Teknion interpret WWSPK Operating and maintenance instructions

Part and Product Identification
Section:
Description: Page No:
Date:
Rev. No: 4
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
Jun 2017 1 of 10
INT_007b
interpret Installation Guides
B1 - Height Adj. Threaded Rod
(E01-0795) x 2
For Customer Support please contact
[email protected]
B2 - 1/4 - 20 UNC. Nut Hex Keps
Zinc (E03-0059) x 2
B3 - 516 -18 x 3.50 Socket Head
Cap Screw (E01-0781) x 8
C1 - Center Rail Height Adj.
Bracket (A15-9865) x 2 or 4
C2 - Height Adj. Clamp
(A16-1284) x 2 or 4
A - Height Adjustable Stacker
Puck (WWSPK) x 2
B4 - 5/16 - 18 Hex Nut, 1/2 A/F
.265 Thk (E03-0755) x 8
C3 - 1/4 - 20 UNC x .500 Mach. Scr,
Cross Truss (E01-0110) x 6
C4 - #10 x 0.875" LG. Screw Quad
Pan Washer (E07-0077) x 4
C5 - 5/16 - 18 x 3/8 Botton Head
Hex Socket Cap(E01-0798) x 2
C6 - 5/16 - 18 Hex Jam Nut, .190
Thk (E03-0551) x 2
WWSCT
WWSPK
48" - 54" length = 2 Height Adjustable Cantilevers
60" - 96" length = 4 Height Adjustable Cantilevers
48" - 54" length = 2 Height Adjustable Cantilevers
60" - 96" length = 4 Height Adjustable Cantilevers
WWSBK
Height Adjustable Pucks (WWSPK), Height Adjustable Cantilever (WWSCT)
Bolt Kit (WWSBK)
A
C1
Worksurface (WWWRW)
C2

Section:
Description: Page No:
Date:
CLAMPS AND PUCKS INSTALLATION DETAIL
MIDDLE CONNECTION DETAIL
INT_007b
2 of 10
Jun 2017
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 1: Attach Clamp Brackets and Height Adjustable Pucks LOOSELY to the Beam. Make
sure positioning of Clamps is applicable to the connection specified.
A
A
NOTE: Don't tighten screws!
Beams and Clamps are part of Single
Sided Frame.
Refer to Installation Guide INT_009
for Complete Frame or INT_010 for
Beginning, Middle and Finish
Frame.
End Connection shown.
Beam
Clamp Bracket
B3
NOTE: Up to 3 Stacker Blocks can be placed on Beam.
NOTE: Up to 3 Pucks
can be used.
A
Clamp Bracket
A
Don't tighten screws!

Section:
Description: Page No:
Date:
ATTACH BEAM TO GABLES FASTEN
INT_007b
3 of 10
Jun 2017
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 3: Secure in place.
STEP 2: Assemble gables as per Guide # INT_009 for Complete Frame or INT_010 for
Beginning, Middle and Finish Frames. Connect them with the Beam.
B4
B3
Legs and Cross Beans are part of
Single Sided Frame.
Refer to Installation Guide
INT_009.

Section:
Description: Page No:
Date:
ATTACH CORNER BRACKETS ASSEMBLE AND ATTACH ACCESSORY RAIL
INT_007b
4 of 10
Jun 2017
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 5: Assemble and drop Center Rail on the top of Corner Brackets. Refer to Guide
INT_009 for Complete Frame or INT_010 for Beginning, Middle and Finish frame.
STEP 4: Remove screws from Gables on both sides as shown. Use them to attach Corner
Brackets. For more details refer to INT_009 for Complete Frame and INT_010 for Beginning,
Middle and Finish Frame.
NOTE: Refer to INT_009
for more information.
NOTE: Refer to INT_009
or INT_010 for more information.
Middle Rail with Ends and nuts
installed.

Section:
Description: Page No:
Date:
ATTACH HEIGHT ADJUSTABLE CLAMP ALIGNMENT
INT_007b
5 of 10
Jun 2017
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 6: Slide set of Nuts to align with holes on Height Adjustable Clamp and fasten loosely
with screws provided. Repeat with second Bracket.
STEP 7: Align Modesty Panel with Corner Bracket and position Clamps on the Rail to line
up with pilot holes on Modesty. Place Modesty Panel aside and tighten screws from the back
of the frame.
C2
C5
Underside back view. Underside back view
Modesty Panel
Modesty Panel
pilot holes.
Underside front view

Section:
Description: Page No:
Date:
ATTACH MODESTY PANEL
Jun 2017 6 of 10
INT_007b
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 8: Fasten Modesty Panel to Frame and Cantilever Brackets.
C3
48" - 54" length = 2 Height Adjustable Cantilevers
60" - 96" length = 4 Height Adjustable Cantilevers
NOTE: Please refer to INT_005b
for Modesty Installation

Section:
Description: Page No:
Date:
BRACKET TO CLAMP
Jun 2017 7 of 10
INT_007b
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 9: Align holes from bracket to holes from clamp and fasten using screws provided.
NOTE: Use indicated pilot holes to secure Bracket to Clamp according to Illustration shown on right.
C5
3 Stacker Blocks
2 Stacker Blocks
0 Stacker Blocks
Cantilever
1 Stacker Blocks
Cantilever
Cantilever
Cantilever
C1C2

Section:
Description: Page No:
Date:
INSERT THREADED ROD
Jun 2017 8 of 10
INT_007b
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 10: Align pilot holes from Worksurface and Insert threaded rod through clamp and fasten. Fasten Nut. Cut excess Threaded Rod at location indicated on illustration.
B1
B2

3 5/8"
2 5/8"
1 5/8"
Section:
Description: Page No:
Date:
THREADED ROD
Jun 2017 9 of 10
INT_007b
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 11: Cut excess Threaded Rod at location indicated on illustration.
NOTE: To prevent Threaded Rod penetrating
top of Worksurface, follow dimensions given
Cut Cut
Cut

Section:
Description: Page No:
Date:
FASTEN WORKSURFACE
Jun 2017 10 of 10
INT_007b
HEIGHT ADJUSTABLE CANTILEVER, PUCKS AND BOLT KIT - SINGLE SIDED FRAME
FRAMES, SUPPORTS AND WORKSURFACES
interpret Installation Guides
STEP 12: Fasten brackets to other side of Clamp using screws provided.
Worksurface
C4
