Supertrax Cosmic User manual

Cosmic Kids Ride on Car
Installation and Operation Instructions
Please read this instruction manual carefully. It is important to read and
follow all of the steps during assembly to ensure proper operation and safety
of the child. Please keep this manual for future reference.
Scan this QR Code to
view the Range Rover
Assembly Video

SPECIFICATIONS:
Car Type:
Range Rover Style
Battery Type:
12V7AH
Electric Motor:
12V30W(Drive) 12V8W(Steering)
Age Range:
2 –5 Years
Max. Weight:
65 lbs
Product Size:
50”L x 34”W x 25”H
Avg. Speed:
2 –3 MPH
Charging time:
8-12 hrs
Avg. Use Time:
1-2 Hrs (depending on use)
Remote Battery:
2 - AA (not included)
IMPORTANT!
•Assembly of car and charging of
battery is only to be done by an
adult.
•WARNING!! NOT TO BE USED
ON STREETS or IN TRAFFIC.
•Never modify the electric circuit
system or tamper with electric
system. Can cause permanent
damage.
•Please check the product
regularly for any loose parts or
wires to ensure proper
operation.
•Adult supervision is
recommended during operation
by child to avoid injury. Safety
equipment is recommended.
•Please make sure that the child
uses caution to avoid falls and
collisions causing injury to the
child or third party.
•Do not pick up vehicle by
steering wheel.
•Do not pick up battery by wires
or charger.
•Keep all plastic bags out of the
reach of young children.
•Not recommended for children
under the age of 2 yrs. due to
small parts that could cause a
choking hazard.
•Battery must be charged for a
minimum of 8-12 hours prior to
first use of the car to avoid
damage to the battery. Power
switch must be in off position
when charging.
•Battery charger should be
examined for damage prior to
each use. It is important to
inspect the cord and both ends
for damage. If damage is found,
DO NOT USE THE CHARGER!
Contact us for replacement
charger.
•Please retain instruction manual
for future reference.
•Please retain packaging in the
event it is necessary to return.

All assembly videos can be found on YouTube
under SUPERtrax
PARTS LIST:
1
Car Body
7
Windshield
15
Screws
2
Front Wheels
8
Seat
3
Wheel Covers
11
Rear Spoiler
4
Rear Wheels
12
Steering Wheel
5
Drive Motor
13
Remote Control
6
Rearview Mirror
14
Charger
ASSEMBLY INSTRUCTIONS:
Front Wheel Assembly: Locate the Front axle, both on the left and right side of the
vehicle and insert the wheel as shown in the illustration above.
Rear Wheel Assembly: (Rear Wheels have a hub) Insert the wheel aligning
the hole within the wheel with the rear axle. Push rear wheels on both sides
of the rear axle at same time until you hear it click. Once inserted tug on
wheels to make sure wheels are secured.

Installation of the Steering Wheel: Connect the wires (connect the red, black &
white wires together and connect the green & black wires to the black wire). Cut
the wire tie holding wires together then push the wires gently into the steering
column and align the chrome pins and the holes and insert steering wheel firmly.
Windshield Assembly: Align the tabs on bottom of windshield with the tabs on
body of the car and push in until you hear a click. Then insert the screws on both
sides of the windshield (located by mirrors) to secure windshield firmly.

Connect the Battery Power: Connect the plug-in unit of the motor and car wire
one, then connect the red power wire (remove the plastic cover) with the battery
positive polarity (red wire). (This step is typically completed when the vehicle is
tested prior to being shipped out).
Circuit Diagram:
Fuse: This car has an auto-reset fuse. If the car stops suddenly during
operation, it is likely due to an instantaneous and excessive current, causing
the fuse to trip. If this occurs, simply stop vehicle operation for 30-60
seconds. To avoid the fuse tripping and power being cut off, please keep the
following in mind:

-Do not overload the vehicle; the maximum load is 65 pounds.
-Do not drag, pull, tow or haul anything in or behind the vehicle.
-Do not allow water or any other liquids to contact the battery or any other
electrical component on the vehicle.
-Do not change the circuit system or attempt to rebuild or reassemble the
electrical structure of the vehicle.
Installation of Seat: Insert the seat, secure at a good position and screw firmly in
position at both the left and right sides of the saddle.
Installation of the Rear Spoiler: Connect the wires, then align the tabs on bottom
of rear spoiler with the tabs on the body of car and push in until you hear a click.

Charging the battery: The charging port is located on the right side of the
dashboard. Plug the charger into the charging port first, then plug the charger into
wall outlet. BATTERY MUST BE CHARGED FOR A MINIMUM OF 12 HOURS BEFORE
INITIAL USE TO AVOID DAMAGE TO THE BATTERY.
Replacement Fuse for Battery: If the fuse is broken or burned out, there is a spare
fuse in the fuse box located under the seat or behind the body of the car. Replace it
and restart the car.
Please Note: As a safety precaution and to avoid damage to the charger, the car
will not power up while charger port is plugged into the car.
Remote Control Instructions: For the first time use of remote control or after replacing
the battery, you need to sync the remote to the car.
1) Press the car-select button down until the remote indicator light is
flashing, turn on car, and when the light stops flashing pairing has
been successful.
2) Repeat if this does not happen.
3) Once paired for the first time, no need to pair remote for later use
unless batteries are changed in the remote.
4) To use speed selection button, you press button until speed
indicator light is set at desired speed. 1st light low speed, 2nd light
medium speed, 3rd light high speed.

5) Emergency brake. Press & hold stop button down to stop motion
of the car immediately. Release the button to restore the normal
functions of the car.
Once battery is fully charged, disconnect from charger. Depress power button to turn on the car. Once power is
on, all lights light up, accompanied by the sound of the engine. (If no sound is heard, turn up the volume) To allow
child to operate the car, remote control/manual switch must be set to the manual position. To move the car
forward, forward/reverse switch must be set to the forward position and to move the car backward, the switch will
need to be set to the reverse position. To operate the car using the remote control, remote control/manual switch
must be set to the remote-control position. The buttons found on the handlebars are for the horn and the on-board
music. There is a MP3 interface located on the dash area with a volume knob to control the level of sound.

All assembly videos can be found on YouTube
under SUPERtrax
WARNING:
- Use only the rechargeable battery and charger supplied with
your vehicle. NEVER substitute the battery or charger with
another brand. Using another battery or charger may cause
damage.
- NEVER modify the electric circuit system. Tampering with the
electric system may cause permanent damage to the system.
- Do not allow direct contact between battery terminals.
- Do not allow any type of liquid on the battery or its
components.
- Charge the battery in a well-ventilated area ONLY. Do not
charge near or around flammable materials.
- NEVER pick up the battery by the wires or charger. Damage can
occur to the battery and may cause a fire. Pick up the battery by
the case ONLY.
- Charge the battery in a dry area ONLY.Wash hands after
handling.
- Do not open the battery. Battery contains lead acid and other
materials that are toxic and corrosive.
- Do not open the charger. Exposed wiring and circuitry inside
case could cause electric shock. NEVER allow a child to handle
or charge the battery. Battery is heavy and contains lead acid
(electrolyte).
- Do not drop the battery. Permanent damage to the battery
could occur or cause serious injury. Before charging the
battery, check for wear or damage to the battery, charger, its
supply cord and the connectors. DO NOT charge the battery if
any damage to parts has occurred.
- Do not allow the battery to drain completely. Recharge the
battery after each use or once per month if not used regularly.
- Do not charge the battery upside down.
- Always secure the battery with the bracket. Battery can fall out
and injure a child if vehicle tips over.
- The Power Switch must be turned in the OFF position when
charging.
- When the car begins to run slowly, recharge the battery.

GENERAL MAINTENANCE:
It is the parent’s responsibility to check main parts of the toy before using. Regularly
examine the car for potential hazard, such as damage to the battery, charger, cable
or cord, and plug. Also, check that all screws are tightened throughout the car. In
the event of such damage, the toy must not be used until that damage is repaired
or replaced.
•Make sure the plastic parts of the vehicle are not cracked or broken.
•Occasionally use a lightweight oil to lubricate moving parts such as wheels.
•Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
•Keep the vehicle away from sources of heat, such as stoves and heaters. Plastic
parts may melt.
•Recharge the battery after each use. Only an adult should handle the battery.
Recharge the battery at least once a month when not being used.
•Do not wash the vehicle with a hose. Do not wash the vehicle with soap and
water. Do not drive the vehicle in rainy or snowy weather as water will damage
the motor, electric system and battery.
•Clean the vehicle with a soft, dry cloth. To restore shine to plastic parts, use a
non-wax furniture polish. Do not use car wax. Do not use abrasive cleaners.
•Do not drive the vehicle in loose dirt, sand or fine gravel which could damage
moving parts, motors or the electric system.
•For extended times when the car will not be used, the power switch needs to be
in the off position and the electrical connections should be disconnected from
the battery.

TROUBLE SHOOTING GUIDE:
Problem
Possible Cause
Possible Solutions
Car will not move
1. Battery voltage is low.
2. Battery connector or wires
are loose.
3. Battery is damaged or
dead.
4. Electrical box or motor is
damaged
Charge the battery
Re-connect the battery
connector to the car
Replace battery
Replace motor
The battery will not
charge.
1. Battery connector may
have come apart or have a
bad connection.
2. Battery charger plugged
into a bad wall outlet.
3. Battery charger is
damaged.
Re-connect the battery
connector to the car
electrical connector
Try another wall outlet
Replace battery charger
Shortened battery life
Battery was not charged fully
Battery is old
Charge battery fully
Change battery
Some Noise and heat
when charging battery
Chemical reaction
Normal
Low Speed
Battery is old
Battery is low on charge
Weight limit exceeded
Uneven or uphill path
Vehicle is being used in harsh
conditions
Change the battery
Charge the battery
Do not exceed max weight
limit
Use on flat surfaces
Avoid using car in harsh
conditions
Noise coming from
motor/gearbox
Gear in motor/gearbox broken
Call for replacement
motor
The car shakes when
moving
Bad Connection of the motor
wires
Possible motor failure
Reconnect wires
Call for replacement
motor
Car needs a push to go
forward
Poor contact of wires and/or
connectors
“Dead Spot” on motor
Check that the battery
connectors are firmly
plugged into each other. If
wires are loose around
the motor, contact the
distributor’s service
department
A dead spot means the
electric power is not being
delivered to the terminal
connection. Call our
service department
Self-Resetting Breaker –The vehicle is equipped with a self-resetting breaker. In
the event the power is tripped the breaker will reset itself in approximately one
minute.
If you are unable to solve a problem, please feel free to contact us.
Phone: [phone] or Email: [email protected]
