Symmons Duro SLS3622PP Manual

Model Numbers Feature Highlights
☐SLS3622PP Single Handle Lavatory Faucet with
Push Pop Drain Assembly • Single hole mount configuration
• Single lever cartridge with ceramic control components
• 25 inch braided hose water supply connections
• 4-1/2" height
• Standard 1.0 gpm (3.8 L/min) flow rate
• Faucet shall be metal construction, plated in standard
polished chrome finish
Compliance
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
Warranty
Duro®
SLS3622PP
Single Handle Lavatory Faucet
Operation & Maintenance Manual
c
- ASME A112.18.1/CSA B125.1
- NSF/ANSI/CAN 61: Q<1, NSF/ANSI 372
- WaterSense 1.0 gpm (3.8 L/min) only Certied by
IAPMO R&T
WARNING: This product can expose you to
chemicals including lead, which is known to the
state of California to cause cancer, birth defects, or
other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
Dimensions
Measurements
B
Hole Size:
Min. Ø 1-1/4", 32 mm
Max. Ø 1-1/2", 38 mm
I
Deck Thickness Ref.
Min. 7/8", 22 mm
Max. 2-1/2", 64 mm
K3/8" compression fitting
BBII
KK
Note: Dimensions subject to change without notice.

Parts Breakdown
2
Replacement Parts
Item Description Part Number
A
B
C
Handle
Set Screw
Plug Button
LN-01416*
D Cartridge with Limit Stop RL-070
F
Aerator 1.5
Aerator 1.0
Aerator 0.5
RL-059-1.5
RL-059-1.0
RL-059-0.5
KPush Pop Drain Assem-
bly RL324*
G, H
I
Y
Mounting Gaskets (2x)
Fasteners
Supply Hose
RL-011
Z Deck Plate RL-082*
Required for Installation
Adjustable wrench
Allen wrench:
2.5mm
Plumber tape
Plumber putty
A
D
E
G
H
I
F
Y
B
C
X
K
Z
* Note: When ordering replacement parts for faucets
with an optional decorative nish, append appropriate
three letter nish sufx code to part numbers marked
with an asterisk (*).

3
1
2
G
X
H
I
11
2
Hotter (+)
Colder (–)
1
3
22
Installation
2) Slide mounting gasket (G) and
metal washer (H) on to fasteners (X).
Secure with mounting nuts (I).
3) Install teon tape to inlets of
shut-off valves. Attach supply lines
to shut-off valves and hand tighten.
Using a wrench, nish with one-half
turn. DO NOT overtighten.
1) Insert faucet body (E) through deck
plate (Z) and deck surface.
Note: Hoses removed for clarity.
4) Apply plumber putty to underside
of ange (L).
5) Push Pop Install: Insert drain body
(L) into drain opening. From below,
Tighten locking nut (O) with gasket
(M) and washer (N) to ange.
Tighten tail nut (Y) with washer (X)
to secure tail pipe (Q).
DO NOT overtighten.
E
Z
6) The handle limit stop can
be set to limit handle turn to
the hot position. To measure
temperature, turn handle to
full hot position and lift handle
half way open. If water is too
hot or cold, loosen set screw
and remove handle. Remove
limit stop ring and rotate
counter clockwise to lower
temperature or clockwise to raise
temperature.
1
2
3
Plumbers Putty L
Q
X
N
Y
O
M
L

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2023 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3721 REV 0 ■ 021623
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then
quickly rinse with water.
Faucet is leaking from handle
or faucet body.
Cartridge o-rings are worn or foreign
matter (dirt, chips) is lodged between
cartridge and o-rings.
Remove cartridge and inspect for
foreign matter. Replace cartridge
if necessary.
Faucet no longer maintains desired
temperature.
Hard water deposits inside of
cartridge is preventing accurate mix
of hot and cold water.
Soak cartridge in white vinegar for
1 hour to breakdown hard water
deposits, then rinse with water.
Replace cartridge if necessary.
