TE Connectivity CERTI-CRIMP II Reference guide

409--10055
Customer Manual
CERTI- CRIMP* II Battery Powered
1of 8
LOC B
E2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company
All Rights Reserved
*Trademark
TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Other logos, product and/or Company names may be trademarks of their respective owners.
TOOLING ASSISTANCE CENTER
1--800 -- 722--1111
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at www.te.com
13 JUL 11 Rev F
Crimp Tool Kit 1213805- [ ]
READ THIS FIRST ! 2.........................
SAFETY PRECAUTIONS
1. INTRODUCTION 4...................................................
2. RECEVING/INSPECTION 5.............................................
3. INSTALLATION AND REMOVAL OF CRIMPING HEADS 5......................
3.1. Installation of Crimping Heads 5......................................
3.2. Removal of Crimping Heads 6.......................................
4. OPERATION 6......................................................
4.1. Battery Installation and Removal 6....................................
4.2. Crimping 6.....................................................
5. PREVENTIVE MAINTENANCE 7........................................
5.1. Daily Maintenance 7..............................................
5.2. Yearly Maintenance 7..............................................
6. SPARE PARTS 7....................................................
7. TROUBLESHOOTING 7...............................................
8. REPLACEMENT AND REPAIR 7.........................................
9. RoHS INFORMATION 8...............................................
10. REVISION SUMMARY 8..............................................
-- -- -- --
Safeguards are designed into this application equipment to protect operators and
maintenance personnel from most hazards during equipment operation. However,
certain safety precautions must be taken by the operator and repair personnel to
avoid personal injury, as well as damage to the equipment. For best results,
application equipment must be operated in a dry, dust--free environment. Do not
operate equipment in a gaseous or hazardous environment.
Carefully observe the following safety precautions before and during operation of
the equipment:
DALWAYS wear appropriate ear protection.
DALWAYS wear appropriate eye protection.
DALWAYS wear approved eye protection when operating powered equipment.
DALWAYS keep guard(s) in place during normal operation.
DNEVER wear loose clothing or jewelry that may catch in moving parts of the
application equipment.
DNEVER insert hands into installed application equipment.
DNEVER alter, modify, or misuse the application equipment.
ORIGINAL INSTRUCTIONS

409- 10055
Rev F2of 8
SAFETY PRECAUTIONS - - IMPORTANT SAFETY INFORMATION
DANGER
DANGER
DANGER
DANGER
DANGER
DANGER This unit should only be used by trained
competent personnel.
Read and understand the entire manual
before using the equipment.
Always wear approved eye protection
when using the equipment.
NOTE: Keep all decals clean and legible, and replace
when necessary.
CAUTION
CAUTION
CAUTION
CAUTION

409- 10055
Rev F 3of 8
TOOLING ASSISTANCE CENTER
CALL TOLL FREE 1 - 800 - 722 - 1111 (CONTINENTAL UNITED STATES AND PUERTO RICO ONLY)
The Tooling Assistance Center offers a means of providing technical assistance when required.
In addition, Field Service Specialists are available to provide assistance in the adjustment or repair of the
application equipment when problems arise which your maintenance personnel are unable to correct.
INFORMATION REQUIRED WHEN CONTACTING THE TOOLING ASSISTANCE CENTER
When calling the Tooling Assistance Center regarding service to equipment, it is suggested that a person
familiar with the device be present with a copy of the manual (and drawings) to receive instructions. Many
difficulties can be avoided in this manner.
When calling the Tooling Assistance Center, be ready with the following information:
01. Customer name
02. Customer address
03. Person to contact (name, title, telephone number, and extension)
04. Person calling
05. Equipment number (and serial number if applicable)
06. Product part number (and serial number if applicable)
07. Urgency of request
08. Nature of problem
09. Description of inoperative component(s)
10. Additional information/comments that may be helpful

409- 10055
Rev F4of 8
Typical Crimping
Head (Ref)
SDE Adapter
Trigger
Battery
Cartridge
1725839--1
Battery Lock
Battery Powered
Crimp Tool
Release Switch
(1213805--1, --2,
and --5 Only)
Quick--Release
Pin 217873--2
Quick--Release
Pins 217873--1
(Recommended
Spare)
(Recommended
Spare)
CRIMPING TOOL (with Battery Installed)
Length 305 mm [12 In.]
Width 60 mm [2 3/8 In.]
Depth 80 mm [3 1/8 In.]
Mass/Weight (w/Battery) 1.3kg[2.9lb.]
Sound Level 75 dBA at 1 Meter
Vibration <2.5m/s2
Hydraulic Oil Shell Tellus T 15
CRIMPING CAPACITIES
Maximum Crimping Force 15.6 kN [1.75 Tons]
Average Crimping Time 2 Seconds
Average Crimps Per Charge Approximately 150
BATTERY
Charging Voltage 9.6 V
Charging Time 40 Min
Figure 1
1. INTRODUCTION
The CERTI--CRIMP II Battery Powered Crimp Tool Kit 1213805--[ ] is comprised of the battery crimp tool (with
the SDE Hand Tool Adapter installed), as well as two rechargeable battery cartridges (1725839--1) to power
the tool. See Figure 1. Each kit has a battery charger. The battery charger part number, its voltage, and the
kit’s region of use are listed in the table below. A battery tool may have a release switch to retract the ram as
listed in the table below. The CERTI--CRIMP II Battery Powered Crimp Tool Kit is designed to adapt the
crimping head from any CERTI--CRIMP II straight action hand tool (SAHT) for use with the battery powered

409- 10055
Rev F 5of 8
crimp tool. For crimp head information (including wire preparation, crimping procedures, maintenance and
inspection procedures, as well as repair and replacement procedures) refer to the appropriate instruction sheet
for the associated hand tool and crimping head.
BATTERY TOOL KIT REGION OF USE BATTERY CHARGER BATTERY CHARGER
VOLTAGE
RAM RETRACT
SWITCH
1213805--1 North America 1725840--1 110 V Yes
1213805--2 Europe 1725840--2 220 V Yes
1213805--3 North America 1725840--1 110 V No
1213805--4 Europe 1725840--2 220 V No
1213805--5 United Kingdom 1725840--3 220 V Yes
2. RECEIVING/INSPECTION
The CERTI--CRIMP II Battery Powered Crimp Tool Kit 1213805--[ ] is thoroughly inspected during and after
assembly. Prior to packaging and shipping a final series of tests and inspections is made to ensure proper
function of the tool. The following inspection should be performed as a safeguard against potential problems
generated in transit.
1. In a well--lighted area, carefully uncrate the tool kit and inspect each component as it is removed from
the crate.
2. Thoroughly inspect each component for evidence of damage that may have occurred in transit. If any
of the components are damaged, file a claim against the carrier and notify TE Connectivity immediately.
3. Keep this manual and all drawings and product samples with the tool for the benefit of operation and
maintenance personnel.
The crimp tool should be inspected at regularly scheduled intervals, depending on care, degree of operator
skill, the type and size of product being crimped, and environmental conditions. At a minimum, the tool should
be inspected after every 40 hours of use.
3. INSTALLATION/REMOVAL OF CRIMPING HEADS
Do not operate the tool without the SDE hand tool adapter Installed. Damage to the ram or seals can result.
Do not operate the tool without a hand tool crimp head installed. Damage to the adapter can result.
CERTI--CRIMP II Battery Powered Crimp Tool Kit 1213805--[ ] comes with SDE hand tool adapter already
installed on the battery powered hand tool. The only installation required is the installation of the crimping
heads.
To avoid personal injury, be sure to exercise extreme caution when handling the crimp tool. Remove the battery before
installing or removing crimping heads.
3.1. Installation of Crimping Heads
As supplied, the adapter has three quick--release pins installed (Figure 1). The two outer pins will be used to
secure the two outer housing tabs of the crimp head (exposed portion of the crimp head) to the adapter. The
center pin will be used to secure the movable die of the crimp head to the ram of the adapter.
These pins must be removed prior to installing the crimping head.
1. Remove the battery from the tool.
2. Remove the quick--release pins, described above.
3. Insert the exposed portion of the crimp head into the adapter cavity. See Figure 1.
CAUTION
!
CAUTION
!
DANGER

409- 10055
Rev F6of 8
4. Insert the two outer quick--release pins through the holes in the adapter, and through the holes in the
two outer tabs of the crimping head.
The quick--release pins will “snap” into position when they are properly inserted.
5. Insert the center quick--release pin into the adapter and through the holes in the ram and the
moveable die of the crimp head.
The quick--release pin will “snap” into position when it is properly inserted.
3.2. Removal of Crimping Heads
To avoid personal injury, remove the battery before removing the crimping heads.
To remove the crimping head, it will be necessary to remove the quick--release pins and the crimp head from
the battery powered crimp tool.
4. OPERATION
4.1. Battery Installation and Removal (Refer to Figure 1)
The Batteries Directive 2006/66/EC introduces new requirements from September 2008 on removability of batteries
from waste equipment in EU Member States. To comply with this Directive, this device is designed to allow the
rechargeable battery pack to be easily removed by the end--user when it needs to be replaced.
To install the battery, slide the battery into the bottom of the crimp tool until it can go no further. There will be an
audible “click” of the battery lock to indicate that the battery has been properly installed.
To remove the battery, disengage the battery lock by applying pressure on the lock toward the bottom of the
tool and slide the battery away from the tool.
Always dispose of the old battery pack in an environmentally--responsible way, in accordance with local waste
regulations. Where possible, please recycle the battery cartridge. Contact your local authority for details of battery
recycling locations in your area.
4.2. Crimping
The following procedure provides only general information concerning crimping. Refer to the instructions
packaged with the crimping head for detailed information, including wire stripping dimensions and instructions
for positioning terminals and splices in the crimpers.
To operate the CERTI--CRIMP II Battery Powered Crimp Tool 1213805--[ ]:
To avoid personal injury, keep fingers clear of the crimping area.
1. Insert the contact into the dies.
2. Depress the trigger to advance the moving jaw in order to hold the contact in place. Do NOT deform
the insulation barrel or wire barrel.
3. Place a pre--stripped wire in the barrel of the contact.
4. Depress and hold the trigger to complete the crimp. The crimp tool returns automatically to the first
position of its cycle when the crimp is complete.
NOTE
i
NOTE
i
DANGER
NOTE
i
DANGER
DANGER

409- 10055
Rev F 7of 8
If it is necessary to retract the ram before a crimping cycle is completed, push the release switch. Pushing the release
switch will result in the complete retraction of the ram. Only kits 1213805--1, --2, and --5 have a ratchet release switch.
This tool is not designed for continuous operation. After 100 cycles, allow the crimp tool to cool for 15 minutes.
5. PREVENTIVE MAINTENANCE
5.1. Daily Maintenance
Perform the following maintenance on a daily basis:
1. Inspect the dies for wear or damage such as cracks, gouges, or chips.
2. Inspect the tool for damage or leaks. If damage is detected, return the tool to TE for repair
3. Clean the tool, removing accumulations of dirt and grease on the adapter, particularly in areas where
heads are installed and contacts are crimped. Wipe the entire tool frequently with a clean, lint--free cloth.
5.2. Yearly Maintenance
Once a year, or every 10,000 cycles (whichever comes first) The CERTI--CRIMP II Battery Powered Crimp
Tool should be returned to TE for inspection.
6. SPARE PARTS
SBattery: 1725839--1
SCharger: 1725840--1 (120 V, US), 1725840--2 (220 V, EU), 1725840--3 (220 V, UK)
7. TROUBLESHOOTING (Figure 2)
Prior to beginning troubleshooting procedures, be sure the battery is operational.
1. Be sure that the battery is charged. Recheck the battery after several minutes to ensure that the
battery is holding its charge.
2. Use a nonflammable contact cleaner or pencil eraser to clean the the electrical contacts on the
battery and crimp tool.
3. Reinstall the battery and check the crimp tool again.
PROBLEM PROBABLE CAUSE REMEDY
Dirt, contaminants, etc, in ram area of tool Return tool to TE.
Tool is inoperative. Crimp tool battery contacts damaged Reform the contacts.
p
Tool components are worn or damaged. Return tool to TE.
Oil level is low. Return tool to TE.
Dies stop during operation. Air in the hydraulic system.
Pull the trigger and hold the retract button
simultaneously. Hold for approximately 10
seconds.
Crimp tool loses oil. Damaged internal seal. Return tool to TE.
Figure 2
8. REPLACEMENT AND REPAIR
To avoid personal injury, ALWAYS remove the battery cartridge from the tool BEFORE performing any maintenance on
the tool.
Replacement parts are identified in Figure 1. The recommended spares should be stocked for immediate
replacement. Order replacement parts (or return parts) through your TE Representative, or call
1--800--526--5142, or send a facsimile of your purchase order to 717--986--7605. Or write to:
NOTE
i
CAUTION
!
DANGER

409- 10055
Rev F8of 8
CUSTOMER SERVICE (38--35)
TYCO ELECTRONICS CORPORATION
P.O. BOX 3608
HARRISBURG, PA 17105--3608
For replacement parts for crimping heads, refer to the instruction sheets packaged with the specific heads.
9. RoHS INFORMATION
Information on the presence and location of any substances subject to RoHS (Restriction on Hazardous
Substances) can be found at the following website:
http://www.te.com/customersupport/rohssupportcenter/
Click on “Find Compliance Status” and enter equipment part number.
10. REVISION SUMMARY
SUpdated document to corporate requirements
SAdded new text to Section 4, OPERATION
NOTE
i

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
TE Connectivity:
1213805-4
