Supertrax Licensed Lexus LX Parts list manual

Licensed Lexus LX
Kids Ride on Vehicle
Assembly and Operation Instructions
Please read this instruction manual carefully. It is important to read and
follow all the steps during assembly to ensure proper operation and safety of
the child. Please keep this manual for future reference.

SPECIFICATIONS:
Battery Type:
12V10AH
Avg. Speed:
2 –3 MPH
Age Range:
2 –8 Years
Charging time:
8-12 hrs -MAX
Charge once per
month
Max. Weight:
80 lbs
Avg. Use Time:
48-90 Minutes
(depending on use)
Product Size:
53”L x 34”W x 22”H
Remote
Battery:
2 - AAA (not
included)
IMPORTANT!
●Assembly of car and charging of
battery by adult only.
●WARNING!! NOT TO BE USED ON
STREETS or IN TRAFFIC.
●Never modify the electric circuit
system or tamper with electric
system. Can cause permanent
damage.
●Please check the product regularly
for any loose parts or wires to ensure
proper operation.
●Adult supervision is recommended
during operation by child to avoid
injury. Safety equipment is
recommended.
●Please make sure that the child uses
caution to avoid falls and collisions
causing injury to the child or third
party.
●Do not pick up vehicle by steering
wheel.
●Do not pick up battery by wires or
charger.
●Keep all plastic bags out of the reach
of young children.
●Not recommended for children
under the age of 2 yrs. due to small
parts that could cause a choking
hazard.
●Battery must be charged for a
minimum of 8-12 hours prior to first
use of the car to avoid damage to the
battery. Power switch must be in off
position when charging.
●Battery charger should be examined
for damage prior to each use. It is
important to inspect the cord, and
both ends for damage. If damage is
found, DO NOT USE THE CHARGER!
Contact us for replacement charger.
●Please retain instruction manual for
future reference.
●Please retain packaging in the event
it is necessary to return for repair.
If the charger is plugged into the charging port, the car will not power up regardless if
the charger is plugged into the wall outlet or not.

Parts List by Part Number:
#
Part Name
Qty
#
Part Name
Qty
#
Part Name
Qty
1.
Body
1
6.
Hubcap
4
11.
Steering Wheel
1
2.
Gear Box
4
7.
Windshield
1
12.
Front Axle
1
3.
Wheels
4
8.
Seat
1
13.
Hood
1
4.
Rear Axle
1
9.
Rear Hatch
1
14.
Remote Control
1
5.
Charger
1
10.
Hardware
Bag
1
Assembly Instructions:
●Before using, the vehicle must be assembled by an adult. It takes
about 30 minutes to assemble the product.
●A Philips head screw driver and needle nose pliers will be needed.
●Do not allow children to play with parts or packaging.
●Check that all parts are present before beginning assembly.
All assembly videos can be found on YouTube under
SUPERtrax
Remove Rear Hatch
1. First, flip the vehicle over.
2. Then, remove brackets from rear wheel wells.
3. Gently remove the rear hatch from the wheel well.
4. Replace the brackets, you will use 3 screws to secure each bracket.

Installing the Tires
1. With the car still flipped over, install a tire onto the rear axle.
2. Once the tire is on the axle, slide a washer onto the axle.
3. Then insert a cotter pin into the hole on the axle.
4. Using the needle nose pliers, bend the ends of the cotter pin so that
they are going in opposite directions.
5. Repeat steps 1-4 for all tires.
6. Then collect the hubcaps and the stickers.
7. Place one sticker in the center of each hubcap
8. Snap hubcap into place on the tire.
9. Repeat for all tires.
Connecting the Steering Wheel
1. Remove the steering
wheel bolt from the
steering wheel.
2. Connect the wires from
the steering column to the
wires from the steering
wheel.
3. Slide wires down into the
steering column and slide
steering wheel onto
steering column.
4. Placing the nut on one side of the steering column insert the bolt and
screw into place.

Install Rear Hatch
1. Align the tabs on the hatch with the car.
2. Snap into place, then secure with screws.
Connecting the Battery
1. Remove the battery cover by twisting the latches.
2. INSPECT WIRING, power connections should be red wire to positive
(+) side of battery and black wire to negative (-) side of battery.
Typically, these connections are made during the quality control
inspection prior to shipping.
3. Check all remaining connectors to make sure all wiring is connected
for proper operation.
4. Replace the battery cover.
Install the Windshield and Hood
1. Align the tabs on the windshield with the car and press firmly into
place.
2. Screw down and secure the windshield.
3. Once the windshield is secure, insert the tabs on the hood to the slots
on the windshield.
4. Then close the hood.
Install the Side Mirrors
1. Align side mirror with the hole on the body.
2. Gently pressing in slide mirror into hole.
3. Mirror will pop into place, repeat for other side.
Install the Seat
1. Align the tabs on the back of the seat with the hole on the rear hatch.
2. Then align the screw holes, and secure with screws.

Connecting the Remote Control
1. To connect the remote, first place two AAA batteries in the remote.
2. Then with the car off, press and hold the car select button on the
remote until it begins flashing, then release car select button.
3. Turn on the car, the remote should stop flashing, then the remote
will be paired.
Battery Disposal and Replacement:
The battery will eventually lose the ability to hold a charge. Depending
on the amount of use, and varying conditions, the battery should
operate for one to three years. Follow these steps to replace and/or
dispose of the battery:
●Open the front hood of the vehicle
●Disconnect the battery connectors (Red).
●Position the battery lock switch to unlock. Carefully lift the battery -
you may want to wear protective gloves before removal - Do Not lift
the battery by its connectors or cables.
●Place the dead battery in a plastic bag.
●Replace the battery and reconnect the connectors.
●Close the Hood.

WARNING:
- Use only the rechargeable battery and charger supplied with your
vehicle. NEVER substitute the battery or charger with another brand.
Using another battery or charger may cause damage.
- NEVER modify the electric circuit system. Tampering with the electric
system may cause permanent damage to the system.
- Do not allow direct contact between battery terminals.
- Do not allow any type of liquid on the battery or its components.
- Charge the battery in a well-ventilated area ONLY. Do not charge near
or around flammable materials.
- NEVER pick up the battery by the wires or charger. Damage can occur
to the battery and may cause a fire. Pick up the battery by the case
ONLY.
- Charge the battery in a dry area ONLY. Wash hands after handling.
- Do not open the battery. Battery contains lead acid and other
materials that are toxic and corrosive.
- Do not open the charger. Exposed wiring and circuitry inside case
could cause electric shock. NEVER allow a child to handle or charge the
battery. Battery is heavy and contains lead acid (electrolyte).
- Do not drop the battery. Permanent damage to the battery could
occur or cause serious injury.
- Before charging the battery, check for wear or damage to the battery,
charger, its supply cord and the connectors. DO NOT charge the battery
if any damage to parts has occurred.
- Do not allow the battery to drain completely. Recharge the battery
after each use or once per month if not used regularly.
- Do not charge the battery upside down.
-Always secure the battery with the cover. Battery can fall out and
injure a child if vehicle tips over.
- The Power Switch must be turned in the OFF position when charging.
- When the car begins to run slowly, recharge the battery.

GENERAL MAINTENANCE:
It is the parent’s responsibility to check main parts of the toy before
using. Regularly examine the car for potential hazard, such as damage
to the battery, charger, cable or cord, and plug. Also, check that all
screws are tightened throughout the car. In the event of such damage,
the toy must not be used until that damage is repaired or replaced.
●Make sure the plastic parts of the vehicle are not cracked or broken.
●Occasionally use a lightweight oil to lubricate moving parts such as
wheels.
●Park the vehicle indoors or cover it with a tarp to protect it from wet
weather.
●Keep the vehicle away from sources of heat, such as stoves and
heaters. Plastic parts may melt.
●Recharge the battery after each use. Only an adult should handle
the battery. Recharge the battery at least once a month when not
being used.
●Do not wash the vehicle with a hose. Do not wash the vehicle with
soap and water. Do not drive the vehicle in rainy or snowy weather
as water will damage the motor, electric system and battery.
●Clean the vehicle with a soft, dry cloth. To restore shine to plastic
parts, use a non-wax furniture polish. Do not use car wax. Do not
use abrasive cleaners.
●Do not drive the vehicle in loose dirt, sand or fine gravel which could
damage moving parts, motors or the electric system.
●For extended times when the car will not be used, the power switch
needs to be in the off position and the electrical connections should
be disconnected from the battery.

TROUBLE SHOOTING GUIDE:
Problem
Possible Cause
Possible Solutions
Car will not move
1. Battery voltage is low.
2. Battery connector or
wires are loose.
3. Battery is damaged or
dead.
4. Electrical box or motor
is damaged
Charge the battery
Re-connect the battery
connector to the car
Replace battery
Replace motor
The battery will not
charge.
1. Battery connector may
have come apart or
have a bad connection.
2. Battery charger
plugged into bad
outlet.
3. Battery charger is
damaged.
Re-connect the battery
connector to the car electrical
connector
Try another wall outlet
Replace battery charger
Shortened battery life
Battery not charged fully
Battery is old
Charge battery fully
Change battery
Noise and heat when
charging
Chemical reaction
Normal
Low Speed
Battery is old
Battery is low on charge
Weight limit exceeded
Uneven or uphill path
Vehicle is being used in
harsh conditions
Change the battery
Charge the battery
Do not exceed max weight
limit
Use on flat surfaces
Avoid using car in harsh
conditions
Noise coming from
motor/gearbox
Gear in motor/gearbox
broken
Call for replacement motor
The car shakes when
moving
Bad Connection of the
motor wires
Possible motor failure
Reconnect wires
Call for replacement motor
Car needs a push to
go forward
Poor contact of wires
and/or connectors
“Dead Spot” on motor
Check that the battery
connectors are firmly plugged
into each other. If wires are
loose
, contact the distributor’s
service dept.
A dead spot means the electric
power is not being delivered.
Call service department
Self-Resetting Breaker –The vehicle is equipped with a self-resetting breaker.
In the event the power is tripped the breaker will reset itself in approx. 1 min.
If you are unable to solve a problem, please feel free to contact us.
Phone: [phone] or Email: [e-mail]
