Swann alpha Series User manual

1
EN
Combination Product Name:
Home Assistance Button and
Movement Sensor Kit
HomeSafe Alert Kit
Instruction Manual
Manual de instrucciones
EN
ES
Powered by Swann

2
EN
OVERVIEW
How does it work?
Basically, the Home Assistance Button and Movement Sensor Kit/HomeSafe Alert Kit
consists of the following components:
1. The Indoor Alarm Receiver works as an alarm buzzer and a door chime. It monitors
for signals coming from the Alert Sensor and the Doorbell, and plays an alert sound
in response to that signal. It also features a series of LED indicators on the front
of the unit so you can visually tell where an alert is coming from. The Indoor Alarm
Receiver can be either mounted to a xed location or completely freestanding.
2. The Alert Sensor enables you to monitor for movement in a particular zone or area
of your property. The Alert Sensor sends a signal to the Indoor Alarm Receiver
whenever movement is detected. The Alert Sensor can be deployed outdoors, for
example, near the entry to your driveway and garage, or placed indoors at various
entry/exit points in your home or business.
3. The Doorbell enables visitors to send a chime to the Indoor Alarm Receiver so you
know that someone’s waiting at your doorstep. The Doorbell can also easily be
carried around the home in your pocket and used as a help button.
Need more coverage and protection for different areas around your property? Simply
purchase additional Alert Sensor and Doorbell units and add them to your alarm
system. The Indoor Alarm Receiver has 4 separate channels — each with customizable
alert sounds and the capability to support continuous monitoring of up to 15 devices
per channel.
Extend the System
Have Questions?
We are here to help! Visit us at
http://support.swann.com. You can also email us at any
time via: [email protected]

3
EN
GETTING TO KNOW THE DEVICES
Indoor Alarm Receiver Overview(Model:SWALPH-CHM2)
Sensor Channel 1
LED Indicator
Speaker
Battery Compartment
Volume
Button
Doorbell Channel
Button
Keyhole Mounting Slots
Sensor Channel
1, 2, 3 Buttons
Melody Select
Button
Doorbell Channel
LED Indicator
Sensor Channel 3
LED Indicator
Sensor Channel 2
LED Indicator

4
EN
GETTING TO KNOW THE DEVICES
Alert Sensor Overview(Model:SWALPH-ALSEN2)
Doorbell Overview(Model:SWALPH-BUTTON)
Passive Infrared
Motion Detector
LED Indicator
Single Blink - Motion Detected
Continuous Blinking - Low Battery
Doorbell Button /
LED Indicator
Mounting
Bracket Slot
Mounting
Bracket Slot
Battery
Compartment
CODE Button
(inside battery
compartment)
Locking Screw
Battery
Compartment
Locking Screw

5
EN
BATTERY INSTALLATION
Indoor Alarm Receiver
The Indoor Alarm Receiver requires 3 AA batteries (not supplied) to operate.
For reliable, long-lasting performance, use only high quality alkaline batteries.
To install batteries:
1. Push the release tab and lift off the battery compartment cover.
2. Insert 3 new AA batteries, matching the polarity markings (+ and -) shown inside the
battery compartment.
3. Replace the battery compartment cover.
Alert Sensor
The Alert Sensor requires 3 AAA batteries (not supplied) to operate.
For reliable, long-lasting performance, use only high quality alkaline batteries.
To install batteries:
1. Using a small Phillips®screwdriver, remove the two screws securing the battery
compartment cover, and then lift off the cover.
2. Insert 3 new AAA batteries, matching the polarity markings (+ and –) shown inside
the battery compartment.
3. Replace the battery compartment cover and screw it back into place with the
previously removed screws.
Doorbell
WARNING! This product contains a button/coin cell battery. If the button/coin cell battery is swallowed,
it can cause internal chemical burns in as little as two hours and lead to death. Dispose of used
batteries immediately. Keep new and used batteries away from children. If the battery compartment
does not close securely, stop using the product. If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate medical attention.
Australia: If you think batteries might have been swallowed or placed inside any part of the body,
immediately call the 24-hour Poisons Information Centre on 13 11 26 for fast, expert advice and go
straight to the nearest hospital emergency room.
The Doorbell is powered by a CR2025 battery (supplied).
To install the battery:
1. Using a small Phillips®screwdriver, remove the screw securing the battery
compartment cover.
2. Rotate the battery compartment cover counter-clockwise until the arrow aligns
with the Unlock position and lift off the cover.
3. Place the new CR2025 battery in the battery compartment with the positive (+) side
facing up.
4. Replace the battery compartment cover rotating clockwise until the arrow aligns
with the Lock position and fasten with the previously removed screw.

6
EN
OPERATING BASICS
Pairing the Alert Sensor with the Indoor Alarm Receiver
1. Place the Alert Sensor faced down to avoid triggering it.
2. Decide which Sensor Channel (1, 2 or 3) you want to assign to the Alert Sensor,
then press and hold the desired Sensor Channel Number button on the side of the
Indoor Alarm Receiver until the corresponding Sensor Channel LED indicator lights
up and a beep is heard. The Indoor Alarm Receiver is now in pairing mode.
3. Within 25 seconds, trigger the Alert Sensor by lifting it up. The Sensor Channel
melody sounds with the corresponding Sensor Channel LED indicator blinking on
the Indoor Alarm Receiver to conrm successful pairing.
Note: You can also pair the Alert Sensor by pressing the CODE button inside the
battery compartment of the Alert Sensor.
4. If pairing is not completed within 25 seconds, the Sensor Channel LED indicator
goes off and the Indoor Alarm Receiver is no longer in pairing mode. Repeat the
steps above to pair the Alert Sensor again.
Pairing the Doorbell with the Indoor Alarm Receiver
1. Press and hold the Doorbell Channel button on the side of the Indoor Alarm
Receiver until the Doorbell Channel LED indicator lights up. The Indoor Alarm
Receiver is now in pairing mode.
2. Within 25 seconds, press the Doorbell button. The Doorbell Channel melody sounds
with the Doorbell Channel LED indicator blinking on the Indoor Alarm Receiver to
conrm successful pairing.
3. If pairing is not completed within 25 seconds, the Doorbell Channel LED indicator
goes off and the Indoor Alarm Receiver is no longer in pairing mode. Repeat steps
above to pair the Doorbell again.
Adjusting the Indoor Alarm Receiver Volume
There are three volume levels available. Simply press the Volume button on the side of
the Indoor Alarm Receiver until the desired volume level is obtained. You will hear the
difference in volume each time the Volume button is pressed.
TIP: The Doorbell can also be paired with one of the Sensor Channels, if desired. In step
1 above, press and hold any Sensor Channel Number button (instead of the Doorbell
Channel button) until the Sensor Channel LED indicator lights up.
TIP: The Alert Sensor can also be paired with the Doorbell Channel, if desired. In step
2 above, press and hold the Doorbell Channel button (instead of the Sensor Channel
Number button) until the Doorbell Channel LED indicator lights up.

7
EN
OPERATING BASICS
Resetting the Indoor Alarm Receiver
Resetting the Indoor Alarm Receiver removes all devices that have been paired with
it. This will enable you to add those devices to different channels. Resetting can also
help x some common issues (for example, the Indoor Alarm Receiver sounding
unexpectedly because of signal interference from neighboring devices).
To reset the Indoor Alarm Receiver:
• Press and hold the Melody Select button on the side of the Indoor Alarm Receiver
until all of the Doorbell and Sensor Channel LEDs light up at the same time.
• After resetting the Indoor Alarm Receiver, you will need to pair the Alert Sensor and
the Doorbell with it again.
Muting the Indoor Alarm Receiver
Like some peace and quiet for a period of time? You can easily turn off the alert sounds
coming from any channel on the Indoor Alarm Receiver.
To mute a channel:
• Briey press the Sensor/Doorbell Channel button that corresponds with the
channel that you want muted. The Indoor Alarm Receiver beeps twice to conrm
the selected channel has been muted.
• Any alerts triggered by devices on that particular channel will not be sounded,
however, you will still be visually alerted by the corresponding Sensor/Doorbell
Channel LED blinking for 25 seconds when the device is triggered.
To unmute a channel:
• Briey press the Sensor/Doorbell Channel button that corresponds with the
channel that is currently muted. The Indoor Alarm Receiver beeps once to conrm
the selected channel has been unmuted.
Changing the Channel Melody
You can set a different melody sound for each Sensor/Doorbell Channel.
1. Press the Melody Select button on the side of the Indoor Alarm Receiver. The next
melody is played. Keep pressing the Melody Select button until you hear a melody
you like. There are 36 melodies to choose from.
2. Choose the Sensor/Doorbell Channel (must have at least one paired device) you want
the melody to be assigned to by pressing and holding the desired Sensor/Doorbell
Channel button until the corresponding Sensor/Doorbell Channel LED lights up.
3. Within 25 seconds, trigger any device linked to the Sensor/Doorbell Channel:
— trigger Alert Sensor by waving your hand in front of it, or
— trigger Doorbell by pressing the Doorbell button
4. The Indoor Alarm Receiver plays the chosen melody with the corresponding Sensor/
Doorbell Channel LED blinking as conrmation.

8
EN
MOUNTING THE DEVICES
Indoor Alarm Receiver
• The Indoor Alarm Receiver can be completely freestanding or mounted. The
operating distance between the Indoor Alarm Receiver and the Alert Sensor/
Doorbell is up to 100ft/30m but the range may vary depending on local conditions.
• As it is also completely freestanding, you may nd it more convenient to place it on
a shelf or table. One of the benets of a battery-powered wireless receiver is that
if you have a large house, you can bring the receiver with you. No more missing
visitors because you were all the way at the back of the house.
• If you would like to mount the Indoor Alarm
Receiver, simply attach two screws to the
wall using the supplied mounting template
as a guide (if mounting on drywall/masonry,
install wall anchors rst). Do not insert the
screws all the way in but leave a small gap
between the screw head and wall so that
you can hang the Indoor Alarm Receiver on
the screws using the keyhole slots on the
back of the Indoor Alarm Receiver.
Alert Sensor
• The Alert Sensor, under typical conditions, is designed to detect people and vehicles
moving within the detection area of up to 13ft/4m. The LED indicator blinks once
when movement is detected.
• For optimal coverage, mount the Alert Sensor approximately 6.5ft/2m above the
ground, pointing slightly downwards at an angle where the most likely approach
path of visitors and vehicles is across the front of the Alert Sensor. Motion
detection is less effective when movement is directly towards or away from the
front of the Alert Sensor.
• Avoid placing the Alert Sensor in a position where it will face direct sunlight, objects
that produce heat such as replaces, heaters and air conditioners, or reective
surfaces such as windows which can cause sunlight to be reected onto the PIR
detector.
• Avoid mounting on surfaces that can move or vibrate.
More sensitive Less sensitive
13 ft / 4m
(Actual detection range is subject to
environmental conditions)

9
EN
MOUNTING THE DEVICES
To mount the Alert Sensor:
• Wall mounting using screws
Doorbell
The Doorbell can be mounted to the surface using the supplied mounting plate and
adhesive tape. Avoid mounting on metal surfaces as this can reduce the operating range.
1. Make sure the surface is dry, smooth and free of dust and other substances that
could affect adhesion. Clean the surface with an alcohol/
cleaning wipe, and let dry.
2. Peel off the adhesive tape liner on the back of the Doorbell
mounting plate, and then press the mounting plate rmly to the
surface for 60 seconds to ensure solid adhesion.
3. Slide the Doorbell down onto the mounting plate until it clicks
into place.
A
B
1. Attach the mounting bracket to the
wall using two screws (supplied).
You may need to use wall anchors
depending on the surface.
2. Slide the Alert Sensor down onto the
mounting bracket until it is secured
in place. Then, adjust the angle of the
Alert Sensor accordingly to achieve
the best detection results.
1. Do not use on rough surfaces. Works best on at, smooth
surfaces. Clean the surface with an alcohol/cleaning wipe,
and let dry.
2. Attach the circular wall plate Ato the mounting
bracket using two small screws (supplied).
3. Afx the double-sided tape Bto the back of the
wall plate A, then press the mounting bracket
rmly to the wall for 60 seconds to ensure solid
adhesion.
4. Slide the Alert Sensor down onto the
mounting bracket until it is secured
in place. Then, adjust the angle of the
Alert Sensor accordingly to achieve
the best detection results.
• Wall mounting using adhesive tape

10
EN
TROUBLESHOOTING
I keep getting false alerts from the Alert Sensor
• The Alert Sensor uses passive infrared to detect changes in temperature so check
that there are no shifting heat sources in the view of the sensor. This includes the
obvious things, such as moving pets or people, but also things such as a moving
shadow on a hot day or bushes which can absorb a lot of heat and trigger motion
alerts as they sway in the wind. Sometimes reected infrared heat from the sun is
also enough to trigger the Alert Sensor.
• Avoid placing the Alert Sensor in a location where sunlight will shine directly on the
PIR detector. Direct sunlight may cause false alarms and may also cause damage
to the PIR detector.
• If you’re using the system in an environment with a high level of radio ‘noise’ (that
is, somewhere with multiple wireless devices in use) then these interfering signals
might be interpreted by the system as alarm signals. This should, however, be a
very rare occurrence.
• Batteries could be running low which can cause the Alert Sensor to behave
erratically. The Alert Sensor's LED indicator will start blinking continuously when the
batteries need replacing. See the "Battery Installation — Alert Sensor" section for
instructions.
I am getting too many alerts from the Alert Sensor
• Try repositioning the Alert Sensor so it doesn’t face the street or bush. By changing
the Alert Sensor's angle even slightly, it can help reduce unwanted alerts triggered
by passing objects.
• Ensure the Alert Sensor is mounted in areas that are not exposed to unfavorable
environmental conditions including, but not limited to, excessive vibration and wind.
• Put the Indoor Alarm Receiver on silent temporarily if you're working (for example,
gardening) in the vicinity of the Alert Sensor and don't want it to continually go off.
See the "Muting the Indoor Alarm Receiver" section for instructions.
The Indoor Alarm Receiver is sounding for no reason
• There might be interference from other similar alarm receiver devices operating
nearby. Try resetting the Indoor Alarm Receiver - see the "Resetting the Indoor
Alarm Receiver" section for instructions.
• Batteries could be running low which can cause the Indoor Alarm Receiver to
behave erratically. Try installing fresh batteries, see the "Battery Installation —
Indoor Alarm Receiver" section for instructions.
The Indoor Alarm Receiver doesn't sound when the Alert Sensor is triggered
• Ensure the Sensor/Doorbell channel associated with the Alert Sensor has not been
muted. See the "Muting the Indoor Alarm Receiver" section for details.
