Teltonika ModemUSB TMU-10 Series User manual

TELTONIKA ModemUSB (TMU-10x)
User’s Manual v .1.1.19
All manuals and user guides at all-guides.com
all-guides.com

ModemUSB User’ Manual v .1.1.19
2
Table of contents
Attention!.......................................................................................................................................................3
Legal Notice ..................................................................................................................................................3
Introduction ..................................................................................................................................................4
1. package contents.......................................................................................................................................5
2. Technical specifications...........................................................................................................................6
2.1. ata transferring...............................................................................................................................6
2.2. Mechanical specifications ................................................................................................................6
2.3. Electrical and operating specifications ..........................................................................................7
2.4. Indication...........................................................................................................................................8
3. Modem setup ............................................................................................................................................9
3.1. Connecting to PC .............................................................................................................................9
3.2. Installation of “Modem Control Tool”.........................................................................................9
3.3. Setting up an Internet connection............................................................................................... 13
3.4. Sending Short Text Messages (SMS) .......................................................................................... 16
3.5. Changing of security settings ....................................................................................................... 18
3.6. Settings of program language....................................................................................................... 20
3.7. Choice of GSM operators ............................................................................................................ 20
3.8. Other functions of program......................................................................................................... 21
4. Acronyms ............................................................................................................................................... 22
5. Technical support.................................................................................................................................. 23
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
3
ATTENTION!
All wireless devices for data transferring may be susceptible to
interference, which could affect performance.
Only qualified personnel may install or repair this product.
Your device is not water-resistant. Keep it dry.
LEGAL NOTICE
Copyright © 2006 TELTONIKA Ltd.
All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of TELTONIKA Ltd is prohibited.
Other product and company names mentioned herein may be trademarks or trade names of their
respective owners.
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
4
INTRODUCTION
This document will provide you with the instructions how to install and use “ModemUSB” and
its software.
“ModemUSB” is a device designed for data transmission via GSM Network. The design of this
modem enables the connection to your PC through USB interface. Once the modem is connected to
the PC, you can get access to the Internet via one of the data transmission type the GSM are
supported. “ModemUSB” supports the following data-bearers: E GE, GPRS, CS , CSF, HSCS ,
and SMS.
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
5
1. PACKAGE CONTENTS
“ModemUSB” is supplied to clients in carton with all contents, which are needed for connection to
PC and normal work.
1) Carton;
2) “ModemUSB” modem;
3) “USB A  mini USB B” connecting cable;
4) C with User’s Guide and drivers;
5) External GSM antenna (just upon special orders).
Notice: the producer does not provide a SIM card among other items of a package, which is
necessary for connection to GSM Network! You can obtain a SIM card from your oca GSM service
provider!
If any of the components is missing please contact your local distributor.
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
6
. TECHNICAL SPECIFICATIONS
.1. Data transferring
“ModemUSB” supports all bearers of GSM Network. Which data-bearer is used depends
on GSM operator and data transfer capacity in the chosen GSM Network.
• E GE class 6 (class B);
• GPRS class 10 (class B);
• HSCS ;
• CS ;
• CSF;
• SMS textual messages.
. . Mechanical specifications
“ModemUSB” housing is made of plastic. One part of the housing is covered by rubber.
The external dimensions and measures of the unit are shown in picture 1.
Picture 1. An external look and measures of the device
All manuals and user guides at all-guides.com
all-guides.com

ModemUSB User’ Manual v .1.1.19
7
.3. Electrical and operating specifications
Modem is supplied from +5V USB interface. The device does not need any external
power supply at all! The PC to which is the “ModemUSB” modem connected must have a USB
interface, corresponding to USB 1.1 or USB 2.0 standards.
Notice: The USB connection must support high power mode, which a ows the device to use a
currency up to 500 mA from the connection.
Electrical parameters of the device are shown in the Table 1.
Table 1. Electrical parameters of the device
Parameter Min Typical
Max Meas. Units
Power Supply Voltage +4.5 +5V +5.5V V
Average Power
consumption - 360 500 mA
Operating conditions and other parameters are shown in Table 2.
Table 2. Operating conditions and the like.
Parameter Min.
Typical Max Meas. Units
Weight 90 ± 10 g
Recommended
operating temperature +15 +35 ºC
Marginal operating
temperature -25 +55 ºC
Storage temperature -40 +85 ºC
Notice: if the settings outreach the characteristics given above the device can be damaged!
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
8
.4. Indication
“ModemUSB” has 2 LE s for indication. They are located at the top part of the device.
ue to these indicating LE s we can determine in which mode is the device operating, are
there any shortcuts in its functionality or not. The indication status of the modem is given in
the Table 3.
Table 3. escription of modem status.
“Power” is on Power supply is connected
“Status” is green and blinking Modem is powering up
“Status” is green The device is ready to use
“Status” is yellow and blinking No SIM card inside, no PIN code entered or any
possibility to connect to the GSM Network
“Status” is yellow The device has successfully connected to the
Network for data transfer
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
9
3. MODEM SETUP
3.1. Connecting to PC
1) Insert the SIM card into modem. Follow the instructions on the device sticker.
Make sure, the SIM card is pushed inside till it fixes;
2) Plug the cable to the USB connection of PC.
Notice: When the driver insta ation is performed for the first time, the modem shou d be unp ugged from the PC.
3. . Installation of “Modem Control Tool”
1) Open the „ModemUSB“ pack and take
only the C and Plug the C into the PC
C rive;
2) Wait till the system displays the screen
“Select Setup Language” choose your
language and press
„Ok“ button. Following
TELTONIKA Home screen will appear;
3) The installation program should start automatically there to start installation progress click
Install button, please. If it is not the case, so find a catalogue “Software” in the C and start
“setup.exe” file. The first
“Modem Setup” dialog box will be opened;
Installation processing
button
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
10
4) Press “Next” button in the opened box. A
second
“Modem Control tool Setup” dialog
box will appear;
5) You can select a preferable driver
installation way in the dialog box. When
“Complete” installation is chosen, a
standard driver will be installed. When
“Custom” installation is chosen, you can
install separate driver components and show
the driver installation folder. It is
recommended to select a
“Complete”
installation;
6) Press “Install” in the opened dialog;
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
11
7) Should a dialog box appear, stating that there
has been performed any “Windows Logo”
testing to the driver, select
“Continue
Anyway”
. Upon this selection copy of
appropriate files will begin;
8) You must plug your “ModemUSB”
modem Now!
After you do that, wait till
system detect your new device and go to the
next steps;
Note: Do not press
“Next” sti .
8.1) Windows XP OS will automatically detect
a new device and ask to install driver. In the
opened
„Found New Hardware Wizard“
window, mark off 


„No, not this time“
and press button
„Next“ ;
All manuals and user guides at all-guides.com
all-guides.com

ModemUSB User’ Manual v .1.1.19
12
8.2) In this opened „Found New Hardware
Wizard“
window mark off 

 „Install
software automatically (recommended)“
and press button
„Next“ ;
8.3) The „
Hardware Installation” dialog box
will appear. Press
“Continue Anyway” button
in the dialog box again. And continue
installation.
Using
“Windows 000” OS, all “Modem
Control Tool”
installation steps are identical,
with exception of appearance of
“Digital
Signature Not Found”
dialog box, where
“Yes” button should be clicked;
8.4) Press “Finish” in the last opened
„Found New Hardware Wizard“ window;
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
13
9) Press „Next“ now;
10) Enter dial-up connection parameters:
“ISP
Name”
, “Phone number” , “APN” , “User
Name”
and “Password” .
“ISP Name” and “Phone number” by
default is Internet and *99# and press
“Next”
in the opened dialog;
Note: APN, user name and password ask your
GSM operator!
11) Press “Finish” in the opened dialog box
“Modem Control tool Setup” . The
installation is done!
3.3. Setting up an Internet connection
In this chapter we will provide you with general information and procedures necessary for
setting up an Internet connection in your PC. When using
“Modem Control Tool” , the Internet
connection settings are determined automatically.
Before you begin make sure that:
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
14
• You have a GSM SIM card with activated data transfer service;
• “ModemUSB”
is ready to work – SIM card is pushed in, the device is correctly connected
to the PC, the drivers are properly installed;
• TCP/IP protocol is installed on your PC;
Then you using “ModemUSB“ you can get access to the Internet via one of this data transmission
types:
• GPRS/E GE packet data transfer. In this case you have to know APN, User name and
Password”;
• HSCS /CS data transfer. You have to know a phone number of a dial-up server.
If GPRS/E GE data transfer is used, you have to set up an APN, if needed, user name and
password.
1) Start “Modem Control Tool” . If needed the PIN code, enter it;
2) Press
“Program Settings” button:
3) Select
“GPRS Settings” ;
4) Enter the APN;
5) Enter the ISP and Phone number [
*99# ], if they not entered automatically;
6) If needed, enter the User name and User password;
7) Press
“Update Data” .
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
15
Note: APN, user name and password ask your GSM operator!
Getting connected to the Internet:
1) The dial-up connections being set start
“Modem Control Tool” program. The program
can be started also from the PC desktop (or “Start → Programs → Modem Contro Too →
Modem Contro Too ”) while clicking on the shortcut. When the shortcut will be clicked,
“Modem Control Tool” dialog box will be opened. If PIN control code is set on your
SIM card, the program will ask you to enter PIN code;
2) The program should automatically detect a connected modem. If you start the program
before connect modem, you have to wait till modem will be ready to work. If the program
not detected your modem, press “Program Settings → Modem Settings → Autodetect Modem”;
3) To connect to the Internet, press
“Connect To Internet Using Modem” button:
4) The modem starts connecting to Internet after clicking on this button. Then the modem
connected to Internet, you will see message
“Connected To Internet Using Modem” .
5) Exit the program, press “Exit Program” button:
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
16
If you can not connect the Internet using Internet Explorer after using Modem fallow these
steps, press “Start → Settings → Contro Pane → Internet Options”. Select the box
“Connections”
in the appeared dialogue box
“Internet Properties” .
Select dial-up pictogram In the
“Dial-up and Virtual Private Network settings” square
and press
“Set Default” button, then chose “Always dial my default connection” and press
“Apply” and “OK” buttons. Now try to connect to Internet again.
3.4. Sending Short Text Messages (SMS)
1. Using “ModemUSB” it is possible to send and receive short text messages (SMS). Before
start using that “ModemUSB”
function it is obligatory to disconnect from the Internet.
This will be performed while clicking on
“Disconnect From Internet” button;
. Before sending SMS messages you have to check number of messages sending center.
Press
“Program Settings” and “SMS Settings” . In the window of “ SMS Settings”
should be entered number of messages sending center if it not entered, enter it. This
Number you can ask your GSM operators;
All manuals and user guides at all-guides.com
all-guides.com

ModemUSB User’ Manual v .1.1.19
17
3. Press
“Short Messages Service” button on “Modem Control Tool” window for
writing and reading of SMS messages:
4. In the window
“Create New SMS ” you can write your short SMS messages. In the
“Type Phone Number” square enter phone number with code of country you will send
without “+” symbol. Below in the
“Place Your Text Below” square write your short
SMS message. How many symbols left you can see in the right side above SMS text
square. Then your short SMS message is over press
“Send” . And wait for the message:
“Message Sent Successful” or “Message Was Not Sent” ;
5. All so you can read your incoming, sent and unsent short SMS messages. Press
“Short
Messages Service”
and “Unread” button. In the window will open, will be list of all
unread messages. Then you select one of the messages, on the right side of windows
appears the selected SMS message’s text. All readied short SMS messages goes to menu
“Read” . To delete selected message press “Delete SMS”, to delete more than one SMS
press and hold “Shift” button on the keyboard and select SMS you want to delete
. To
update messages windows press
“Update SMS” button.
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
18
3.5. Changing of security settings
For SIM security a unique PIN (Personal Identification Number) is used. Before starting using
GSM network services, it is necessary to enter a PIN code. “ModemUSB”
supports two main GSM
security modes:
“PIN Request Disable” , “PIN Request Enable” . When “PIN Request
Disable”
is chosen, PIN code has to be entered just once and this will not be required further on
while turning the device on. If the mode
“Enable” is chosen, the PIN code will be required each
time the modem is turned on.
“Modem Control Tool” program is used for changing security settings.
PIN control code switching off:
1) Start
“Modem Control Tool” ;
2) Select
“Program Settings” ;
3) Select
“Security Settings” ;
4) Select
“PIN Request Disable” ;
5) Press
“Update Date” ;
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
19
6) On the window will open enter PIN code and press “OK” .
PIN control code switching on:
1) Start
“Modem Control Tool” ;
2) Select
“Program Settings” ;
3) Select
“Security Settings” ;
4) Select
“PIN Request Enable” ;
5) Press
“Update Data”,
6) On the window will open enter PIN code and press
“OK” .
All manuals and user guides at all-guides.com

ModemUSB User’ Manual v .1.1.19
20
3.6. Settings of program language
On press
“Program Settings” and “Language” , you can change the program language:
Note: by defau t program anguage is Eng ish
3.7. Choice of GSM operators
Choose “Program Settings 

 GSM Oper. Selection”. The “GSM Operator Selection”
screen will appear
Then you will click “Get GSM Operators List” button the program will show all
available GSM operators. Click
“Select Available GSM Operator” button after you choose
your desirable operator and the desirable operator will be chosen.
All manuals and user guides at all-guides.com
