Taurus Dual Pro User manual

SESS7133.01.01
TF- Taurus Dual Pro Assisted Chin & Dip
max. 180 kg
L 116 | W 154 | H 220
~ 180 Min.
CM
236 kg
Assembly and Operating Instructions
SKU: SESS7133

2
Chin & Dip

3
Content
1 GENERAL INFORMATION 7
1.1 Technical Data 7
1.2 Personal Safety 8
1.3 Set-Up Place 9
2 ASSEMBLY 10
2.1 General Instructions 10
2.2 Scope of Delivery 10
2.3 Assembly 14
3 STORAGE AND TRANSPORT 30
3.1 General Instructions 30
4 TROUBLESHOOTING, CARE AND MAINTENANCE 31
4.1 General Instructions 31
4.2 Faults and Fault Diagnosis 31
4.3 Maintenance and Inspection Calendar 32
5 DISPOSAL 32
6 RECOMMENDED ACCESSORIES 33
7 ORDERING SPARE PARTS 34
7.1 Serial Number and Model Name 34
7.2 Parts List 35
7.3 Exploded Drawing 39
8 WARRANTY 41
9 CONTACT 43

4
Chin & Dip

5
Dear customer,
Thank you for choosing a high-quality equipment of the brand Taurus®. Taurus® oers sports and
tness equipment for the sophisticated home sport and the equipment of tness studios and
business customers.WithTaurus® tness equipment, the focus is on what sport is all about: maximum
performance! Therefore, the equipment is developed in close consultation with athletes and sports
scientists. Because athletes know best what makes perfect tness equipment.
Further information can be found at www.sport-tiedje.com.
Legal Notice
Sport-Tiedje GmbH
Europe’s No. 1 for home tness
International Headquarters
Flensburger Straße 55
24837 Schleswig
Germany
Management:
Christian Grau
Sebastian Campmann
Dr. Bernhard Schenkel
No. HRB 1000 SL
Local Court Flensburg
European VAT Number: DE813211547
Disclaimer
©2011 Taurus® is a registered brand of the company SportTiedje GmbH. All rights
reserved. Any use of this trademark without the explicit written permission of Sport-
Tiedje is prohibited.
Product and manual are subject to change. Technical data can be changed without
advance notice.
Intended Use
The equipment may only be used for its intended purpose.
This tness equipment is suitable for home use, semi-professional use and commercial or
professional use. The semi-professional sector includes, for example, institutional facilities such
as hospitals, schools, hotels and associations. Professional use refers to commercial use, e.g. in a
tness studio.

6
Chin & Dip
ABOUT THIS MANUAL
Please carefully read the entire manual before installation and rst use. The manual will help you to
quickly set up the system and explains how to safely use it. Make sure that all persons exercising with
the equipment (especially children and persons with physical, sensory, mental or motor disabilities)
are informed about this manual and its contents in advance. In case of doubt, responsible persons
must supervise the use of the equipment.
Due to ongoing changes and software optimisations, the manual may have to be updated. If
you notice any discrepancies during assembly or use, please refer to the manual uploaded to the
webshop. The latest manual is always available there.
This equipment has been manufactured according to the latest safety knowledge. As far as possible,
potential safety hazards which could cause injury have been eliminated. Make sure to carefully follow
the instructions and that all parts are securely in place. If required, read through the
instructions again to correct any mistakes.
Please pay close attention to the safety and maintenance instructions given here.
The contract partner cannot be held liable for damage to health, accidents or
damage to the equipment when it is not used in accordance with these instructions.
The following safety instructions may appear in this manual:
࣑ATTENTION
This notice indicates potentially hazardous situations which, if not avoided, may result in
property damage.
⚠CAUTION
This notice indicates potentially hazardous situations which, if not avoided, may result in slight
or minor injuries!
⚠WARNING
This notice indicates potentially hazardous situations which, if not avoided, may result in death
or serious injuries!
⚠DANGER
This notice indicates potentially hazardous situations which, if not avoided, will result in death
or serious injuries!
LNOTICE
This notice indicates further useful information.
Retain these instructions in a safe place for future reference, maintenance or when ordering
replacement parts.

7
1 GENERAL INFORMATION
1.1 Technical Data
Weight and Dimensions
Packaging dimensions (L x W x H) and article weight (gross, incl. packaging):
Box 1: 163 cm x 91 cm x 19.5 cm 25 kg / 55 lbs
Box 2: 152 cm x 89 cm x 28.5 cm 35 kg / 77 lbs
Box 3: 170 cm x 103.5 cm x 36 cm 125 kg / 275 lbs
Box 4: 45 cm x 9 cm x 30 cm 6.5 kg / 14 lbs
Box 5 (weight plates): 30.5 cm x 11.5 cm x 12.5 cm 70 kg/154 lbs in total
Set-up dimensions (L x W x H): 116.4 cm x 154.3 cm x 220 cm
Article weight (net, without packaging): 236.2 kg / 520 lbs
Maximum user weight: 180 kg / 396 lbs
Weight Stack
Weight stack: 1
Weight plates: 7 x 10 lbs, 5 x 20 lbs + 1 top plate
Cable material: Steel
Cover material: Nylon
Cable length: 4625 mm
Transmission ratio: 1:1

8
Chin & Dip
1.2 Personal Safety
⚠DANGER
+ Before you start using the equipment, you should consult your physician that this type of
exercise is suitable for you from a health perspective. Particularly aected are persons who:
have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,
smoke, have high cholesterol values, are overweight and/or have not exercised regularly in
the past year. If you are under medical treatment that aects your heart rate, medical advice
is absolutely essential.
+ Note that excessive training can seriously endanger your health. Please also note that
heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,
nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising
immediately and seek advice from your doctor if necessary.
⚠WARNING
+ This equipment may not be used by children under the age of 14.
+ Children should not be allowed unsupervised access to the equipment.
+ Persons with disabilities must have a medical license and must be under strict observation
when using the equipment.
+ The equipment is strictly for use by one person at a time.
+ If your equipment provides a safety key, the clip of the safety key must be attached to your
clothing before starting your training. In the event of a fall, the EMERGENCY STOP of the
equipment can be initiated.
+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well
clear of moving parts.
+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing
sports shoes, make sure they have suitable soles, preferably made of rubber or other non-
slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise
barefoot.
⚠CAUTION
+ If your equipment needs to be connected to the power supply with a mains cable, make
sure that the cable is not a potential tripping hazard.
+ Make sure that nobody is within the range of motion of the equipment during training so as
not to endanger you or other persons.
࣑ATTENTION
+ Do not insert any objects of any kind into the openings of the device.

9
1.3 Set-Up Place
⚠WARNING
+ Do not place the equipment in main corridors or escape routes.
⚠CAUTION
+ Choose a location in which to place the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The training room should be well ventilated during training and not be exposed to any
draughts.
+ Choose the place in which to set up the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The set-up and mounting surface of the equipment should be at, loadable and solid.
࣑ATTENTION
+ The device may only be used in one building, in suciently tempered and dry rooms
(ambient temperatures between 10°C and 35°C). The equipment should not be used
outdoors or in rooms with high humidity (over 70%) like swimming pools.
+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight
unevenness.

10
Chin & Dip
2 ASSEMBLY
2.1 General Instructions
⚠DANGER
+ Do not leave any tools, packaging materials such as foils or small parts lying around,
as otherwise there is a danger of suocation for children. Keep children away from the
equipment during assembly.
⚠WARNING
+ Pay attention to the instructions attached to the equipment in order to reduce the risk of
injuries.
⚠CAUTION
+ Ensure to have sucient room for movement in each direction during assembly.
+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek
the help of a third technically skilled person.
࣑ATTENTION
+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or
packaging board.
LNOTICE
+ In order to make the assembly as simple as possible, some screws and nuts to be used can
already be pre-assembled.
+ Ideally, assemble the equipment at its later set-up place.
2.2 Scope of Delivery
The scope of delivery consist of the following parts. At the beginning, check whether all parts
and tools belonging to the device are included in the scope of delivery and whether damage has
occurred. In the event of complaints, the contractual partner must be contacted directly.
⚠CAUTION
If parts of the scope of delivery are missing or damaged, the assembly must not be carried out.

Number Name Quantity
Frame
Pulley set (Φ114)
Pulley set (Φ89)
Pulley bae
001
013
012
004
005 + 008 +
006
Left shield + rear
middle trim +
right shield
005 + 009 +
006
Left shield + front
middle trim +
right shield
Side shield
007
Tray
010
Connecting strip
011
10lb weight stack plate
59 & 60
20lb weight stack plate
61
1
1
1
1
1
1
2
11 + 1
2
2
4
11

10lb top weight
48 1
Cable set
46 1
High foot frame
33-2 1
Short foot frame
43 1
Left parallel bars frame
36-2 1
Right parallel bars
frame
37-2 1
Horizontal bar bracket
42 1
Left bracket
40 1
Right bracket
41 1
Joint frame
35-2 1
Leg pad
105 1
12
Chin & Dip

Glide frame
38 1
Main frame
34-2 1
Sliding guide rod
54 2
13

No. Name Specication Qty.
001 Frame 1
027 Hex socket countersunk head screw M12*30 4
032 Flat washer Φ24*Φ13*2.5 4
033-1 Spring washer M12 4
33-2 High foot frame 1
35-2 Joint foot frame 1
43 Short foot frame 1
86 Hex socket head cap screw M10*25 8
98 Spring washer M10 8
101 Plain washer Φ20*Φ10.5*2 8
14
Chin & Dip
2.3 Assembly
Before assembly, take a close look at the individual assembly steps shown and carry out the assembly
in the order given.
LNOTICE
First loosely screw all parts together and check that they t properly. Tighten the screws using
the tool only when you are instructed to do so.
Step 1: Assembly of the Frame and Foot Frames
1. Fix the joint frame (35-2) to the frame (001) with four screws (027), four spring washers (033-1)
and four at washers (032).
2. Fix the high foot frame (33-2) and the short foot frame (43) to the joint frame (001) with a total
of eight screws (86), eight spring washers (98) and eight plain washers (101).

15

No. Name Specication Qty.
012 Pulley set φ89*25.8 1
013 Pulley set φ114*32 1
34-2 Main frame 1
35-2 Joint frame 1
46 Cable 1
86 Hex socket head cap screw M10*25 4
98 Spring washer M10 4
101 Plain washer Φ20*Φ10.5*2 4
034-1
034-1
16
Chin & Dip
Step 2: Assembly of the Main Frame, Pulleys and Cable Routing
LNOTICE
+ The majority of the pulleys are pre-assembled when delivered.These pulleys (65) need to be
disassembled in order to perform the cable routing.
+ The two pulleys (012 and 013) for the frame are not pre-assembled.
1. Pass the cable (46) over the pulley (013) [point A] and x the pulley (013) to the upper side of the
frame (001) and pulley bae (004) with the pre-assembled screw (026), two at washers (031)
and one nut (034-1).
2. Pass the cable (46) down and under the pulley (012) [point B] and x the pulley (012) to the
lower side of the frame (001) with the pre-assembled screw (025), two at washers (031) and
one nut (034-1).
3. Disassemble the pulley (65) [point C], pass the cable (46) below the pulley (65) and reassemble
the pulley (65).
࣑CAUTION
Make sure to pass the cable through the opening of the main frame before mounting it.
4. Now x the main frame (34-2) to the joint frame (35-2) with four screws (86), four spring washers
(98) and four plain washers (101).
5. Disassemble the pulley (65) [point D], pass the cable (46) over the pulley (65) and reassemble
the pulley (65).
LNOTICE
The cable ends will be attached later during assembly.

65
65
013
012
46
A
B
C
D
17

No. Name Specication Qty.
34-2 Main frame 1
36-2 Left parallel bars frame 1
37-2 Right parallel bars frame 1
40 Left bracket 1
41 Right bracket 1
86 Hex socket head cap screw M10*25 8
89 Hex socket head cap screw M10*85 1
90 Hex socket head cap screw M12*30 4
98 Spring washer M10 8
99 Spring washer M12 4
101 Plain washer Φ20*Φ10.5*2 10
102 Plain washer Φ24*Φ13*2.5 4
103 Nylon insert lock nut M10 1
18
Chin & Dip
Step 3: Assembly of the Parallel Bars and Brackets
1. Fix the left and right parallel bars frame (36-2 & 37-2) to the main frame (34-2) with a total of four
screws (90), four spring washers (99) and four plain washers (102) as well as one screw (89), two
plain washer (101) and one lock nut (103).
2. Fix the left bracket (40) to the main frame (34-2) and the joint frame (35-2) with a total of four
screws (86), four spring washers (98) and four plain washers (101).
3. Repeat step 2 with the right bracket (41).

19

No. Name Specication Qty.
34-2 Main frame 1
42 Horizontal bar bracket 1
90 Hex socket head cap screw M12*30 1
91 Hex socket head cap screw M12*90 2
99 Spring washer M12 1
102 Plain washer Φ24*Φ13*2.5 5
104 Nylon insert lock nut M12 2
20
Chin & Dip
Step 4: Assembly of the Horizontal Bar Bracket
Fix the horizontal bar bracket (42) to the main frame (34-2) with two screws (91), four plain washers
(102) and two lock nuts (104) as well as one screw (90), one spring washer (99) and one plain washer
(102).
