Telstra A60 User manual

Telstra A60
Telephone User Guide
If you have any
problems with your
phone, refer to the Help
section of this User
Guide or call TecHelp
on 1300 369 193.


In this guide
Introduction 3
TelstraA60partschecklist 4
TelstraA60ataglance 5
SettinguptheTelstraA60 6
Safety instructions 7
UsingyourTelstraA60 8
Time, date & display contrast settings 8
Making a call 8
Receiving a call 8
To alternate between handset and handsfree operation 9
Ring volume 9
Adjusting the handsfree speaker volume 9
Adjusting the handset volume 9
Using last number redial and the redial list 9
To store a number in the Phonebook from the redial list 10
Speed dial memory 10
To make a call using speed dial 10
Phonebook 11
To review, edit and delete Phonebook entries 1
To make a call from the Phonebook 1
Low battery warning 1
To replace the batteries 1
Telstranetworkservices 13
Using Calling Number Display 13
Total calls indicator 13
Missed calls indicator 13
Viewing received calls 13
Storing numbers from the received calls list 14
Deleting numbers from the received calls list 14
MessageBank ® and Telstra Home Messages 101® 14
Flashing Message Indicator 15
Using Call Waiting 15
Help 16
Customerservice&Productwarranty 17
Thingsyouneedtoknow 17

Introduction
to your Telstra A60 Corded Telephone
Keyfeatures
CallingNumberDisplay1
Calling Number Display* allows you to see the number of the person calling
before you answer. If the caller’s number and name is stored in your Phonebook,
the callers name will also be displayed.
NOTE: You will need to subscribe to Calling Number Display to receive the
telephone number of your callers.
Speeddialmemorykeys
For quick dialling, your Telstra A60 is equipped with 10 speed dial memory keys
(0-9)
Handsfreeoperation
The handsfree feature allows you to make or receive calls without having to hold
the handset.
Name&numberPhonebook
For easy dialling, you can store the name and number of 69 of your most
frequently used numbers.
See page 17 for important information
IMPORTANT
This User Guide provides you with all the information you need to get
the most from your phone.
Before you make your first call you will need to set up your phone.
Follow the simple instructions in ‘Setting up the Telstra A60’, on the next
few pages.
Needhelp?
If you have any problems setting up or using your Telstra A60 please
contact the TecHelp line on 1300 369 193. Alternatively, you may find
the answer in ‘Help’ at the back of this guide.
3

4
Telstra A60 parts checklist
Your Telstra A60 has been designed for ease of use and made to the high
standards set by Telstra.
Please read the instructions carefully and keep this User Guide for future
reference.
If anything is missing, please contact TecHelp on 1300 369 193 immediately.
Telephone base unit and handset with coil cord (shown assembled)
Telephone line cord
Telephone adaptor plug
4 x AAA alkaline batteries

5
Telstra A60 at a glance
Keyfeatures
1.Delete button to exit
a setting or delete an
entry
2.OK/tick button is used
to confirm an action
and open the redial list
3.Mute button to mute
the microphone during
a call
4.Volume buttons to
control the speaker and
handset volume
5.Handsfree button to
make and receive calls
handsfree
6.Up/Down buttons to
view the calls list and
scroll through lists.
7.Recall button is used for
some Telstra Network
Features,and also to
set time, date & display
contrast.
8.Phonebook button for
dialling frequently used
numbers
9.Store button to store
numbers for speed
dialling
10.Redial/Pause button to
redial the last number
dialled or insert a
pause
11.CallWaiting button
allows you to access
another call whilst
you are on the phone,
by the press of a
button.
12.MessageBank
button used to dial
‘15101’ to access
Telstra Messagebank
or Telstra home
Messages 101. (See
page 14).
13.Callindicator flashes
when calls have been
missed. (See page 15).
14.IncomingCall
indicator flashes
when receiving an
incoming call
N
Displayinformation
15.Dateandtime
16.Messageindicator (see page 15)
17.TotalnumberofCNDrecords
18.Numbershowingunchecked
incomingcalls
19.Batterylowindicator

6
Setting up the Telstra A60
Planthelocation
Situate your A60 close enough to the phone socket so that the cable will reach.
Batteryinstallation
For the display and handsfree features to operate you must install the 4 AAA
batteries supplied. You may also connect a mains power adaptor (not supplied)
which replaces the need for batteries. This mains power adaptor is also
necessary for the operation of Telstra Flashing Message Indicator (see page 15).
To purchase the optional power adaptor call TecHelp on 1300 369 193.
1. Remove battery cover from the bottom of the phone.
. Insert the four AAA size 1.5 volt alkaline batteries supplied.
3. Replace the battery cover.
FollowthesestepstosetupyourTelstraA60.
Connectingthelinecord
Insert one end of the telephone line cord into the socket at the rear of the phone
marked ‘Line’.
>YaKVVZRYXO]YMUO^
2KXN]O^MY\N

7
Insert the other end of the line cord into the telephone line wall socket using the
adaptor supplied if necessary.
Safetyinstructions
• There is a slight chance that your A60 could be damaged by an electrical
storm. We recommend that you unplug your A60 from the mains and
telephone sockets during storms.
• Do not use your A60 in damp, humid conditions such as bathrooms.
• Do not expose the equipment to fire or water.
>YaKVVZRYXO]YMUO^
2KXN]O^
MY\N
9Z^SYXKVZRYXOKNKZ^Y\ZV_Q

8
Using your Telstra A60
Time,date&displaycontrastsettings
1. Press and hold the button and the display will show SET TIME
. Using the and arrow keys set the right entry.
3. Press the button, and repeat the above step for the Minute, Day, Month and
Year.
4. When the date and time is set correctly press the button to exit, or press
the button to set the contrast.
The display will now show SET CONTRAST. You can now change the contrast
between HI and LO by pressing the and arrow keys. When you have
set the desired contrast level, press the button to exit.
Makingacall
1. Lift the handset or press the button. Listen for a dial tone then enter the
number you wish to call. The number will be dialled. After a few seconds the
display will clear and the call timer will begin.
. To end the call, simply hang up or press the button.
Receivingacall
To receive a call either pick up the handset or press the button.
To end the call, simply replace the handset. If you have made the call
using speakerphone, press the button and the call will end.

9
Toalternatebetweenhandsetandhandsfreeoperation
While using the handset, you can switch to handsfree by pressing the button
and replacing the handset.
While using handsfree you can use the handset by simply lifting the handset.
Ringvolume
The ring volume is set by the switch on the bottom of the unit. The available
options are High , Low and Off .
Adjustingthehandsfreespeakervolume
During a handsfree call you can adjust the speaker volume by pressing the
or buttons.
The display will show SPEAKER VOLUME and a number from 1 to 4.
1 is the maximum setting, 4 is the lowest.
Adjustingthehandsetvolume
During a call using the handset, you can adjust the handset volume by pressing
the buttons. The display will show HANDSET VOLUME and a number
from 1 to 4. 1 is the maximum setting, 4 is the minimum.
Usinglastnumberredialandtherediallist
You can call the last number you dialled with the press of a single key.
1. Pick up the handset or press
. Press the button, the last number will be dialled.
Alternately, your Telstra A60 shows the last 10 numbers dialled in the redial list.
To dial a number from the redial list;
1. Press the button
. Select the desired number using the and arrow keys
3. Pick up the handset or press and the number will be dialled”

10
TostoreanumberinthePhonebookfromtherediallist
1. Locate the number from the redial list.
. Press and hold the button until a flashing cursor appears on the display
3. You may now enter the desired name or reference for that number.
4. Press the button once to store the entry. Press to exit.
Speeddialmemory
The Telstra A60 is equipped with 10 speed dial memory keys (0-9). Follow the
instructions below to store a number into the speed dial bank.
1. Press and hold the button until the display shows - - >
. You can now enter the desired telephone number. There is a limit of 18 digits
and If you use a Pause in your number this is counted as one digit.
If your phone is connected to a PABX, you may need to insert a PAUSE
after the PABX access code. To do this, press the button.
3. Press the button once again, and ‘- - >’ will appear on the display.
4. Press a numbered key from 0-9 to select a speed dial location until the display
shows SAVE OK. Press the button twice to save and return to standby mode.
5. To delete a speed dial entry, a new number needs to be entered in each
location to cover the old one.
Tomakeacallusingspeeddial
Press and hold the desired numbered button from 0-9 until the display shows
the stored number. Lift the handset or press the button. The number will be
dialled.
