Thermo Scientific BioCane CK50900 Series User manual

BioCane™
Cryobiological Storage Vessel
Type CK50900
Operation Manual and Parts List
LT509X17 Rev. 0
© 2010 Thermo Fisher Scientific
All rights reserved
Printed in U.S.A.

Thermo ScientificThermo Scientific
Manual Number LT509X17 (7000807)
0 -- 5/13/10 Transfer to Marietta (was LT509X17 8/12/09) ccs
REV ECR/ECN DATE DESCRIPTION By
Preface
Cryobiological Storage Vessel i
Catalog Number Model Number Name
CK509X2 807 BioCane 20
CK509X3 808 BioCane 34
CK509X4 809 BioCane 47
CK509X6 820 BioCane 73

Thermo Scientificii Cryobiological Storage Vessel Thermo Scientific
Preface
Important Read this instruction manual. Failure to read, understand and follow the instructions in this manual
may result in damage to the unit, injury to operating personnel, and poor equipment performance. s
Caution All internal adjustments and maintenance must be performed by qualified service personnel. s
Material in this manual is for information purposes only. The contents and the product it describes are subject to
change without notice. Thermo Fisher Scientific makes no representations or warranties with respect to this
manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to
the use of this manual.

Thermo Scientific Cryobiological Storage Vessel iiiThermo Scientific
Preface
Important operating and/or maintenance instructions. Read the accompanying text carefully.
Extreme temperature hazards. Only qualified persons should perform procedures associated with this
symbol.
Potential biological hazards. Proper protective equipment and procedures must be used.
Marking of electrical and electronic equipment, which applies to electrical and electronic equipment
falling under the Directive 2002/96/EC (WEEE) and the equipment that has been put on the market
after 13 August 2005.
This product is required to comply with the European Union’s Waste Electrical & Electronic
Equipment (WEEE) Directive 2002/96/EC. It is marked with the WEEE symbol. Thermo Fisher
Scientific has contracted with one or more recycling/disposal companies in each EU Member State
European Country, and this product should be disposed of or recycled through them. Further
information on Thermo’s compliance with this directive, the recyclers in your country and
information on Thermo products will be available at www.thermofisher.com.
4Always use the proper protective equipment (clothing, gloves, goggles, etc.)
4Always dissipate extreme cold or heat and wear protective clothing.
4Always follow good hygiene practices.
4Each individual is responsible for his or her own safety.

Thermo Scientificiv Cryobiological Storage Vessel Thermo Scientific
Preface
Do You Need Information or Assistance on
Thermo Scientific Products?
If you do, please contact us 8:00 a.m. to 6:00 p.m. (Eastern Time) at:
1-740-373-4763 Direct
1-800-438-4851 Toll Free, U.S. and Canada
1-877-213-8051 FAX
http://www.thermofisher.com Internet Worldwide Web Home Page
Service E-Mail Address
Thermo Fisher Scientific
401 Millcreek Road, Box 649
Marietta, OH 45750
Our staff can provide information on pricing and give you quotations. We can
take your order and provide delivery information on major equipment items or make
arrangements to have your local sales representative contact you. Our products are listed on the
Internet and we can be contacted through our Internet home page.
Our staff can supply technical information about proper setup, operation or
troubleshooting of your equipment. We can fill your needs for spare or replacement parts or
provide you with on-site service. We can also provide you with a quotation on our Extended
Warranty for your Thermo Scientific products.
Whatever Thermo Scientific products you need or use, we will be happy to discuss your
applications. If you are experiencing technical problems, working together, we will help you
locate the problem and, chances are, correct it yourself...over the telephone without a service
call.
When more extensive service is necessary, we will assist you with direct factory trained
technicians or a qualified service organization for on-the-spot repair. If your service need is
covered by the warranty, we will arrange for the unit to be repaired at our expense and to your
satisfaction.
Regardless of your needs, our professional telephone technicians are available to assist you
Monday through Friday from 8:00 a.m. to 6:00 p.m. Eastern Time. Please contact us by
telephone or fax. If you wish to write, our mailing address is:
International customers, please contact your local Thermo Scientific distributor.
Sales Support
Service Support
[e-mail]

Cryobiological Storage Vessel vThermo Scientific
Table of Contents
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Please Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Measuring Liquid Nitrogen Quantity . . . . . . . . . . . . . . . . . . . . . . . .3-2
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Section 1
Section 2
Section 3
Section 4
Section 5

Cryobiological Storage Vessel 1-1Thermo Scientific
Please Read
Section 1 Safety Information
This manual contains important operating and safety information. The
user must carefully read and understand the contents of this manual prior
to the use of this equipment.
Your Thermo Scientific cryogenic vessel has been designed with function,
reliability, and safety in mind. It is the user’s responsibility to install it in
conformance with local electrical codes. For safe operation, please pay
attention to the warnings and cautions throughout the manual.
All cryopreservation vessels, regardless of who manufactures them, use a
vacuum to provide for the super insulative properties needed to keep
nitrogen in a liquid form. They are very similar, in fact, to the thermos
vessels you may have used to store coffee, soup or milk.
Remember how fragile they were? Since no vacuum is perfect or will last
forever, we suggest that you monitor the consumption of liquid nitrogen
used by your vessel on a regular basis, i.e. every 1-2 days. By monitoring,
you may be able to anticipate subtle changes in consumption and possibly
react to problems before they arise.You may opt to use a level monitor for
this purpose.
Also, if your samples are super critical, one-of-a-kind, or irreplaceable,
consider allocating your samples into 2 separate vessels.
Remember the old adage about placing all your eggs into one basket…
Finally, because no vacuum will last forever, consider having your vessel
tested by a qualified cryovessel manufacturer every 7-10 years regardless of
any problems (or lack thereof) you may have had in the past. This will
help insure your samples against sudden loss of nitrogen due to vacuum
failure.

1-2 Cryobiological Storage Vessel Thermo Scientific
Section 1
Safety Information
Warnings
• Liquid nitrogen is extremely cold; it boils at -196°C.
• To avoid injury due to frostbite or ruptured vials use extreme care
whenever handling liquid nitrogen, liquid nitrogen storage or transfer
vessels or any objects which have come in contact with liquid
nitrogen.
• Leave no areas of skin exposed.
• Always wear proper safety attire over clothing: face shield, cryogenic
gloves, cryogenic apron.
• Do not tightly seal liquid nitrogen containers or prevent nitrogen gas
from escaping.
• Always handle vials with tongs.
• Use extreme care to prevent spilling and splashing liquid nitrogen
during transfer and removal of storage contents and holders.
• Immediately remove any clothing or safety attire on which liquid
nitrogen has been spilled or splashed .
• Get immediate medical attention for any frostbite injuries due to
liquid nitrogen.
• Never overfill liquid nitrogen vessels.
When inserting or removing cans, be careful not to come in contact
with the neck tube area of the vessel. Remove or insert cans slowly,
in a vertical manner. Scratches on the neck tube are can cause
premature vacuum failure.
Do not tamper with, or remove vacuum port (covered by black
plastic cap on side of vessel); this will void warranty.
Do not spill liquid nitrogen on vacuum port - this can cause vacuum
failure.
Always keep liquid nitrogen in an upright position.

Cryobiological Storage Vessel 2-1Thermo Scientific
Section 2 General Specifications
Declaration of Conformity
Copies of the Declaration of Conformity are available upon request.
Cryogenics Dewars (liquid nitrogen containers) meet the requirements of
Annex V Medical Devices Directive 93/42/EEC
EC Certificate - CE 00127
BioCane 20 BioCane 34 BioCane 47 BioCane 73
Height (Inches) 25.70" 26.60" 26.50" 27.00"
Diameter (Inches) 14.50" 18.20" 20.00" 22.00"
LN2 Capacity 20.50L 34.80L 47.40L 73.0L
Static Holding Time (Days) 227 193 121 121
Static LN2 Evaporation Rate 0.1L/day 0.18L/day 0.40L/day 0.60L/day
Liquid Phase Capacity 1.2 ml 180 vials 720 vials 1512 vials 2880 vials

2-2 Cryobiological Storage Vessel Thermo Scientific
Section 2
General Specifications
Unpacking Before using your new vessel, carefully inspect it. Check for signs of
damage which may have occurred in shipment. It is advisable to fill (see
Filling Instructions) all new units with liquid nitrogen and watch liquid
nitrogen loss rate for a few days. If there are any problems, call Technical
Services as soon as possible.
The Warranty Registration card enclosed with the vessel must be
completed and returned to the factory within 30 days to make warranty
effective. This information must include the serial number which is located
on the handle of the vessel.
Note The most prevalent cause of failure of liquid nitrogen storage vessels
is mechanical. The vessel neck tube supports the full weight of the inner
shell and all liquid nitrogen it contains. A side or corner blow to the vessel
causes the inner shell to swing in a pendulum motion causing the neck
tube to be damaged. Any storage vessel which has been exposed to an
accident, has been dropped or lowered to hit on one corner will tend to fail
more rapidly than one which has not. s
Caution Exercise caution when moving your BioCane™ vessel. BioCane
cryobiological storage systems are not transportation vessels. Transport carts
are designed for mobility within the lab or lab to lab only. Moving full
vessels long distances, over cracks in floor, thresholds, on inclined ramps or
in elevators can cause premature vacuum failure.
Note If samples must be transported under cryogenic conditions, consider
the Thermo Scientific Arctic Express line of Dry Shippers.

Cryobiological Storage Vessel 3-1Thermo Scientific
Section 3 Operation
To avoid damage to your cryogenic storage vessel which may result in
premature vacuum loss, it is important that the following procedure be
used during the addition of liquid nitrogen to a warm vessel:
1. Add only a small amount of liquid nitrogen (2-10 liters) to new or
warm vessels.
2. Allow this small amount of liquid nitrogen to sit in the covered vessel
for a minimum of 2 hours. This will limit stress caused by the sudden
temperature change associated with adding liquid nitrogen to a warm
vessel.
3. Add an additional 2-10 liters LN2 to vessel.
4. Allow vessel to sit for 48 hours and monitor liquid nitrogen
consumption.
5. Fill vessel as desired. Remember to allow for displacement of liquid
nitrogen when cannisters and canes are inserted.
6. Insert and remove cannisters slowly. Allow liquid nitrogen to run out
of cannisters.
Caution Never overfill liquid nitrogen vessels.
When inserting or removing cans, be careful not to come in contact with
the neck tube area of the vessel. Remove or insert cans slowly, in a
vertical manner. Scratches on the neck tube area can cause premature
vacuum failure.
Do not spill liquid nitrogen on vacuum port - this can cause vacuum
failure. s

3-2 Cryobiological Storage Vessel Thermo Scientific
Section 3
Operation
Measuring Liquid
Nitrogen Quantity
1. Use a wooden yardstick to measure liquid nitrogen level. Never use a
hollow tube or plastic dipstick to measure liquid nitrogen level.
2. Level will be indicated by frost line which develops when dipstick is
removed and waved in a back and forth motion away from the user.

Cryobiological Storage Vessel 4-1Thermo Scientific
Section 4 Replacement Parts
Part Number Description
AY509X13 Nalge Cyrovials 1.2ml, 500/case
AY509X12 Nalge Cryovials 2.0ml, 500/case
AY509X20 CryoCane (aluminum) - each cane holds 5 vials for storage in BioCane cannisters (48/case)
AY509X21 CryoSleeve enclosures - Clear plastic sleeve fits over CryoCane for added security during handling or storage (100/case)
CS509X17 Nalgene System 100-ampule box accommodates most internally threaded 1.2 and 2.0 ml vials
CS509X18 Nalgene System 100-ampule box accommodates most internally threaded 1.2 and 2.0 ml vials
AY509X32 Nalgene System 100 Cyrogenic Vials - 1 ml (500/case)
AY509X33 Nalgene System 100 Cryogenic Vials - 1.5 ml (500/case)
AY509X34 Nalgene System 100 Cryogenic Benchtop Vial Holder (1/package)
AY509X35 Nalgene System 100 Cryogenic Benchtop Vial Holder (1/package)
CryoCane coders - Aluminum identification tabs that slip over the end of a CryoCane to identify the cane written on for further
identification (100/case)
AY509X22 White
AY509X23 Yellow
AY509X24 Blue
AY509X25 Green
AY509X26 Red
Cryovial closure color coders - Plastic disks that fit into the top of Nalge Cryovials to identify individual (100/package)
AY509X27 White
AY509X28 Yellow
AY509X29 Blue
AY509X30 Green
AY509X31 Red

4-2 Cryobiological Storage Vessel Thermo Scientific
Section 4
Replacement Parts
Please refer to the Specification Plate for the complete model number,
serial number, and series number when requesting service, replacement
parts or in any correspondence concerning this unit.
All parts listed herein may be ordered from the Thermo Scientific dealer
from whom you purchased this unit or can be obtained promptly from the
factory.When service or replacement parts are needed, check first with your
dealer. If the dealer cannot process your request, then contact our Technical
Services Department.
Prior to returning any materials, please contact our Technical Services
Department for a “Return Materials Authorization” number (RMA).
Material returned without an RMA number will be refused.
Ordering Procedures

Cryobiological Storage Vessel 5-1Thermo Scientific
Section 5
Warranty Information
THERMO FISHER SCIENTIFIC STANDARD PRODUCT WARRANTY
(LN2Vacuum)
The Warranty Period starts two weeks from the date your equipment is shipped from our facility. This allows for shipping time so the warranty will go into effect at approximately the same time your equipment is delivered. The warranty protec- tion extends to any subsequent owner during the first year warranty period. During the first year, component parts proven to be non-conforming in materials or workmanship will be repaired or replaced at Thermo's expense, labor included. LN2Vacuum Integrity is covered for three years. Installation and calibration are not
covered by this warranty agreement. The Technical Services Department must be contacted for warranty determination and direction prior to performance of any repairs. Expendable items, glass, filters and gaskets are excluded from this warranty. Replacement or repair of components parts or equipment under this warranty shall not extend the warranty to either the equipment or to the component part beyond the original warranty period. The Technical Services Department must give prior approval for return of any components or equipment. At Thermo's option, all non-conforming parts must be returned to Thermo postage paid and replacement parts are shipped FOB destination. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, WHETHER WRITTEN, ORAL OR IMPLIED. NO WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL APPLY. Thermo shall not be liable for any indirect or consequential damages including, without limitation, damages relating to lost profits or loss of products. Your local Thermo Sales Office is ready to help with comprehensive site preparation information before your equipment arrives. Printed instruction manuals carefully detail equipment installation, operation and preventive maintenance. If equipment service is required, please call your Technical Services Department at 1-800-438-4851 (USA and Canada) or 1-740-373-4763. We're ready to answer your questions on equipment warranty, operation, maintenance, service and special application. Outside the USA, contact your local distributor for warranty information.
Rev. 0 5/10
ISO
9001
REGISTERED

Thermo Fisher Scientific
401 Millcreek Road
Marietta, Ohio 45750
United States
www.thermofisher.com
