Texas Instruments LP8864 User manual

User’s Guide
LP8864 Evaluation Module
ABSTRACT
The Texas Instruments LP8864EVM evaluation module helps designers to evaluate the operation and
performance of the LP8864-Q1 device. This document includes a hardware setup instructions, software
instructions, a complete schematic diagram, printed-circuit board (PCB) layout, and bill of materials (BOM) of the
LP8864EVM.
Table of Contents
1 Introduction.............................................................................................................................................................................2
1.1 Features............................................................................................................................................................................. 2
1.2 Applications........................................................................................................................................................................2
2 Test Setup................................................................................................................................................................................3
2.1 LP8864EVM Kit..................................................................................................................................................................3
2.2 System and Equipment Requirements...............................................................................................................................3
2.3 Hardware Setup................................................................................................................................................................. 4
2.4 Software Installation...........................................................................................................................................................4
2.5 Quick Start-Up Procedure.................................................................................................................................................. 5
2.6 Additional GUI Functions................................................................................................................................................... 7
2.7 Instructions for Standalone Evaluation...............................................................................................................................9
3 LP8864EVM Board Layout................................................................................................................................................... 10
4 LP8864EVM Schematic.........................................................................................................................................................11
5 LP8864EVM Bill of Materials................................................................................................................................................12
6 LED Load Board....................................................................................................................................................................14
Trademarks
All trademarks are the property of their respective owners.
www.ti.com Table of Contents
SNVU731 – NOVEMBER 2020
Submit Document Feedback
LP8864 Evaluation Module 1
Copyright © 2020 Texas Instruments Incorporated

1 Introduction
The LP8864EVM helps designers to evaluate the characteristics, operation, and use of the LP8864-Q1 device, a
high-performance LED driver for automotive lighting. The LP8864-Q1 device is a high-efficiency LED driver with
boost controller. The four 200-mA high-precision current sinks support phase shifting that is automatically
adjusted based on the number of channels in use. LED brightness can be controlled globally through the I2C
interface or PWM input.
1.1 Features
The EVM has the following features:
• Up to 48-V VOUT boost controller
• Four high-precision current sinks
• Supports built-in phase-shift PWM dimming, hybrid dimming, current dimming and direct PWM dimming
mode
• LED brightness controlled globally through I2C interface or PWM input
• Extensive fault diagnostics
1.2 Applications
Backlight for:
• Automotive infotainment
• Automotive instrument clusters
• Smart mirrors
• Heads-Up Displays (HUD)
• Central Information Displays (CID)
• Audio-Video Navigation (AVN)
Introduction www.ti.com
2LP8864 Evaluation Module SNVU731 – NOVEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated

2 Test Setup
This section describes how to properly connect and setup the LP8864EVM.
2.1 LP8864EVM Kit
The LP8864EVM kit contains (see Figure 2-1):
• USB2ANY
– Ribbon cable
– USB cable
• LP8864EVM
• LP886X-LEDLOAD-EVM
Figure 2-1. LP8864EVM Kit
2.2 System and Equipment Requirements
• DC power supply: 24 V or higher, 6 A or higher
• LED cable: 5-position ribbon cable
• PC to run GUI software
• GUI software
www.ti.com Test Setup
SNVU731 – NOVEMBER 2020
Submit Document Feedback
LP8864 Evaluation Module 3
Copyright © 2020 Texas Instruments Incorporated

2.3 Hardware Setup
Figure 2-2 shows the hardware setup of the LP8864EVM.
• Connect a 12-V external power supply between the power input terminals VBAT+ and GNDin on the
LP8864EVM
• Connect the USB2ANY module to the PC with the USB cable
• Connect the USB2ANY module to the LP8864EVM with the provided ribbon cable
• Connect the LP8864EVM to the LP886X-LEDLOAD-EVM with a 5-position ribbon cable
Figure 2-2. LP8864EVM Hardware Setup
2.4 Software Installation
Download the GUI software from the LP8864EVM tools folder. Follow the instructions to finish the GUI
installation. Once installed, a shortcut to the GUI is found on the desktop and also in the start-up menu under the
Texas Instruments folder.
Test Setup www.ti.com
4LP8864 Evaluation Module SNVU731 – NOVEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated

2.5 Quick Start-Up Procedure
1. After the hardware is connected successfully, run the GUI software. Turn on the 12-V external power supply.
Select the right device variant of the EVM, which is LP8864, as shown in Figure 2-3.
Figure 2-3. LP8866/4 Family GUI Landing Page
2. Check the connection status button on the bottom left corner of the GUI. The button should be like the one
shown in Figure 2-3. There should be a Hardware Connected message on the status bar next to the button. If it
shows Hardware not Connected, click the button to manually connect the hardware. This button can be used to
connect or disconnect the GUI to the hardware during the evaluation. Besides the connection status button, the
device should be enabled to be connected to the GUI. Ensure the Enable button on the LED Control Page (see
Figure 2-5) is enabled.
www.ti.com Test Setup
SNVU731 – NOVEMBER 2020
Submit Document Feedback
LP8864 Evaluation Module 5
Copyright © 2020 Texas Instruments Incorporated

3. Click the EXPLORE LP8864 button to go to the LP8864EVM GUI home page (see Figure 2-4).
Figure 2-4. LP8864EVM GUI Home Page
4. Click the START button to go to the LED Control page (see Figure 2-5). On the LED Control page, the user
can control all the register-based control functions of the device, like brightness control, current control, sloper
control, dither control, boost synchronization configuration, and spread spectrum configuration.
Figure 2-5. LP8864EVM LED Control Page
Test Setup www.ti.com
6LP8864 Evaluation Module SNVU731 – NOVEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated

2.6 Additional GUI Functions
In the selection tab on the left-hand side, the user can switch between LED Control, Monitor Faults, Diagnostics
and Register Map tabs. This section introduces GUI functions provided in the Monitor Faults, Diagnostics, and
Register Map tabs.
2.6.1 Monitor Faults Page
From the Monitor Faults page (see Figure 2-6), the user has access to LP8864-Q1 fault status bits. Faults can
be cleared by software by clicking the Clear All button. Fault interrupt can be enabled or disabled globally by
toggling the Interrupt All button. Besides that, each fault interrupt and each fault status can be controlled
individually.
Figure 2-6. LP8864EVM Monitor Faults Page
www.ti.com Test Setup
SNVU731 – NOVEMBER 2020
Submit Document Feedback
LP8864 Evaluation Module 7
Copyright © 2020 Texas Instruments Incorporated

2.6.2 Diagnostics Page
From the Diagnostics page (see Figure 2-7), the user can read back the following diagnostics register values
and corresponding device status.
• FSM_LIVE_STATUS: current status of the functional state machine
• PWM_INPUT_STATUS: 16-bit value for detected duty cycle of PWM input signal
• PWM_OUTPUT_STATUS: 16-bit value for configured duty cycle of PWM output signal
• LED_CURRENT_STATUS: 12-bit current DAC code that brightness path is driving to OUT1-4 output
• VBOOST_STATUS: 11-bit boost voltage code that adaptive voltage control loop sending to analog boost
block
• AUTO_PWM_FREQ_SEL: LED PWM frequency value from PWM_SEL resistor detection
• AUTO_LED_STRING_CFG: LED string configuration from LED_SET resistor detection
• AUTO_BOOST_FREQ_SEL: boost switching frequency value from PWM_FSET resistor detection
• MODE_SEL: LED dimming mode value from MODE resistor detection
Figure 2-7. LP8864VM Diagnostics Page
Test Setup www.ti.com
8LP8864 Evaluation Module SNVU731 – NOVEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated

2.6.3 Register Map Page
Figure 2-8 shows the registers map page. All the registers are available on this page. When Auto Read is set to
other than "Off", all the registers will be read automatically and periodically according to the interval time the user
selects. Otherwise, the user needs to click the READ REGISTER button to read the selected register or click the
READ ALL REGISTERS button to read all of the registers.
Clicking on the row of a register automatically updates the corresponding field view on the right side of the page.
The register value can be updated by modifying the hexadecimal value in the Value column or by double-clicking
the corresponding bit in the Bits column. The modified value is effective immediately if "Immediate Write" is
selected in the drop-down menu. When "Deferred Write" is selected, the modified value will not take effect until
the user clicks the WRITE REGISTER button. The value of all the registers can be updated together by clicking
the WRITE ALL REGISTERS button.
Figure 2-8. LP8864EVM Register Map Page
2.7 Instructions for Standalone Evaluation
The LP8864EVM can be used for standalone evaluation (without GUI software and PC connection). To support
standalone mode, it must be modified from its default settings as described in the following list:
1. Mount R20 to pull up EN input.
2. Change pullup and pulldown resistors to select spread spectrum enable (R18) or disable (R25) option.
3. Mount R19 to pull up PWM input for 100% brightness. If brightness needs to be changed from 100%, connect
external PWM source at PWM pin.
The minimum procedures for turning on the LEDs after the previously-listed modifications are as follows:
1. Connect a 12-V external power supply between the power input terminals VBAT+ and GNDin on the
LP8864EVM.
2. Connect the LP886X-LEDLAOD-EVM board (4 strings, 8 LEDs per string) to J10 on the LP8864EVM.
3. Turn on the external power supply.
www.ti.com Test Setup
SNVU731 – NOVEMBER 2020
Submit Document Feedback
LP8864 Evaluation Module 9
Copyright © 2020 Texas Instruments Incorporated

3 LP8864EVM Board Layout
Figure 3-1 and Figure 3-2 illustrate the EVM board layout.
Figure 3-1. LP8864EVM Layout - Top
Figure 3-2. LP8864EVM Layout - Bottom
LP8864EVM Board Layout www.ti.com
10 LP8864 Evaluation Module SNVU731 – NOVEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated

4 LP8864EVM Schematic
Figure 4-1 shows the LP8864EVM schematic.
3V to 48V
J9
J8
1
3
2
D1
220pF
C1
DNP
909k
R9
100k
R12
VDDEXT
5
4
1
2
3Q1
49.9
R6
68uF
C24 10µF
C10
DNP
10µF
C11
DNP
10µF
C12
10µF
C13
GND
GND
GND
GND
GND
GND
GND
VINP
GND 2.2µF
C29
0.1uF
C31
GND GND
OUT1
OUT2
OUT3
OUT4
220pF
C28 DNP
GND
GND
GND
220pF
C25 DNP
10uF
C23
1 23
4
L3
VIN VDD_3V3
22uF
C44
IN
1
2
EN
3NC 4
OUT 5
GND
TLV70033QDDCRQ1U3
1uF
C45
1uF
C46
GND
GND
VBOOST
GND
OUT1
OUT2
OUT3
OUT4
D2
2.26k
R17
D3
2.26k
R21
D4
2.26k
R22
VDDIO
0
R16
DNP
0
R10
1 2
3 4
5 6
7 8
9 10
J11
MAX 47V, 0.8A
VBOOST
GND
GND
SDASCL
EN
PWM SYNC
INT
GND
INT
SDA
SCL
GND
EN
SYNC
3.92k R28
3.92k R30
11.0k R31
J1
VBAT+
J6
GNDin
J7
VDDEXT
J2
VIN
DNP J3
VINP
DNP
J14
VDD DNP
4
1
2
3
J12
4
1
2
3
J13
3.92k R24
5
4
1
2 3
Q2
10.0
R7
4.7µF
C26
0.1uF
C27
VDD
GND
20.8k
R32
PWM
VDD_5V
0
R14
0R34
DNP
0R35
DNP
0R36
VDDEXT
VDD_5V
VDD_3V3
VDDIO 0R37
DNP
0R38
VDD
VDD_3V3
VDD
GND
10.0k
R20
DNP
10.0k
R25
DNP
10.0k
R19
10.0k
R26
DNP
SYNC PWM
10.0k
R18
2.26k
R27
2.26k
R29
20.5k
R13
76.8k
R11
15A
F1 0.02
R3
0.02
R15
EN
10.0k
R23
0
R8
2.2uH
L1
FB1
4.7µF
C16
0.01uF
C18
4.7µF
C17
0.01uF
C19
10nF
C6
10nF
C7
33uF
C14
10nF
C8
10nF
C9
33uF
C15
FB2
10nF
C22
GND
VBOOST
0
R33
0
R2
0
R5
4.7µF
C20
4.7µF
C21
5.1
R1
DNP
J5
GNDin
VBAT+
MAX 5A
FB3
VDD
S
3
S
4
22µH
L2
GND
1nF
C34
DNP
1nF
C38
DNP
1nF
C32
DNP
1nF
C36
DNP
1nF
C33
1nF
C35
1nF
C37
1nF
C39
TP1
GND
J4
SD
SD
VIN
20.0k
R4
EN
2
IN
1
GND 6
NC 4
OUT 5
TPS7B8250QKVURQ1
U2
GND
VDD
1
CPUMP
5
CPUMP
6OUT4 19
LED_SET 30
OUT1 22
OUT2 21
OUT3 20
BST_FSET 32
BST_SYNC
27
PWM
28 PWM_FSET 31
VSENSE_N
37
VSENSE_P
36
C1N
3
C1P
4
DISCHARGE 15
EN
2
FB 13
GD 7
INT
24
ISET
12
ISNS 10
MODE 33
SCL
26
SD
38
SDA
25
UVLO
35
NC
14
NC
16
NC
23
DGND 34
ISNSGND 11
LED_GND 17
LED_GND 18
LED_GND 39
PGND 8
PGND 9
SGND 29
LP8864QDCPRQ1
U1
5
4
1
2
3
6
7
8
J10
10uF
C2
10uF
C3
10uF
C4
10uF
C5
10uF
C47
4.7µF
C30
Figure 4-1. LP8864EVM Schematic
www.ti.com LP8864EVM Schematic
SNVU731 – NOVEMBER 2020
Submit Document Feedback
LP8864 Evaluation Module 11
Copyright © 2020 Texas Instruments Incorporated

5 LP8864EVM Bill of Materials
Table 5-1 lists the bill of materials for the LP8864EVM.
Table 5-1. LP8864EVM Bill of Materials
Designator QTY Value Part Number Manufacturer Description Package Reference
!PCB1 1 PSIL105 Any Printed Circuit Board
C4, C5, C23, C47 4 10uF UMK325AB7106KMHT Taiyo Yuden CAP, CERM, 10 uF, 50 V, ±10%, X7R, AEC-Q200 Grade 1, 1210 1210
C6, C7, C8, C9, C22 5 0.01uF GCM188R72A103KA37J MuRata CAP, CERM, 0.01 µF, 100 V, ±10%, X7R, AEC-Q200 Grade 1, 0603 0603
C12, C13 2 10uF CGA6P1X7R1N106M250AC TDK CAP, CERM, 10 µF, 75 V, ±20%, X7R, AEC-Q200 Grade 1, 1210 1210
C14, C15 2 33uF EEH-ZC1J330P Panasonic CAP, Polymer Hybrid, 33 uF, 63 V, ±20%, 40 ohm, 8x10 SMD 8x10
C16, C17, C20, C21 4 4.7uF CGA5L3X7R1H475K160AE TDK CAP, CERM, 4.7 µF, 50 V, ±10%, X7R, AEC-Q200 Grade 1, 1206 1206
C18, C19 2 0.01uF GCM155R71H103KA55D MuRata CAP, CERM, 0.01 uF, 50 V, ±10%, C0G/NP0, 0402 0402
C24 1 68uF EEE-FK1J680UP Panasonic CAP, AL, 68 uF, 63 V, ±20%, 0.65 ohm, AEC-Q200 Grade 2, SMD SMT Radial F
C26, C30 2 4.7uF GCM21BR71C475KA73L MuRata CAP, CERM, 4.7 uF, 16 V, ±10%, X7R, AEC-Q200 Grade 1, 0805 0805
C27, C31 2 0.1uF C0402C104K4RACAUTO Kemet CAP, CERM, 0.1 uF, 16 V, ±10%, X7R, AEC-Q200 Grade 1, 0402 0402
C29 1 2.2uF CGA4J3X7R1H225K125AB TDK CAP, CERM, 2.2 uF, 50 V, ±10%, X7R, AEC-Q200 Grade 1, 0805 0805
C33, C35, C37, C39 4 1000pF CGA3E2X7R2A102K080AA TDK CAP, CERM, 1000 pF, 100 V, ±10%, X7R, AEC-Q200 Grade 1, 0603 0603
C44 1 22uF CGA6P1X7R1C226M250AC TDK CAP, CERM, 22 uF, 16 V, ±20%, X7R, AEC-Q200 Grade 1, 1210 1210
C45, C46 2 1uF CGA5L2X7R1E105M160AA TDK CAP, CERM, 1 uF, 25 V, ±20%, X7R, AEC-Q200 Grade 1, 1206_190 1206_190
D1 1 100V FSV10100V Fairchild Semiconductor Diode, Schottky, 100 V, 10 A, AEC-Q101, TO-277A TO-277A
D2, D3, D4 3 Super
Red VLMS20J2L1-GS08 Vishay-Semiconductor LED, Super Red, SMD 2.2x1.3x1.4mm
F1 1 0679L9150-01 Bel Fuse FUSE BRD MNT 15A 125VAC/VDC 2410
FB1 1 50 ohm BLM31SN500SZ1L MuRata Ferrite Bead, 50 ohm @ 100 MHz, 12 A, 1206 1206
FB2, FB3 2 560
ohm 782853561 Wurth Elektronik Ferrite Bead, 560 ohm @ 100 MHz, 1.5 A, 0805 0805
H1, H2, H3, H4 4 NY PMS 440 0025 PH B&F Fastener Supply Machine Screw, Round, #4-40 x 1/4, Nylon, Philips panhead Screw
H5, H6, H7, H8 4 1902C Keystone Standoff
H9 1 PSIL110 PSIL110, LP886X-LEDLOAD-EVM, CDDS#: 6631820
H10 1 USB2ANY USB2ANY, CDDS#: 6542513
J1, J6, J7 3 TSW-101-07-G-S Samtec Header, 100mil, 1pos, Gold, TH Testpoint
J4 1 6091 Keystone Standard Banana Jack, Insulated, Red 6091
J5, J9 2 6092 Keystone Standard Banana Jack, Insulated, Black 6092
J8 1 108-0907-001 Cinch Connectivity BANANA JACK, 15A, Insulated, Nylon,Yellow 940x438x438mil
J10 1 TSW-108-07-G-S Samtec Header, 100mil, 8x1, Gold, TH 8x1 Header
J11 1 SBH11-PBPC-D05-RA-BK Sullins Connector Solutions Header(shrouded), 2.54mm, 5x2, Gold, R/A, TH Header, 2.54mm, 5x2, R/A,
TH
J12, J13 2 TSW-104-07-G-S Samtec Header, 100mil, 4x1, Gold, TH 4x1 Header
L1 1 2.2uH IHLP3232DZER2R2M01 Vishay-Dale Inductor, Shielded, Powdered Iron, 2.2 uH, 10.5 A, 0.0137 ohm, SMD 322x158x322mil
L2 1 22uH IHLE4040DDER220M5A Vishay-Dale Inductor, Shielded, 22 µH, 4.1 A, 0.07544 ohm, AEC-Q200 Grade 0, SMD Shielded Inductor
LP8864EVM Bill of Materials www.ti.com
12 LP8864 Evaluation Module SNVU731 – NOVEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated

Table 5-1. LP8864EVM Bill of Materials (continued)
Designator QTY Value Part Number Manufacturer Description Package Reference
L3 1 9uH PLT10HH501100PNL MuRata Coupled inductor, 9 uH, 10A, 0.0036 ohm, SMD 12.9x6.6mm
Q1 1 -60V SQJ459EP-T1_GE3 Vishay-Semiconductor MOSFET, P-CH, -60 V, -52 A, AEC-Q101, PowerPAK_SO-8L PowerPAK_SO-8L
Q2 1 60V NVMFS5C673NLWFAFT1G ON Semiconductor MOSFET, N-CH, 60 V, 50 A, SO-8FL SO-8FL
R2, R5 2 0 CRCW12100000Z0EAHP Vishay-Dale RES, 0, 1%, 0.75 W, AEC-Q200 Grade 0, 1210 1210
R3, R15 2 0.02 CRA2512-FZ-R020ELF Bourns RES, 0.02, 1%, 3 W, 2512 2512
R4 1 20.0k ERJ-3EKF2002V Panasonic RES, 20.0 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R6 1 49.9 CRCW060349R9FKEA Vishay-Dale RES, 49.9, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R7 1 10.0 CRCW060310R0FKEA Vishay-Dale RES, 10.0, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R8, R10, R14, R33,
R36, R38 6 0 RMCF0603ZT0R00 Stackpole Electronics Inc RES, 0, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R9 1 909k CRCW0603909KFKEA Vishay-Dale RES, 909 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R11 1 76.8k CRCW060376K8FKEA Vishay-Dale RES, 76.8 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R12 1 100k CRCW0603100KFKEA Vishay-Dale RES, 100 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R13 1 20.5k CRCW060320K5FKEA Vishay-Dale RES, 20.5 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R17, R21, R22, R27,
R29 5 2.26k CRCW06032K26FKEA Vishay-Dale RES, 2.26 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R18, R19, R23 3 10.0k RMCF0603FT10K0 Stackpole Electronics Inc RES, 10.0 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R24, R28, R30 3 3.92k CRCW06033K92FKEA Vishay-Dale RES, 3.92 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R31 1 11.0k RMCF0603FT11K0 Stackpole Electronics Inc RES, 11.0 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R32 1 20.8k RT0603BRD0720K8L Yageo America RES, 20.8 k, 0.1%, 0.1 W, 0603 0603
U1 1 LP8864QDCPRQ1 Texas Instruments Automotive display LED-backlight with Four 200-mA channels HTSSOP38
U2 1 TPS7B8250QKVURQ1 Texas Instruments Automotive 300-mA high-voltage ultra-low-Iq low-dropout (LDO) regulator,
KVU0005A (TO-252-5) KVU0005A
U3 1 TLV70033QDDCRQ1 Texas Instruments
Single Output Automotive LDO, 200 mA, Fixed 3.3 V Output, 2 to 5.5 V
Input, with Low IQ, 5-pin SOT (DDC), -40 to 125 degC, Green (RoHS & no
Sb/Br)
DDC0005A
C1 0 220pF GRM188R72A221KA01D MuRata CAP, CERM, 220 pF, 100 V, ±10%, X7R, 0603 0603
C2, C3 0 10uF UMK325AB7106KMHT Taiyo Yuden CAP, CERM, 10 uF, 50 V, ±10%, X7R, AEC-Q200 Grade 1, 1210 1210
C10, C11 0 10uF CGA6P1X7R1N106M250AC TDK CAP, CERM, 10 µF, 75 V, ±20%, X7R, AEC-Q200 Grade 1, 1210 1210
C25, C28 0 220pF CGA2B2X7R1H221K050BA TDK CAP, CERM, 220 pF, 50 V, ±10%, X7R, AEC-Q200 Grade 1, 0402 0402
C32, C34, C36, C38 0 1000pF CGA3E2X7R2A102K080AA TDK CAP, CERM, 1000 pF, 100 V, ±10%, X7R, AEC-Q200 Grade 1, 0603 0603
FID1, FID2, FID3,
FID4, FID5, FID6 0 N/A N/A Fiducial mark. There is nothing to buy or mount. N/A
J2, J3, J14 0 TSW-101-07-G-S Samtec Header, 100mil, 1pos, Gold, TH Testpoint
R1 0 5.1 CRCW20105R10JNEF Vishay-Dale RES, 5.1, 5%, 0.75 W, AEC-Q200 Grade 0, 2010 2010
R16, R34, R35, R37 0 0 RMCF0603ZT0R00 Stackpole Electronics Inc RES, 0, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
R20, R25, R26 0 10.0k RMCF0603FT10K0 Stackpole Electronics Inc RES, 10.0 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603
www.ti.com LP8864EVM Bill of Materials
SNVU731 – NOVEMBER 2020
Submit Document Feedback
LP8864 Evaluation Module 13
Copyright © 2020 Texas Instruments Incorporated

6 LED Load Board
An LED load board LP886X-LEDLOAD-EVM is included in the EVM kit. The LED board is intended to be used as the load for LED driver and can be
configured for up to 6 strings and up to 20 LEDs in the string (Number of LEDs in use is defined by jumpers). The initial setting on the board is 8 LEDs in
series per string. Cree XLamp ML-C LEDs with maximum current of 350 mA (for parallel use) and maximum forward voltage of 3.4 V at 100 mA (3.2-V
typical) are used on the board.
J4
OUTPUT6
J3
5
4
1
2
3
6
7
J2
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
VBOOST
5
4
1
2
3
J89
GND
J1
OUT6
J11J10 J13J12 J15J14 J17J16 J19J18 J21J20 J23J22 J25J24 J27J26 J29J28 J31J30 J33J32 J35J34 J37J36 J39J38 J41J40 J43J42 J45J44J7J6 J9J8
1 3
5
D1A
2 4
D1B
1 3
5
D2A
1 3
5
D3A
1 3
5
D4A
1 3
5
D5A
1 3
5
D6A
1 3
5
D7A
1 3
5
D8A
1 3
5
D9A
1 3
5
D10A
1 3
5
D11A
1 3
5
D12A
1 3
5
D13A
1 3
5
D14A
1 3
5
D15A
1 3
5
D16A
1 3
5
D17A
1 3
5
D18A
1 3
5
D19A
1 3
5
D20A
2 4
D2B
2 4
D3B
2 4
D4B
2 4
D5B
2 4
D6B
2 4
D7B
2 4
D8B
2 4
D9B
2 4
D10B
2 4
D11B
2 4
D12B
2 4
D13B
2 4
D14B
2 4
D15B
2 4
D16B
2 4
D17B
2 4
D18B
2 4
D19B
2 4
D20B
J53J52 J55J54 J57J56 J59J58 J61J60 J63J62 J65J64 J67J66 J69J68 J71J70 J73J72 J75J74 J77J76 J79J78 J81J80 J83J82 J85J84 J87J86J49J48 J51J50
1 3
5
D21A
2 4
D21B
1 3
5
D22A
1 3
5
D23A
1 3
5
D24A
1 3
5
D25A
1 3
5
D26A
1 3
5
D27A
1 3
5
D28A
1 3
5
D29A
1 3
5
D30A
1 3
5
D31A
1 3
5
D32A
1 3
5
D33A
1 3
5
D34A
1 3
5
D35A
1 3
5
D36A
1 3
5
D37A
1 3
5
D38A
1 3
5
D39A
1 3
5
D40A
2 4
D22B
2 4
D23B
2 4
D24B
2 4
D25B
2 4
D26B
2 4
D27B
2 4
D28B
2 4
D29B
2 4
D30B
2 4
D31B
2 4
D32B
2 4
D33B
2 4
D34B
2 4
D35B
2 4
D36B
2 4
D37B
2 4
D38B
2 4
D39B
2 4
D40B
J96J95 J98J97 J100J99 J102J101 J104J103 J106J105 J108J107 J110J109 J112J111 J114J113 J116J115 J118J117 J120J119 J122J121 J124J123 J126J125 J128J127 J130J129J92J91 J94J93
1 3
5
D41A
2 4
D41B
1 3
5
D42A
1 3
5
D43A
1 3
5
D44A
1 3
5
D45A
1 3
5
D46A
1 3
5
D47A
1 3
5
D48A
1 3
5
D49A
1 3
5
D50A
1 3
5
D51A
1 3
5
D52A
1 3
5
D53A
1 3
5
D54A
1 3
5
D55A
1 3
5
D56A
1 3
5
D57A
1 3
5
D58A
1 3
5
D59A
1 3
5
D60A
2 4
D42B
2 4
D43B
2 4
D44B
2 4
D45B
2 4
D46B
2 4
D47B
2 4
D48B
2 4
D49B
2 4
D50B
2 4
D51B
2 4
D52B
2 4
D53B
2 4
D54B
2 4
D55B
2 4
D56B
2 4
D57B
2 4
D58B
2 4
D59B
2 4
D60B
J138J137 J140J139 J142J141 J144J143 J146J145 J148J147 J150J149 J152J151 J154J153 J156J155 J158J157 J160J159 J162J161 J164J163 J166J165 J168J167 J170J169 J172J171J134J133 J136J135
1 3
5
D61A
2 4
D61B
1 3
5
D62A
1 3
5
D63A
1 3
5
D64A
1 3
5
D65A
1 3
5
D66A
1 3
5
D67A
1 3
5
D68A
1 3
5
D69A
1 3
5
D70A
1 3
5
D71A
1 3
5
D72A
1 3
5
D73A
1 3
5
D74A
1 3
5
D75A
1 3
5
D76A
1 3
5
D77A
1 3
5
D78A
1 3
5
D79A
1 3
5
D80A
2 4
D62B
2 4
D63B
2 4
D64B
2 4
D65B
2 4
D66B
2 4
D67B
2 4
D68B
2 4
D69B
2 4
D70B
2 4
D71B
2 4
D72B
2 4
D73B
2 4
D74B
2 4
D75B
2 4
D76B
2 4
D77B
2 4
D78B
2 4
D79B
2 4
D80B
J180J179 J182J181 J184J183 J186J185 J188J187 J190J189 J192J191 J194J193 J196J195 J198J197 J200J199 J202J201 J204J203 J206J205 J208J207 J210J209 J212J211 J214J213J176J175 J178J177
1 3
5
D81A
2 4
D81B
1 3
5
D82A
1 3
5
D83A
1 3
5
D84A
1 3
5
D85A
1 3
5
D86A
1 3
5
D87A
1 3
5
D88A
1 3
5
D89A
1 3
5
D90A
1 3
5
D91A
1 3
5
D92A
1 3
5
D93A
1 3
5
D94A
1 3
5
D95A
1 3
5
D96A
1 3
5
D97A
1 3
5
D98A
1 3
5
D99A
1 3
5
D100A
2 4
D82B
2 4
D83B
2 4
D84B
2 4
D85B
2 4
D86B
2 4
D87B
2 4
D88B
2 4
D89B
2 4
D90B
2 4
D91B
2 4
D92B
2 4
D93B
2 4
D94B
2 4
D95B
2 4
D96B
2 4
D97B
2 4
D98B
2 4
D99B
2 4
D100B
J221J220 J223J222 J225J224 J227J226 J229J228 J231J230 J233J232 J235J234 J237J236 J239J238 J241J240 J243J242 J245J244 J247J246 J249J248 J251J250 J253J252 J255J254J217J216 J219J218
1 3
5
D101A
2 4
D101B
1 3
5
D102A
1 3
5
D103A
1 3
5
D104A
1 3
5
D105A
1 3
5
D106A
1 3
5
D107A
1 3
5
D108A
1 3
5
D109A
1 3
5
D110A
1 3
5
D111A
1 3
5
D112A
1 3
5
D113A
1 3
5
D114A
1 3
5
D115A
1 3
5
D116A
1 3
5
D117A
1 3
5
D118A
1 3
5
D119A
1 3
5
D120A
2 4
D102B
2 4
D103B
2 4
D104B
2 4
D105B
2 4
D106B
2 4
D107B
2 4
D108B
2 4
D109B
2 4
D110B
2 4
D111B
2 4
D112B
2 4
D113B
2 4
D114B
2 4
D115B
2 4
D116B
2 4
D117B
2 4
D118B
2 4
D119B
2 4
D120B
MAX 200mA
4.99
R1
J46
OUTPUT5
J5
OUT5
MAX 200mA
4.99
R2
J88
OUTPUT4
J47
OUT4
MAX 200mA
4.99
R3
J131
OUTPUT3
J90
OUT3
MAX 200mA
4.99
R4
J173
OUTPUT2
J132
OUT2
MAX 200mA
4.99
R5
J215
OUTPUT1
J174
OUT1
MAX 200mA
4.99
R6
GND
VBOOST
Figure 6-1. LP886X-LEDLOAD-EVM Schematic
LED Load Board www.ti.com
14 LP8864 Evaluation Module SNVU731 – NOVEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated

Table 6-1. LP886X-LEDLOAD-EVM Bill of Materials
Designator QTY Part Number Manufacturer Description Package Reference
!PCB1 1 PSIL110 Printed Circuit Board
D1…D120 120 MLCAWT-A1-0000-000XE1 Cree Inc. LED XLAMP COOL WHITE 6500K 4SMD SMD4
H1, H2, H3, H4 4 NY PMS 440 0038 PH B&F Fastener Supply
H5, H6, H7, H8 4 1902C Keystone Standoff
H9, H10, H11, H12 4 4802 Keystone
H13 1 MCH050
Gray smoked plexiglass, 0.125" THK. Must
comply with REACH directive. Must meet or
exceed UL94-V0
7.53" X 4" X 0.125"
J7, J9...J43, J45; J49, J51...J85, J87;
J92, J94...J128, J130; J134, J136...J170,
J172; J176, J178...J212, J214; J217,
J219...J253, J255; J1, J3, J4, J5, J46,
J47, J88, J90, J131, J132, J173, J174,
J215
133 TSW-102-07-G-S Samtec Header, 100mil, 2x1, Gold, TH 2x1 Header
J2 1 TSW-107-07-G-S Samtec Header, 100mil, 7x1, Gold, TH 7x1 Header
J6, J8...J42, J44; J48, J50...J84, J86;
J91, J93...J127, J129; J133, J135...J169,
J171; J175, J177...J211, J213; J216,
J218...J252, J254
120 TSW-101-07-G-S Samtec Header, 100mil, 1pos, Gold, TH Testpoint
J89 1 TSW-105-07-G-S Samtec Header, 100mil, 5x1, Gold, TH 5x1 Header
R1, R2, R3, R4, R5, R6 6 CRCW12064R99FKEAHP Vishay Dale Res Thick Film 1206 4.99 Ohm 1% 0.75W(3/4W)
±100ppm/C Pad SMD Automotive T/R 1206
SH-J1...SH-J19 19 SPC02SYAN Sullins Connector
Solutions Shunt, 100mil, Flash Gold, Black Closed Top 100mil Shunt
FID1, FID2, FID3 0 N/A N/A Fiducial mark. There is nothing to buy or mount. N/A
www.ti.com LED Load Board
SNVU731 – NOVEMBER 2020
Submit Document Feedback
LP8864 Evaluation Module 15
Copyright © 2020 Texas Instruments Incorporated

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
WARNING
Evaluation Kits are intended solely for use by technically qualified,
professional electronics experts who are familiar with the dangers
and application risks associated with handling electrical mechanical
components, systems, and subsystems.
User shall operate the Evaluation Kit within TI’s recommended
guidelines and any applicable legal or environmental requirements
as well as reasonable and customary safeguards. Failure to set up
and/or operate the Evaluation Kit within TI’s recommended
guidelines may result in personal injury or death or property
damage. Proper set up entails following TI’s instructions for
electrical ratings of interface circuits such as input, output and
electrical loads.
NOTE:
EXPOSURE TO ELECTROSTATIC DISCHARGE (ESD) MAY CAUSE DEGREDATION OR FAILURE OF THE EVALUATION
KIT; TI RECOMMENDS STORAGE OF THE EVALUATION KIT IN A PROTECTIVE ESD BAG.

www.ti.com
2
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.

www.ti.com
3
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/
/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.

www.ti.com
4
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.
6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT
LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL
FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT
NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE
SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE
CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR
INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE
EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR
IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY
WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL
THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.

www.ti.com
5
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR
REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,
OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF
USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI
MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS
OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED
HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN
CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR
EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE
CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2019, Texas Instruments Incorporated
