three h Hook Up User manual

Hook Up
Transaction Desk

Hook Up | Transaction Desk 2
Parts & Hardware
1
1. Transaction Counter
(bottom shown)
3. Transaction Leg
(left aligned) 6. Worksurface Legs
2. Main Surface
(bottom shown)
4. Frame
(long side)
M6x10mm 5/8" Panhead
5. Frame
(short side)
2
4
3
5
6#8 x 7/8" Panhead

Hook Up | Transaction Desk 3
Instructions
Slide both Worksurface Legs onto the
Short Frame.
Fasten the legs to the frame using the
provided M6x10mm flathead screws.
Do not fully tighten, only enough to
keep together.
Slide the Long Frames into the Leg
brackets.
Fasten the frame to the legs using the
provided M6x10mm flathead screws.
Do not fully tighten, only enough to
keep together.
1
2
Allen Key
Allen Key
M6x10mm
M6x10mm
Qty: 8
Qty: 8

Hook Up | Transaction Desk 4
Instructions
Flip the parts from Step 2 so the feet
are on the ground. Slide the Transaction
Leg into the Frame slots.
Fasten the legs to the frame using the
provided M6x10mm flathead screws.
Proceed with tightening ALL M6x10
screws equally around the frame.
Lower the Main Worksurface into place
centered over the frame. Verify all leg
tubes are equal distance from surface
edges (approximately 1/8" overhang).
Apply one #8 x 7/8" Panhead screw on
each corner leg to start.
Once the surface is centered and in
place with 1 screw per leg, fasten the
remaining screws.
3
4
Allen KeyM6x10mm
Qty: 8
Qty: 10
#8 x 7/8" Panhead

Hook Up | Transaction Desk 5
Instructions
Continue to fasten the worksurface to
the frame using the small L brackets
and provided #8 x 7/8" Panhead
screws. The quantity of screws will
depend on the length and depth.
Use a power drill as there are no
pre-drilled holes for this step.
Lower the Transaction Counter into
place centered over elevated frame.
Align the touch-points and fasten the
surface to the transaction bracket using
the provided 5/8" Panhead screws.
Ensure you have the correct screws,
anything longer than 5/8" will damage
the top.
Finally, adjust the levelers and tighten
any remaining screws.
5
6
Qty: 10
5/8" Panhead
#8 x 7/8" Panhead

Three H Furniture Systems Limited
156462 Clover Valley Rd.
New Liskeard, ON
Canada P0J 1P0
T. 1.800.767.5374
F. 1.888.484.5786
customer[email protected]
www.three-h.com © 2022 Three H Furniture Systems Limited. All rights reserved.
Revision 4 · 06/20/2022
