Tennsco ESP-1236 Instruction Manual

PK-2490920
ASSEMBLY INSTRUCTIONS & PARTS MANUAL
RETAIN INSTRUCTIONS FOR FUTURE REFERENCERETAIN INSTRUCTIONS FOR FUTURE REFERENCE
Open ESP Shelving
Models ESP-1236, ESP-1836, ESP-2436,
ESP-6-1236, ESP-6-1836, ESP-6-2436
Tennsco LLC., Dickson, TN 37056-1888 • [phone]
GENERAL SAFETY INFORMATIONGENERAL SAFETY INFORMATION
Some parts may have sharp edges. CARE must be taken when handling various pieces to avoid injury.
For safety, wear a pair of work gloves when assembling or performing any maintenance on the units.
LIMITED WARRANTYLIMITED WARRANTY
Tennsco warrants goods purchased hereunder to be free of defects in materials and workmanship for a period of one (1) year from the date of shipment, hereunder. This warranty shall not apply in
the event goods are damaged as a result of misuse, abuse, neglect, accident, improper application, modication or repair by persons not authorized by Seller, where goods are damaged during
shipment, or where the date stamps on the goods have been defaced, modied or removed. UNLESS CONSIDERED UNENFORCEABLE OR UNLAWFUL UNDER APPLICABLE LAW:
a. ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXCLUDED:
b. BUYERS REMEDY, IF ANY, FOR ANY DEFECTIVE GOODS SHALL BE LIMITED TO A REFUND BY SELLER OR REPLACEMENT OF THE GOODS AT SELLER’S OPTION, AND SHALL IN NO
EVENT INCLUDE DAMAGES OF ANY KIND, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
NO GOODS ACCEPTED FOR RETURN WITHOUT PRIOR APPROVAL. Seller shall have the right to inspect any goods claimed to be defective at Buyers place of business or require Buyer to return the
goods to Seller for inspection on Seller’s premises. Transportation charges covering returned goods will be borne by Seller only if such goods are proven to be defective, are covered by this warranty
and are returned within the warranty period stated above.
ESP-6-1236 ESP-2436
LOAD CAPACITIESLOAD CAPACITIES
PER SHELF LEVELPER SHELF LEVEL
250 lbs.

ASSEMBLY OF OPEN ESP SHELVING
Two people are recommended for assembly. Approximate assembly time: 10-15 minutes.
2. Lay the two corner posts (Ref. No. 1) parallel on the oor or
on saw horses with the short sides facing up.
1. The reference numbers used throughout this sheet refer
to the illustration on the back cover. This is to help you
to identify the various parts as they are mentioned.
3. Create an upright assembly by bolting a side sway plate (Ref.
No. 3) 10 holes down from the top of both corner posts,
connecting them together. Then bolt another side sway plate
ten holes up from the bottom on both corner posts.
5. Lean one upright assembly against a wall
or another stable surface and place a
shelf (Ref. No. 2) on the bottom clips
of the post.
4. Place the upright assembly to the side and repeat the rst two
steps on the remaining corner posts, creating a second upright
assembly. Place shelf clips (Ref. No. 7) in the top and bottom
holes of all four posts.

Bolt in the tenth hole
from the bottom.
Shelf Clip
Shelf Clip





6. Place the second upright assembly in
place with the bottom shelf and hook
the shelf in over the bottom clips.
7. Place the top shelf over the four clips at the top of the posts.
8. Bolt the rear sway braces (Ref. No. 4) in place. The top
brace should be in the 27th hole from the top of the
posts. Be sure they are
stretched to full extension;
otherwise the braces
will appear loose.
9. Position the remaining shelves where desired, making sure
each shelf is supported by four clips. Before loading the
shelves, make sure all
bolts and nuts are
securely tightened.
NOTE: If sway braces interfere with your desired
shelf placement, they may be moved one hole up
or down on the unit.





REPLACEMENT PARTSREPLACEMENT PARTS

Corner PostCorner Post
(Ref No. 1)(Ref No. 1)
NOTE: Additional hardware may be included for replacement purposes.NOTE: Additional hardware may be included for replacement purposes.
Tennsco makes every effort to ensure that all units ship complete with all parts and arrive undamaged.Tennsco makes every effort to ensure that all units ship complete with all parts and arrive undamaged.
However, should your unit contain missing or damaged parts, please contact your purchase location.However, should your unit contain missing or damaged parts, please contact your purchase location.



REF.REF.
NO.NO. ESP-1236 ESP-6-1236 ESP-1836 ESP-6-1836 ESP-2436 ESP-6-2436ESP-1236 ESP-6-1236 ESP-1836 ESP-6-1836 ESP-2436 ESP-6-2436
PART NO.PART NO. 36w x 12d36w x 12d 36w x 18d36w x 18d 36w x 24d36w x 24d
DESCRIPTIONDESCRIPTION
1
2
3
4
5
6
7
Corner Post
Shelves
Side Sway Braces
Back Braces (Pair)
1/4
”-20
5/8
” Bolts
1/4
”-20 Nuts
ESP Shelving Clips
SSP-75
ES-12
ES-18
ES-24
SSB-12
SSB-18
SSB-24
SBB-36
*
*
ESPCLIP
4
5
4
1
20
20
20
4
6
4
1
20
20
20
4
5
4
1
20
20
20
4
6
4
1
20
20
20
4
6
4
1
20
20
20
4
5
4
1
20
20
20
Back Braces (Pair)Back Braces (Pair)
(Ref No. 4)(Ref No. 4)
Side Sway BraceSide Sway Brace
(Ref No. 3)(Ref No. 3)
11//44”-20 Nuts”-20 Nuts
(Ref No. 6)(Ref No. 6)
11//44”-20”-20 55//88BoltsBolts
(Ref No. 5)(Ref No. 5)
ESP Shelving ClipESP Shelving Clip
(Ref No. 7)(Ref No. 7)
ShelfShelf
(Ref No. 2)(Ref No. 2)
49B249
