Supertrax Ghost User manual

Ghost
Kids Ride on Car
Installation and Operation Instructions
Please read this instruction manual carefully. It is
important to read and follow all of the steps during
assembly to ensure proper operation and safety of the
child. Please keep this manual for future reference.
Scan this QR Code
to view the
Assembly Video

SPECIFICATIONS:
Car Type:
Rolls Royce Phantom Style - 1518
Battery Type:
12V10AH
Age Range:
2 –6 Years
Max. Weight:
65 lbs
Product Size:
51”L x 28”W x 24”H
Avg. Speed:
2 –3 MPH
Charging time:
8-12 hrs –Minimum 1 Charge per month
Avg. Use Time:
1-2 Hrs (depending on use)
Remote Battery:
2 - AA (not included)
IMPORTANT
•Assembly of car and charging of
battery is only to be done by an
adult.
•WARNING!! NOT TO BE USED
ON STREETS or IN TRAFFIC.
•Never modify the electric circuit
system or tamper with electric
system. Can cause permanent
damage.
•Please check the product
regularly for any loose parts or
wires to ensure proper
operation.
•Adult supervision is
recommended during operation
by child to avoid injury. Safety
equipment is recommended.
•Please make sure that the child
uses caution to avoid falls and
collisions which could cause
injury to the child or third party.
•Do not pick up vehicle by
steering wheel.
•Do not pick up battery by wires
or charger.
•Keep all plastic bags out of the
reach of young children.
•Not recommended for children
under the age of 2 yrs. due to
small parts that could cause a
choking hazard.
•Battery must be charged for a
minimum of 8-12 hours prior to
first use of the car to avoid
damage to the battery. Power
switch must be in off position
when charging.
•Battery charger should be
examined for damage prior to
each use. It is important to
inspect the cord and both ends
for damage. If damage is found,
DO NOT USE THE CHARGER!
Contact us for replacement
charger.
•Please retain instruction manual
for future reference.
•Please retain packaging in the
event it is necessary to return.
If the charger is plugged into the charging port, the car will not
power up regardless if the charger is plugged into the wall
outlet or not.

PARTS LIST:
1
Car Body
2
Hood Emblem
3
Windshield
4
Rearview Mirrors
5
Steering Wheel
6
Seat
7
Rear Body Support
8
Front Body Support
9
Motor/Gearbox
10
Rear Wheels/Tires
11
Front Wheels/Tires
12
13
Hubcap center caps
14
Wheel Bushings
15
Washers
16
Lock Nut
17
Upper door windows
All assembly videos can be found on
YouTube under SPORTrax

ASSEMBLY INSTRUCTIONS:
Step 1 - Install rear axle:
Turn car upside down. As seen in the photo above, insert the springs
into the spring pockets toward the rear of the car. Place plastic spring
caps over the springs so that the open end is facing up. Slide rear axle
through the hole in the side of the body while pushing down the plastic
spring caps far enough to line up the holes. This will allow you to feed
the axle completely through to the opposite side.
Step 2 - Install rear wheel/gearbox assembly:
Turn car right side up. Place the motor/gearbox marked with an “R”
onto the axle on the right side of the car (facing the car from the rear).
While sliding the gearbox onto the axle you will need to feed the
electrical connector and motor through the hole in the body. Next,
insert a wheel bushing into each side of the wheel, slide the rear wheel
onto the axle followed by the wheel bushing & washer. Thread on lock
nut until snug. Finally, install the wheel cover center cap. Repeat steps
for left side of car.

Step 3 - Installing the front wheels:
Slide a washer on the end of the front axle. Insert a wheel bushing into
each side of the front wheel. Slide wheel onto the axle, making sure
that the wheel bushings stay in place, followed by a washer. Thread on
lock nut until snug. Finally, install the wheel cover center cap. Repeat
steps for opposite side of car.
Step 4 –Install rear body support:
Turn car upside down. Line up rear body support as shown in photo
above, ensuring that the holes in the rear body support line up with the
screw posts in the body. Install screws through each hole in rear body
support and tighten until snug. Do not overtighten!

Step 5 –Install side mirrors & hood emblem:
Insert the mirrors into the holes in the body and press firmly down until
they snap into place. Repeat steps for hood emblem.
Step 6 - Install steering wheel:
Remove screw and nut from the shaft of the steering wheel. Connect
electrical connection between the steering wheel and the wires from
the car. Slide steering wheel onto the steering shaft. Align the screw
hole in the steering shaft and the steering wheel and slide the bolt
through the hole. Apply the nut to the end of the bolt and tighten until
snug.

Step 7 - Install windshield:
Align the tabs on bottom of windshield with the tabs on body of the car
and push down until you hear a click. Then insert the screws on both
sides of the windshield (located by mirrors) to secure the windshield.
Step 8 –Connections in battery area:
Connect plastic electrical connector from the motor to the
corresponding plastic electrical connector from the car. Make
connection to both motors. Connect red wire to the positive (+) side of
the battery. Connect black wire to the negative (-) side of the battery.
Step 9 –Install the seat:
Slip tabs on back of seat into the slots in the body of the car. Attach seat to body through
the two holes located in the front corners of the seat with 2 screws.

1) Power switch: turn the car on and off
2) Forward/backward switch: changes the direction the car moves from
forward to reverse: To move the car forward, press the top of the
switch down; To move the car backward, press the bottom of the
switch down; Shift the switch to the middle, the car will stop
3) High/Low Switch: Press top of switch down for fast speed; Press
bottom of switch down for slow speed.
4) Music Keys: press for sounds of music playing
5) MP3 socket: plug MP3 cable to play music from mobile or MP3 player
6) Foot Pedal: Applies power (speed) to the car: To move the car, press
the foot pedal down; To brake or slow down the car, release the foot
pedal
7) The charging hole: Located under the front of the seat.
8) Volume knob: Adjust level of music through the speaker.
10. Charging the battery: The charging port is located just under the front portion of
the seat. Plug the charger into the charging port first, then plug the charger into wall
outlet. BATTERY MUST BE CHARGED A MINIMUM OF 8 TO 12 HOURS AT
LEAST ONCE PER MONTH!!!
Please Note: As a safety precaution and to avoid damage to
the charger, the car will not power up while charger port is
plugged into the car.

BATTERY REPLACEMENT AND DISPOSAL:
The battery will eventually lose the ability to hold a charge. Depending on the amount of
use, and varying conditions, the battery should operate for one to three years. Follow
these steps to replace and/or dispose of the battery:
•Remove the cars seats
•Disconnect the battery connectors
•Remove the metal battery bracket
•Remove the battery cover
•Carefully lift the battery - you may want to wear protective gloves before
removal - Do Not lift the battery by its connectors or cables
•Place the dead battery in a plastic bag
•Replace the battery and reconnect the connectors
•Replace the metal battery bracket
•Replace the seat
Remote Control Instructions: For the first time use of remote
control or after replacing the battery, you need to sync the remote to the car.
1) Press the car-select button down until the remote indicator light is
flashing, turn on car, and when the light stops flashing pairing has
been successful.
2) Repeat if this does not happen.
3) Once paired for the first time, no need to pair remote for later use
unless the batteries are changed in the remote.
4) Emergency brake. Press & hold stop button down to stop motion
of the car immediately. Release the button to restore the normal
functions of the car.
Forward Backward Turn Right Turn Left

WARNING:
- Use only the rechargeable battery and charger supplied with
your vehicle. NEVER substitute the battery or charger with
another brand. Using another battery or charger may cause
damage.
- NEVER modify the electric circuit system. Tampering with the
electric system may cause permanent damage to the system.
- Do not allow direct contact between battery terminals.
- Do not allow any type of liquid on the battery or its
components.
- Charge the battery in a well-ventilated area ONLY. Do not
charge near or around flammable materials.
- NEVER pick up the battery by the wires or charger. Damage can
occur to the battery and may cause a fire. Pick up the battery
by the case ONLY.
- Charge the battery in a dry area ONLY.
Wash hands after handling.
- Do not open the battery. Battery contains lead acid and other
materials that are toxic and corrosive.
- Do not open the charger. Exposed wiring and circuitry inside
case could cause electric shock. NEVER allow a child to handle
or charge the battery. Battery is heavy and contains lead acid
(electrolyte).
- Do not drop the battery. Permanent damage to the battery
could occur or cause serious injury
- Before charging the battery, check for wear or damage to the
battery, charger, its supply cord and the connectors. DO NOT
charge the battery if any damage to parts has occurred.
- Do not allow the battery to drain completely. Recharge the
battery after each use or once per month if not used regularly.
- Do not charge the battery upside down.
- Always secure the battery with the bracket. Battery can fall out
and injure a child if vehicle tips over.
- The Power Switch must be turned in the OFF position when
charging.
- When the car begins to run slowly, recharge the battery.

GENERAL MAINTENANCE:
It is the parent’s responsibility to check main parts of the
toy before using. Regularly examine the car for potential
hazard, such as damage to the battery, charger, cable or
cord, and plug. Also, check that all screws are tightened
throughout the car. In the event of such damage, the toy
must not be used until that damage is repaired or replaced.
•Make sure the plastic parts of the vehicle are not
cracked or broken.
•Occasionally use a lightweight oil to lubricate moving
parts such as wheels.
•Park the vehicle indoors or cover it with a tarp to
protect it from wet weather.
•Keep the vehicle away from sources of heat, such as
stoves and heaters. Plastic parts may melt.
•Recharge the battery after each use. Only an adult
should handle the battery. Recharge the battery at least
once a month when not being used.
•Do not wash the vehicle with a hose. Do not wash the
vehicle with soap and water. Do not drive the vehicle in
rainy or snowy weather as water will damage the
motor, electric system and battery.
•Clean the vehicle with a soft, dry cloth. To restore shine
to plastic parts, use a non-wax furniture polish. Do not
use car wax. Do not use abrasive cleaners.
•Do not drive the vehicle in loose dirt, sand or fine gravel
which could damage moving parts, motors or the
electric system.
•For extended times when the car will not be used, the
power switch needs to be in the off position and the
electrical connections should be disconnected from the
battery.

TROUBLE SHOOTING GUIDE:
Problem
Possible Cause
Possible Solutions
Car will not move
1. Battery voltage is low.
2. Battery connector or wires
are loose.
3. Battery is damaged or
dead.
4. Electrical box or motor is
damaged
Charge the battery
Re-connect the battery
connector to the car
Replace battery
Replace motor
The battery will not
charge.
1. Battery connector may
have come apart or have a
bad connection.
2. Battery charger plugged
into a bad wall outlet.
3. Battery charger is
damaged.
Re-connect the battery
connector to the car
electrical connector
Try another wall outlet
Replace battery charger
Shortened battery life
Battery was not charged fully
Battery is old
Charge battery fully
Change battery
Some Noise and heat
when charging battery
Chemical reaction
Normal
Low Speed
Battery is old
Battery is low on charge
Weight limit exceeded
Uneven or uphill path
Vehicle is being used in harsh
conditions
Change the battery
Charge the battery
Do not exceed max weight
limit
Use on flat surfaces
Avoid using car in harsh
conditions
Noise coming from
motor/gearbox
Gear in motor/gearbox broken
Call for replacement
motor
The car shakes when
moving
Bad Connection of the motor
wires
Possible motor failure
Reconnect wires
Call for replacement
motor
Car needs a push to go
forward
Poor contact of wires and/or
connectors
“Dead Spot” on motor
Check that the battery
connectors are firmly
plugged into each other. If
wires are loose around
the motor, contact the
distributor’s service
department
A dead spot means the
electric power is not being
delivered to the terminal
connection. Call our
service department
Self-Resetting Breaker –The vehicle is equipped with a self-
resetting breaker. In the event the power is tripped the breaker
will reset itself in approximately one minute.
If you are unable to solve a problem, please feel free to contact us.
Phone: [phone] or Email: [e-mail]
