Elite2Mini XS Plus Rev.B
1.0 User informaon
Thank you for choosing a Sunrise Medical scooter. Sunrise Medical’s high-
quality mobility products are designed to enhance independence and make
your everyday life easier.
As a part of our ongoing product improvement iniave, Sunrise Medical
reserves the right to change specicaons and design without noce.
However, any changes to informaon provided for exisng users shall be
clearly communicated if they are safety crical.
Further, not all features and opons oered are compable with all
conguraons of the scooter.
All dimensions are approximate and may be subject to change.
The intended lifeme of the scooter is 5 years. Please DO NOT use or t any
3rd party components to the scooter unless they are ocially approved by
Sunrise Medical.
1.1 This user manual
This user manual will help you to use and maintain your scooter safely.
Do not use your scooter unl this enre manual has been read and
understood!
1.2 For further informaon
Please contact your local, authorized Sunrise Medical dealer if you have
any quesons regarding the use, maintenance or safety of your scooter. In
case there is no authorized dealer in your area or you have any quesons,
contact Sunrise Medical either in wring or by telephone.
For informaon about product safety noces and product recalls, go to
www.SunriseMedical.co.uk
In the event of a safety-related product change being made by Sunrise
Medical, all customers will be contacted and informed of this.
If you are visually impaired,
this document can be viewed
in PDF format at
www.SunriseMedical.co.uk
AB FG
D
CE
or alternavely is available on
request in large text.

5
ENGLISH
Elite2Mini XS Plus Rev.B
1.3 Symbols used in this manual
DANGER! Potenal risk of injury or serious injury or death
WARNING! Potenal risk of injury
CAUTION! Potenal damage to equipment
NOTE! General advice or best pracce
Reference To Addional Documentaon
As the manufacturer, SUNRISE MEDICAL, declares that this product conforms
to the Medical Device Regulaon (2017/745).
NOTE:
General user advice.
Not following these instrucons may result in physical injury, damage to the
product or damage to the environment!
Noce to the user and/or paent: Any serious incident that has occurred
in relaon to the device should be reported to the manufacturer and the
competent authority of the Member State in which the user and/or paent
is established.
B4Me special adaptaons
Sunrise Medical strongly recommends that in order to ensure that your
B4Me product operates, and performs as intended by the manufacturer;
all the user informaon supplied with your B4Me product is read and
understood, before the product is rst used.
Sunrise Medical also recommends that the user informaon is not discarded
aer reading it, but it is kept safely stored for future reference.
Medical Device Combinaons
It may be possible to combine this Medical device with one or more other
Medical Device or other product. Informaon on which combinaons are
possible can be found at www.Sunrisemedical.co.uk. All combinaons
listed have been validated to meet the General Safety and Performance
Requirements, Annex I Nr. 14.1 of the Medical Device Regulaon 2017/745.
Guidance on the combinaon, such as mounng, can be found at
www.SunriseMedical.co.uk.

6
ENGLISH
Elite2Mini XS Plus Rev.B
2.0 Safety
Follow the instrucons carefully next to these warning symbols! Not
paying careful aenon to these instrucons could result in physical
injury or damage to the scooter or the environment. Where ver possible,
safety informaon is provided in the relevant chapter.
2.1 Symbols and labels used on the product
The signs, symbols and instrucons axed to the scooter comprise part
of the safety facilies. They must never be covered or removed. They
must remain present and clearly legible throughout the enre lifespan of
the scooter.
Replace or repair all illegible or damaged signs, symbols and instrucons
immediately. Please contact your dealer for assistance.
Fig. 2.1 Taxi xaon point
Fig. 2.2 Not crash-tested (Black Scooters)*
Fig. 2.3.1 Maximum user weight for the Elite2 Mini = 136 kg
Fig. 2.3.2 Maximum user weight for the Elite2 XS = 175 kg
Fig. 2.3.3 Maximum user weight for the Elite2 Plus = 175 kg
Fig. 2.4 Freewheel mechanism: outward lever down (A) = freewheel
Fig. 2.5.1 The serial number and informaon label - Elite2 Mini
Fig. 2.5.2 The serial number and informaon label - Elite2 XS
Fig. 2.5.3 The serial number and informaon label - Elite2 Plus
Fig. 2.6.1 Locaon of Serial Number Label - Elite2 Mini Serial Label (next
page)
Fig. 2.6.2 Locaon of Serial Number Label - Elite2 Mini UDI Label (next
page)
Fig. 2.6.3 Locaon of Serial Number Label - Elite2 XS & Elite2 Plus - UDI
label (A) & Serial Label (B) (next page)
2.2 Safety: Temperature
WARNING!
• Avoid physical contact with the scooter’s motors at all mes.
Motors are connuously in moon during use and can reach high
temperatures. Aer use, the motors will cool down slowly. Physical
contact could cause burns. Allow the motors aer using at least 30
min. to cool down.
• If you do not use the scooter, ensure that it is not exposed to direct
sunlight for lengthy periods of me. Certain parts of the scooter, such
as the seat, the back and the armrests can become hot if they have
been exposed to full sunlight for too long. This may cause burns or
allergic reacons to the skin.
• Be aware that in extremely cold weather, exposed metal parts can
present a freeze burn hazard, parcularly if the hands are wet.
Fig. 2.4
Fig. 2.5.1
Fig. 2.5.2
Sunrise Medical GmbH
Kahlbachring 2-4
D-69254 Malsch/Germany
2020-10-01
SCOOTER / SKOTER / ROLLER
21520020100
max
175kg
max
307kg
max
15km/h
max
10º
max
214.9/92.1kg
ISO 7176-19:2008
B 123456789
:
Type: Elite2
Fig. 2.1 Fig. 2.2
A
Fig. 2.5.3
Sunrise Medical GmbH
Kahlbachring 2-4
D-69254 Malsch/Germany
2020-10-01
SCOOTER / SKOTER / ROLLER
242210201001
max
136kg
max
246kg
max
12km/h
max
9º
max
172/74kg
ISO 7176-19:2008
B 123456789
:
Type: Elite2 Mini
Sunrise Medical GmbH
Kahlbachring 2-4
D-69254 Malsch/Germany
2020-10-01
SCOOTER / SKOTER / ROLLER
21520020100
max
175kg
max
315kg
max
15km/h
max
10º
max
220.5/94.5kg
ISO 7176-19:2008
B 123456789
:
Type: Elite2
136 kg
MAX
175 kg
MAX
175 kg
MAX
Fig. 2.3.1 Fig. 2.3.3Fig. 2.3.2

7
ENGLISH
Elite2Mini XS Plus Rev.B
2.3 Safety: Moving parts, (Fig.2.7)
DANGER!
A scooter has moving and rotang parts. Contact with moving parts
may result in serious physical injury or damage to the scooter. Contact
with the moving parts of the scooter should be avoided.
• Wheels
• Seat rotaon lever
• Seat forward/backward posioning lever
• (maybe the) Tiller height adjustment on Elite2 Plus
2.4 Safety: Electromagnec radiaon
CAUTION!
The standard version of your electric scooter has been tested on the
applicable requirements with respect to electromagnec radiaon
(EMC requirements) In spite of these tests:
It cannot be excluded that electromagnec radiaon may have an
inuence on the scooter. For example:
• mobile telephony
• large-scale medical apparatus
• other sources of electromagnec radiaon
• It cannot be excluded that the scooter may interfere with
electromagnec elds. For example:
• shop doors
• burglar alarm systems in shops
• garage door openers
In the unlikely event that such problems do occur, we request that
you nofy your dealer immediately.
DANGER!
• When operang two-way radio, walkie-talkies, C.B., Amateur radio,
public mobile radio and other powerful transming devices the
scooter should be brought to a halt and turned o.
• The operaon of cordless, mobile telephones and cell phones
including hands-free devices is permied but if abnormal operaon
of the scooter is encountered then the scooter must be brought
immediately to a halt and turned o.
Elite2XS & Elite2Plus
Elite2Mini
Elite2Mini
Serial Label - right side
UDI Label - le side
SunriseMedical GmbH
Kahlbachring2-4
D-69254Malsch/Germany
2020-10-01
SCOOTER / SKOTER / ROLLER
21520020100
max
175kg
max
315kg
max
15km/h
max
10º
max
220.5/94.5kg
ISO 7176-19:2008
B 123456789
:
Type: Elite2
A
B
Fig. 2.7
Fig. 2.6.3
Fig. 2.6.2
Fig. 2.6.1
SunriseMedical GmbH
Kahlbachring2-4
D-69254Malsch/Germany
2020-10-01
SCOOTER / SKOTER / ROLLER
242210201001
max
136kg
max
246kg
max
12km/h
max
9º
max
172/74kg
ISO 7176-19:2008
B 123456789
:
Type: Elite2 Mini

8
ENGLISH
Elite2Mini XS Plus Rev.B
2.6 Safety: Choking hazard
DANGER!
This mobility aid uses small parts which under certain
circumstances may present a choking hazard to young
children.
2.7 Ramps for transporng scooter:
DANGER!
• When using a ramp, please ensure that it is capable of taking
the combined weight of the scooter and yourself.
• If a ramp is being used to load a scooter into a vehicle,
please ensure the ramp is properly secured to the vehicle.
• Always approach the ramp head-on and exercise cauon.
• Please ensure the ramp is suitable for the product you are
transporng.
• Maximum ramp angle = 10° (18%)
• Follow all the user instrucons supplied with the ramp.
• Be aware that accessories aached to the scooter, may
aect the overall stability.
DANGER!
• Ensure that the user and all carers fully understand the li
manufacturer’s instrucons for using the passenger li.
• Never exceed the li manufacturer’s recommended safe
working load and load distribuon guidance.
• Always turn o all power when you are on the li. If you fail
to do so, you may touch the wigwag or side throle/controls
by accident and cause your scooter to drive o the plaorm.
Be aware that a roll-stop at the end of the plaorm may not
prevent this.
• Always posion the user securely in the scooter to help
avoid falls while on the li.
• Always ensure the scooter is in drive mode when using
passenger li (wheels locked not in freewheel mode).
2.8 Safety: Liing the scooter
WARNING!
• Do not li this scooter, seat or baeries by any parts that are
removable, doing so may result in damage to the scooter or
injury to the user.

9
ENGLISH
Elite2Mini XS Plus Rev.B
3.0 Intended use of the scooter
General descripon
This Sterling Elite2 scooter range is designed for comfort, safety and
durability.
Due to its modular design, simplicity and wide range of adjustments,
the Sterling Elite2 scooter range is a perfect choice for easy service,
refurbishment and recycle requirements.
The Sterling Elite2 scooter range fulls individual preferences, needs
or circumstances and is available in the following conguraons:
• Sterling Elite2 Mini
• Sterling Elite2 XS
• Sterling Elite2 Plus
3.1 Area of applicaon: The user
Scooters are exclusively for a user who may have diculty walking
distances or for periods of me, for their own personal use indoors
and outdoors.
Driving a scooter requires cognive, physical and visual skills.
The user must be able to esmate and correct the results of acons
when operang the scooter.
The scooter cannot transport more than 1 person at a me. The
maximum weight limit (includes both the user and any weight of
accessories ed to the scooter) is marked on the serial number
label, which is axed to the chassis of the scooter (Figs. 2.6.1, 2.6.2
and 2.6.3).
For restricons on user weight limit refer to technical specicaon,
chapter 11.
The user must be informed of the contents of this user manual
before driving the scooter. In addion, the user of the scooter must
be given thorough instrucon by a qualied specialist before he or
she parcipates in trac. The rst sessions in the scooter should be
pracced under supervision of a trainer/advisor.
Indications
The variees of ng variants, as well as the modular design, mean
that it can be used by those who cannot walk or have limited mobility
because of:
• Paralysis
• Loss of extremity (leg amputaon)
• Extremity defect deformity
• Joint contractures/joint injuries
• Strokes and brain injuries
• Neurological disabilies
• Illnesses such as heart and circulaon deciencies, disturbance of
equilibrium or cachexia as well as for elderly people who sll have
strength in the upper body.
Contraindications
The mobility scooter shall not be used in case of:
• Percepon disorder
• Imbalance
• Loss of both arms
• Joint contracture/joint damage on both arms
• Seang disability
6
7
12
Fig. 3.1
3
Basic Components (Fig.3.1).
1. SEAT 6. BATTERY BOX
2. CONTROLS 7. FOOT BOARD
3. TILLER 8. LIGHTS
4. ARMRESTS 9. FRONT BASKET (MAX. 5kg)
5. WHEELS
4
5
9
5
8

10
ENGLISH
Elite2Mini XS Plus Rev.B
WARNING!
• If you are under the inuence of medicines that can have an
eect on your ability to drive, you are not permied to drive
a scooter.
• Adequate vision is required in order to safely operate a
scooter in the user situaon concerned.
• Not more than one person at a me can be seated in the
scooter.
• Do not allow children to ride in the scooter unsupervised.
CAUTION!
• The user of the scooter is at all mes completely responsible
for complying with the applicable local safety regulaons
and guidelines.
3.2 Area of applicaon: The user environment
Class B Scooter’s are usually large in size, not necessarily
intended for indoor use but capable of travelling longer
distances and negoang outdoor obstacles.
They are intended for use in public places and similar locaons
where there are pavements, pedestrian paths or oors that
have hard and rm surfaces. The safe limit for slopes and
obstacles shall be observed.
They may be used on the roads in compliance with local
country trac law.
The speed must be adapted to suit the environment.
WARNING!
• Drive carefully on slippery roads resulng from rain, ice or
snow!
• You are required to turn on the lights in case of limited
visibility.
• When driving at higher speeds you must be extra careful.
• Select a lower maximum speed indoors, on the pavement
and in pedestrian areas.
• Do not drive o high obstacles.
• Do not aach a weight to the scooter without the approval
of a qualied specialist. This may negavely aect the
stability of the product.
CAUTION!
• Prevent the scooter from coming into contact with seawater:
seawater is causc and may damage the scooter.
• Prevent the scooter from coming into contact with sand:
sand can permeate into the moving parts of the scooter,
causing extensive wear on these parts.
• Do not use the scooter if temperatures are below: -25˚C or
above +50˚C.
• Do not push and/or tow any objects with the scooter.
• Do not drive through puddles of water.

11
ENGLISH
Elite2Mini XS Plus Rev.B
4.0 Seng up the scooter
Sunrise Medical scooters can be adjusted according to specic
needs of the user.
Pre-sengs are carried out once, the rst me the scooter
is going to be used. They must be executed by a qualied
specialist, unless explicitly stated otherwise.
4.1 Seat height (Fig. 4.1)
1. Loosen (A).
2. Adjust (B) to the desired posion.
3. Tighten (A).
Fig. 4.1
A
B
KM
Fig. 4.2
4.2 Handlebar Adjustment
CAUTION!
The handlebar angle can be adjusted to suit the users needs,
(Fig 4.2). The handlebar is clamped within the control system.
Your dealer or supplier can adjust the angle of the handlebar
if needed. Do not aempt adjustment of this yourself.
Damage to the control system of the scooter could happen if
unauthorized adjustment is carried out.
4.3 Elite2 Plus ller height adjustment (Fig. 4.3)
The Elite2 Plus ller has a standard height adjustment of 0mm
– 50mm.
1. Loosen (A), with 6 mm Allen key.
2. Adjust (B) to the desired posion, carefully pull the ller
up using the ller steering handle.
3. Tighten (A).
Fig. 4.3
B
A
Fig. 4.4
A
B
C
4.4 Tiller Adjustment (executed by the user) (Fig. 4.4)
DANGER!
• Do not adjust the ller while the scooter is being driven as
serious injury could happen if you lose control.
• Do not use the ller adjustment handle to hold or carry
items such as bags etc.
• Ensure ngers or other items are not around the area of the
lower ller when making adjustments. Serious injury could
happen due to entrapment.
1. Rotate (A) clockwise.
2. Hold (B) and move (C) to the required posion.

12
ENGLISH
Elite2Mini XS Plus Rev.B
Fig. 4.5
Fig. 4.7
A
A
B
Fig. 4.6
4.6 Lumbar support (executed by the user) (Fig. 4.6)
1. Adjust by turning (B).
A
4.5 Back angle (executed by the user) (Fig. 4.5)
1. Adjust by turning (A).
WARNING!
Take care when adjusng the back angle as it could be possible
to fall backwards and harm the user or the scooter.
• When adjusng the back angle, be careful not to get your
ngers caught.
Fig. 4.8
4.7 Seat posion (executed by the user) (Fig. 4.7)
1. Pull (A) to slide forward or backward.
2. Release (A)
4.8 Armrest angle (executed by the user) (Fig. 4.8)
1. Turn (A).
4.9 Control system programme
This scooter is equipped with a control system that can be
programmed by adjusng sengs within the system. This is a
specialized job that needs training and can only be adjusted
with professional soware. The end user is not allowed to
adjust these sengs.
DANGER!
The incorrect seng of the parameters for the control system
may result in very dangerous situaons.
Sengs must be made by qualied specialists.

13
ENGLISH
Elite2Mini XS Plus Rev.B
1
2
4.10 Lap strap / seang posioning belt
DANGER! / WARNING!
• This product is only to be used to posion a single person in
a scooter.
Mounng a lap strap / seang posioning belt
The lap belt is ed to the scooter as shown in the ng
photographs, (Fig.4.9 - 4.10). It is important that the belt is
ed correctly and is not twisted.
The belt is adjusted automacally to the correct tension by the
internal reel system.
To lock the belt:
Pull the buckle over your lap and push rmly into the slot in
the receiver, (1).
The belt will adjust to the correct tension.
To release the belt:
Push the red buon marked ‘PRESS’ to release the belt, (2),
(Fig 4.11).
Fig. 4.9
Fig. 4.10
Fig. 4.11

14
ENGLISH
Elite2Mini XS Plus Rev.B
Fig. 4.12
Fig. 4.13
Positioning an person with a lap strap
• Adjust the lap strap to suit, leaving no more than a hand’s
width gap for comfort and safety (Fig 4.12).
• The hand clearance should be with the lap strap under
normal tension and not allow large gaps or loops.
• For your comfort, the Lap Belt must be correctly ed to the
scooter. If you are unsure about the ng or operaon of
this opon, please contact your approved Sunrise Medical
dealer.
• Generally, the lap strap should be xed so that the straps
sit at an angle of approximately 45° (Fig. 4.13), and when
correctly adjusted should not allow user to slip down in the
seat.
• The lap belt must be checked on a daily basis to ensure it
is adjusted correctly and it is free from any obstrucon or
adverse wear.
• Failure to make sure that the lap belt is secure and adjusted
prior to use could cause serious injury to the user. E.g. too
loose a strap may allow the user to slip down in the seat and
risk suocaon.
DANGER! / WARNING!
• Always make sure that the lap strap is correctly secured and
adjusted prior to use.
• If a strap is too loose it could cause the user to slip down
and cause serious injury.
• Check lap strap and securing components at regular intervals
for any signs of fray or damage. Replace if necessary.
• When servicing, check for correct operaon of the release
buckle and for any signs of wear on the material or plasc
brackets.
• Regular Checks/Acvies:
• As with all posioning components, there is a need for
correcve adjustments as the person changes their seang
posion over me.
• Check the belts regularly for correct ng, to ensure the
safety and comfort of the user.
45°

15
ENGLISH
Elite2Mini XS Plus Rev.B
4.11 An Tips (Fig. 4.14):
WARNING!
• Ensure the an ps are ed before using the scooter.
• Ensure that an ps are not damaged or worn before using
your scooter.
• Aendants must be aware of the locaon of the an ps to
prevent feet being trapped underneath causing injury.
• Do not allow adults or children to stand on the an ps, or
any other part of the scooter as this could cause the scooter
to become unstable.
4.12 Available OPTIONS.
4.12.1 Foot Control
This can be mounted anywhere on the oor of the scooter
or on the raised foot plaorm. It is used in conjuncon with
either a twist grip or a side lever control. Two switches are also
used, one to switch between forwards and reverse and one
to switch between the foot control and the twist grip or side
lever control, (Fig.4.15).
WARNING!
Accidental depression of the pedal while the scooter is
switched on, will cause the scooter to move. Exercise cauon
and always turn the scooter o when not driving.
4.12.2 Twist Grip Throle
The twist grip control may be used on its own or in
conjuncon with the foot control. If it is used on its own, it
it has a forward/reverse switch supplied. If the twist grip is
used in conjuncon with the foot control, two switches are
used, forwards/reverse and an addional switch to select each
control, (Fig.4.16).
4.12.3 Crutch holder (Fig. 4.17)
WARNING!
• Ensure that the crutch is securely fastened to the crutch
holder.
• Ensure that the crutch is not interfering with the
mechanisms of the scooter.
• Ensure that the crutch does not protrude from the scooter.
• Do not aempt to remove the crutch whilst the scooter is in
moon.
Fig. 4.14
Fig. 4.15
Fig. 4.16
Fig. 4.17

16
ENGLISH
Elite2Mini XS Plus Rev.B
4.12.4 Raised Foot Plaorm
This is to facilitate the correct knee / leg angle to obtain
maximum comfort for users with shorter lower leg lengths.
WARNING!
Be aware of the extra height from the ground and take care
when geng on and o the scooter.
4.12.5 Angle Adjustable Foot Support
The foot support helps to provide extra support for the foot,
ankle and leg, helping to prevent cramp and reducing joint
pain. It can be mounted anywhere on the oor of the scooter
or on the raised foot plaorm, (Fig.4.18)
4.12.6 Walker - Rollator Mount
This rear mounted frame allows the carriage of Sunrise
Medical walkers and rollators on board the scooter, (Fig.4.19).
WARNING!
• Be aware that aached accessories increase the eecve
footprint of the scooter.
• Take extra care when manoeuvring if you have a rollator or
walker on board.
• Ensure that the load is secured properly before moving o.
• Be aware that the load you are carrying may obscure the
rear lights on the scooter. If this is the case, please use the
foot path whilst carrying the load, parcularly at night.
4.12.7 Oxygen Bole Holder.
Fits to the seat via the armrest bracket bolts. It can be
posioned on the le or right hand side of the seat. The holder
is designed to accept a 3.9 kg bole, (Fig.4.20).
WARNING!
While you are taking Oxygen, observe all safety regulaons
pertaining to the use of Oxygen.
• Do not enter an area where naked ames may be used.
• Do not smoke.
• Do not use transming devises such as mobile phones etc.
Fig. 4.18
Fig. 4.19
Fig. 4.20

17
ENGLISH
Elite2Mini XS Plus Rev.B
5.0 Using the scooter
DANGER!
• Be aware that you may need to adjust the controller sengs
of your scooter.
DANGERS!
Weight limits
• The user, plus opons and accessories, plus items carried
should never exceed the maximum user weight.
• Never sit in the scooter while weight training if the total
weight (user plus addional weighs) exceed the maximum
user weight.
• Exceeding the weight limit is likely to damage the seat frame
or fasteners and may cause severe injury to you or others
from scooter failure.
• Exceeding the weight limit will void the warranty
• Do not hang shopping bags from the handlebars as they
could swing and cause loss of steering control or cause
inadvertent drive acons.
• Do not overload the front and rear baskets as steering
control and stability will be negavely aected.
5.1 Checking scooter before use
Perform the following daily check roune before driving:
WARNING!
• Ensure all controls are funconing properly.
• If you discover any scooter malfuncon, take it to be
repaired or reset. Your dealer can help you nd the fault and
correct it.
• Use extreme care when you drive the scooter in reverse. If
one of the wheels hits an obstacle, you could lose control of
the scooter and fall o.
• When traveling along, always ensure the backrest is upright
and the seat faces forward.
• Never short-circuit electrical connecon as you could cause
an explosion.
• Do not use the scooter if any of the res are damaged or
under/over inated.
• When using mobile phones you should switch the scooter
o.
• Do no smoke whilst on board the scooter.
• If you take a break from driving, but remain seated on the
scooter for more than just a moment; switch the scooter o
at the ignion key.
CAUTION!
Checking wheels & tyres
• Are the tyres suciently inated (Chapter 8.2).
Checking batteries
• Before using your vehicle for the very rst me, please
charge your baeries for a period of 24 hours.
• Are the baeries suciently charged? The green lights on
the baery indicator must be on. (Chapter 7.2).
• Do not use the scooter when the baery charge level is low.
The scooter may come to a sudden, unexpected stop.
Checking lights and indicators
• Ensure that the lights and indicators are funconing
correctly and lens are clean before going outdoors at night.
Checking remote
• With the control system switched o, check that the wigwag
is not bent or damaged and that it returns to the centre
when you push and release it.
Checking free wheel lever
• Before using the scooter, ensure that the free wheel lever
has been set to ‘drive’ (Chapter 5.8).
Checking seating
• Ensure that all the cushions are in place.
• Make sure that the backrest is correctly ed and adjusted.
• Visually inspect the Scooter to make sure the armrests etc.
are correctly posioned and all fasteners are suciently
ghtened.
Checking clothing on potential entrapment
• When operang the scooter, ensure that your clothing
does not hamper the Scooter (i.e. too long). Before use,
always check if your clothing or accessories do not come
into contact with the wheels or and other moving and/or
rotang parts in which they could become entangled.
Checking weather conditions
• In winter, baeries have a reduced capacity. During a period
of light frost, the capacity is roughly 75% of the normal
capacity. At temperatures below -5˚C this will be roughly
50%. This will reduce your range of acon.
WARNING!
Avoid wearing loose cus/sleeves when operang the wigwag/
side-throle as this could cause entanglement.

18
ENGLISH
Elite2Mini XS Plus Rev.B
Fig. 5.1
Fig. 5.2
Fig. 5.3
Fig. 5.4
5.2 Making a transfer
DANGER! / WARNING!
To prevent a fall:
1. Ensure that the key is turned o during transfers to avoid
unintenonal movement. If you fail to do so, you may
touch the controller and cause your scooter to move when
you do not expect it.
2. Stand at the side of the scooter and li the nearest
armrest, (Fig.5.1).
3. Push the seat rotate lever forwards and rotate the seat
unl it faces you. (Fig. 5.2).
4. Make sure that the seat is locked securely into posion.
5. Push the seat rotate lever forwards and rotate the seat
unl facing forward (Fig.5.3).
6. Pull the seat sliding mechanism lever and slide forward or
rearward to nd a good seang posion.
7. Make sure that the seat is locked securely into posion
and the armrest is down.
8. Ensure that your feet are placed rmly on the foot board
of the scooter
9. Adjust the ller so you can reach all the controls
comfortably, (Fig.5.4).

19
ENGLISH
Elite2Mini XS Plus Rev.B
5.3 Driving the scooter
WARNING!
• The user of the scooter is at all mes completely responsible
for complying with the applicable local safety regulaons and
guidelines.
Scooters are driven by means of the operang levers and the
control panel (controller). See chapter 6
Rear view mirror
WARNING!
• To avoid injury to people around you please be aware that
the mirror protrudes outside the space envelope of the
scooter and could cause injury to someone when driving
past.
• The mirror must be used on models at speeds over 6 kph on
roads according to local law.
• Always make sure that when using the mirror that it is clean
and unbroken so that it does not impair your visibility.
Road use
Please show the utmost consideraon for the other trac on
the road.
DANGER!
• Remember that the last thing a car or lorry driver expects to
see is a scooter backing o the kerb into the road.
• If in any doubt, do not risk crossing the road unl you are
certain that it is safe.
• Always cross the road as quickly as possible, there may be
other trac.
• Do not drive over anything that could cause punctures in the
tyres.
• Ensure that there are no objects in your path that could
possibly become lodged in your scooter mechanism or in the
spokes of the rear wheels. This could cause the scooter to
come to a sudden stop.
• Riding over drains or grids could cause the scooter wheels
to become lodged, causing the scooter to come to a sudden
stop.
• When using your Scooter on public walkways and footpaths,
always be aware of pedestrians and situaons which might
require extra care.
• When manoeuvring in conned areas, including shops,
ensure the minimum speed is selected.
• For the safety of the operator and other pedestrians, Sunrise
Medical recommends that whilst driving on footpaths and
other pedestrian walkways, the scooter preset speed should
be set to less than 4 mph/6kph.
Additional dangers
• Be especially vigilant around young children and pets.
• Remember, when driving in public places drive with cauon
and regard for others at all mes.
• Remember to keep the key with you at all mes for your
safety and security.
Adverse conditions:
Please be aware that when driving your scooter in adverse
condions, e.g. on wet grass, mud, ice, snow or other slippery
surfaces, you may experience a reducon in the grip and
tracon of your scooter.
DANGER!
• We recommend you take extra precauons in these
condions, parcularly on hills and slopes; your scooter
could become unstable or skid causing possible injury.
• When you are using a Scooter, take extra care with loose or
long items of clothing. Moving parts, such as wheels, can
be potenally dangerous or even fatal if clothing becomes
entangled.
NOTE :
Extreme variances in temperature may trigger the self-protect
mechanism in the control system. If this occurs the control
system will temporarily shut down to prevent damage to the
electronics or the scooter.

20
ENGLISH
Elite2Mini XS Plus Rev.B
!
Fig. 5.5
5.6 Driving on a slope (Fig 5.5)
Your scooter has been designed and tested to allow its use on
slopes or gradients of at least 6°.
For Elite2 Mini with 90 amp controller 6° rated slope or
gradient
For Elite2 XS & Elite2 Plus with 140 amp
controller. Elite2 Mini with 120 amp
controller.
6° rated slope or
gradient
DANGER!
• Stopping distances on slopes can be signicantly longer than
on level ground.
DANGER!
• In certain circumstances, your scooter could become
unstable.
• To improve stability lean forward when driving uphill, with
the seat and back in an upright posion.
• Alternavely, sit in an upright posion when travelling in
a forward, downhill direcon or and/or recline the seat
backwards.
• If you are in any doubt about the capabilies of your scooter
on a slope then do not aempt to drive up or down the
slope/kerb; try to nd an alternave route.
5.4 Curves
Steering the scooter is easy and logical. Just be sure to
remember to get wide clearance when turning so that the rear
wheels clear any obstacle.
Shortcung a pavement corner can cause the back wheel to
go o the pavement, causing problems, if the corner is very
rough. Avoid this at all mes by steering an exaggerated curve
around the obstacle.
When steering in a ght spot, such as a doorway or when
turning around, stop the scooter and then turn the handlebar
to where you want to go, then apply power gently. This will
make the scooter turn ghtly. It is also recommended that the
pre-set speed is set to a slower seng to aid control in ght
spots.
DANGER!
Full speed turns should not be aempted. If you need to turn
sharply you must reduce your speed with the wigwag or side
throle or speed seng. This is parcularly important when
travelling across or down a slope. Disregarding this advice
could lead to your scooter pping over.
WARNING!
Use indicators when changing direcon.
5.5 Braking & Emergency stop
There are three ways to stop your scooter:
• Simplest and safest way to stop the scooter is to release
the operang lever. This will bring the scooter to a halt in a
controlled manner.
• Going in reverse will break the scooter abruptly with a fast
stop.
• Switching the control system o using the ON/OFF key
switch whilst the scooter is in moon will also bring the
scooter to a halt.
WARNING!
• Switching the control system o is only to be used in an
emergency as the stopping acon is very abrupt.
