UCD90xxx Sequencer Schematics Guidelines
User's Guide
SLVUB50C–June 2017–Revised March 2019
UCD90xxx Sequencer Schematics Guidelines
This document is a quick guideline to help the user perform a schematics review to achieve the best
performance. This document does not apply to the UCD9080 and UCD9081 devices.
1 Introduction
The UCD90xxx family of digital power supply sequencers, also known as system health monitors are
flexible and powerful enough to meet users sequencing, monitoring, margining and other needs. The
entire family of devices are designed to have similar behaviors, with a different number of rails or some
other minor features. Users only need to learn how to use the device once, and can then seamlessly
switch to other devices within the family that best fit their future designs. This document is a quick
guideline to help user to perform a schematics review to achieve the best performance. This document
does not apply to the UCD9080 and UCD9081 device.
2 UCD Power Supply Review
If a brownout circuit is used, ensure that forward voltage of the selected Schottky diode does not trigger
the brownout voltage threshold under operational temperature range. The pullup source for the RESET
signal must be connected to the cathode side of the diode, if brownout circuitry is used.
2.1 UCD90240, UCD90320 and UCD90320U
The UCD90240, UCD90320 and UCD90320U devices have the following power supply parameters:
• Pin A2, G13, M12, and N10 leave floating or isolated
• Pin G12, K11, M10 and N13 ties to DVSS
• K12 ties to V33D
• Three 1-μF X7R ceramic capacitors in parallel with two 0.1-μF X7R ceramic capacitors for BPCAP
decoupling
• Two 1-μF X7R ceramic capacitors in parallel with four 0.1-μF X7R ceramic capacitors and two 0.01-μF
X7R ceramic capacitors for V33D decoupling
• One 1-μF X7R ceramic capacitor in parallel with one 0.1-μF X7R ceramic capacitor and one 0.01-μF
X7R ceramic capacitor for V33A decoupling. A 1-Ωresistor can be placed between V33D and V33A to
decouple the noise on V33D from V33A.
• One 1-μF X7R ceramic capacitor in parallel with one 0.01-μF X7R ceramic capacitor for VREFA+
decoupling (if used)
• Place decoupling capacitors as close to the device as possible
• If an application does not use the RESET signal, the RESET pin must be tied to V33D, either by direct
connection to the nearest V33D pin, or by an R-C circuit as shown in Figure 1.
Figure 1. RESET With R-C Network Figure 2. Example of Analog Inputs

UCD Power Supply Review www.ti.com
2SLVUB50C–June 2017–Revised March 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
UCD90xxx Sequencer Schematics Guidelines
2.2 Remaining UCD90xxx Devices
For supply-voltage decoupling, provide power-supply pin bypass to the device as follows:
• The TRST pin must have a 10-kΩpulldown resistor to ground
• The RESET pin must have a 10-kΩpullup resistor to V33D and 1-nF decoupling capacitor to ground
as shown in Figure 1. The components should be placed as close to the RESET pin as possible
• 1-μF, X7R ceramic in parallel with 0.01-μF, X7R ceramic at the BPCAP pin
• 0.1-μF, X7R ceramic in parallel with 4.7-μF, X5R ceramic at the V33D pin
• 0.1-μF, X7R ceramic in parallel with 4.7-μF, X5R ceramic at the V33A pin
• 0.1-μF, X7R ceramic at pin 7 (V33DIO1 if applicable)
• Connect the V33D pin, V33DIO1 pin (if applicable), and V33DIO2 pin (if applicable), directly to the 3.3-
V supply
• Connect V33A to V33D through a 4.99-Ωresistor. This resistor and V33A decoupling capacitors form a
low-pass filter to reduce noise on V33A, which improves the ADC accuracy
3 I/O Signals Review
All pullup resistors must use the same 3.3-V source as the UCD90xxx devices.
It is recommended to ground all unused pins.
3.1 Analog Monitor (MONx/AMONx) Pin Review
The following list provides analog monitor (MONx/AMONx) pin information:
• Internal or external voltage reference is used by ADC to monitor the external signal. Be sure to have
the proper voltage divider to limit the input signal.
Table 1. UCD90xxx Voltage References
UCD90240, UCD90320 and
UCD90320U Remaining UCD90xxx Devices
Internal Voltage Reference V33D 2.5 V
External Voltage Reference 2.4–3 V N/A
• When a digital signal is connected to the analog monitor (MONx/AMONx) pin, please check the logic
level of the input signal to see whether it is over the voltage reference
• TI recommends having a 10-nF to 100-nF decoupling capacitor close to the analog monitor
(MONx/AMONx) pin to remove rail ripple voltage
• For UCD90240,UCD90320 and UCD90320U, TI recommends maintaining at least a 200-Ωresistance
between a low-impedance analog input and an AMON pin. For example, when monitoring a rail voltage
without a resistor divider, place a 200-Ωresistor in series between the rail output and AMON pin, as
shown in Figure 2.
• Ground unused MONx/AMONx pins to save power consumption and decrease EMI.
3.2 PMBUS Signals Review
Pull up SCL and SDA (2.2 kΩrecommended) to the same power supplies as the UCD devices. The
ALERT signal is pulled up to the same 3.3-V source as SCL or SDA. When the CONTROL pin is not
used, either pull it down or up, the device does not care about the input state of the CONTROL pin. Do not
leave it floating.
For the UCD90xxx (other than the UCD90240,UCD90320 and UCD90320U), make sure the resistors used
for PMBUS_ADDRESS give a valid 7-bit I2C address other than 126.

www.ti.com I/O Signals Review
3
SLVUB50C–June 2017–Revised March 2019
Submit Documentation Feedback Copyright © 2017–2019, Texas Instruments Incorporated
UCD90xxx Sequencer Schematics Guidelines
3.3 GPIO Pins Review
Consider the initial I/O states detailed in Table 2 when the device is under reset and initialization, and
consider their impact to the application circuitry.
Table 2. Initial I/O States of UCD90xxx
DEVICE RESET I/O STATE
UCD90240 Hi-ZUCD90320
UCD90320U
UCD90xxx FPWM pins are low, all other I/O pins are Hi-Z
3.4 Margin Pins Review
It is a good design practice to provide a series impedance of 20 Ωto 33 Ωat the signal source to slow fast
digital edges and route FPWM signals away from sensitive analog signals when they are used for fan
control or margining function. Consult Design Voltage Margining Circuit for UCD90xxx Power Sequencer
and System Manager (SLVA845) for margining circuit design and UCD90xxx Voltage Margining Circuit
Design Tool (SLVC676).
3.5 Trademarks
All trademarks are the property of their respective owners.

Revision History www.ti.com
4SLVUB50C–June 2017–Revised March 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
Revision History
Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from B Revision (September 2018) to C Revision .......................................................................................... Page
• Updated Section 2.2 ...................................................................................................................... 2
• Updated Section 3 ........................................................................................................................ 2
Changes from A Revision (June 2018) to B Revision .................................................................................................... Page
• Added reference to UCD90320U device in Section 2.1.............................................................................. 1
• Added reference to UCD90320U device in Table 1 .................................................................................. 2
• Added reference to UCD90320U device in Section 3.2.............................................................................. 2
• Added reference to UCD90320U device in Table 2 .................................................................................. 3
Changes from Original (June 2017) to A Revision ......................................................................................................... Page
• Changed "K1 ties to V33D" to "K12 ties to V33D" in Section 2.1 .................................................................. 1
• Added bullet item: 0.1- μF, X7R ceramic at pin 7 (V33DIO1 if applicable) in the Section 2.2 ................................. 2
• Added bullet item: Ground unused MONx/AMONx pins to save power consumption and decrease EMI. to Section 3.1 .. 2
