Toro 110-2025 User manual

Form No. 3354-112 Rev A
40in Bagger Enhancement KitFor 2006 and After Mid-Size MowersModel No. 110–2025
Installation Instructions
Loose PartsUse the chart below to verify that all parts have been shipped.
Step
Description
Qty.
Use
1
No parts required
–
Prepare the mower deck forinstallation.
Right side rubber bafe
1
Left side rubber bafe
1
Left metal bafe stiffener
1
Carriage bolt (5/16 x 1 inch)
8
Locknut (5/16 inch)
82
Right metal bafe stiffener
1
Install the bafes.
Step
1
Preparing the Mower Deck
No Parts Required
Procedure
1. P osition the mo w er on a flat surface .
2. Diseng ag e the PTO , mo v e the motion control
lev ers to the neutral loc k ed position and set
the parking brak e .
3. Stop the engine , remo v e the k ey , and w ait for
all mo ving par ts to stop before lea ving the
operating position.
4. Lift the front of the mac hine and suppor t the
mac hine using jac k stands .
5. T horoughly clean the mo w er dec k. All debris
m ust be remo v ed to ensure the baffle will fit
properly ag ainst the mo w er dec k.
6. R e pair all bent and damag ed areas of the
mo w er dec k and re place any missing par ts .
Mechanical or h y draulic jacks may f ail to
suppor t the machine and cause a serious
injur y .
• Use jack stands when suppor ting the
machine.
• Do not use h y draulic jacks.
Step
2
Installing the Bafes
Parts needed for this step:
1
Right side rubber bafe
1
Left side rubber bafe
1
Left metal bafe stiffener
8
Carriage bolt (5/16 x 1 inch)
8
Locknut (5/16 inch)
1
Right metal bafe stiffener
Procedure
Note: Install bolts as sho wn in Figure 1 .
© 2005—The Toro® Company8111 Lyndale Avenue SouthBloomington, MN 55420
Register at www.Toro.com. Original Instructions (EN)Printed in the USA.All Rights Reserved

Note: T here are different ends on the left and
right metal baffle stiffeners . See Figure 1 to
identify the difference betw een the left and right
metal stiffeners .
1. Install the left side r ubber baffle and the left
metal baffle stiffener with 4 bolts (5/16 x 1
inc h) and 4 loc kn uts (5/16 inc h) ( Figure 1 ).
2. Install the right side r ubber baffle and the right
metal baffle stiffener with 4 bolts (5/16 x 1
inc h) and 4 loc kn uts (5/16 inc h) ( Figure 1 ).
3. R otate the cutting blades and mak e sure they
do not hit the baffles .
Figure 1
1. Mower deck
5. Carriage bolt (5/16 x 1inch)2. Locknut (5/16 inch)
6. Right side rubber bafe3. Left side rubber bafe 7. Left metal bafe stiffener4. Right metal bafe stiffener 8. Note the different ends onbafes
2
