Supertrax Licensed Volvo XC90 User manual

Licensed Volvo XC90
Kids Ride on Car
Installation and Operation Instructions
Please read this instruction manual carefully. It is important to read and
follow all of the steps during assembly to ensure proper operation and safety
of the child. Please keep this manual for future reference.
Scan this QR Code
to view the
Assembly Video

SPECIFICATIONS:
Battery Type:
12V10AH
Avg. Speed:
2 –5 MPH
Age Range:
2 –6 Years
Charging time:
8-12 hrs –Minimum
1 Charge per month
Max. Weight:
75 lbs
Avg. Use Time:
48-90 Minutes
(depending on use)
Product Size:
51”L x 26”W x 25”H
Remote Battery:
2 - AAA (not
included)
IMPORTANT!
•Assembly of car and charging of
battery is only to be done by an
adult.
•WARNING!! NOT TO BE USED
ON STREETS or IN TRAFFIC.
•Never modify the electric circuit
system or tamper with electric
system. Can cause permanent
damage.
•Please check the product
regularly for any loose parts or
wires to ensure proper
operation.
•Adult supervision is
recommended during operation
by child to avoid injury. Safety
equipment is recommended.
•Please make sure that the child
uses caution to avoid falls and
collisions causing injury to the
child or third party.
•Do not pick up vehicle by
steering wheel.
•Do not pick up battery by wires
or charger.
•Keep all plastic bags out of the
reach of young children.
•Not recommended for children
under the age of 2 yrs. due to
small parts that could cause a
choking hazard.
•Battery must be charged for a
minimum of 8-12 hours prior to
first use of the car to avoid
damage to the battery. Power
switch must be in off position
when charging.
•Battery charger should be
examined for damage prior to
each use. It is important to
inspect the cord and both ends
for damage. If damage is found,
DO NOT USE THE CHARGER!
Contact us for replacement
charger.
•Please retain instruction manual
for future reference.
•Please retain packaging in the
event it is necessary to return.
If the charger is plugged into the charging port, the car will not power up
regardless if the charger is plugged into the wall outlet or not.

All assembly videos can be found on YouTube
under SPORTrax

2: Installation of Headrest onto Seat: Locate the Headrests and Seat
from the parts. Snap the corresponding headrest (R) in the right side
of the top of the seat. Snap the corresponding headrest (L) in the left
side of the top of the seat.
3: Installation of Rear View Mirror: Locate rear view mirrors from
parts. Insert each mirror into the correct position on each door.
NOTE: One mirror will install properly on the left door and one will
install properly on the right door.
4: Installation of the Seat: Place the seat assembly into the correct
location of the car (directly over the location of the battery) use
screws provided to secure seat to body of car.

5: Installation of front wheels and wheel covers:
Locate the 2 wheels that do not have the hub attached to them.
(Wheels will be flat on both sides) Insert the small black plastic
bushings into the center hole on the back side of the wheel. Install a
flat washer onto each of the front axles. Slide one wheel onto the
front axle on each side of the car. While sliding the wheel onto the
axle, press the center button of the wheel and slide wheel on
completely and let go of center button. Pull gently on the wheel to
make sure that wheel is locked into place.
6: Installation of the rear wheels and wheel covers:
The remaining 2 wheels will have a hub on the back side of the
wheel. Insert small black plastic bushings into the center hole on the
back side of the wheel. Slide one wheel onto the rear axle on each
side of the car. You will need to line up the hub with the motor on
the axle. While sliding the wheel onto the axle, press the center
button of the wheel and slide wheel on completely and let go of
center button. Pull gently on the wheel to make sure that wheel is
locked into place.

7: Installation of the steering wheel:
Remove nut and bolt from the steering wheel assembly. Connect the
wire connector from the steering wheel to the corresponding
connector at the steering column. Slide the steering wheel onto the
steering shaft while feeding the wire connector into the steering
column. Line up the hole in the steering column to the hole through
the steering wheel assembly and slide bolt through. Secure with the
nut.
NOTE: Due to possible movement in the steering shaft through the
column, the hole in the steering shaft may not line up with the hole
through the steering wheel assy. If this happens, use one hand under
the car and push the steering shaft upward while attempting to line up
the holes for the bolt to secure the steering wheel. Please see photo.

Main Functions
Remote Control Function
Operating the remote control
1. Install batteries.
2. Remote lights will flash briefly and then go out.
2. With the lights on the remote off and the car “OFF” press and hold the car select button.
(The lights on the remote will come on.) While holding the “car select” button, turn on the car.

Continue holding the “car select” button throughout the synching process. When the “car
select” light goes out, the remote is synched to the car. STOP Button=Parking brake
Music Player Function
1. Press once to change to the story time feature. Press for about 3 seconds to
lower the volume.
2. Press to change to the music feature. Press for about 3 seconds to raise the
volume.
3. Press once to change to the next song. Long press for about 3 seconds to
pause.
4. Press to change the education feature.
BATTERY REPLACEMENT AND DISPOSAL:
The battery will eventually lose the ability to hold a charge. Depending on the amount of use, and
varying conditions, the battery should operate for one to three years. Follow these steps to replace
and/or dispose of the battery:
•Remove the cars seats
•Disconnect the battery connectors
•Remove the metal battery bracket
•Carefully lift the battery - you may want to wear protective gloves before removal - Do Not lift
the battery by its connectors or cables
•Place the dead battery in a plastic bag
•Replace the battery and reconnect the connectors
•Replace the metal battery bracket
•Replace the seat

WARNING:
- Use only the rechargeable battery and charger supplied with
your vehicle. NEVER substitute the battery or charger with
another brand. Using another battery or charger may cause
damage.
- NEVER modify the electric circuit system. Tampering with the
electric system may cause permanent damage to the system.
- Do not allow direct contact between battery terminals.
- Do not allow any type of liquid on the battery or its components.
- Charge the battery in a well-ventilated area ONLY. Do not
charge near or around flammable materials.
- NEVER pick up the battery by the wires or charger. Damage can
occur to the battery and may cause a fire. Pick up the battery by
the case ONLY.
- Charge the battery in a dry area ONLY.
Wash hands after handling.
- Do not open the battery. Battery contains lead acid and other
materials that are toxic and corrosive.
- Do not open the charger. Exposed wiring and circuitry inside
case could cause electric shock. NEVER allow a child to handle or
charge the battery. Battery is heavy and contains lead acid
(electrolyte).
- Do not drop the battery. Permanent damage to the battery
could occur or cause serious injury.
- Before charging the battery, check for wear or damage to the
battery, charger, its supply cord and the connectors. DO NOT
charge the battery if any damage to parts has occurred.
- Do not allow the battery to drain completely. Recharge the
battery after each use or once per month if not used regularly.
- Do not charge the battery upside down.
- Always secure the battery with the bracket. Battery can fall out
and injure a child if vehicle tips over.
- The Power Switch must be turned in the OFF position when
charging.
- When the car begins to run slowly, recharge the battery.

GENERAL MAINTENANCE:
It is the parent’s responsibility to check main parts of the toy before using.
Regularly examine the car for potential hazard, such as damage to the battery,
charger, cable or cord, and plug. Also, check that all screws are tightened
throughout the car. In the event of such damage, the toy must not be used
until that damage is repaired or replaced.
•Make sure the plastic parts of the vehicle are not cracked or broken.
•Occasionally use a lightweight oil to lubricate moving parts such as wheels.
•Park the vehicle indoors or cover it with a tarp to protect it from wet
weather.
•Keep the vehicle away from sources of heat, such as stoves and heaters.
Plastic parts may melt.
•Recharge the battery after each use. Only an adult should handle the
battery. Recharge the battery at least once a month when not being used.
•Do not wash the vehicle with a hose. Do not wash the vehicle with soap
and water. Do not drive the vehicle in rainy or snowy weather as water
will damage the motor, electric system and battery.
•Clean the vehicle with a soft, dry cloth. To restore shine to plastic parts,
use a non-wax furniture polish. Do not use car wax. Do not use abrasive
cleaners.
•Do not drive the vehicle in loose dirt, sand or fine gravel which could
damage moving parts, motors or the electric system.
•For extended times when the car will not be used, the power switch needs
to be in the off position and the electrical connections should be
disconnected from the battery.

TROUBLE SHOOTING GUIDE:
Problem
Possible Cause
Possible Solutions
Car will not move
1. Battery voltage is low.
2. Battery connector or wires
are loose.
3. Battery is damaged or
dead.
4. Electrical box or motor is
damaged
Charge the battery
Re-connect the battery
connector to the car
Replace battery
Replace motor
The battery will not
charge.
1. Battery connector may
have come apart or have a
bad connection.
2. Battery charger plugged
into a bad wall outlet.
3. Battery charger is
damaged.
Re-connect the battery
connector to the car
electrical connector
Try another wall outlet
Replace battery charger
Shortened battery life
Battery was not charged fully
Battery is old
Charge battery fully
Change battery
Some Noise and heat
when charging battery
Chemical reaction
Normal
Low Speed
Battery is old
Battery is low on charge
Weight limit exceeded
Uneven or uphill path
Vehicle is being used in harsh
conditions
Change the battery
Charge the battery
Do not exceed max weight
limit
Use on flat surfaces
Avoid using car in harsh
conditions
Noise coming from
motor/gearbox
Gear in motor/gearbox broken
Call for replacement
motor
The car shakes when
moving
Bad Connection of the motor
wires
Possible motor failure
Reconnect wires
Call for replacement
motor
Car needs a push to go
forward
Poor contact of wires and/or
connectors
“Dead Spot” on motor
Check that the battery
connectors are firmly
plugged into each other. If
wires are loose around
the motor, contact the
distributor’s service
department
A dead spot means the
electric power is not being
delivered to the terminal
connection. Call our
service department
Self-Resetting Breaker –The vehicle is equipped with a self-resetting breaker.
In the event the power is tripped the breaker will reset itself in approximately
one minute.
If you are unable to solve a problem, please feel free to contact us.
Phone: [phone] or Email: [email protected]
