INSTALLATION GUIDE
102503 40/60 Bench
ISUZU W5 / NPR Chevrolet LCF 3500-6500 (2012-2020)

For assistance with installation, call us at 507.246.3545
BILL OF MATERIALS
ITEMITEM QUANTITY
Driver Seat Back Cover 1
Driver Seat Bottom Cover 1
Passenger Seat Back Cover 1
Passenger Seat Bottom Cover 1
Middle Passenger Seat Back Cover 1
Long String 1
General care instructions:
1. In most cases dirt, debris, spills and pet hair can be removed by wiping with a
damp cloth.
2. Seat covers can be removed and machine washed on low temperature setting
using mild detergent.
Drip dry or machine tumble dry on a no heat cycle.
Straps should be coiled and secured with rubber bands for machine washing
and drying.
3. Soil may be removed with spray cleaner or detergent and water.
4. Oil or grease stains should rst be treated with a dry cleaning solvent followed
by a spray cleaner or detergent and water.
5. Do not use bleach.
Seat Backs & Bottoms have tag signifying Driver or Passenger.

For assistance with installation, call us at 507.246.3545
1 - Preparation - Driver’s Side
q 1.1 - Slide seat forward.
q 1.2 - Lean seat back forward
q 2.1 - Turn seat back cover 3/4 of the way inside out and pull over seat back.
q 2.2 - Continue pulling the cover down over the seat, unrolling it as you go.
q 2.3 - Push front ap between seat back and seat bottom.
q 2.4 - Pull front ap tight and fasten to Velcro on seat back.
2 - Install Seat Back Cover - Driver’s Side

For assistance with installation, call us at 507.246.3545
3 - Install Seat Bottom Cover - Driver’s Side
q 3.1 - Put cover over seat bottom.
q 3.2 - Tuck inside string behind seatbelt bracket and pull towards the rear of the seat.
q 3.3 - Run outside string under seat bottom.
q 3.4 - Pull strings tight., and fasten using StringLock device. See next page.
q 3.5 - Push top ap between seat back and seat bottom.
q 3.6 - Run front ap underr seat and over seat adjustment lever, wires, and brackets.
q 3.7 - Pull front ap tight and fasten to Velcro on top ap.

For assistance with installation, call us at 507.246.3545
THE STRINGLOCK
Run one string through the channel on the
end of the StringLock.
Pull the string tight, pulling the StringLock
towards one edge of the seat. Press the
string into the clamp, locking it in place.
Run the second string through the
StringLock just like the other one.
Pull the loose end of the second string until
everthing is tight and lock it into place as
well.
1
3
2
4
Watch the video
ttcovers.com/stringlock

For assistance with installation, call us at 507.246.3545
4 - Preparation - Passenger’s Side Bottom
q 4.1 - Remove the seat bottom by pulling it up. The seat will release from ve plastic clips on the oor.
5 - Install Seat Bottom Cover - Passenger’s Side
q 5.1 - Put seat cover over seat bottom, lining hole in cover up with the hole in the seat bottom for the seatbelts.
q 5.2 - Pull the edges of the cover around the seat bottom.
q 5.3 - Make sure the hole in the side of the cover lines up with the metal clip in the side of the seat bottom.

For assistance with installation, call us at 507.246.3545
5 - Install Seat Bottom Cover - Passenger’s Side
q 5.4 - Turn seat bottom over.
q 5.5 - Lace strings through loops on seat cover as shown above.
q 5.6 - Pull as tight as possible tie string o󰀨 at last loop.
1
Tie
Here
2
4 3
56
Tie
Here

For assistance with installation, call us at 507.246.3545
5 - Install Seat Bottom Cover - Passenger’s Side
q 5.7 - Pull aps from front of seat cover as tight as possible and fasten to Velcro on back of seat cover.
q 5.8 - Make sure that all metal loops on the seat bottom are not covered. These fasten into the plastic clips on the
oor of the truck.
q 5.9 - Install seat bottom into the truck.
q 5.10 - Line metal loops up with plastic clips and press down rmly on the seat bottom.

For assistance with installation, call us at 507.246.3545
6 - Install Center Seat Back - Passenger’s Side
q 6.1 - Turn seat back cover 3/4 of the way inside out and pull over seat back.
q 6.2 - Continue pulling the cover down over the seat, unrolling it as you go.
q 6.3 - Push ap on driver’s side behind the metal bracket.
q 6.4 - Pull tight and fasten to Velcro on seat back.
q 6.5 - Push front ap between seat back and seat bottom.
q 6.6 - Pull front ap tight and fasten to Velcro on seat back.
<

For assistance with installation, call us at 507.246.3545
7 - Preparation - Passenger’s Side Back
q 7.1 - Slide seat forward.
q 7.2 - Lean seat back forward
q 8.1 - Turn seat back cover 3/4 of the way inside out and pull over seat back.
q 8.2 - Continue pulling the cover down over the seat, unrolling it as you go.
q 8.3 - Push front ap between seat back and seat bottom.
q 8.4 - Pull front ap tight and fasten to Velcro on seat back.
8 - Install Seat Back Cover - Passenger’s Side
