Texas Instruments AFE881H1 User manual

User’s Guide
AFE881H1 Evaluation Module
ABSTRACT
This user's guide describes the characteristics, operation, and recommended use cases of the AFE881H1EVM.
This document provides examples and instructions on how to use the AFE881H1EVM board and included
software. Throughout this document, the terms evaluation board, evaluation module, and EVM are synonymous
with the AFE881H1EVM. This document also includes a schematic, reference printed circuit board (PCB)
layouts, and a complete bill of materials (BOM).
Table of Contents
1 Overview..................................................................................................................................................................................3
1.1 Kit Contents........................................................................................................................................................................3
1.2 Related Documentation From Texas Instruments.............................................................................................................. 3
2 USB2ANY Interface Adapter.................................................................................................................................................. 4
2.1 Signal Definitions for J10................................................................................................................................................... 4
2.2 USB2ANY Theory of Operation......................................................................................................................................... 5
3 EVM Hardware Overview........................................................................................................................................................6
3.1 Electrostatic Discharge Caution......................................................................................................................................... 6
3.2 EVM Block Diagram........................................................................................................................................................... 6
3.3 EVM Jumper Summary...................................................................................................................................................... 7
3.4 Terminal and Pin Definitions...............................................................................................................................................8
3.5 Connecting the USB2ANY................................................................................................................................................. 9
3.6 Connecting the USB Cable to the USB2ANY Interface Adapter......................................................................................10
3.7 Optional EVM Operations................................................................................................................................................ 10
4 Software Overview................................................................................................................................................................11
4.1 Software Installation......................................................................................................................................................... 11
4.2 Launching the Software................................................................................................................................................... 12
4.3 Software Features............................................................................................................................................................13
www.ti.com Table of Contents
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 1
Copyright © 2021 Texas Instruments Incorporated

5 Schematics, PCB Layout, and Bill of Materials................................................................................................................. 16
5.1 Board Schematic..............................................................................................................................................................16
5.2 PCB Components Layout.................................................................................................................................................17
5.3 Bill of Materials.................................................................................................................................................................19
List of Figures
Figure 2-1. AFE881H1EVM Hardware Setup.............................................................................................................................. 4
Figure 2-2. USB2ANY Interface Adapter Block Diagram.............................................................................................................5
Figure 3-1. AFE881H1EVM Block Diagram.................................................................................................................................6
Figure 3-2. Default Header Settings for the AFE881H1EVM.......................................................................................................7
Figure 3-3. Terminal and Pin Locations for the AFE881H1EVM..................................................................................................9
Figure 3-4. USB2ANY Connection to the AFE881H1EVM.......................................................................................................... 9
Figure 3-5. Confirmation of USB2ANY Driver Installation......................................................................................................... 10
Figure 4-1. AFE881H1EVM Software Installation Prompts........................................................................................................11
Figure 4-2. Launching the AFE881H1EVM GUI........................................................................................................................ 12
Figure 4-3. AFE881H1EVM GUI at Launch...............................................................................................................................12
Figure 4-4. USB2ANY Digital Controller Connection Status......................................................................................................12
Figure 4-5. AFE881H1 Register Page....................................................................................................................................... 13
Figure 4-6. AFE881H1 High Level Tab...................................................................................................................................... 14
Figure 4-7. Launch Script Window.............................................................................................................................................14
Figure 4-8. Scripting Tool Recording a Macro........................................................................................................................... 15
Figure 4-9. Deselecting App Execution Aliases.........................................................................................................................15
Figure 5-1. AFE881H1EVM Schematic..................................................................................................................................... 16
Figure 5-2. AFE881H1EVM PCB Top Layer Layout.................................................................................................................. 17
Figure 5-3. AFE881H1EVM PCB Mid Layer 1 Layout............................................................................................................... 17
Figure 5-4. AFE881H1EVM PCB Mid Layer 2 Layout............................................................................................................... 18
Figure 5-5. AFE881H1EVM PCB Bottom Layer Layout............................................................................................................ 18
List of Tables
Table 1-1. AFE881H1EVM Kit Contents...................................................................................................................................... 3
Table 1-2. Related Documentation.............................................................................................................................................. 3
Table 2-1. USB2ANY Connector AFE881H1EVM (J10) Pinout...................................................................................................4
Table 3-1. AFE881H1EVM Jumper Summary............................................................................................................................. 7
Table 3-2. AFE881H1EVM Terminal and Pin Definitions............................................................................................................. 8
Table 5-1. Bill of Materials for the AFE881H1EVM.................................................................................................................... 19
Trademarks
LabVIEW™ is a trademark of National Instruments Corporation.
Python™ is a trademark of Python Software Foundation.
HART® is a registered trademark of FieldComm Group.
All trademarks are the property of their respective owners.
Trademarks www.ti.com
2AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

1 Overview
The AFE881H1 16-bit digital-to-analog converter (DAC) is a highly-integrated, high-accuracy, and extremely low-
power device with voltage-outputs designed for HART® enabled sensor transmitter applications. The AFE881H1
includes most of the components required to construct a transmitter for 2-wire (loop-powered), 4-mA to 20-
mA sensor transmitter applications. These components include a 16-bit highly accurate DAC, a HART FSK
modem, an internal 10-ppm/°C voltage reference, and an internal diagnostic ADC. To accommodate intrinsic and
functional safety concerns, external voltage-to-current conversion and power-regulation are required.
1.1 Kit Contents
Table 1-1 details the contents of the EVM kit. Contact the TI Product Information Center at [phone] if any
component is missing. Download the latest versions of the related software on the TI website, www.ti.com.
Table 1-1. AFE881H1EVM Kit Contents
Item Quantity
AFE881H1EVM 1
Note
The EVM requires the USB2ANY digital controller. This controller is not included, and must be
purchased separately.
1.2 Related Documentation From Texas Instruments
The documents in Table 1-2 provides information regarding Texas Instruments integrated circuits used in the
assembly of the AFE881H1EVM. This user's guide is available from the TI web site under literature number
SLAU858. Any letter appended to the literature number corresponds to the document revision that is current
at the time of the writing of this document. Newer revisions may be available from the TI web site at , or call
the Texas Instruments Literature Response Center at [phone] or the Product Information Center at (972)
644-5580. When ordering, identify the document by both title and literature number.
Table 1-2. Related Documentation
Document Literature Number
AFE881H1 product data sheet SLASEU7
USB2ANY interface adapter user's guide SNAU228
REF3312 product data sheet SBOS392
SN74LVC8T245 product data sheet SCES584
SN74LVC2T45 product data sheet SCES516
Download the latest version of the EVM graphical user interface (GUI) installer from the Order and start
development subsection of the AFE881H1EVM web folder on TI.com. Run the GUI installer to install the EVM
GUI software on your personal computer (PC).
www.ti.com Overview
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 3
Copyright © 2021 Texas Instruments Incorporated

2 USB2ANY Interface Adapter
The AFE881H1EVM is controlled by a USB2ANY Interface Adapter. A PC runs the software that communicates
with the USB2ANY, which provides the power and digital signals used to communicate with the EVM board.
Connectors on the EVM board are used to connect the required external power supply. Figure 2-1 shows a
diagram of the connections from the PC to the AFE881H1EVM.
A-to-Mini-B USB
Cable
AFE881H1
GUI AFE881H1
EVM
Digital
Control
DAC
Output
HART
In / Out
Supply
Selection
ADC
Inputs
30-Pin Ribbon
Cable
3.3 V / 5 V
GPIO
I2C / SPI
External
Power Supply
(Optional)
USB2ANY
Figure 2-1. AFE881H1EVM Hardware Setup
2.1 Signal Definitions for J10
Table 2-1 shows the pinout for the 30-pin connector socket used to communicate between the EVM and the
USB2ANY. Be aware that the I2C communications lines (I2C_SCL and I2C_SDA1) are not used. Both the
connectors and cables from the USB2ANY to the AFE881H1EVM are keyed to make sure the cable is correctly
connected.
Table 2-1. USB2ANY Connector AFE881H1EVM (J10) Pinout
Pin on J10 Signal Definition
4, 6, 8, 16, 27, 28 GND Ground
11 ALARM Alarm notification; open drain.
When an alarm occurs, this pin is held low. Otherwise, this pin goes to Hi-Z.
12 CS SPI communication for AFE881H1 chip select
13 MISO SPI communication for AFE881H1 digital output
14 MOSI SPI communication for AFE881H1 digital input
15 3p3V 3.3-V supply voltage
17 CD Carrier detect. A logic high on this pin indicates a valid carrier is present.
18 SCLK SPI communication for AFE881H1 digital clock
19 GPIO1 GPIO1 (unused)
20 GPIO2 GPIO2 (unused)
25 RTS Request to send.
A logic high on this pin enables the demodulator and disables the modulator.
A logic low on this pin enables the modulator and disables the demodulator.
Do not leave any digital input pins floating.
26 UARTOUT UART data output.
29 RESET Reset.
A logic low on this pin places the device into power-down mode and resets the device.
Logic high returns the device to normal operation.
Do not leave any digital input pins floating.
30 UARTIN UART data input. Do not leave any digital input pins floating.
1, 2, 3, 5, 7, 9, 10, 21,
22, 23, 24
NC Not connected
USB2ANY Interface Adapter www.ti.com
4AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

2.2 USB2ANY Theory of Operation
Figure 2-2 shows the block diagram for the USB2ANY platform. This platform is a general-purpose data-
acquisition system that is used on several different Texas Instruments evaluation modules. The details of
operation are included in the USB2ANY Interface Adapter User's Guide.
Power Management
(14)
MSP430F5529
Switchable
12C pullups
(4)
+3.3 V
+5.0 V
DAC1
DAC2
GPIO, 12C, PWM,
and other interfaces
(shared lines)
Analog Inputs
Ext. VREF
Figure 2-2. USB2ANY Interface Adapter Block Diagram
www.ti.com USB2ANY Interface Adapter
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 5
Copyright © 2021 Texas Instruments Incorporated

3 EVM Hardware Overview
To use the EVM hardware, set the jumpers, connect the USB2ANY to the EVM together with the 30-pin ribbon
cable, apply external power (optional), and connect the USB cable from the USB2ANY to the PC. This section
presents the details of these procedures.
3.1 Electrostatic Discharge Caution
CAUTION
Many of the components on the AFE881H1EVM are susceptible to damage by electrostatic
discharge (ESD). Observe proper ESD handling precautions when unpacking and handling the
EVM, including the use of a grounded wrist strap at an approved ESD workstation.
3.2 EVM Block Diagram
A block diagram of the EVM hardware setup is shown in Figure 3-1. This board provides connections and test
points for the SPI and UART communication, power, reference, ground connections, ADC inputs, HART modem,
and the analog output of the DAC.
AFE881H1
USB2ANY
Connector
Bus
Transceiver/
Level Shifter
SPI
Connections
UART, CD,
RTS, ALARM
Connections
PVDD
Supply
(Optional)
IOVDD
Supply
(Optional)
Selectable
REF3312
Reference
(Not populated)
CLKOUT
ADC
AIN0,
AIN1
HART
IN
HART
Filtering
PVDD/
IOVDD
3.3-V
Supply
VOUT
HART
OUT
Figure 3-1. AFE881H1EVM Block Diagram
EVM Hardware Overview www.ti.com
6AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

3.3 EVM Jumper Summary
Table 3-1 summarizes all of the EVM jumper functionality.
Table 3-1. AFE881H1EVM Jumper Summary
Header Name Function
J2 PVDD to IOVDD Short 1-2 – PVDD connected to IOVDD
Open 1-2 – PVDD, IOVDD disconnected (default)
J3 USB 3.3V Short 1-2 – PVDD connected to USB2ANY 3p3V (default)
Open 1-2 – PVDD disconnected from USB2ANY 3p3V
Short 3-4 – IOVDD connected to USB2ANY 3p3V (default)
Open 3-4 – IOVDD disconnected from USB2ANY 3p3V
J5 Ext REF Short 1-2 – VREFIO connected to external reference
Open 1-2 – VREFIO disconnected from external reference (default)
J6 IOVDD Shunt Short 1-2 – IOVDD connected to device (default)
Open 1-2 – IOVDD disconnected from device
J7 REF EN Short 1-2 – REFEN connected to IOVDD (default)
Short 2-3 – REFEN connected to GND
J8 UARTIN Short 1-2 – UART_IN connected to bus transceiver (default)
Open 1-2 – UART_IN disconnected from bus transceiver
J13 POL SEL Short 1-2 – POL_SEL connected to PVDD through 100-kΩ resistor
Short 2-3 – POL_SEL connected to GND through 100-kΩ resistor (default)
J14 Resistor Load Short 1-2 – VOUT connected to 10-kΩ load
Open 1-2 – VOUT no resistive load (default)
J17 Cap Load Short 1-2 – VOUT connected to 100-pF load
Open 1-2 – VOUT no capacitive load (default)
J19, J20 FILT SEL Short 1-2 – HART IN pin external filter selected
Short 2-3 – HART IN pin internal filter selected
J23 Level Translator Short 1-2 – Bus transceiver OE connected to GND (default)
Short 2-3 – Bus transceiver OE connected to IOVDD
Figure 3-2 shows the default jumper settings with the device using USB power. The EVM can be fully operated
using only the USB2ANY connector for both power and communication.
Figure 3-2. Default Header Settings for the AFE881H1EVM
www.ti.com EVM Hardware Overview
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 7
Copyright © 2021 Texas Instruments Incorporated

3.4 Terminal and Pin Definitions
Table 3-2 shows the EVM terminal and pin definitions, allowing the user to operate and connect the device to
optional power settings and other input and output signals.
Table 3-2. AFE881H1EVM Terminal and Pin Definitions
Terminal or Pin Name Function
J1 VDD Shunt 1-2: Connect VDD to PVDD for use when VDD = PVDD = 1.8 V
Open 1-2: Disconnects VDD when PVDD > 1.8 V
J2 PVDD Banana Jack: Optional for external PVDD
J3 3p3V Shunt 1-2: Connect PVDD to USB2ANY 3.3-V supply
Shunt 3-4: Connect IOVDD to USB2ANY 3.3-V supply
J4 GND Banana Jack: Optional for external GND
J5 VREFIO Shunt 1-2: Connect REF3312 to VREFIO for external reference
Open 1-2: Open for device internal reference
J6 IOVDD Shunt 1-2: Connect IOVDD to power
J7 REF EN Shunt 1-2: Enable device internal reference
Shunt 2-3: Disable device internal reference
J8 UARTIN Shunt 1-2: Connect UARTIN to device from USB2ANY through voltage level shifter
J9 SPI Conn Pin 1: RESET
Pin 3: SCLK
Pin 5: SDI
Pin 7: CS
Pin 9: SDO
Pin 2, 4, 6, 8, 10: GND
J10 USB2ANY 30-pin ribbon cable connection, see Table 2-1
J11 ADC Terminal 1: AIN0
Terminal 2: GND
Terminal 3: AIN1
J12 UART Conn Pin 1: UART_IN
Pin 3: UART_OUT
Pin 5: RTS
Pin 7: CD
Pin 9: ALARM
Pin 2, 4, 6, 8, 10: GND
J13 POL_SEL Shunt 1-2: Pull up to PVDD
Shunt 2-3: Pull down to GND
Open: Connection to AIN1 terminal of J11
J14 RES_LOAD Shunt 1-2: Connect 10-kΩ load to VOUT
J15 VOUT Terminal 1: GND
Terminal 2: VOUT
J16 CLK_OUT Pin 1: CLK_OUT
Pin 2: GND
J17 CAP_LOAD Shunt 1-2: Connect 150-pF load to VOUT
J18 IOVDD Banana Jack: Optional for external IOVDD
J19, J20 FILT_SEL Shunt 1-2: HART IN terminal internal filter selected
Shunt 2-3: HART IN terminal external filter selected
J21 HART_IN Terminal 1: GND
Terminal 2: HART input
J22 HART_OUT Terminal 1: GND
Terminal 2: HART output
EVM Hardware Overview www.ti.com
8AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

Figure 3-3 shows the terminal and pin locations on the EVM.
Power Terminals
(Optional)
USB2ANY
SPI UART
REF EN
POL_SEL
RX Filter
AFE881H1
UARTIN
CLKOUT
AIN
Connections VOUT
MOD IN
MOD OUT
IOVDDPVDD GND
RX_IN/
INF SEL
Power from
USB2ANY
(Default)
External
Reference
VOUT Load
IOVDD
Connect
VDD Connection
for low supplies
Figure 3-3. Terminal and Pin Locations for the AFE881H1EVM
3.5 Connecting the USB2ANY
To connect the EVM board and the USB2ANY Interface Adapter together, firmly slide the cable ends of the
30-pin ribbon cable into the USB2ANY Interface Adapter and the AFE881H1EVM, as shown in Figure 3-4. Make
sure that the connectors are completely pushed together. Loose connections between the USB2ANY and the
EVM may cause intermittent operation.
USB2ANY AFE881H1EVM
Figure 3-4. USB2ANY Connection to the AFE881H1EVM
www.ti.com EVM Hardware Overview
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 9
Copyright © 2021 Texas Instruments Incorporated

3.6 Connecting the USB Cable to the USB2ANY Interface Adapter
Figure 3-5 shows the typical response to connecting the USB2ANY Interface Adapter board to a USB port for
the first time. Typically, the PC responds with a Found New Hardware, USB Device pop-up dialog window. The
pop-up window then changes to Found New Hardware, USB Human Interface Device. This pop-up indicates that
the device is ready to be used. The USB2ANY Interface Adapter uses the human interface device drivers that
are included in the Windows® operating system (OS).
In some cases, the Add Hardware Wizard appears. If this prompt occurs, allow the system device manager to
install the human interface drivers by clicking Yes when requested to install drivers.
Figure 3-5. Confirmation of USB2ANY Driver Installation
CAUTION
The EVM default configuration does not require external power supplies, and power is sourced from
the USB2ANY. If external supplies are used, disconnect the supply connection from the 3p3V line
coming from the USB2ANY before attaching external supplies.
3.7 Optional EVM Operations
This section describes the various operational options that can be used by the EVM.
3.7.1 Power Configuration
The default configuration of the AFE881H1EVM allows the board to be powered from the 3p3V line coming from
the USB2ANY. Jumper J3 connects power from the 3p3V line to the PVDD and IOVDD pins of the device. To
use external power supplies, remove the jumpers in J3 to connect supplies to J1 and J4 for connections to
PVDD and IOVDD. When the external supply is 1.8 V, install R1 on the board; this resistor is not installed by
default. Provide the external 1.8-V supply to PVDD, VDD, and IOVDD through J1 and J4.
3.7.2 External SPI and UART Controllers
To use an external SPI or UART controller with EVM board, disconnect the USB2ANY controller, and disable the
U2 level shifter by uninstalling R13 and installing R2.
EVM Hardware Overview www.ti.com
10 AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

4 Software Overview
This section discusses how to use the AFE881H1EVM software.
4.1 Software Installation
Before starting software installation, verify that the USB2ANY controller is not connected or else the driver may
not properly install.
Download and run the latest version of the EVM GUI installer from the Tools and Software section of the
AFE881H1EVM web folder to install the EVM GUI software on your PC. The software installation automatically
copies the required LabVIEW™ software files and drivers to the local machine. The AFE881H1EVM installer
installs all the driver files necessary to operate the USB2ANY controller.
Choose the destination directory for the GUI software, accept the license agreements, and follow the on-screen
instructions shown in Figure 4-1 to complete the installation.
Figure 4-1. AFE881H1EVM Software Installation Prompts
To use the scripting tool, the Python™ programming environment must also be installed. Download the latest x86
version of Python 2.7 at https://www.python.org/downloads/.
www.ti.com Software Overview
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 11
Copyright © 2021 Texas Instruments Incorporated

4.2 Launching the Software
After installation, a shortcut to launch the GUI can be found in the Start menu. If installed in the default directory,
the AFE881H1EVM software can also be launched by navigating to the Texas Instruments folder in the Program
Files (x86) directory, as Figure 4-2 shows.
Figure 4-2. Launching the AFE881H1EVM GUI
Figure 4-3 shows the GUI after launch. If the USB2ANY controller is not connected to the PC when the software
is launched, the GUI defaults to demo mode. Figure 4-4 illustrates the bottom-left corner of the GUI showing
the hardware connection status: DEMO MODE or CONNECTED. After the USB2ANY controller is properly
connected to the PC, close and reopen the AFE881H1EVM software to detect the device.
Figure 4-3. AFE881H1EVM GUI at Launch
Figure 4-4. USB2ANY Digital Controller Connection Status
Software Overview www.ti.com
12 AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

4.3 Software Features
The AFE881H1EVM GUI allows for SPI communication with the AFE881H1 and control of the device. While
the entire register map is available to the user, some features have been integrated into user controls for easy
operation.
4.3.1 AFE881H1 Register Page
Figure 4-5 shows the AFE881H1 Register page of the AFE881H1EVM GUI. This page allows direct access
to all registers on the AFE881H1. The GUI handles page address management, allowing seamless access to
registers.
The Register Map section in the center of the page lists all the registers, grouped by the pages in the device.
Directly above the Register Map section are four buttons that allow read and write access to all registers.
The Field View section on the right side of the page shows the various fields in the currently selected register.
Select a register name to highlight the register. The Field View section displays the register contents as
described in the data sheet.
Figure 4-5. AFE881H1 Register Page
www.ti.com Software Overview
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 13
Copyright © 2021 Texas Instruments Incorporated

4.3.2 High Level Configuration Page
The High Level Configuration page is used to set the configuration of the AFE881H1EVM GUI. Figure 4-6 shows
the AFE881H1 High Level tab of the High Level Configuration Page. This tab is used to set the DAC range and
outputs, ADCs controls and settings, and HART modem functions for the device. Alarms and status information
are also displayed on this tab.
Figure 4-6. AFE881H1 High Level Tab
4.3.3 Using the Python Scripting Tool
The AFE881H1EVM software provides a scripting tool to automate register reads and writes for reuse. To use
the scripting tool, the Python™ programming environment must be installed. Download the latest x86 version of
Python 2.7 at https://www.python.org/downloads/. To launch the scripting tool, click Script > Launch Window, as
shown in Figure 4-7.
Figure 4-7. Launch Script Window
Software Overview www.ti.com
14 AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

The scripting tool launches a Python IDLE window. This window lists any register interaction when recording a
macro. To record a macro, find the Launch Window function in the Scripting tab. Figure 4-8 shows the scripting
tool recording a macro. After the actions are recorded, use the Stop button to end the script. This script can be
saved and reused as desired.
Figure 4-8. Scripting Tool Recording a Macro
If the python IDLE window does not appear, check the settings for application execution aliases. To do so, open
the Windows Settings, and then select Apps. In the resulting Apps window, select Apps & features, and then
click on the Manage app execution aliases link. The next page loads a list of apps. Deselect both application
installers for python.exe and python3.exe. Figure 4-9 shows the windows settings for managing application
execution aliases.
Figure 4-9. Deselecting App Execution Aliases
www.ti.com Software Overview
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 15
Copyright © 2021 Texas Instruments Incorporated

5 Schematics, PCB Layout, and Bill of Materials
5.1 Board Schematic
The AFE881H1EVM schematic is shown in Figure 5-1.
Figure 5-1. AFE881H1EVM Schematic
Schematics, PCB Layout, and Bill of Materials www.ti.com
16 AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

5.2 PCB Components Layout
Figure 5-2 through Figure 5-5 show the board layout for the AFE881H1EVM.
Figure 5-2. AFE881H1EVM PCB Top Layer Layout
Figure 5-3. AFE881H1EVM PCB Mid Layer 1 Layout
www.ti.com Schematics, PCB Layout, and Bill of Materials
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 17
Copyright © 2021 Texas Instruments Incorporated

Figure 5-4. AFE881H1EVM PCB Mid Layer 2 Layout
Figure 5-5. AFE881H1EVM PCB Bottom Layer Layout
Schematics, PCB Layout, and Bill of Materials www.ti.com
18 AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

5.3 Bill of Materials
Table 5-1 lists the AFE881H1EVM BOM.
Table 5-1. Bill of Materials for the AFE881H1EVM
Designator Quantity Value Description Package
Reference Part Number Manufacturer
PCB 1 Printed Circuit Board DC163 Any
C1, C2, C3 3 10uF CAP, CERM, 10 uF, 25 V, +/- 20%, X5R, 0603 0603 GRT188R61E106ME13D MuRata
C5, C6, C8, C9, C10,
C11, C12, C20, C24, C25
10 0.1uF CAP, CERM, 0.1 uF, 25 V, +/- 5%, X7R, 0603 0603 06033C104JAT2A AVX
C13 1 100pF CAP, CERM, 100 pF, 100 V, +/- 5%, X7R, 0805 0805 C0805C101J1RACTU Kemet
C14, C15 2 680pF CAP, CERM, 680 pF, 25 V, +/- 10%, X7R, 0805 0805 885012207085 Würth Elektronik
C16 1 2200pF CAP, CERM, 2200 pF, 50 V, +/- 5%, C0G/NP0, 0603 0603 GRM1885C1H222JA01D MuRata
C17, C18 2 1000pF CAP, CERM, 1000 pF, 50 V, +/- 1%, C0G/NP0, 0805 0805 08055A102FAT2A AVX
C19, C21 2 680pF CAP, CERM, 680 pF, 100 V, +/- 5%, C0G/NP0, 0805 0805 08051A681JAT2A AVX
C22 1 4700pF CAP, CERM, 4700 pF, 25 V, +/- 5%, C0G/NP0, 0805 0805 08053A472JAT2A AVX
C23 1 1000pF CAP, CERM, 1000 pF, 50 V, +/- 5%, C0G/NP0, AEC-
Q200 Grade 1, 0402
0402 CGA2B2C0G1H102J050BA TDK
D3, D4 2 V Diode, TVS, Bi, 5.5 V, 14 Vc, 1x0.6mm 1x0.6mm ESD105B102ELE6327XTMA1 Infineon Technologies
H1, H2, H3, H4 4 Machine Screw, Round, #4-40 x 1/4, Nylon, Philips
panhead
Screw NY PMS 440 0025 PH B&F Fastener Supply
H5, H6, H7, H8 4 Standoff, Hex, 0.5"L #4-40 Nylon Standoff 1902C Keystone
J1, J6, J8, J14, J16, J17 6 Header, 100mil, 2x1, Tin, TH Header, 2x1,
100mil, TH
5-146278-2 TE Connectivity
J2, J4, J18 3 Standard Banana Jack, Uninsulated, 5.5mm Keystone_575-4 575-4 Keystone
J3 1 Header, 100mil, 2x2, Gold, TH 2x2 Header TSW-102-07-G-D Samtec
J7, J13, J19, J20 4 Header, 100mil, 3x1, Gold, TH 3x1 Header TSW-103-07-G-S Samtec
J9, J12 2 Header, 100mil, 5x2, Gold, TH 5x2 Header TSW-105-07-G-D Samtec
J10 1 Header(shrouded), 2.54mm, 15x2, Gold, TH Header(shrouded),
2.54mm, 15x2, TH
302-S301 On-Shore Technology
J11 1 Terminal Block, 3.5mm Pitch, 3x1, TH 10.5x8.2x6.5mm ED555/3DS On-Shore Technology
J15, J21, J22 3 Terminal Block, 3.5mm Pitch, 2x1, TH 7.0x8.2x6.5mm ED555/2DS On-Shore Technology
R1, R12 2 2.0k RES, 2.0 k, 5%, 0.125 W, AEC-Q200 Grade 0, 0805 0805 ERJ-6GEYJ202V Panasonic
www.ti.com Schematics, PCB Layout, and Bill of Materials
SLAU858 – NOVEMBER 2021
Submit Document Feedback
AFE881H1 Evaluation Module 19
Copyright © 2021 Texas Instruments Incorporated

Table 5-1. Bill of Materials for the AFE881H1EVM (continued)
Designator Quantity Value Description Package
Reference Part Number Manufacturer
R3, R5 2 15.8 RES, 15.8, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW060315R8FKEA Vishay-Dale
R4, R6, R11, R14 4 100k RES, 100 k, 1%, 0.125 W, AEC-Q200 Grade 0, 0805 0805 CRCW0805100KFKEA Vishay-Dale
R7 1 10.0k RES, 10.0 k, 1%, 0.125 W, AEC-Q200 Grade 0, 0805 0805 CRCW080510K0FKEA Vishay-Dale
R8 1 150k RES, 150 k, 0.1%, 0.125 W, 0805 0805 RG2012P-154-B-T5 Susumu Co Ltd
R9 1 30.0k RES, 30.0 k, 0.1%, 0.125 W, 0805 0805 RG2012P-303-B-T5 Susumu Co Ltd
R10 1 300k RES, 300 k, 0.1%, 0.125 W, 0805 0805 RG2012P-304-B-T5 Susumu Co Ltd
TP1, TP5, TP8, TP9,
TP11, TP12, TP13, TP14,
TP15, TP16
10 Test Point, Miniature, White, TH White Miniature
Testpoint
5002 Keystone
TP2, TP3, TP4, TP6 4 Test Point, Multipurpose, Black, TH Black Multipurpose
Testpoint
5011 Keystone
TP7 1 Test Point, Miniature, Orange, TH Orange Miniature
Testpoint
5003 Keystone
TP10 1 Test Point, Miniature, Red, TH Red Miniature
Testpoint
5000 Keystone
U2 1 8-Bit Dual-Supply Bus Transceiver with Configurable
Voltage-Level Shifting and Three-State Outputs,
DB0024A (SSOP-24)
DB0024A SN74LVC8T245DBR Texas Instruments
U4 1 16-Bit, Low-Power DACs With Internal HART
Modem, Voltage Reference, and Diagnostic ADC for
4-20mA Loop-Powered Applications, UQFN24
UQFN24 AFE881H1RRUT Texas Instruments
U3, U5 2 2-Bit Dual Supply Transceiver with Configurable
Voltage-Level Shifting and 3-State Outputs,
DCU0008A (VSSOP-8)
DCU0008A SN74LVC2T45DCURG4 Texas Instruments
C4 0 0.1uF CAP, CERM, 0.1 uF, 25 V, +/- 5%, X7R, 0603 0603 06033C104JAT2A AVX
C7 0 1uF CAP, CERM, 1 uF, 50 V, +/- 10%, X7R, 0603 0603 UMK107AB7105KA-T Taiyo Yuden
J5 0 Header, 100mil, 2x1, Tin, TH Header, 2x1,
100mil, TH
5-146278-2 TE Connectivity
R2 0 2.0k RES, 2.0 k, 5%, 0.125 W, AEC-Q200 Grade 0, 0805 0805 ERJ-6GEYJ202V Panasonic
U1 0 30 ppm / degC Drift, 3.9 uA, Voltage Reference, -40
to 125 degC, 3-pin SOT-23 (DBZ), Green (RoHS &
no Sb/Br)
DBZ0003A REF3312AIDBZR Texas Instruments
Schematics, PCB Layout, and Bill of Materials www.ti.com
20 AFE881H1 Evaluation Module SLAU858 – NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
