Topens CASAR HJ4021 User manual

Swing Gate Opener
User’s Manual
Model:
TOPENS Website
www.topens.com
Email: [e-mail]
HJ4021 (Single Actuator)
HJ4022 (Dual Actuator)
VER 22a
C030605
★Please read this manual and the enclosed safety materials carefully before install
and use.
★Periodic checks of the opener are required to ensure safe operation.
★For residential use only.

CONTACT US:
Visit: www.topens.com
Please record the product model, your email address etc.
in the spaces provided below. Refer to this list when contacting TOPENS
for technical service or assistance with your automatic gate opener.
Where did you purchase? (Amazon.com; Amazon.ca: Amazon.co.uk, Amazon.de; Other, Please
Specify)
Order#
Product Model
Purchase Date
Full Name
Phone#
Email Address (VERY
IMPORTANT)
Street Address, Apartment /Unit, City, State /Province, Zip Code
Country/Region
Approximate Gate Weight Per
Leaf (pounds; kg: Other.
Please Specify)
Approximate Gate Length Per
Leaf (feet meter; Other. Please
Specify)
Did you purchase any
accessories? (Please list
below)
Issue Details
Email Us: supp[email protected]
Call: [phone] (Toll Free USA & Canada)

Table of Contents
Safety Installation Information ........................................................................................................................... 1
Installation Overview ..........................................................................................................................................3
Dual Gate Opener Parts List（HJ4022）..........................................................................................................3
Single Gate Opener Parts List（HJ4021）.......................................................................................................4
Accessories Parts (Included in some models, refers to the actual package) .......................................................4
Optional Accessories Parts List (Available at TOPENS Store) .............................................................................5
Replacement Parts ............................................................................................................................................... 5
Tools Needed: .................................................................................................................................................... 6
Technical Specifications & Features ..................................................................................................................6
Gate Capacity of HJ4022 for Each Actuator and HJ4021 .................................................................................... 6
Opener Installation .............................................................................................................................................7
Install the Opener on the Gate – for Pull to Open ................................................................................................ 7
Install the Opener on the Gate – for Push to Open ............................................................................................ 11
Mounting the Control Box ................................................................................................................................ 14
Connection of Power Supply ........................................................................................................................... 15
Connection of the Control Board ..................................................................................................................... 15
How to Program or Erase the Remote ............................................................................................................ 18
How to Use the Remote to Operate Your Gate Opener ..................................................................................19
Wireless Keypad Programming ....................................................................................................................... 19
Setting of the Control Board ............................................................................................................................ 20
Digital Display When Gate Opener is Running ............................................................................................... 23
How to Operate ................................................................................................................................................ 24
Maintenance .....................................................................................................................................................24
Trouble Shooting ..............................................................................................................................................24
Quick-Setting Guide .........................................................................................................................................26

1
Safety Installation Information
1. READ and FOLLOW all instruction.
2. The gate opener is intended for use with Class I
vehicular swing gates.
Class I denotes a vehicular gate opener (or system)
dwellings, or a garage or parking area associated
therewith.
Install the gate opener only when the opener is
appropriate for the construction and the usage class of
the gate.
3. Gate opening system designers, installers and
users must take into account the possible hazards
associated with each individual application. Improperly
designed, installed or maintained systems can create
risks for the user as well as the bystander. Gate
system design and installation must reduce public
exposure to potential hazards. All exposed pinch
points must be eliminated or guarded.
4. A gate opener can create high levels of force
during normal operation. Therefore, safety features
must be incorporated into every installation. Specific
safety features include safety sensors.
5. The gate must be properly installed and work
freely in both directions prior to the installation of the
gate opener.
6. The gate must be installed in a location so that
enough clearance is provided between the gate and
adjacent structure when opening and closing to
reduce the risk of entrapment. Swinging gates shall
not open into public access areas.
7. The opener is intended for use only on gates used
for vehicles. Pedestrians must be supplied with a
separate access opening. The pedestrian access
opening shall be designed to promote pedestrian
usage. The pedestrian access shall be located such
that persons will not come in contact with the moving
vehicular gate.
8. Pedestrians should never cross the pathway of a
moving gate. The gate opener is not acceptable for
use on any pedestrian gate. Pedestrians must be
supplied with a separate pedestrian access.
9. For an installation utilizing non-contact sensors
(safety sensors), see product manual on the
placement of non-contact sensors (safety sensors) for
each type of application.
a. Care shall be exercised to reduce the risk of
nuisance tripping, such as when a vehicle trips the
safety sensor while the gate is still moving.
b. One or more non-contact sensors (safety sensors)
shall be located where the risk of entrapment of
obstruction exists, such as the perimeter reachable by
a moving gate or barrier.
10. Never mount any device that operates the gate
opener where the user can reach over, under, around
or through the gate to operate the controls. Controls
are to be placed at least 6’ (1.8m) from any part of the
moving gate.
11. Controls intended to be used to reset an operator
after 2 sequential activations of the entrapment
protection device or devices must be located in the
line of sight of the gate, or easily accessible controls
shall have a security feature to prevent unauthorized
use. Never allow anyone to hang on or ride the gate
during the entire travel of the gate.
12. Each gate opener is provided with two safety
warning placards. The placards are to be installed on
the front and back of the gate where they are plainly
visible. The placards may be mounted using cable ties
through the four holes provided on each placard.
All warning signs and placards must be installed
where visible in the area of the gate.

2
13. To AVOID damaging gas, power, or other
underground utility lines, contact underground utility
locating companies BEFORE digging.
14. Do not permit children to play on or around the
gate and keep all controls out of their reach.
NOTE:
TOPENS Gate Operator can be used for driveway gates made by steel, wood, vinyl, and shaped as panel,
tube, and chain-link. While use on solid surface gates is NOT recommended. Solid surface gates have a high
resistance to the wind. If the wind is strong enough, the operator will obstruct and stop.

3
Installation Overview
Dual Gate Opener Parts List（HJ4022）

4
Single Gate Opener Parts List（HJ4021）
Accessories Parts (Included in some models, refers to the actual package)

5
Optional Accessories Parts List (Available at TOPENS Store)
M12 Remote Control
ERM12 External
Receiver
TC186-R WiFi
Smartphone Remote
Control with Camera
TC186 WiFi Smartphone
Remote Control with
Camera
TC188 Universal Keypad
TKP3 Wireless
Keypad
TC175P Wired Keypad
ET24 Electric Gate Lock
TEW3 Vehicle Sensor
Exit Wand
HLR01 HomeLink
Remote Control Kit
TC173 Wireless Push
Button
TC147 Wired Push Button
TC148 Waterproof Wired
Push Button
TRF3 Reflection
Photocell Sensor
TC102 Photo Eye
Beam Sensor
JD24VY 24V Warning
Light
TSP30W 30W Solar
Panel Charging Kit
TSQ20W 20W
Solar Panel Kit
TCS3 Solar Charge
Controller
Replacement Parts
PKMJ11A Control Board
Arm Actuator
WARNING: Changes or modifications not expressly specified by this user manual, TOPENS could void
the warranty of this equipment.

6
Tools Needed:
·Power Drill
·Tape Measure
·Open End Wrenches —14# &17# or Adjustable Wrenches
·Wire Strippers
·C-Clamps —small, medium, and large
·Level
·Phillips Screwdriver
·An extra person will be helpful
Technical Specifications & Features
Specifications
Input:
110V~120V/60Hz or 220~240V/50Hz
Motor voltage:
24VDC
Motor Power:
40W
Motor Current:
2A
Actuator speed:
30mm/s
Max. actuator travel:
380mm
Ambient Temperature:
-20℃~ +50℃(0°F to 120°F)
Protection class:
IP44
Gate Capacity of HJ4022 for Each Actuator and HJ4021
200 kg (440 lbs)
√
NR
NR
NR
150 kg (330 lbs)
√
√
NR
NR
100 kg (220 lbs)
√
√
√
NR
50 kg (110 lbs)
√
√
√
√
1.2-1.8 m (4-6’)
2.4 m (8’)
3 m (10’)
3.6 m (12’)
These specifications are subject to change without notice.
Gate Length
NOTE: “NR" indicates this size and weight combination is NOT recommended for one arm actuator.
NOTE: Ball bearing hinges should be used on all gates weighing over 140kg (300 lbs).

7
Features:
·Soft start and soft stop
·Emergency release key in case of power failure
·Dual/Single gate running mode
·Adjustable opening/closing interval between master and slave gate
·Stop/Reverse in case of obstruction during gate opening/closing
·Built in adjustable auto-close (0-99 seconds)
·Built in max. Motor running time (MRT: 40 seconds) for multiple safety protection
·Digital display indicates the running situation and setting menu
·Can be equipped with a wide range of accessories
Opener Installation
Please read the instruction manual carefully before installation of swing gate opener. This will help
insure that your installation is performed in an efficient and professional manner.
Opener Dimensions
Install the Opener on the Gate – for Pull to Open
Determining the Position of Mounting Hardware
NOTE: The following steps are intended for Pull-to-Open gate installation only.
You will find a series of sizes from following chart to determine the proper mounting position

8
Pull-to-Open Installation — Gate in Closed position (Moving-Rod is extended)
Step 1
Insert the bolts through the holes of post brackets and pull to open
bracket as shown. Place washers and nuts on the bottom of the
bolts and hand tighten.
Step 2
Attach the post bracket assembly to the opener by inserting a
clevis pin. Secure the clevis pin by using a hairpin clip. Insert the
gate bracket into the front mount and connect them with the
release key.

9
Step 3
With the opener fully retracted and with the gate in the fully open position (for Pull-to-Open
installation), place the opener assembly onto the gate post and the gate. Position the post bracket
assembly and the gate bracket so that the gate opener is level with the horizontal cross member of the gate.
While holding the opener in the desired level position, temporarily secure it with C-clamps.
Step 4

10
Step 5
Sign the bolt-hole points on the post and gate. Then remove the
opener assembly by taking off the C-clamps.
Step 6
Use an electric hammer to drill ￠12 holes on the concrete post.
Secure post bracket assembly with four M8x75 expansion bolts
to the gate post.
Step 7
Drill two ￠8.5 holes on the gate, and fix gate
bracket on the gate with two M8x70 bolts.
Fasten each bolt with a ￠8 lock washer, ￠8
washer and M8 nut.
Step 8
Firmly secure the gate opener assembly to the post and gate.
NOTE: The setting of the PULL/PUSH TO OPEN of the control board should be in accordance
with the installation.

11
Install the Opener on the Gate – for Push to Open
Determining the Position of Mounting Hardware
NOTE: The following steps are intended for Push-to-Open gate installation only.
You will find a series of sizes from following chart to determine the proper mounting position
Push-to-Open Installation — Gate in Closed position (Moving-Rod is retracted)

12
Step 1
Insert the bolts through the holes of post brackets and push to
open bracket as shown. Place washers and nuts on the bottom
of the bolts and hand tighten.
Step 2
Attach the post bracket assembly to the opener by inserting a
clevis pin. Secure the clevis pin by using a hairpin clip. Insert the
gate bracket into the front mount and connect them with the
release key.
Step 3
With the opener fully retracted and with the gate in the fully closed position (for Push-to-Open
installation), place the opener assembly onto the gate post and the gate. Position the post bracket
assembly and the gate bracket so that the gate opener is level with the horizontal cross member of the gate.
While holding the opener in the desired level position, temporarily secure it with C-clamps.

13
Step 4
Step 5
Sign the bolt-hole points on the post and gate. Then remove
the opener assembly by taking off the C-clamps.
Step 6
Use an electric hammer to drill ￠12 holes on the concrete
post. Secure post bracket assembly with four M8x75 expansion
bolts to the gate post.
Step 7
Drill two ￠8.5 holes on the gate, and fix gate
bracket on the gate with two M8x70 bolts.
Fasten each bolt with a ￠8 lock washer, ￠
8 washer and M8 nut.

14
Step 8
Firmly secure the gate opener assembly to the post and gate.
Mounting the Control Box
Step 1
To install the control box use the deck screws (not provided).
Even though the control box is waterproof designed, for safety reason and
a longer service life, it is recommended to install the control box inside a
secure surface and at least 100 cm (40 inches) above the ground to avoid
being flooded or buried under snow.
Step 2
Insert the power cable and cable of the first gate opener through the front strain relief
and into the control box by loosening the strain relief screw located in the leftmost of
outside bottom of the control box and feeding the cables into the control box. Check
the length of cables is long enough to their respective terminal block in control box.
Retighten the sealing nut so that cables are well locked.
NOTE: The setting of the PULL/PUSH TO OPEN of the control board should be in accordance
with the installation.

15
CAUTION: Install the Control Box in a well-ventilated place protected against rain and sunlight.
CAUTION: Make sure that the cable outlet hole in the Control Box is always down during installation, so as
to drain off the water.
Step 3
Insert the cable of the second gate opener and warning light cables into the control box through middle
strain relief. Then repeat step 2.
Step 4
Insert the cables of the optional parts into the control box through the right strain relief. Then repeat step 2.
Connection of Power Supply
WARNING: NEVER connect the gate opener to the power
supply before all the installations have been done.
Connect the power supply to the Control Box refers to the following
illustration.
NOTE:
1. Use copper conductors to connect to the power supply terminals.
2. The wire (not provided) size should be at least 18AWG (0.75mm2)
which is intended to connect the power supply.
3. Run the wires in conduit to the control box to prevent damage to
the wires from lawn mowers, weed eaters and grazing animals.
4. The fuse in the control board is interchangeable. A 10a, 250vac, Φ5*20mm fuse is suitable to the control
board.
Connection of the Control Board
Motor connection for PULL-TO-OPEN
Actuator 1
Insert the stripped cable wires into the appropriate terminals
on the opener terminals block. The red wire should be inserted
into the “MOTOR 1+” terminal, the black wire into “MOTOR
1-”.
NOTE: For dual gate mode, actuator 1 must be used for
master gate. Master gate would open first and close last.
Actuator 2
Similar as the connection of Actuator 1, insert the stripped cable wires into the appropriate terminals on
the opener terminals block. The red wire should be inserted into the “MOTOR 2+” terminal, the black wire
into “MOTOR 2-”.
Connection of the actuator for “Push to Open” is different from the connection for “Pull to Open”. The
connection of the actuator for “Push to Open” must be referred to the figure on the right.
Black wire should be inserted into the “Motor+” terminal. Red wire should be inserted into the “Motor-”
terminal.

16

17
Back-up Battery & Solar Panel & Solar Controller (optional)
The battery could be charged by the solar panel & solar controller. Please refer to the manual instruction of
solar panel and controller separated for wire connection.
Photocell Beam System (PBS) (Included in some models, refers to the actual package)
Use a 2-core cable to connect the “- ~” terminal of the photocell’s emitter to the “GND” (#12) terminal, the
“+ ~” terminal to the “+24” (#11) terminal. Also the “- ~” and “+ ~” terminals of the photocell’s receiver
should be connected to the “+24” (#11) and “GND” (#12) terminals in parallel.
Use another 2-core cable to connect the “COM” terminal of the receiver to the “PHOT” (#13) terminal, the
“NC” terminal to the “GND” (#14) terminal.
Reflection Photocell Sensor (optional)
The “AC10-25V/DC12-30V” terminals of the reflection photocell sensor should be connected to the “+24” (#11)
and “GND” (#12) terminals, no matter the polarity.
The “NC” terminal should be connected to the “GND” (#14) terminal.
The “COM” terminal should be connected to the “PHOT” (#13) terminal.
Warning Light (Included in some models, refers to the actual package)
The red wire of the warning light should be inserted into “+LAMP” (#5) terminal, the white wire into the
“LAMP-” (#6) terminal.
Push Button (optional)
The push button should be wired to the “OSC” (#15) and “GND” (#14) terminals, no matter the polarity.
The gate operator works alternately by pushing the button (open-stop-close-stop-open).
External Receiver (optional)
The BROWN wire of the external receiver should be connected into the “OSC” (#15) terminal.
The BLACK wire of the external receiver should be connected into the “GND” (#12) terminal.
