Tally T9312 User manual

®
T9312
Maintenance manual Laser printer

Exploded Views and Parts List
5-2
5-1 Main Exploded View
0
1
2
3
16
4
5
6
7
8
21
20
9
10
11
12
12-1
13
14
17
18
15
19

Location No. Description Code Q'ty
1 ELA HOU-HOUSING T9312C 398 471 1
2 UNIT-LSU 398 425 1
3 ELA UNIT-MOTOR 398 464 1
4 ELA UNIT-DEVE ASSY 1
5 MEC RACK-MPF 1
6 MEA RACK-FEEDER CST 398 473 1
7 CBF-HARNESS-MOTOR 1
8 MEA UNIT-FEEDER 398 427 1
9 PMO-CAP SENSOR 1
10 SHIELD-PCU 1
11 PCT-INSULATOR PCU 1
12 PBA MAIN-ENGINE_V2 398 432 1
12-1 FUSE-CARTRIDGE 396 403 1
13 ELA UNIT-FRAME BASE 398 433 1
14 PBA MAIN CTRL-LOW 398 470 1
15 ELA UNIT-FUSER 398 472 1
16 CBF HARNESS-LSU 1
17 PBA PWR-HVPS_HAWK 398 495 1
18 MEA RACK-HOU EXIT 398 496 1
19 PMO-DUCT FAN 1
20 PMO-DUMMY FACE MAIN(L) 1
21 PMO-DUMMY FACE MAIN(R) 1
5-3
Exploded Views and Parts List
Main Parts List

Exploded Views and Parts List
5-4
5-2 Cover Exploded View
0
1
2
16 4
4
5
6
7
8
9
10
11
12
13 15
14
17
3
3-1
3-3
3-2
3-4
3-5
3-6

5-5
Exploded Views and Parts List
Cover Parts List
Location No. Description Code Q'ty
0 ELA HOU-COVER MAIN (T9312) 398 471 1
1 PMO-COVER OPEN 1
2 PMO-COVER MAIN 1
3 MEA UNIT-MP TRAY 398 438 1
3-1 PMO-COVER-MP 1
3-2 PMO-TRAY LINK MP 2
3-3 PMO-TRAY EXTENSION MP 1
3-4 PMO-TRAY HOLDER MP 1
3-5 IPR-GUIDE LATCH 1
3-6 PMO-SIDE GUIDE MP 1
4 STOPPER HINGE OPEN 2
5 PMO-LENS LED 1
6 PMO-KEY BUTTON 1
7 PMO-KEY SAVE MODE 1
8 PBA LED PANEL-II 399 454 1
9 PMO-GUIDE EXIT 1
10 PMO-BUSHING F/DOWN 1
11 PMO-COVER REAR 398 439 1
12 PMO-STACKER REAR 398 440 1
13 IPR-SPRING LOCKER REAR 398 441 2
14 PMO-COVER CONTROLLER 398 442 1
15 PMO-CAP REAR 398 443 1
16 PMO-SUPPONT MAIN 1
17 PMO-STOPPER_EXIT,P 1
S1 SCREW-TAPTITE 7

Exploded Views and Parts List
5-6
5-3 Frame Exploded View
29-4
29-1
29-2
29-3
25-1
25-2
24-2
24-1
25
24
27
26
42
9
41
43
23
22
29
4
22-1
22-3
22-2
22-4
14 13
7
21
16
17
5
16-1
16-2
16-3
16-4
3
46
46
45
45
47
47
48
8
19-2
18-218-1
19-1
11
0
15
15-1
15-2
15-3
2
44
39
19
1
38
20
36
30
31
30-3
30-2
30-1
31-2
31-3
31-1
32
32-1
32-2
34
33
35
28
28-1
28-2
18

5-7
Exploded Views and Parts List
Frame Parts List
Location No. Description Code Q'ty
0 ELA UNIT-FRAME BASE 1
1 FAN-DC-HAWK 398 444 1
2 PMO-GUIDE RIB 1
3 CBF HARNESS-INLET ASS'Y 1
4 PMO-HOLDER WIRE 1
5 PMO-KEY DEVE HAWK 1
6 CBF HARNESS-ENGINE_CONTROL 1
7 CBF-HARNESS_FUSER 1
8 PBA SUB-EXIT SENSOR 398 445 1
9 CBF-HARNESS-THERMISTOR JOINT 1
11 PBA SUB-FUSER_SW 398 446 1
13 PMO-FRAME COVER 1
14 IPR-TERMINAL FU 2
15 ELA-UNIT-HOLDER TR L 398 447 1
15-1 PMO-BUSHING TR 1
15-2 SPRING TR L HAWK 1
15-3 PMO-TRANSFER HOLDER L 1
16 ELA-UNIT-HOLDER TR R 398 448 1
16-1 PMO-BUSHING TR 1
16-2 SPRING TR R HAWK 1
16-3 PMO-TRANSFER HOLDER R 1
16-4 IPR-PLATE TR 1
17 GEAR-TR 29 398 449 1
18 ELA UNIT-GUIDE DEVE L 398 450 1
18-1 PMO-GUIDE DEVE L 1
18-2 SPRING GUIDE DEVE 1
19 ELA UNIT-GUIDE DEVE R 398 451 1
19-1 PMO-GUIDE DEVE R 1
19-2 SPRING GUIDE DEVE 1
20 ELA HOU-VARISTOR 1

Exploded Views and Parts List
5-8
Frame Parts Lists
Location No. Description Code Q'ty
21 IPR-TERMINAL TR HAWK 1
22 ELA UNIT-SENSOR DEVE 1
22-1 PBA -SUB SWITCH 398 452 1
22-2 PMO-HOLDER ACTUATOR 1
22-3 PMO-ACTUATOR DEVE 1
23 GROUND FU 1
24 ELA UNIT-TERMINAL TR L 399 455 3
24-1 ICT-SHAFT HV LARGE 3
24-2 SPRING-HV LARGE 3
25 ELA UNIT-TERMINAL TR S 399 456 1
25-1 ICT-SHAFT HV LARGE 1
25-2 SPRING-HV SMALL 1
26 GROUND-HVPS 1
27 IPR-REMOVE KEY XEROX 1
28 ELA UNIT-ACTUATOR FEED 399 457 1
28-1 PMO-ACTUATOR FEED 2
28-2 PMO-HOLDER ACTUATOR 2
29 ELA UNIT-GUIDE TRANSFER 1
29-1 PMO-HADER PLATE SAW 1
29-2 IPR-PLATE SAW 1
29-3 IPR-GUIDE TRANSFER HAWK 1
29-4 PMO-GUIDE RIB TR 1
30 ELA UNIT-GUIDE FEED 398 453 1
30-1 PMO-GUIDE OPTIC 1
30-2 GUIDE FEED 1
30-3 PMO-HOLDER G/PAPER 1
31 ELA UNIT-PTL 398 454 1
31-1 GUIDE PLATE FEED 1
31-2 PMO-HOLDER PTL 1
31-3 PBA SUB-PTL 1

5-9
Exploded Views and Parts List
Location No. Description Code Q'ty
32 ELA UNIT-EMPTY ACT 399 458 1
32-1 PMO-ACTUATOR EMPTY HAWK 1
32-2 SPRING EMPTY 1
33 PMO-HINGE GUIDE FEED 1
34 IPR-GND ICU 2 1
35 PMO-CAP SENSOR 399 459 1
36 GND MP 1
38 GROUND MOTOR 1
39 IPR-GUIDE_DUST 1
41 IPR-OPC HAWK 1
42 CAP CONNECTOR L 1
43 CAP CONNECTOR U 1
44 MEC-ROLLER TRANSFER 398 455 1
45 GEAR-IDLE27 398 467 2
46 RING-CS 2
47 WASHER-PLAIN 2
48 IPR-WASHER SPRING SU 1
Frame Parts Lists

Exploded Views and Parts List
5-10
5-4 Exit Exploded View
1
6
7
8
5
13
12
10
9
9
11
2
3
3
4
0

5-11
Exploded Views and Parts List
Exit Parts List
Location No. Description Code Q'ty
0 MEA RACK-HOU EXIT 398 436 1
1 PMO-FRAME REAR 1
2 GEAR-IDLE 15 1
3 RING-CS 2
4 GEAR-IDLE 25 1
5 SPRING-F/DOWN 4
6 PMO-HOLDER EXIT_F/DOWN 4
7 PMO-ROLLER-EXIT, MAIN 4
8 PMO-ROLLER-EXIT, FR 4
9 MEC-BEARING EXIT 2
10 RMO-RUBBER EXIT 4
11 PMO-SHAFT EXIT_F/DOWN 1
12 GEAR-EXIT 1
13 RMP-RUBBER EXIT_F/UP 4

Exploded Views and Parts List
5-12
5-5 Fuser Exploded View
0
2
11
1
3
4
7
6
10
11
12
13
9
14
15
16
17
18
19
20
26
25
2237 23
21
24
33
34
29
30 31
27
28
32
35
36
5
8

Location No. Description Code Q'ty
0 ELA UNIT FUSER (220V) 398 472 1
1 SCREW TAPTITE M3 x 8, BH+ 6
2 SCREW TAPTITE M3 x 10, FH+ 1
3 SCREW MACHINE M3 x 6 2
4 THERMISTOR-FUSER 398 457 1
5 NPR-ELECTRODE FU R 1
6 NPR-ELECTRODE FU M 1
7 NPR-ELECTRODE FU L 1
8 THERMOSTAT 398 458 1
9 PMO-BRKT GEAR FUSER 1
10 GEAR-IDLE 25 399 460 1
11 GEAR-IDLE 15 399 461 1
12 RING-CS 2
13 PMO-COVER FUSER 1
14 PMO-ROLLER EXIT_F/UP 3
15 IPR-EXIT_F/UP (SPRING) 3
16 SPRING-CLAW 398 462 4
17 PMO-GUIDE CLAW 4
18 LAMP-HALOGEN 398 459 1
19 NEX-ROLLER-HEAT 1
20 MEC-ROLLER PRESSURE 1
21 ICT-FRAME FUSER 1
22 GEAR FUSER, Z32 1
23 PMO-BUSHING HR-L 1
24 PMO-BUSHING HR-R 1
25 PMO-SPRING-BEARING PR 2
26 PMO-BUSHING PR 2
27 PMO-GUIDE REAR 398 460 1
28 PMO-SHAFT EXIT_F/UP 1
29 PMO-BUSHING TX 3
30 GEAR-EXIT 399 463 1
31 PMO-RUBBER,EXIT 3
32 PMO-RUBBER EXIT_F/UP 1
33 PMO-ACTUATOR EXIT 1
34 SPRING-ACTUATOR 1
35 PMO-HOLDER_BRUSH 1
36 MEC-BRUSH ANTISTATIC 1
37 PMO-HOLDER SHAFT 1
38 SEREW TAPTITE M3X6,BH+ 4
5-13
Exploded Views and Parts List
Fuser Parts List

Exploded Views and Parts List
5-14
5-6 Rack-MPF Exploded View
0
3
21
4

5-15
Exploded Views and Parts List
Rack-MPF Parts List
Location No. Description Code Q'ty
0 ELA HOU-MPF 1
1 PMO-FRAME_MP 1
2 PMO-PLATE MANUAL 1
3 BRACKET-MANUAL 1
4 SCREW TAPTITE 1

Exploded Views and Parts List
5-16
5-7 Drive Exploded View
0
2
16 911 10
15
1313
7
68
12
5
16
14
4

5-17
Exploded Views and Parts List
Drive Parts List
Location No. Description Code Q'ty
0 ELA UNIT-MOTOR 398 464 1
1 MOTOR-STEP 398 465 1
2 IPR-BRKT GEAR 1
3 IPR-BRKT MOTOR 1
4 GEAR-RDCN 145-70 1
5 GEAR-RDCN 90-24 1
6 GEAR-OPC DRV 135 1
7 GEAR-OPC DRIVE2 1
8 GEAR-FEED DRV 1
9 GEAR-CLUTCH 56 1
10 GEAR-FUSER DRV23 1
11 PMO-CLUTCH LEVER 2
12 SPRING-CLUTCH 2
13 WASHER-PLAIN 1
14 MPR-POLYWASHER 8 1
15 WASHER-PLAIN 1
16 SCREW-MACHINE 5

Exploded Views and Parts List
5-18
5-8 Pick-Up Exploded View
0
82
2
5
5
11
7
9
24 25
6
26
12 18
13
3
19
1
10
15
15
5
2
22
4
20
17
16
10
21 52
14 23

5-19
Exploded Views and Parts List
Pick-Up Parts List
Location No. Description Code Q'ty
0 MEA UNIT-FEEDER 398 427 1
1 SCREW-TAPTITE 1
2 WASHER-PLAIN 4
3 SPRING-FEED(1) 399 468 1
4 SPRING-FEED(2) 399 469 1
5 BEARING-PICK UP 4
6 GEAR-P/UP DRIVE 1
7 GEAR-FEED 1
8 GEAR-PICK UP(12) 1
9 IPR-SHAFT FEED 1
10 IPR-SHAFT FEED IDLER 3
11 IPR-SHAFT PICK UP 1
12 GROUND_FEED 1
13 IPR-GUIDE_FEED 1
14 PMO-HOUSING P/UP 1
15 PMO-ROLLER FEED L 2
16 PMO-ROLLER FEED S 1
17 PMO-SUB HOLDER FEED 1
18 PMO-FRAME_FEED 1
19 PMO-HOLDER FEED(1) 1
20 PMO-HOLDER FEED(2) 1
21 PMO-IDLE PICK_UP 1
22 PMO-ROLL_FEED, DRV 12 1
23 RMO-RUBBER PICK_UP 396 364 1
24 RMO-LEVER PICK_UP 1
25 SPRING PICK UP(12) 1
26 RING-CS 1

Exploded Views and Parts List
5-20
5-9 Cassette Exploded View (270)
0
17
16
15
14
13
12
11
1
2
3
5
4
6
10
9
8
7
18
