Texas Instruments TPS51220A EVM-476 User manual

User’s Guide
TPS51220A Buck Controller Evaluation Module User's
Guide
Table of Contents
1 Introduction.............................................................................................................................................................................3
2 Description.............................................................................................................................................................................. 3
2.1 Typical Applications............................................................................................................................................................3
2.2 Features............................................................................................................................................................................. 3
3 Electrical Performance Specifications................................................................................................................................. 3
4 Schematic................................................................................................................................................................................5
5 Test Setup................................................................................................................................................................................6
5.1 Test Equipment.................................................................................................................................................................. 6
5.2 Recommended Test Setup.................................................................................................................................................6
5.3 List of Test Points............................................................................................................................................................... 7
6 Test Procedure........................................................................................................................................................................ 8
6.1 Line/Load Regulation and Efficiency Measurement Procedure......................................................................................... 8
6.2 Output Ripple Test..............................................................................................................................................................9
6.3 Measuring Improved Light Load Efficiency........................................................................................................................ 9
6.4 Control Architecture and OVP Select...............................................................................................................................10
6.5 Overcurrent Trip Level and Output Discharge Select.......................................................................................................10
7 Performance Data and Typical Characteristic Curves.......................................................................................................11
7.1 Efficiency.......................................................................................................................................................................... 11
7.2 Load Regulation............................................................................................................................................................... 11
7.3 Bode Plot..........................................................................................................................................................................12
7.4 Transient Response......................................................................................................................................................... 12
7.5 Output Ripple and Switch Node....................................................................................................................................... 13
7.6 Turn-On Waveform...........................................................................................................................................................13
7.7 Turn-Off Waveform...........................................................................................................................................................14
8 EVM Assembly Drawing and PCB Layout.......................................................................................................................... 15
9 List of Materials.....................................................................................................................................................................21
10 Revision History................................................................................................................................................................. 21
List of Figures
Figure 4-1. TPS51220A EVM-476 Schematic............................................................................................................................. 5
Figure 5-1. TPS51220A EVM-476 Recommended Test Setup....................................................................................................6
Figure 5-2. Recommended Tip and Barrel Technique to Measure Output Ripple Voltage.......................................................... 6
Figure 7-1. Efficiency, 12 VIN, 5.0-V Output............................................................................................................................... 11
Figure 7-2. Efficiency, 12 VIN, 3.3-V Output............................................................................................................................... 11
Figure 7-3. 12 VIN, 5.0-V Load Regulation.................................................................................................................................11
Figure 7-4. 12 VIN, 3.3-V Load Regulation.................................................................................................................................11
Figure 7-5. CCM mode 5-V Loop Response Gain and Phase, fCO = 95 kHz, PM = 48°........................................................... 12
Figure 7-6. CCM mode 3.3-V Loop Response Gain and Phase, fCO = 90 kHz, PM = 63°........................................................ 12
Figure 7-7. 5-V CCM Mode Load Transient...............................................................................................................................12
Figure 7-8. 5-V D-CAP Mode Load Transient............................................................................................................................12
Figure 7-9. 5-V CCM Mode Output Ripple and Switch Node.................................................................................................... 13
Figure 7-10. 3.3-V CCM Mode Output Ripple............................................................................................................................13
Figure 7-11. Enable Turn-On Waveform.................................................................................................................................... 13
Figure 7-12. Enable Turn-Off With Discharge Waveform.......................................................................................................... 14
Figure 7-13. Enable Turn-Off Without Discharge Waveform..................................................................................................... 14
Figure 8-1. Top Layer Assembly Drawing (Top View)................................................................................................................ 15
Figure 8-2. Bottom Assembly Drawing (Top View).................................................................................................................... 16
Figure 8-3. Top Copper (Top View)............................................................................................................................................ 17
Figure 8-4. Internal Layer 1 (Top View)......................................................................................................................................18
www.ti.com Table of Contents
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 1
Copyright © 2022 Texas Instruments Incorporated

Figure 8-5. Internal Layer 2 (Top View)......................................................................................................................................19
Figure 8-6. Bottom Copper (Top View)...................................................................................................................................... 20
List of Tables
Table 3-1. TPS51220A EVM-476 Electrical Performance Specifications.................................................................................... 3
Table 5-1. Test Point Functions Found on the TPS51220A EVM-476......................................................................................... 7
Table 6-1. SKIPSEL1 or SKIPSEL2 (jumpers JP1 and JP4) Selections......................................................................................9
Table 6-2. FUNC (jumper JP2) Selections.................................................................................................................................10
Table 6-3. TRIP (JP3) Selections...............................................................................................................................................10
Table 9-1. EVM Components List According to Schematic Shown in Figure 4-1 ..................................................................... 21
Trademarks
All trademarks are the property of their respective owners.
Trademarks www.ti.com
2TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

1 Introduction
This EVM utilizes Texas Instrument’s TPS51220A in a dual output design. The device includes many test points
to help the engineer monitor and evaluate the control characteristics of the TPS51220A. The TPS51220A is
a dual peak current mode synchronous buck controller with three linear regulators. The EVM also allows the
engineer to configure several of the features of the TPS51220A controller.
2 Description
The TPS51220A EVM-476 provides two 8-A outputs: 3.3 V and 5 V. It accepts an input voltage from 8 V to 20 V.
Several jumpers and switches allow the user to evaluate various control functions of the TPS51220A. Switches
provide an easy method to enable and disable the EVM or each of the two outputs independently. Two jumper
blocks allow the user to select the mode of operation of each output. One jumper block allows the engineer to
select the control architecture and OVP function. One block allows for selection of overcurrent trip level and if the
output is discharged by the converter. See the following sections for more details.
2.1 Typical Applications
• Notebook computers and I/O bus
• Point-of-load in such applications as digital TV and multi-function printers
2.2 Features
• Input range from 8 V to 20 V
• Dual 8-A outputs: 3.3 V and 5 V
• Individual enable function for 3.3-V and 5-V output
• Selectable light load operation
• Selectable control architecture
• Inductor current sensing
• OVP disable function
• Output discharge disable function
• Test points for easy access to measure key parameters
3 Electrical Performance Specifications
Table 3-1. TPS51220A EVM-476 Electrical Performance Specifications
PARAMETER TEST CONDITIONS MIN TYP MAX UNITS
Input Characteristics
Voltage range 8 12 20 V
Maximum input current 12 VIN, both outputs at 8 A 5.8 A
Output Characteristics
Output voltage, VOUT 1 5 V
Output load current, IOUT1 0 8 A
Output voltage regulation Line regulation: input voltage = 8 V to 20 V ±0.5%
Load regulation: output current = 0 A to 8 A ±1%
Output voltage ripple At IOUT1 = 8 A 50 mVpp
Output over current 12 A
Switching frequency 330 kHz
Peak efficiency 97.8%
Full load efficiency 96.9%
Output voltage, VOUT 2 3.3 V
Output load current, IOUT2 0 8 A
Output voltage regulation Line regulation: input voltage = 8 V to 20 V ±0.5%
Load regulation: output current = 0 A to 8 A ±1%
Output voltage ripple At IOUT = 8 A 50 mVpp
Output over current 12 A
Switching frequency 330 kHz
www.ti.com Introduction
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 3
Copyright © 2022 Texas Instruments Incorporated

Table 3-1. TPS51220A EVM-476 Electrical Performance Specifications (continued)
PARAMETER TEST CONDITIONS MIN TYP MAX UNITS
Peak efficiency 96%
Full load efficiency 95%
Electrical Performance Specifications www.ti.com
4TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

4 Schematic
+ + ++ + +
Figure 4-1. TPS51220A EVM-476 Schematic
www.ti.com Schematic
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 5
Copyright © 2022 Texas Instruments Incorporated

5 Test Setup
5.1 Test Equipment
Voltage Source: The power source must be capable of supplying 8 VDC to 20 VDC at up to 10 A.
Multimeters: A minimum of three voltage meters are required. Other voltage meters can be used to monitor
some of the test points.
Output Load: Two constant current electronic loads are recommended. They must be able to sink up to 10 A
when the output is 3.3 V or 5 V.
Oscilloscope: A minimum 50-MHz digital oscilloscope and a voltage probe is required. The scope can be used
to measure output ripple and monitor some of the test points.
Fan: A fan is not required when testing the EVM.
Recommended Wire Gauge: Both loads and input should be connected using a minimum gauge wire of
AWG#16. Also these connections should be kept as short as possible.
5.2 Recommended Test Setup
V1
V3V4
V5
V6
12V/10A
DC Power
Source
+
-
V2
Electronic
Load #2.
3.3V/8A
+
-
Electronic
Load #1.
5V/8A
+
-
Figure 5-1. TPS51220A EVM-476 Recommended Test Setup
TP7
(TP8)
TP2
(TP3)
Metal Ground
Barrel
Probe Tip
Figure 5-2. Recommended Tip and Barrel Technique to Measure Output Ripple Voltage
Test Setup www.ti.com
6TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

5.3 List of Test Points
Table 5-1. Test Point Functions Found on the TPS51220A EVM-476
TEST POINT NAME DESCRIPTION
TP1 VIN Measurement point for input voltage with respect to TP18
TP2 VOUT1 Measurement point for output 1 voltage with respect to TP7
TP3 VOUT2 Measurement point for output 2 voltage with respect to TP8
TP4 SW1 Output 1 switch node with respect to TP20
TP5 VREG5 5-V/100-mA output, enabled EN is high, use switch S3
TP6 SW2 Output 2 switch node with respect to TP21
TP7 GND1 Ground reference for VOUT1
TP8 GND2 Ground reference for VOUT2
TP9 VREG3 3.3-V/10-mA output should be present when input voltage is applied to EVM.
TP10 EN1 Output 1 enable signal, will be high when output is enabled via switch S1
TP11 EN2 Output 2 enable signal, will be high when output is enabled via switch S2
TP12 PG1 Output 1 power good signal, will be high when output is in regulation
TP13 PG2 Output 2 power good signal, will be high when output is in regulation
TP14 EN 5-V and 2-V reference enable signal, high when EVM is enabled with switch S3
TP15 VREF2 2-V internal reference, enabled when EN is high, use switch S3
TP16 – Not used
TP17 – Not used
TP18 GNDIN Ground reference for VIN
TP19 GNDS General ground
TP20 GND Ground reference for SW1
TP21 GND Ground reference for SW2
TP22 GND General ground
TP23 GND General ground
TP24 SYNC Not used
www.ti.com Test Setup
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 7
Copyright © 2022 Texas Instruments Incorporated

6 Test Procedure
6.1 Line/Load Regulation and Efficiency Measurement Procedure
1. Ensure the switches S1 (EN1), S2 (EN2), and S3 (EN) are in the “OFF” position.
2. Ensure the shunt jumper are set as follows, see Section 6.3, Section 6.4, and Section 6.5 for details on how
to change these settings:
a. JP1 (SKIPSEL1): jumper 3 pin to 4 pin (AS)
b. JP2 (FUNC): jumper 1 pin to 2 pin (CMODE_ON)
c. JP3 (TRIP): jumper 7 pin to 8 pin (LV_D-ON)
d. JP4 (SKIPSEL2): jumper 3 pin to 4 pin (AS)
3. Set the DC power source current limit to 10 A. Increase VIN voltage from 0 V to 8 VDC. V3 should be used
to verify VIN.
4. Measure VREG3 (TP9) voltage using V4. It should be between 3.2 V and 3.4 V.
5. Set S3 (EN) to “ON” position. Measure VREG5 (TP5) voltage using V5, it should read between 4.9 V and 5.1
V. Measure VREF2 (TP15) voltage using V6, it should read 1.98 V to 2.02 V.
6. Make sure electronic load #1 is set to sink 0 A. Set S1 (EN1) to “ON” position, S3 remains in “ON” position.
7. Record VOUT1 voltage using V1, IOUT1 current, VIN using V3 and input current from source.
8. Increase electronic load #1’s current in 0.5-A steps from 0 A to 8 A, Record VOUT1 voltage using V1, IOUT1
current, VIN using V3 and input current from source for each step.
9. Set input voltage to 20 V.
10. Reduce the current of electronic load #1 from 8 A to 0 A, the current electronic load #1 in 0.5-A steps from
0 A to 8 A. Record VOUT1 voltage using V1, IOUT1 current, VIN using V3 and input current from source for
each step.
11. Similar technique can be used for VOUT2. Use S2 to enable VOUT2.
Test Procedure www.ti.com
8TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

6.2 Output Ripple Test
1. Use steps 1 to 6 of Section 6.1 to start output.
2. Set up the scope as follows:
a. HORIZONTAL SWEEP: 2 μs/div
b. TRIGGER MODE: auto, rising edge
c. TRIGGER SOURCE: Ch1
d. CH1: 50 mV/div, AC coupled, bandwidth 20 MHz
3. Use the tip and barrel technique shown in Figure 5-2 to probe VOUT1 and VOUT2 during test procedure.
6.3 Measuring Improved Light Load Efficiency
1. All jumper modifications should be done with no power applied to the EVM
2. SKIPSEL1 and SKIPSEL2 allow the user to select how the EVM operates when in light load. Table 6-1
describes each possible selection.
Table 6-1. SKIPSEL1 or SKIPSEL2 (jumpers JP1 and JP4) Selections
JUMPER LOCATION MODE DESCRIPTION
CCM (1 and 2 shorted) CCM EVM remains in continuous current mode
AS (3 and 4 shorted) default Auto-skip EVM enters auto skip mode at light load, audible noise may
be heard.
OOA_L (5 and 6 shorted) OOA (< 400 kHz) EVM enters skip mode with no audible noise
OOA_H (7 and 8 shorted) OOA (> 400 kHz) Not recommended
3. Once a mode has been selected, efficiency and regulation measurements may be retaken. Repeat steps 3
to 11 of Section 6.1. The engineer should reduce the step current when the output is less than 1 A. Section 7
shows typical data for the various modes of operation
www.ti.com Test Procedure
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 9
Copyright © 2022 Texas Instruments Incorporated

6.4 Control Architecture and OVP Select
1. All jumper modifications should be done with no power applied to the EVM.
2. The FUNC jumper (JP2) allows the user to select the control architecture the EVM uses to control the output.
It also enables or disables the OVP function. Table 6-2 describes each possible selection.
Table 6-2. FUNC (jumper JP2) Selections
JUMPER LOCATION MODE
CMODE_ON (1 and 2 shorted) default Current mode control and OVP enabled
DCAP_OFF (3 and 4 shorted) D-Cap mode control and OVP disabled
DCAP_ON (5 and 6 shorted) D-Cap mode control and OVP enabled
CMODE_OFF (7 and 8 shorted) Current mode control and OVP disabled
3. Once a mode has been selected efficiency and regulation measurements may be retaken. Repeat steps 3 to
11 of Section 6.1. The engineer should reduce the step current when the output is less than 1 A. Section 7
shows typical data for the various modes of operation
6.5 Overcurrent Trip Level and Output Discharge Select
1. All jumper modifications should be done with no power applied to the EVM.
2. The TRIP jumper (JP3) allows the user to select the voltage level used by the EVM to implement current
limit. It also enables or disables the output discharge function. Table 6-3 describes each possible selection.
Table 6-3. TRIP (JP3) Selections
JUMPER LOCATION MODE
UL_D-ON (1 and 2 shorted) Overcurrent uses ultra low voltage threshold (31 mV typical) and output
discharge is enabled
UL_OFF (3 and 4 shorted) Overcurrent uses ultra low voltage threshold (31 mV typical) and output
discharge is disabled
LV_OFF (5 and 6 shorted) Overcurrent uses low voltage threshold (60 mV typical) and output discharge is
disabled
LV_D-ON (7 and 8 shorted) default Overcurrent uses low voltage threshold (60 mV typical) and output discharge is
enabled
3. Once a mode has been selected efficiency and regulation measurements may be retaken. Repeat steps 3 to
11 of Section 6.1. The engineer should reduce the step current when the output is less than 1 A. Section 7
shows typical data for the various modes of operation
Test Procedure www.ti.com
10 TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

7 Performance Data and Typical Characteristic Curves
7.1 Efficiency
0.01 0.10 1.00 10.00
ILOAD - Load Current - A
0
20
40
60
80
100
10
30
50
70
90
h- Efficiency - %
AUTOSKIP
OOA
CCM
Figure 7-1. Efficiency, 12 VIN, 5.0-V Output
0.01 0.10 1.00 10.00
ILOAD - Load Current - A
0
20
40
60
80
100
10
30
50
70
90
h- Efficiency - %
AUTOSKIP
OOA
CCM
Figure 7-2. Efficiency, 12 VIN, 3.3-V Output
7.2 Load Regulation
0 3 6 9
ILOAD - Load Current - A
4.95
4.97
4.99
5.01
5.03
5.05
4.96
4.98
5.00
5.02
5.04
VOUT - Output Voltage - V
875421
AUTOSKIP
OOA
CCM
Figure 7-3. 12 VIN, 5.0-V Load Regulation
0 3 6 9
ILOAD - Load Current - A
3.25
3.26
3.28
3.29
3.32
3.27
3.30
3.31
VOUT - Output Voltage - V
875421
AUTOSKIP
OOA
CCM
Figure 7-4. 12 VIN, 3.3-V Load Regulation
www.ti.com Performance Data and Typical Characteristic Curves
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 11
Copyright © 2022 Texas Instruments Incorporated

7.3 Bode Plot
1 10 100 1000
Frequency - kHz
-40
-10
10
40
-30
-20
0
20
30
Gain - dB
-45
0
90
135
45
Phase - o
Gain
Phase
Figure 7-5. CCM mode 5-V Loop Response Gain
and Phase, fCO = 95 kHz, PM = 48°
1 10 100 1000
Frequency - kHz
-40
-10
10
40
-30
-20
0
20
30
Gain - dB
-45
0
90
135
45
Phase - o
Gain
Phase
Figure 7-6. CCM mode 3.3-V Loop Response Gain
and Phase, fCO = 90 kHz, PM = 63°
7.4 Transient Response
Figure 7-7. 5-V CCM Mode Load Transient Figure 7-8. 5-V D-CAP Mode Load Transient
Performance Data and Typical Characteristic Curves www.ti.com
12 TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

7.5 Output Ripple and Switch Node
Figure 7-9. 5-V CCM Mode Output Ripple and
Switch Node
Figure 7-10. 3.3-V CCM Mode Output Ripple
7.6 Turn-On Waveform
Figure 7-11. Enable Turn-On Waveform
www.ti.com Performance Data and Typical Characteristic Curves
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 13
Copyright © 2022 Texas Instruments Incorporated

7.7 Turn-Off Waveform
Figure 7-12. Enable Turn-Off With Discharge
Waveform
Figure 7-13. Enable Turn-Off Without Discharge
Waveform
Performance Data and Typical Characteristic Curves www.ti.com
14 TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

8 EVM Assembly Drawing and PCB Layout
The following figures (Figure 8-1 through Figure 8-6) show the design of the TPS51220A EVM-476 printed circuit
board. The PCB is 0.062” thick. It uses four layers of copper. The two internal layers are 2-oz copper while the
external layers are 1-oz copper.
Figure 8-1. Top Layer Assembly Drawing (Top View)
www.ti.com EVM Assembly Drawing and PCB Layout
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 15
Copyright © 2022 Texas Instruments Incorporated

Figure 8-2. Bottom Assembly Drawing (Top View)
EVM Assembly Drawing and PCB Layout www.ti.com
16 TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

Figure 8-3. Top Copper (Top View)
www.ti.com EVM Assembly Drawing and PCB Layout
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 17
Copyright © 2022 Texas Instruments Incorporated

Figure 8-4. Internal Layer 1 (Top View)
EVM Assembly Drawing and PCB Layout www.ti.com
18 TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

Figure 8-5. Internal Layer 2 (Top View)
www.ti.com EVM Assembly Drawing and PCB Layout
SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
TPS51220A Buck Controller Evaluation Module User's Guide 19
Copyright © 2022 Texas Instruments Incorporated

Figure 8-6. Bottom Copper (Top View)
EVM Assembly Drawing and PCB Layout www.ti.com
20 TPS51220A Buck Controller Evaluation Module User's Guide SLUU381B – SEPTEMBER 2009 – REVISED FEBRUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
