Texas Instruments CC3220 User manual

1
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
User's Guide
SWRU463C–February 2017–Revised March 2020
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development
Kit Hardware
The CC3220 device is part of the SimpleLink™ microcontroller (MCU) platform which consists of Wi-Fi®,
Bluetooth®low energy, Sub-1 GHz, and host MCUs. All share a common, easy-to-use development
environment with a single core software development kit (SDK) and rich tool set. A one-time integration of
the SimpleLink platform lets you add any combination of devices from the portfolio into your design. The
ultimate goal of the SimpleLink platform is to achieve 100 percent code reuse when your design
requirements change. For more information, visit www.ti.com/simplelink.
The CC3220 SimpleLink LaunchPad™ development kit (CC3220-LAUNCHXL) is a low-cost evaluation
platform for Arm®Cortex®-M4-based MCUs. The LaunchPad kit design highlights the CC3220 Internet-on-
a chip™ solution and Wi-Fi capabilities. The CC3220 LaunchPad kit also features temperature and
accelerometer sensors, programmable user buttons, three LEDs for custom applications, and onboard
emulation for debugging. The stackable headers of the CC3220 LaunchPad XL interface demonstrate how
easy it is to expand the functionality of the LaunchPad kit when interfacing with other peripherals on many
existing BoosterPack™ plug-in module add-on boards, such as graphical displays, audio codecs, antenna
selection, environmental sensing, and more.
Figure 1 shows the CC3220 LaunchPad development kit.
Figure 1. CC3220 SimpleLink Wi-Fi LaunchPad Development Kit

www.ti.com
2SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
Contents
1 Introduction ................................................................................................................... 4
1.1 CC3220 LaunchPad Development Kit ........................................................................... 4
1.2 Key Features ....................................................................................................... 5
1.3 What's Included .................................................................................................... 5
1.4 Regulatory Compliance ............................................................................................ 5
1.5 First Steps: Out-of-Box Experience .............................................................................. 5
1.6 Next Steps: Looking into the Provided Code.................................................................... 6
2 Hardware Description ....................................................................................................... 7
2.1 Block Diagram ...................................................................................................... 8
2.2 Hardware Features ................................................................................................. 8
2.3 Connecting a BoosterPack Plug-in Module ..................................................................... 9
2.4 XDS110-Based JTAG Emulator ................................................................................ 10
2.5 Wired Connections, Jumper Settings, Buttons, and LEDs................................................... 10
2.6 Power ............................................................................................................... 20
2.7 Isolated Current Measurement of the CC3220 ............................................................... 23
2.8 RF Connections ................................................................................................... 25
2.9 Assembly Drawing ................................................................................................ 26
2.10 Design Files........................................................................................................ 27
2.11 Software ............................................................................................................ 27
3 Development Environment Requirements .............................................................................. 27
3.1 CCS IDE............................................................................................................ 27
3.2 IAR IDE............................................................................................................. 27
4 Additional Resources ...................................................................................................... 27
4.1 CC3220 Product Page............................................................................................ 27
4.2 LaunchPad Development Kit Wiki............................................................................... 27
4.3 Download a Development Environment........................................................................ 28
4.4 SimpleLink™ Academy for CC3220 SDK ..................................................................... 28
4.5 Support Resources................................................................................................ 28
List of Figures
1 CC3220 SimpleLink Wi-Fi LaunchPad Development Kit .............................................................. 1
2 WEEE Statement ............................................................................................................ 4
3 CC3220 LaunchPad Development Kit Overview ........................................................................ 7
4 CC3220 Block Diagram..................................................................................................... 8
5 Pin 1 Marking on CC3220LP (3V3 Tag).................................................................................. 9
6 XDS-110 Debug Probe ................................................................................................... 10
7 Default Jumper Configuration for JTAG Lines.......................................................................... 10
8 JTAG IN Connector (J8)................................................................................................... 11
9 XDS110 OUT Connector (J4) ............................................................................................ 12
10 I2C Bus Connections....................................................................................................... 13
11 Power Jumpers J14, J21, J20, J19, J17, and J18..................................................................... 14
12 SOP Jumpers (Default Setting Shown) ................................................................................. 16
13 UART Routed to USB COM Port......................................................................................... 17
14 UART Routed to 20-Pin Header Connector ............................................................................ 17
15 CC3220 BoosterPack Module Header Pin Assignments ............................................................. 19
16 Powering From USB Jumper Settings................................................................................... 20
17 Powering the CC3220LP From Battery ................................................................................. 21
18 Only CC3220 and Serial Flash Powered by Battery................................................................... 22
19 Low-Current Measurement (<1 mA)..................................................................................... 23
20 Active Power Measurements (>1 mA)................................................................................... 24
21 Using Onboard Antenna (Default Condition) ........................................................................... 25

www.ti.com
3
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
22 Board Modified for External Antenna Connections.................................................................... 25
23 CC3220x LaunchPad Kit Top-Layer Assembly Drawing.............................................................. 26
24 CC3220 SimpleLink Academy............................................................................................ 28
List of Tables
1 JTAG Header Pin Definitions............................................................................................. 11
2 I2C Jumper Definitions..................................................................................................... 13
3 Default I2C Addresses (of Onboard Sensors) .......................................................................... 14
4 Jumper Settings for LaunchPad Kit Power ............................................................................. 15
5 External Supply Connections and LED Enable Jumper............................................................... 15
6 Reset Pullup Jumper....................................................................................................... 15
7 SOP[2:0] (J13 on LaunchPad Kit)........................................................................................ 16
8 Push-Button Definitions ................................................................................................... 18
9 LED Indicators.............................................................................................................. 18
Trademarks
SimpleLink, LaunchPad, Internet-on-a chip, BoosterPack, Code Composer Studio, Tiva, E2E are
trademarks of Texas Instruments.
Arm, Cortex are registered trademarks of Arm Limited.
Bluetooth is a registered trademark of Bluetooth SIG.
IAR Embedded Workbench is a registered trademark of IAR Systems AB.
Wi-Fi is a registered trademark of Wi-Fi Alliance.
All other trademarks are the property of their respective owners.

Introduction www.ti.com
4SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
1 Introduction
1.1 CC3220 LaunchPad Development Kit
Created for the Internet of Things (IoT), the SimpleLink Wi-Fi CC3220 device is a single-chip
microcontroller (MCU) with built-in Wi-Fi connectivity for the LaunchPad ecosystem, which integrates a
high-performance Arm Cortex-M4 MCU and lets customers develop an entire application with one device.
With on-chip Wi-Fi, Internet, and robust security protocols, no prior Wi-Fi experience is required for fast
development.
The CC3220 LaunchPad kit, referred to by its part number CC3220-LAUNCHXL, is a low-cost evaluation
platform for Arm Cortex-M4-based MCUs. The LaunchPad kit design highlights the CC3220 Internet-on-a
chip solution and Wi-Fi capabilities. The CC3220 LaunchPad kit also features temperature and
accelerometer sensors, programmable user buttons, three LEDs for custom applications, and onboard
emulation for debugging. The stackable headers of the CC3220 LaunchPad XL interface demonstrate how
easy it is to expand the functionality of the LaunchPad kit when interfacing with other peripherals on many
existing BoosterPack add-on boards, such as graphical displays, audio codecs, antenna selection,
environmental sensing, and more. Figure 3 shows the CC3220 LaunchPad kit. There are two variants of
the LaunchPad kit: the CC3220S-LAUNCHXL and the CC3220SF-LAUNCHXL. This user's guide applies
to both variants, and any differences are pointed out in relevant sections.
Multiple development environment tools are also available, including TI’s Eclipse-based Code Composer
Studio™ (CCS) integrated development environment (IDE) and IAR Embedded Workbench®. More
information about the LaunchPad kit, the supported BoosterPack modules, and the available resources
can be found at TI’s LaunchPad portal. Also visit the CC3220 Wiki page for design resources and example
projects.
NOTE: The maximum RF power transmitted in each WLAN 2.4-GHz band is 17.5 dBM (EIRP
power).
NOTE: The antennas used for this transmitter must be installed to provide a separation distance of
at least 20 cm from all persons, and must not be colocated or operating in conjunction with
any other antenna or transmitter.
NOTE: All figures and references in this document apply to RevA and RevB. Most of the document
also applies to higher revisions, unless otherwise stated.
Figure 2. WEEE Statement

www.ti.com Introduction
5
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
1.2 Key Features
• CC3220S/SF, SimpleLink Wi-Fi, Internet-on-a chip solution with integrated MCU
• 40-pin LaunchPad standard that leverages the BoosterPack ecosystem
• XDS110-based JTAG emulation with serial port for flash programming
• Two buttons and three LEDs for user interaction
• Back-channel universal asynchronous receiver/transmitter (UART) through USB to PC
• Onboard chip antenna with U.FL for conducted testing
• Onboard accelerometer and temperature sensor for Out-of-Box Experience (OOBE)
• Micro USB connector for power and debug connections
1.3 What's Included
1.3.1 Kit Contents
• CC3220 LaunchPad development tool (CC3220S-LAUNCHXL or CC3220SF-LAUNCHXL)
• Micro USB cable
• Quick start guide
1.3.2 Software Examples
• Out-of-Box Software
1.4 Regulatory Compliance
The SimpleLink CC3220 Wi-Fi LaunchPad kit is tested for and found to be in compliance with FCC and
ISED regulations regarding unlicensed intentional radiators.
Hereby, Texas Instruments Inc. declares that the radio equipment type CC3220S-LAUNCHXL and
CC3220SF-LAUNCHXL are in compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet addresses:
•CC3220S-LAUNCHXL
•CC3220SF-LAUNCHXL
1.5 First Steps: Out-of-Box Experience
An easy way to get started with the EVM is by using its preprogrammed out-of-box code. It demonstrates
some key features of the EVM.
1.5.1 Connecting to the Computer
Connect the LaunchPad development kit by connecting the included USB cable to a computer. A red
power LED should illuminate. For proper operation, the SimpleLink drivers and Service Pack from the
CC3220 Software Development Kit (SDK) are needed. The SDK is available at
www.ti.com/tool/SIMPLELINK-CC3220-SDK.

Introduction www.ti.com
6SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
1.5.2 Running the Out-of-Box Experience
The CC3220 LaunchPad development kit's Out-of-Box Experience (OOBE) demonstrates and highlights
the following features:
• Easy connection to the CC3220 LaunchPad kit:
– Using the SimpleLink Wi-Fi Starter Pro application (available on iOS and Android™), users can use
Access Point (AP) provisioning or SmartConfig™ provisioning for a fast CC3220 connection.
– Configuring the device in AP mode gives users a direct connection to the CC3220 LaunchPad kit.
Once the device is provisioned and connected to an AP in station mode, the profile is stored on the
local file system so that any reset to the CC3220 automatically connects it to the AP.
• Easy access to the CC3220 through its internal web server, using either:
– The SimpleLink Wi-Fi Starter Pro application
– Any browser; web pages stored on the serial flash are loaded on the browser, to provide ease of
use.
This feature demonstrates configuring and reading onboard sensors.
• Over-The-Air (OTA) updates that demonstrate an update of a full image. OTA service enables in-
system updates of the MCU application, CC3220 firmware releases (Service Pack) made available by
TI, and other vendor files. An update procedure executed in a full-system integrity fashion, such as
failure to upgrade any image components, results in rolling back to the previous valid version.
See the CC3220 LaunchPad Out-of-Box User's Guide for more details on the Out-of-Box Experience.
1.6 Next Steps: Looking into the Provided Code
After the EVM features have been explored, the user can open an integrated development environment
and start editing the code examples from the SDK. See Section 4.3 for available IDEs and where to
download them. The Out-of-Box source code and more code examples are provided in the CC3220 SDK.
Code is licensed under BSD, and TI encourages reuse and modifications to fit specific needs.
With the onboard XDS110 debug probe, debugging and downloading new code is simple. A USB
connection between the EVM and a PC through the provided USB cable is all that is needed.

www.ti.com Hardware Description
7
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2 Hardware Description
Figure 3 shows the CC3220 LaunchPad kit.
Figure 3. CC3220 LaunchPad Development Kit Overview

CC3220
S-Flash
32Mbit
40-MHz XTAL
32.768-kHz XTAL
XDS110 JTAG
Debug Probe
USB
Conn
Filter
Acceleration
Sensor
BMA222
Temp Sensor
TMP006
3.3-V LDO
2× AA Battery
Conn
Reverse
Protection
5 V
5 V
VCC
Push Buttons
GPIO 13, 22 LEDs
GPIO 9,10,11
2× 20 Launchpad Headers
(Compatible with TI MCU Std)
JTAG/SWD
UART (Flashing/Log)
INT (GPIO13)
I2C
U. FL
Copyright © 2017, Texas Instruments Incorporated
Hardware Description www.ti.com
8SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.1 Block Diagram
Figure 4 shows the CC3220 block diagram.
Figure 4. CC3220 Block Diagram
2.2 Hardware Features
• CC3220S/SF, SimpleLink Wi-Fi, Internet-on-a chip solution with integrated MCU
• 40-pin LaunchPad standard that leverages the BoosterPack ecosystem
• TI Standard XDS110-based JTAG emulation with serial port for flash programming
• Supports both 4-wire JTAG and 2-wire SWD
• Two buttons and three LEDs for user interaction
• Back-channel universal asynchronous receiver/transmitter (UART) through USB to PC
• Onboard chip antenna with U.FL for conducted testing selectable using 0-Ωresistors
• Onboard accelerometer and temperature sensor for Out-of-Box Experience, with option to isolate them
from the inter-integrated circuit (I2C) bus
• Micro USB connector for power and debug connections
• Headers for current measurement and external JTAG connection with an option to use the onboard
XDS110 to debug customer platforms
• Bus-powered device, with no external power required for Wi-Fi
• Long-range transmission with a highly optimized antenna (200-meter typical in open air with a 6-dBi
antenna AP)
• Can be powered externally, working down to 2.3 V (typical)

www.ti.com Hardware Description
9
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.3 Connecting a BoosterPack Plug-in Module
A compatible BoosterPack module can be stacked on top of the LaunchPad kit using the 2-pin × 20-pin
connectors. The connectors do not have a key to prevent the misalignment of the pins or reverse
connection.
Ensure that the VCC and 5-V pins are aligned with the BoosterPack module header pins. On the CC3220
LaunchPad kit, a small white 3V3 tag symbol is provided near pin 1 (see Figure 5) to orient all
BoosterPack modules. This same marking, provided on compatible BoosterPack modules, must be
aligned before powering up the boards.
Figure 5. Pin 1 Marking on CC3220LP (3V3 Tag)

Hardware Description www.ti.com
10 SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.4 XDS110-Based JTAG Emulator
To keep development easy and cost effective, TI's LaunchPad development kits integrate an onboard
debug probe, which eliminates the need for expensive programmers. The CC3220 LaunchPad kit has the
XDS-110-based debug probe (see Figure 6), which is a simple and low-cost debugger that supports
nearly all TI Arm device derivatives.
Figure 6. XDS-110 Debug Probe
2.5 Wired Connections, Jumper Settings, Buttons, and LEDs
2.5.1 JTAG Headers
The headers are provided on the board to isolate the CC3220 device from the onboard XDS110-based
JTAG emulator. These jumpers are shorted by default when the board is shipped from TI. Figure 7 and
Table 1 are for default configurations, and Figure 8 shows the external emulator connection.
Figure 7. Default Jumper Configuration for JTAG Lines

www.ti.com Hardware Description
11
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
(1) The only difference between Rev. A and Rev. B are the reference designators on the board.
(2) For SWD mode, the TCK and TMS headers must be shorted.
Table 1. JTAG Header Pin Definitions
Reference (Rev.
A/C) Reference (Rev. B)(1) Use Comments
J3 (TCK)(2) J8 (TCK) JTAG / SWD
Jumpers populated: onboard emulator connected
Jumpers not populated: onboard emulator disconnected
J3 (TMS)(2) J8 (TMS) JTAG / SWD
J3 (TDI) J8 (TDI) JTAG
J3(TDO) J8 (TDO) JTAG
To connect an external emulator, remove these jumpers and place the external emulator on the JTAG IN
connector.
Figure 8. JTAG IN Connector (J8)

Hardware Description www.ti.com
12 SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.5.2 Using the XDS110 Debug Probe With a Different Target
The XDS110 debug probe on the LaunchPad development kit can interface to most Arm Cortex-M
devices, not just the onboard target CC3220 device. This functionality is enabled by the J4 10-pin Cortex-
MJTAG connector (See Figure 9) and a 10-pin cable, such as the FFSD-05-D-06.00-01-N (sold
separately from the LaunchPad development kit).
Figure 9. XDS110 OUT Connector (J4)
Header J4 follows the Cortex-M Arm standard; however, pin 1 is not a voltage sense pin. The XDS110
outputs only 3.3-V JTAG signals. If another voltage level is needed, the user must provide level shifters to
translate the JTAG signal voltages.
1. Remove jumpers on the JTAG signals on the isolation block, including RST, TMS, TCK, TDO, and TDI.
2. Plug the 10-pin cable into J4, and connect to an external target.
a. J4 follows the Arm Cortex Debug Connector standard outlined in Cortex-M Debug Connectors.
3. Plug USB power into the LaunchPad development kit, or power it externally.
a. JTAG levels are 3.3-V ONLY

www.ti.com Hardware Description
13
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.5.3 I2C Connections
The board features an accelerometer and a temperature sensor for the out-of-box demo. These are
connected to the I2C bus, and can be isolated using the jumpers provided (shown as yellow jumpers J15
and J16 in Figure 10).
Figure 10. I2C Bus Connections
By removing J15 and J16, the accelerometer and the temperature sensors are isolated from the I2C bus.
This measure also removes the I2C pullup resistors from the sensor side of the circuit, and therefore any
connection to the circuit requires the user to install external pullup resistors.
Table 2 lists the I2C jumper definitions.
Table 2. I2C Jumper Definitions
Reference (Rev.
A/C) Reference (Rev. B) Use Comments
J16 J2 I2C SDA Populated: CC3220 SDA connected to onboard sensors with
pullup
Open: CC3220 SDA disconnected from onboard sensors
J15 J3 I2C SCL Populated: CC3220 SCL connected to onboard sensors with
pullup
Open: CC3220 SCL disconnected from onboard sensors

Hardware Description www.ti.com
14 SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.5.3.1 Default I2C Addresses
Table 3 lists the default I2C addresses of the onboard sensors.
(1) The TMP116 on Rev. C LaunchPad kits replaced the TMP006 (slave address: 0x41) on Rev. A and B.
Table 3. Default I2C Addresses (of Onboard Sensors)
Sensor Type Reference Designator
on LP (Rev. A/C) Reference Designator on LP (Rev. B) Part Number (Manufacturer) Default Slave Address (Hex)
Temperature (MEMS
IR Thermopile) U10 U6 TMP116(1) (TI) 0x49
Accelerometer
(Triaxial) U11 U10 BMA222E (Bosch) 0x18
2.5.4 Power Connections
The board can be powered by using the onboard micro USB connector. An onboard DC-DC converter
provides 3.3 V for the CC3220 and the rest of the board to operate. This supply can be isolated from the
DC-DC using the jumpers on the board. See the yellow jumpers in Figure 11.
Figure 11. Power Jumpers J14, J21, J20, J19, J17, and J18
NOTE: The blue jumpers in Figure 11 are previously discussed (see Section 2.5.1) and are
populated by default. Figure 11 does not show unpopulated jumpers (which would be
populated normally).

www.ti.com Hardware Description
15
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
Table 4 lists the jumper settings for the LaunchPad kit power.
Table 4. Jumper Settings for LaunchPad Kit Power
Reference
(Rev. A) Reference (Rev. B) Use Comments
J14 J5 OPAMP EN
If the jumper is uninstalled, the power supply to the OPAMP is cut off. This
can be used to enable low-current measurements. Ensure that this jumper
is on to use the OPAMP to drive the input to the ADC. The reference
voltage of the ADC is 1.47 V, so up to 3.48 V can be applied to the input of
the OPAMP. For the configuration of the OPAMP, see the CC3220
LaunchPad Kit Design Files.
J21 J10 GND Ground reference
J20 J29 +5 VDC power
jumper Connects J19, +5 VDC to emulator section
J19 J12 Current measurement Measures the current flowing into the CC3220 device and the serial flash.
J17 J13 Board power Short: Supply the board power from the onboard DC-DC converter. The board power includes the sensors, LED, and the OPAMP used to drive the
ADC input.
J18 J28 VSENSE Used to power the level shifters on the emulator side of the board. The level shifters can be powered by shorting this jumper. Removing this jumper
enables low-current measurement.
The board can be powered by an external supply when USB power is not available, by using either J22 or
J23. J24 is also available to remove any current draw from LEDs being driven by the GPIOs, see Table 5.
Table 5. External Supply Connections and LED Enable Jumper
Reference
(Rev. A/C) Reference (Rev. B) Use Comments
J19 J12 Alternative 3.3-V
power input Can be used to power the board from an external 3.3-V supply; this can be
used to test the VBAT voltage range as the reverse voltage protection diode
on J22 drops the input by approximately 150 mV.
J23 J19 5-V power input Used to power the board from an external 5-V supply.
J22 J20 3.3-V power input Used to power the board from an external 3.3-V supply. J22 has built-in reverse voltage protection to prevent the battery from being plugged in the
reverse manner.
J24 J9 LED EN If uninstalled, the LEDs connected to the GPIO are disabled; this can be
used to enable low-power measurements.
2.5.5 Reset Pullup Jumper
Table 6 lists the reset pullup jumper.
Table 6. Reset Pullup Jumper
Reference
(Rev. A/C) Reference (Rev. B) Use Comments
J9 J26 RESET pullup Install this jumper to enable the pullup resistor on the nRESET pin of the
device, when the board is powered from an external supply.

Hardware Description www.ti.com
16 SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.5.6 Sense on Power (SOP)
The CC3220 can be set to operate in four different modes, based on the state of the sense-on-power
(SOP) lines. These SOP lines are pins 21, 34, and 35 on the CC3220 device. Table 7 describes the state
of the device, and Figure 12 shows the SOP jumpers.
Table 7. SOP[2:0] (J13 on LaunchPad Kit)
Binary
Value Function
000 Functional mode and 4-wire JTAG
001 Functional mode and 2-wire JTAG
010 Functional mode and flash programming
011 Factory default
100 Flash programming
Figure 12. SOP Jumpers (Default Setting Shown)
NOTE: SOP[2:0] corresponds to J13 in the LaunchPad kit schematic design.
NOTE: No jumpers on the block ensure that the line is pulled low using 100-kΩpulldown resistors.
Placing the jumper pulls the pin high using a 270-Ωresistor.

www.ti.com Hardware Description
17
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.5.7 UART Signals
The board supports a USB-based virtual COM port, using the Tiva™ Arm MCU. The LaunchPad kit is
shipped with the UART lines from the CC3220 connected to the UART on the Tiva MCU. The CC3220
UART TX can also be routed to the 20-pin connector for use as a GPIO or external UART. The selection
is performed using jumpers on the board. The RX signal cannot be routed to the 20 pin connector
because it is interfaced to an op-amp to use with an ADC. To use the pin as GPIO or external UART you
must use the second pin on the J6 column.
Figure 13 shows the UART routed to USB COM port and Figure 14 shows the UART routed to 20-pin
header connector.
Figure 13. UART Routed to USB COM Port
Figure 14. UART Routed to 20-Pin Header Connector

Hardware Description www.ti.com
18 SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.5.8 Push-Buttons and LED Indicators
Table 8 list the push-button definitions.
Table 8. Push-Button Definitions
Reference
(Rev. A/C) Reference (Rev. B) Use Comments
SW1 SW1 RESET This is used to reset the CC3220 device. This signal is also output on the
20-pin connector to reset any external BoosterPack module which may be
stacked. The reset can be isolated using the jumper block at the center of
the board.
SW2 SW3 GPIO_13 When pushed, GPIO_13 is pulled to VCC.
SW3 SW2 GPIO_22 When pushed, GPIO_22 is pulled to VCC.
SW4 SW4 Factory default Pressing this button and toggling RESET restores the factory default image on the serial flash. This can be used to recover a corrupted serial flash,
provided the s-flash was programmed with a recovery image.
Table 9 lists the LED indicators.
(1) GPIO_10 and GPIO_11 are also used as I2C. Thus, when the pullup resistors are enabled, the LEDs are on by default, without
configuring the GPIOs.
Table 9. LED Indicators
Reference
(Rev. A/C) Reference (Rev. B) Color Use Comments
D1, D2 D2, D9 Green and
Red Debug Indicates the state of the JTAG emulator. For TI use only.
D3 D1 Yellow nRESET Indicates the state of the nRESET pin. If this LED is on, the device
is functional.
D6 D8 Red Factory Reset Indicates that the push-button for the factory reset is pressed.
D7 D4 Red Power Indicates when the 3.3-V power is supplied to the board.
D8 D5 Green GPIO_11(1) On when the GPIO is logic-1.
D9 D6 Yellow GPIO_10(1) On when the GPIO is logic-1.
D10 D7 Red GPIO_09 On when the GPIO is logic-1.

CC3220
Wi-Fi
NWP
J1
J3 J4
J2
+3.3 V
GPIO_03 *
+5 V
GPIO_13
GPIO_12
GPIO_06
GPIO_04 *
GPIO_14 *
GPIO_07
GPIO_10
GPIO_11
GND
ANALOG_IN
UART_RX
UART_TX
GPIO
ADC_CH2
SPI_CLK
GPIO
12C SCL
12C SDA
1
2
5
62
59
61
3
4
58
GPIO_02ANALOG_IN57
GPIO_05ANALOG_IN60
GPIO_03
ANALOG_IN58
GPIO_04ANALOG_IN59
GPIO_08I2C WS63
GPIO_3012S SCLK53
GPIO_0012S SDin50
GPIO_09I2S SDout64
GND
GPIO_17 SPI CS Wls. 8
18GPIOGPIO_28
45GPIOGPIO_31
RST
GPIO_15
GPIO_16 7MOSI
6MISO
GPIO_01
GPIO_25 21MOSI
55MISO
15GPIOGPIO_22
2PWMOUT
1PWMOUT
17
PWM
NA
64
PWM
IN
62GPIOOUT
60GPIOOUT
16GPIOIN
17GPIOGPIO_24
18CCAP/GPIONA
21
CCAP
OUT
Copyright © 2017, Texas Instruments Incorporated
www.ti.com Hardware Description
19
SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.5.9 BoosterPack Module Header Pin Assignment
The TI BoosterPack module header pinout specification is at Build Your Own BoosterPack. Also see the BoosterPack Pinout Standard.
The CC3220 LaunchPad kit follows this standard, with the exception of naming. (P1:P4 is used instead of J1:J4.) See Figure 15 for CC3220 pin-
mapping assignments and functions.
Figure 15. CC3220 BoosterPack Module Header Pin Assignments
NOTE: RESET output is an open-drain-type output and can only drive the pin low. The pullup ensures that the line is pulled back high when the
button is released. No external BoosterPack module can drive this pin low.
All the signals are referred to by the pin number in the SDK; Figure 15 shows the default mappings. Some of the pins are repeated across the
connector. For instance, pin 62 is available on P1 and P4, but only P1 is connected by default. The signal on P4 is marked with an asterisk (*) to
signify that it is not connected by default. The signal can be routed to the pin by using a 0-Ωresistor in the path. For the exact resistor placement,
see the CC3220 SimpleLink Wi-Fi Wireless MCU LaunchPad Board Design Files.

Hardware Description www.ti.com
20 SWRU463C–February 2017–Revised March 2020
Submit Documentation Feedback
Copyright © 2017–2020, Texas Instruments Incorporated
CC3220 SimpleLink™ Wi-Fi®LaunchPad™ Development Kit Hardware
2.6 Power
2.6.1 USB Power
The LaunchPad kit is designed to work from the USB-provided power supply. The LaunchPad kit provides
addresses as a bus-powered device on the computer. To power the CC3220 device from the USB, the
jumpers must be placed on the following headers, as shown in Figure 16.
Figure 16. Powering From USB Jumper Settings
