Toro 09802 HydroJect 3010 User manual

Operator’s Manual
Domestic English (EN)
Form No. 3356–184 Rev B
HydroJect)3010
Aerator
Model No. 09802—250000001 and Up

2
All Rights Reserved
Printed in the USA
W2005 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
Warning
This spark ignition system complies with Canadian
ICES-002.
Ce système d’allumage par étincelle de véhicule est
conforme à la norme NMB-002 du Canada.
Contents
Page
Introduction 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safe Operating Practices 3. . . . . . . . . . . . . . . . . . . .
Sound Pressure Level 5. . . . . . . . . . . . . . . . . . . . . . .
Sound Power Level 5. . . . . . . . . . . . . . . . . . . . . . . .
Vibration Level 5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety and Instruction Decals 5. . . . . . . . . . . . . . . . .
Specifications 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 9. . . . . . . . . . . . . . . . . . . . .
Controls 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Water Injection System 10. . . . . . . . . . . . . . . . . . . . .
Dimensions 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Depths and Nozzle Configurations 11. . . . . . . . . . . .
Setup 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loose Parts 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Rear Wheels 12. . . . . . . . . . . . . . . . . . .
Before Operating 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Activating and Charging the Battery 13. . . . . . . . . . .
Checking the Engine Oil 14. . . . . . . . . . . . . . . . . . . .
Filling the Gas Tank 14. . . . . . . . . . . . . . . . . . . . . . . .
Checking the Gear Case Fluid Level 15. . . . . . . . . . .
Checking the Pump Case Fluid Level 16. . . . . . . . . .
Checking the Tire Pressure 16. . . . . . . . . . . . . . . . . .
Checking the Accumulator Charge 16. . . . . . . . . . . .
Operation 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Controls 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Precautions 18. . . . . . . . . . . . . . . . . . . . . .
Starting and Stopping the Engine 18. . . . . . . . . . . . . .
Training Period 19. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Water Supply 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Procedure 19. . . . . . . . . . . . . . . . . . . . . . .
Checking the Interlock System 20. . . . . . . . . . . . . . .
Transport Operation 21. . . . . . . . . . . . . . . . . . . . . . . .
Inspection and Clean-Up After Use 21. . . . . . . . . . . .
Pushing or Towing the Machine 21. . . . . . . . . . . . . .
Maintenance 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Maintenance Schedule 23. . . . . . . . .
Daily Maintenance Checklist 24. . . . . . . . . . . . . . . . .
Lubricating the Machine 25. . . . . . . . . . . . . . . . . . . .
Servicing the Pre-Filter 26. . . . . . . . . . . . . . . . . . . . .
Replacing the Main Water Filter 26. . . . . . . . . . . . . .
Changing the Engine Oil and Filter 27. . . . . . . . . . . .
General Air Cleaner Maintenance 27. . . . . . . . . . . . .
Servicing the Air Cleaner 27. . . . . . . . . . . . . . . . . . . .
Checking and Replacing the Spark Plugs 28. . . . . . .
Changing the Gear Case Oil and Filter 29. . . . . . . . .
Changing the Pump Case Oil 30. . . . . . . . . . . . . . . . .
Checking the Hydraulic Lines and Hoses 30. . . . . . .
Adjusting the Traction Pump Belt 30. . . . . . . . . . . . .
Adjusting the Transmission for Neutral 31. . . . . . . . .
Adjusting the Aeration Speed 31. . . . . . . . . . . . . . . .
Adjusting the Parking Brake 32. . . . . . . . . . . . . . . . .
Adjusting the Roller Spray Wash System 32. . . . . . .
Servicing the Spray Wash Nozzles or Strainers 33. . .
Caring for the Battery 33. . . . . . . . . . . . . . . . . . . . . .
Seasonal Storage 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing the Water System 34. . . . . . . . . . . . . . . . . .
Preparing the Engine 34. . . . . . . . . . . . . . . . . . . . . . .
Preparing the Traction Unit 34. . . . . . . . . . . . . . . . . .
Troubleshooting 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Schematic 39. . . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic 40. . . . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic 41. . . . . . . . . . . . . . . . . . . . . . . .
Water System Schematic 42. . . . . . . . . . . . . . . . . . . .
The Toro Aerator Commercial Products Warranty 44. . .

3
Introduction
Read this manual carefully to learn how to operate and
maintain your product properly. The information in this
manual can help you and others avoid injury and product
damage. Although Toro designs and produces safe
products, you are responsible for operating the product
properly and safely.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Service
Dealer or Toro Customer Service and have the model and
serial numbers of your product ready. The model and serial
numbers are stamped on a plate which is riveted to the
frame.
Write the product model and serial numbers in the space
below:
Model No.
Serial No.
This manual identifies potential hazards and has special
safety messages that help you and others avoid personal
injury and even death. Danger, Warning, and Caution are
signal words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
Danger signals an extreme hazard that will cause serious
injury or death if you do not follow the recommended
precautions.
Warning signals a hazard that may cause serious injury or
death if you do not follow the recommended precautions.
Caution signals a hazard that may cause minor or moderate
injury if you do not follow the recommended precautions.
This manual uses two other words to highlight information.
Important calls attention to special mechanical
information and Note: emphasizes general information
worthy of special attention.
Safety
Improper use or maintenance by the operator or owner
can result in injury. To reduce the potential for injury,
comply with these safety instructions and always pay
attention to the safety alert symbol, which means
CAUTION, WARNING, or DANGER—“personal
safety instruction.” Failure to comply with the
instruction may result in personal injury or death.
Safe Operating Practices
The following instructions are from ANSI standard
B71.4—2004.
Training
•Read the Operator’s Manual and other training material.
If the operator(s) or mechanic(s) can not read English it
is the owner’s responsibility to explain this material to
them.
•Become familiar with the safe operation of the
equipment, operator controls, and safety signs.
•All operators and mechanics should be trained. The
owner is responsible for training the users.
•Never let children or untrained people operate or
service the equipment. Local regulations may restrict
the age of the operator.
•The owner/user can prevent and is responsible for
accidents or injuries occurring to himself or herself,
other people or property.
Preparation
•Evaluate the terrain to determine what accessories and
attachments are needed to properly and safely perform
the job. Only use accessories and attachments approved
by the manufacturer.
•Wear appropriate clothing including hard hat, safety
glasses and hearing protection. Long hair, loose
clothing or jewelry may get tangled in moving parts.
•Inspect the area where the equipment is to be used and
remove all objects such as rocks, toys and wire which
can be contacted by the aerator.
•Use extra care when handling gasoline and other fuels.
They are flammable and vapors are explosive.
•Use only an approved container
•Never remove gas cap or add fuel with engine
running. Allow engine to cool before refueling.
Do not smoke.
•Never refuel or drain the aerator indoors.
•Check that operator’s presence controls, safety switches
and shields are attached and functioning properly. Do
not operate unless they are functioning properly.
Operation
•Never run an engine in an enclosed area.
•Only operate in good light, keeping away from holes
and hidden hazards.

4
•Be sure all drives are in neutral and parking brake is
engaged before starting engine. Start the engine only
from the operator’s position.
•Never operate without the shields, covers or other
guards securely in place. Be sure all interlocks are
functioning properly.
•Keep hands and feet away from the nozzle and roller
area. High velocity water jets can penetrate hands and
feet. Penetration by the high velocity water jets can
cause serious personal injury. If accidental penetration
occurs, seek medical attention immediately.
•Never use chemicals in the water supply system.
•Do not operate the water injection system on concrete
or asphalt because water jets will permanently damage
these surfaces.
•Before disconnecting or performing any work on the
water system, all pressure in the system must be
relieved by stopping the engine and opening the bleed
valve. Opening the bleed valve allows any trapped
water to escape from the system and also allows the
accumulator piston to move to the bottom of the
accumulator cylinder.
•Do not change the engine governor setting or overspeed
the engine.
•The accumulator in this machine contains high pressure
dry nitrogen. Accumulator servicing requires special
tools and precautions. Accumulators do not contain user
serviceable components. Improper accumulator
servicing can cause dismemberment or death. Do not
attempt to disassemble an accumulator; have this work
done by an Authorized Toro Distributor.
•Stop on level ground, disengage drives, engage parking
brake, shut off engine before leaving the operator’s
position for any reason.
•Never carry passengers and keep pets and bystanders
away.
•Be alert, slow down and use caution when making
turns. Look behind and to the side before changing
directions.
•Slow down and use caution when crossing roads and
sidewalks.
•Do not operate the aerator under the influence of
alcohol or drugs.
•Use extreme care when loading or unloading the aerator
into a trailer or truck.
•Use care when approaching blind corners, shrubs, trees,
or other objects that may obscure vision.
Slope Operation
•Do not operate near drop–offs, ditches, steep banks or
water. Wheels or rollers dropping over edges can cause
rollovers, which may result in serious injury or death.
•Do not operate on slopes when grass is wet. Slippery
conditions reduce traction and could cause sliding and
loss of control.
•Do not make sudden turns or rapid speed changes.
•Reduce speed and use extreme caution on slopes.
•Remove or mark obstacles such as rocks, tree limbs,
etc. from the operating area. Tall grass can hide
obstacles.
•Watch for ditches, holes, rocks, dips, and rises that
change the operating angle, as rough terrain could
overturn the aerator.
•Be aware that loss of traction may occur going
downhill. Weight transfer may cause drive wheel to slip
and cause loss of braking and steering.
•Always avoid sudden starting or stopping on a slope. If
tire loses traction, disengage the water injection system
and proceed slowly off the slope.
Maintenance and storage
Engine exhaust contains carbon monoxide, which
is an odorless, deadly poison that can kill you.
Do not run engine indoors or in an enclosed area.
Warning
•Make sure all hydraulic line connectors are tight and all
hydraulic hoses and lines are in good condition before
applying pressure to the system.
•Keep your body and hands away from pin hole leaks or
nozzles that eject hydraulic fluid under high pressure.
Use paper or cardboard, not your hands, to search for
leaks. Hydraulic fluid escaping under pressure can have
sufficient force to penetrate the skin and cause serious
injury. Seek immediate medical attention if fluid is
injected into skin.
•Before disconnecting or performing any work on the
hydraulic system, all pressure in the system must be
relieved by stopping the engine and lowering the deck
and attachments to the ground.
•Let engine cool before storing and do not store near
flame.
•Shut off fuel while storing or transporting on trailers.
Do not store fuel near flames or drain indoors.

5
•Park machine on level, hard ground. Never allow
untrained personnel to service machine.
•Use jack stands or safety latches to support components
when required.
•Carefully release pressure from components with stored
energy.
•Disconnect battery or remove spark plug wire before
making any repairs. Disconnect the negative terminal
first and the positive last. Reconnect positive first and
negative last.
•Keep hands and feet away from moving parts. If
possible, do not make adjustments with the engine
running.
•Charge batteries in an open well ventilated area, away
from spark and flames. Unplug charger before
connecting or disconnecting from battery. Wear
protective clothing and use insulated tools.
•Keep all parts in good working condition and all
hardware tightened. Replace all worn or damaged
decals.
•Use only Toro-approved attachments. Warranty may be
voided if used with unapproved attachments.
Sound Pressure Level
This unit has an equivalent continuous A–weighted sound
pressure level at the operator ear of 93 dBA, based on
measurements of identical machines per Directive
98/37/EC and amendments.
Sound Power Level
This unit has a guaranteed sound power level of:
108 dBA/1 pW, based on measurements of identical
machines per Directive 2000/14/EC and amendments.
Vibration Level
This unit does not exceed a vibration level of 4.0 m/s@at
the hands based on measurements of identical machines per
ISO 5349 procedures.
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger. Replace any decal that is damaged or lost.
80-8000
80-8880
80-8760
93-9363
1. Parking brake
2. Locked
3. Unlocked
80-8090

6
80-8040
80-8010
IMPORTANT
THE FIVE MICRON FILTER ELEMENT (86–8620) MUST
BE IN PLACE AT ALL TIMES.
OPERATION WITHOUT PROPER FILTRATION WILL
RESULT IN PREMATURE WEAR AND FAILURE OF THE
WATER SYSTEM COMPONENTS.
USE OF ADDITIONAL FILTRATION OR POTABLE WATER
MAY BE NECESSARY TO PROLONG THE LIFE OF THE
FILTRATION SYSTEM.
D
D
D
SEE OPERATOR’S MANUAL FOR MORE INFORMATION.D
92-9542
72-4080
93-9429
108-1316

7
108-1317
108-1263
1. Choke
80-9450

8
108-1264
108-1265

9
Specifications
Note: Specifications and design subject to change without notice.
General Specifications
Engine
Kohler, 4 cycle, V–twin, air cooled, 27 hp @ 3600 RPM, 44 cu. in (725 cc)
displacement. Electric start. Heavy duty air cleaner. 2 quart oil capacity. Solid state
ignition. Meets California Exhaust Emission Standard and EPA Standards for Lawn
and Garden Equipment.
Clutches Electromagnetic, dual groove belt drive for water pump and drive shaft flange
brake/clutch for main valve gearbox.
Electrical
12 volt system with 15 amp circuit breaker protection. Relays for all high current
switching. Electronic controller and sensors for automatic startup and shutdown
sequence of water injection system. Group 28 battery with 535 cold crank amps.
Traction Drive
Closed loop hydrostatic drive consisting of Sundstrand variable volume pump and
Parker low speed, high torque wheel motor mounted to steering fork. Hydraulic
system contains 5 quarts with 25 micron suction line filter and gearbox reservoir.
Tires/Wheels
Three, smooth tread 2 ply, 18 x 9.50-8,pneumatic tubeless, tires. De–mountable
drop center steel wheels with 4 lug nuts mounted to tapered roller bearing hubs on
transport arms and brake hub on wheel motor. All are interchangeable.
Brake Drum and shoe-type parking brake mounted to wheel motor. Holds unit on a 30%
grade.
Transport Lift 12 volt Warner Electric linear screw actuator with 6 inch stroke. Raises and lowers
lift arm/transport tires and activates hole spacing control.
Fuel Capacity 10.5 gallons gasoline
Ground Speed Aerating: 0–2 MPH (both directions)
Transport: 0–4 MPH (both directions)
Aeration Width 33 inches with 11 nozzles on 3 inch centers
Aeration Depth 4 to 6 inches depending on turf conditions and nozzle configuration
Hole Pattern Variable from 1-1/2 to 6 in. spacing in the direction of travel, and 3 or 6 in.
increments in width
Controls
Engine Panel Throttle, choke, spray wash control, hour meter, water pressure gauge, spacing
control lever, key switch, and circuit breaker reset button
Steering Tiller Panel Traction bail, water system engage and disengage buttons, transport/aerate lift
rocker switch, and parking brake with buzzer alarm.
Electronic Control Module Solid state potted device for sequencing start and stop of water system. Interlocks
for water pressure, transport lift, traction neutral and accumulator over–pressure.

10
Water Injection System
Pre-Filter Spin down type with washable cartridge in clear plastic housing and plastic ball
valve for flushing.
Supply Filter Replaceable cartridge in plastic housing with air bleed button.
Water Pressure Switch Senses for water pressure after filter and turns on when pressure is over 20–28 psi
and turns off when pressure drops below 7–13 psi.
Pump
Pump is a Toro exclusive design with cast stainless steel head and 3 piston
plungers. Vee packing seals and Kevlar guides. Forged crankshaft with plasma
sprayed ceramic on stainless steel plungers and cast iron connecting rods. Nominal
performance is 4 gpm @ 5000 psi with 1400 RPM input.
Accumulator Toro exclusive design with high and low charge pressure sensors, nitrogen gas
charged to a maximum of 2500psi.
Cam and Gearbox
Reduction gear drive for cam that actuates main water valve. Roller cam follower
rides on cam specifically designed to control water injection at 5.3 cycles per
second (320 RPM) and store energy in accumulator between injections. Cast iron
case also serves as 4 quart hydraulic reservoir.
Valve
Cast stainless steel valve body functions as mounting base for accumulator,
gearbox, and manifold outlet. All high pressure water flows in and out through the
valve body. Pressure balanced valve spool with floating, hardened stainless seat
aligns during assembly. Bleed valve in base allows for bleed-off of high pressure
and drain down for cold weather storage. Bolted flanges and polyurethane o-rings
mate all components to valve body.
Rollers
Pivoting aluminum rollers uniformly smooth the turf and provide protection from the
nozzle discharge. Adjustable flow (0–3 gpm) spray wash system with 6 flood tip
nozzles maintain clean rollers.
Pressure Relief Valve Circle Seal Controls poppet-type valve preset to 5000 psi with corrosion resistant
stainless and brass materials.
Manifold and Nozzles
Extruded stainless steel manifold with 11 flanged nozzle extensions containing
check valves and hardened stainless discharge orifice. Check valves may be
reversed in housing to block unused nozzles.
Dimensions
Length 96.2 in. (244 cm)
Wheelbase 53.2 in. (135 cm)
Width 63 in. (160 cm)
Height 38.2 in. (97 cm)
Weight 1120 lb. (508 kg)

11
Depths and Nozzle Configurations
All nozzles are identified with numbers indicating the drill size of the orifice. The standard configuration is 11 nozzles
producing depths of 4 to 6 inches depending on turf conditions. Blocked nozzle locations are obtained by reversing the nozzle
check valve ball and spring. See nozzle size chart and illustrations below:
Important Use only nozzle configurations shown or damage to the machine may occur.
Nozzle Size and Approximate Depth Chart
Part No
Drill Size
Decimal Metric Size Quantity of Nozzles A
pp
rox.
Part No. Drill Size
Decimal
Size (inch)
Metric Size
(mm) Open Blocked
Approx
.
Depth
86-8130 #56 0.0465 1.181 * * *
86-8131 #53 0.0595 1.511 11 04–6 in.
86-8133 #46 0.081 2.057 6 5 6–8 in.
* Use only with varied size configurations
Note: Aluminum Washer, Toro Part no. 80-6680, is required with any nozzle change.
Optional Staggered Size Nozzle Configuration
Part No
Drill Size
Decimal Metric Size Quantity of Nozzles A
pp
rox.
Part No. Drill Size
Decimal
Size (inch)
Metric Size
(mm) Open Blocked**
Approx
.
Depth
86-8130 #56 0.0465 1.181 6 and 0** 3–4 in.
86-8133 #46 0.081 2.057 5 0** 6–8 in.
** Additional nozzles may be blocked to compensate for pump wear.
Note: Aluminum Washer, Toro Part no. 80-6680, is required with any nozzle change.
Closed (Blocked) Nozzle
Open Nozzle
Spring
Spring Check Valve Ball
Check Valve Ball

12
Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Note: Use this chart as a checklist to ensure that all parts have been received. Without these parts, total setup cannot be
completed.
Description Qty. Use
Wheel
Lug nut
3
12 Installing the rear wheels
Ignition key 1Use in ignition switch.
Hose adapter 1Mount to quick coupler on side of machine.
Spanner wrench 1Use for installation and removal of water filter.
Parts catalog 1
Operator’s manual 1Read before operating the machine.
Installing the Rear Wheels
1. Remove the wheels from the shipping pallet.
2. Mount the wheels to the hubs with the lug nuts
(supplied in loose parts) (Fig. 1) and torque the nuts to
45–55 ft.-lb. (61–75 N⋅m).
3. Remove any shipping blocks or braces, which may
obstruct machine removal from the pallet.
Important Refer to the Before Operating section in this
manual, page 13, for instructions on preparing the machine
for operation. 1
2
Figure 1
1. Wheel 2. Lug nuts

13
Before Operating
Activating and Charging the
Battery
Battery posts, terminals, and related accessories
contain lead and lead compounds, chemicals
known to the State of California to cause cancer
and reproductive harm. Wash hands after
handling.
Warning
1. Since the battery is not filled with electrolyte or
activated, bulk electrolyte with 1.260 specific gravity
must be purchased from a local battery supply outlet.
Danger
Battery electrolyte contains sulfuric acid which is a
deadly poison and causes severe burns.
•Do not drink electrolyte and avoid contact with
skin, eyes or clothing. Wear safety glasses to
shield your eyes and rubber gloves to protect
your hands.
•Fill the battery where clean water is always
available for flushing the skin.
2. Release the hood latches and raise the hood.
3. Loosen the capscrew securing the battery clamp to the
machine and remove the battery (Fig. 2). Remove the
filler caps from the battery and slowly fill each cell until
electrolyte is just above the plates.
Battery terminals or metal tools could short
against metal aerator components causing sparks.
Sparks can cause the battery gasses to explode,
resulting in personal injury.
•When removing or installing the battery, do not
allow the battery terminals to touch any metal
parts of the aerator.
•Do not allow metal tools to short between the
battery terminals and metal parts of the aerator.
Warning
1
Figure 2
1. Battery
4. Replace the filler caps and connect a 3 to 4 amp battery
charger to the battery posts. Charge the battery at a rate
of 3 to 4 amperes for 4 to 8 hours.
Charging the battery produces gasses that can
explode.
Never smoke near the battery and keep sparks and
flames away from battery.
Warning
5. When the battery is charged, disconnect the charger
from the electrical outlet and battery posts.
6. Remove the filler caps. Slowly add electrolyte to each
cell until the level is up to the fill ring. Install the filler
caps.
Important Do not overfill the battery. Electrolyte will
overflow onto other parts of the machine and severe
corrosion and deterioration will result.
7. Install the battery and secure it with the battery clamp.
Incorrect battery cable routing could damage the
aerator and cables causing sparks. Sparks can
cause the battery gasses to explode, resulting in
personal injury.
•Always disconnect the negative (black) battery
cable before disconnecting the positive (red)
cable.
•Always connect the positive (red) battery cable
before connecting the negative (black) cable.
Warning

14
8. Install the positive cable (rubber boot over end) to the
positive (+) terminal and the negative cable (black) to
the negative (–) terminal of the battery and secure them
with capscrews and nuts. Slide the rubber boot over the
positive terminal to prevent a possible short-out from
occurring (Fig. 2).
9. Lower the hood and secure the latches.
Checking the Engine Oil
The engine is shipped with oil in the crankcase; however,
the oil level must be checked before and after the engine is
first started.
Crankcase capacity is approximately 2 qt. (1.4 l) with the
filter.
Use high-quality engine oil that meets the following
specifications:
API Classification Level Required: SJ, SK, SL or
higher.
Preferred oil: SAE 10W–30 (above 0_F)
Alternate oil: SAE 5W–30 (below 32_F)
Toro Premium Engine oil is available from your distributor
in 10W–30 viscosity. See the parts catalog for part
numbers.
1. Position the machine on a level surface.
2. Remove the dipstick from the oil filler neck (Fig. 3) and
wipe it with a clean rag. Insert the dipstick into the filler
neck and make sure it is seated fully. Pull the dipstick
from the filler neck and check the oil level. If the oil
level is low, add enough oil to raise the level to the
FULL mark on the dipstick.
1
2
Figure 3
1. Dipstick 2. OIl fill cap
Note: If the oil level is at the ADD mark on the dipstick,
add 1 quart of oil to raise the oil level to FULL. Do not
overfill.
3. Remove the cap from the oil fill. Pour oil into the oil fill
until the level is at the FULL mark on the dipstick.
Important The aerator operates at very high engine
loads, so check the oil level every 8 operating hours or
daily. A new engine may consume some oil until it is
broken in. Initially, change the oil after the first 25 hours of
operation; thereafter, under normal conditions, change the
oil and filter after every 100 hours of operation. Change the
oil more frequently when the engine is operated in
extremely dusty or dirty conditions.
Filling the Gas Tank
We recommend the use of fresh, clean, unleaded regular
grade gasoline. Unleaded gasoline burns cleaner, extends
engine life, and promotes good starting by reducing the
build-up of combustion chamber deposits.
Note: Do not mix oil with the gasoline. Never use
methanol, gasoline containing methanol, gasohol, gasoline
additives, premium gasoline, or white gas because engine
and fuel system damage could result.
1. Remove the cap from the fuel tank (Fig. 4) and fill the
10 gallon tank to about 1 inch (25 mm) from the top of
tank (the bottom of the filler neck) with unleaded
gasoline. Install the fuel tank cap tightly.
1
Figure 4
1. Fuel tank cap
2. Wipe up gasoline that may have spilled to prevent a fire
hazard.

15
Danger
In certain conditions, gasoline is extremely
flammable and highly explosive. A fire or
explosion from gasoline can burn you and others
and can damage property.
•Fill the fuel tank outdoors, in an open area,
when the engine is cold. Wipe up any gasoline
that spills.
•Do not fill the fuel tank completely full. Add
gasoline to the fuel tank until the level is 1 in.
(25 mm) below the bottom of the filler neck.
This empty space in the tank allows gasoline to
expand.
•Never smoke when handling gasoline, and stay
away from an open flame or where gasoline
fumes may be ignited by a spark.
•Store gasoline in an approved container and
keep it out of the reach of children. Never buy
more than a 30-day supply of gasoline.
•Always place gasoline containers on the ground
away from your vehicle before filling.
•Do not fill gasoline containers inside a vehicle or
on a truck or trailer bed because interior
carpets or plastic truck bed liners may insulate
the container and slow the loss of any static
charge.
•When practical, remove gas-powered equipment
from the truck or trailer and refuel the
equipment with its wheels on the ground.
•If this is not possible, then refuel such
equipment on a truck or trailer from a portable
container, rather than from a gasoline dispenser
nozzle.
•If a gasoline dispenser nozzle must be used, keep
the nozzle in contact with the rim of the fuel
tank or container opening at all times until
fueling is complete.
Checking the Gear Case Fluid
Level
The machines reservoir is filled at the factory with
approximately 4–5 quarts of high quality hydraulic fluid.
Check the level of the hydraulic fluid, on the sight
gauge, before the engine is first started and daily
thereafter. The recommended replacement fluid is:
Mobil DTE 26
Alternate fluids: If this fluid is not available, other fluids
may be used provided they meet all the following material
properties and industry specifications. We do not
recommend the use of synthetic fluid. Consult with your
lubricant distributor to identify a satisfactory product.
Note: Toro will not assume responsibility for damage
caused by improper substitutions, so use only products
from reputable manufacturers who will stand behind their
recommendation.
Antiwear Hydraulic Fluid, ISO VG 68
Material Properties:
Viscosity, ASTM D445 cSt @ 40_C 65 to 71
cSt @ 100_C 8.4 to 8.9
Viscosity Index ASTM D2270 97 to 107
Pour Point, ASTM D97 –18_F to –30_F
Industry Specifications:
Vickers I–286–S (Quality Level), Vickers M–2950–S
(Quality Level), Denison HF–0
Note: Many hydraulic fluids are almost colorless, making it
difficult to spot leaks. A red dye additive for the hydraulic
system oil is available in 2/3 oz. (20 ml) bottles. One bottle
is sufficient for 4–6 gal (15–22 1) of hydraulic oil. Order
part no. 44–2500 from your authorized Toro distributor.
1. Position the machine on a level surface.
2. Release the hood latches and raise the hood.
3. Check the level of hydraulic oil on the sight gauge
(Fig. 5). The fluid level should be up to the middle of
the gauge window.
1
2
Figure 5
1. Sight gauge 2. Filler cap
4. If the fluid level is low, remove the filler cap and add
enough hydraulic oil to bring the oil up to the proper
level.
5. Lower the hood and secure the latches.
Important The oil and filter must be changed
immediately when any contamination, sludge, water or
condensation appears in oil or on sight gauge. Determine
and correct oil contamination problem before restarting
engine and operating machine.

16
Checking the Pump Case Fluid
Level
The pump crank case is filled at the factory with
approximately 40 ounces of Mobil DTE Extra Heavy oil.
Check the oil level on the dipstick before the engine is first
started and daily thereafter. Change the oil initially after
25 hours of operation, thereafter change every 200 hours
of operation. See the chart below for equivalent oils.
Shell Morlina Sd 150
Chevron AW Machine Oil 150
Conoco Multipurpose R&O
0.1 150
Exxon Terresstic 150
Philllips Magnus Oil 150
Sun Sunvis 150
76 Lubricants Turbine Oil 150
Castrol Paradene 150 R&O
Important The oil must be changed immediately when
any contamination, sludge, water, or condensation appears
in the oil. Determine and correct any oil contamination
problem before restarting the engine and operating the
machine.
1. Position the machine on a level surface.
2. Release the hood latches and raise the hood.
3. Remove the dipstick/filler cap and check the oil level on
the dipstick. The fluid level should be up to the FULL
mark (Fig. 6).
FULL
1
Figure 6
1. Dipstick/filler cap
4. If the fluid level is low, add enough Mobil DTE Extra
Heavy oil or equivalent oil to bring the oil up to the
proper level. Do not overfill.
5. Lower the hood and secure the latches.
Checking the Tire Pressure
The tires are over inflated for shipping. Make sure that the
front and rear tires are inflated to 8 to 12 p.s.i. (55 to
83 kPa).
Checking the Accumulator
Charge
Have the accumulator charge checked before and after each
operating season by an Authorized Toro Distributor.
Charge accumulators contain high pressure
nitrogen. Nitrogen is the only gas to use for
accumulator charging. Installing improper gases in
an accumulator can cause an explosion and death.
Charging requires special tools and precautions.
•Charge the accumulator in a well ventilated
area.
•Have the accumulator checked and charged by
an Authorized Toro Distributor.
•Wear eye protection.
•Keep your hands and face away from the gas
valve.
Warning
Failure to open the bleed valve before servicing
high pressure water components can cause
personal injury, dismemberment, or death.
Slowly open the high pressure water bleed valve
before servicing any component connected to the
high pressure water system. Opening the high
pressure bleed valve allows any trapped water to
escape from the system and also allows the
accumulator piston to move to the bottom of the
accumulator cylinder.
Warning

17
Operation
Note: Determine the left and right sides of the machine
from the normal operating position.
Controls
Ignition Switch
The ignition switch (Fig. 7), which is used to start and stop
the engine, has three positions: OFF, ON, and START.
1
2
3
4
5
6
7
9
8
Figure 7
1. Ignition switch
2. Choke
3. Throttle
4. Spray wash control
5. Hour meter
6. Water pressure gauge
7. Circuit breaker reset
button
8. Spacing control lever
9. Accumulator pressure
lights
Choke
To start the engine, close the carburetor choke by pulling
the choke control (Fig. 7) outward to the FULL position.
After the engine starts, regulate the choke to keep the
engine running smoothly. As soon as possible, open the
choke by pushing it inward to the OFF position.
Throttle
The throttle (Fig. 7) is used to regulate the engine speed.
Moving the throttle forward increases the engine speed
(FAST); rearward decreases the engine speed (SLOW).
Spray Wash Control
Pull the handle (Fig. 7) upward to activate the roller spray
wash system. Move the control knob up or down to adjust
the spray rate to keep the rollers free of debris.
Hour Meter
The hour meter (Fig. 7) registers accumulated hours of
engine operation. Use the hour meter to determine intervals
for service maintenance and lubrication.
Water Pressure Gauge
The water pressure gauge (Fig. 7) registers supply water
pressure in the system. It also acts as an interlock switch,
preventing the water pump from starting if the water
pressure is below 20–28 p.s.i., or stopping the water pump
if the water pressure drops below 7–13 p.s.i. Check the
gauge frequently to monitor the water pressure.
Circuit Breaker Reset Button
Push the button (Fig. 7) to reset the breaker after correcting
a malfunction in the electrical system. The button also
serves as a switch to interrupt power to the relays.
Spacing Control Lever
Moving the control (Fig. 7) away from the handle increases
the aerating ground speed and the distance between holes.
Moving the control toward the handle decreases the
aerating ground speed and the distance between holes. The
setting will be overridden when the machine is shifted to
the transport position.
Accumulator Pressure Lights
The high or low pressure lights (Fig. 7) will only illuminate
if a high or low pressure condition occurs in the
accumulator. If a light illuminates the system willl not
operate or shut down.
Traction Bail
The traction bail (Fig. 8) engages and regulates fore and aft
traction operation of the machine. Releasing the bail stops
traction operation and will also stop water injection in 3 to
4 seconds, unless the bail is re–engaged. The transport
speed is regulated by the amount the bail is moved.

18
1
5
234
Figure 8
1. Traction bail
2. Transport/aerate rocker
switch
3. Aeration engagement
button
4. Aeration stop button
5. Parking brake
Transport/Aerate Rocker Switch
The switch (Fig. 8) lowers machine onto the rollers to
commence aeration. The switch will override the spacing
control setting when it is moved to the transport position.
Aeration Engagement Button
Depressing the button (Fig. 8), starts the water injection
system only when the water pressure is above 28 p.s.i. and
the rollers are on the ground.
Aeration Stop Button
The red button (Fig. 8) stops the water injection system.
The system continues for a few seconds after the button is
pressed.
Parking Brake
Push the lever (Fig. 8) toward the machine to engage the
parking brake. A warning buzzer will sound if you attempt
to move the machine with parking brake engaged.
Fuel Shut-Off Valve
The fuel shut-off valve is located under the fuel tank. Close
the valve when storing or transporting (trailering) the
machine.
Operating Precautions
Follow these precautions when operating the aerator:
•Before aerating, inspect the work area for debris and
determine the best direction and pattern to operate the
machine.
•If the machine starts to vibrate abnormally, shut the
engine off. Remove the wires from the spark plugs to
prevent the possibility of accidental starting. Check the
machine for damaged parts. Repair any damage before
restarting the engine and operating the machine.
•Only use the aerator in daylight or when there is good
artificial light. Watch for holes or other hidden hazards.
Do not transport the machine close to a sand trap, ditch,
creek, or other hazard.
•To prevent roller marks, always raise the machine to the
transport position when parked on a green.
•Do not operate the water injection system on concrete
or asphalt because water jets will permanently damage
these surfaces. Do not run over the hose as damage will
occur.
•Do not operate the aerator with the roller or injection
system over the edge of anything that could be hit,
damaged, or injured by high velocity water blasts.
•Water jets from the injection system should not damage
irrigation heads on one pass of the machine. Do not
allow multiple shots from the injection system to hit
irrigation heads as damage will occur.
•Use a good, clean, quality water supply in the system. If
good quality water is not available, additional filtration
equipment may be required. Do not use chemicals in
the water system.
•Do not allow the machine to be subject to freezing
temperatures without draining, as damage to the system
will occur.
Starting and Stopping the
Engine
1. Make sure that the wires are installed on the spark plugs
and the fuel shut-off valve is open.
2. Make sure that the parking brake is engaged.
3. Pull the choke lever out to the FULL position and move
the throttle lever to the half throttle position.
Note: When starting a warm engine, the choke may not be
necessary, but HALF throttle is.

19
4. Insert the key into the ignition switch and rotate it
clockwise to start the engine. Release the key when the
engine starts. Gradually return the choke lever to the
OFF position (lever all the way in) after the engine
starts and warms up.
Important To prevent overheating of the starter motor,
do not engage the starter longer than 30 seconds. After 30
seconds of continuous cranking, wait 2 minutes before
engaging the starter motor again.
Important The engine is equipped with an oil pressure
interlock switch which interrupts the engine operation if
there is not sufficient oil pressure in the engine during
starting or operation. The engine may start but will not
continue to run due to a lack of oil pressure.
5. To stop the engine, move the throttle control downward
to the SLOW position and turn the ignition key to OFF.
Remove the ignition key.
Training Period
Before aerating with the machine, it is suggested that you
find a clear area and practice starting and stopping, raising
and lowering machine, turning, etc. This training period
will be beneficial to the operator in gaining confidence in
the performance of the aerator.
Water Supply
Recommended source with 7–8 gallons per minute. A
minimum pressure of 30 p.s.i. at the machine is required for
the pump to engage. Maximum allowable pressure of 200
psi. Although irrigation water pumped from ponds or
effluent holding pools can be used, not all conditions can be
handled by the filtration system. Additional or alternative
filtration may be required.
Operating Procedure
1. Make sure that the wires are installed on the spark plugs
and the fuel shut-off valve is open.
2. Uncoil a garden hose, making sure that there are no
kinks or bends in the hose. Lay out the hose so that
there are no obstructions between the machine and the
area to be aerated. Turn on the water supply to purge
any air from the hose. Turn off the water.
3. Connect the hose adapter (Fig. 9) to the garden hose,
then connect the adapter to the quick coupler on the side
of the machine.
2
1
Figure 9
1. Hose adapter 2. Quick coupler
4. Turn on the water supply and check the water pressure.
The water pressure must be at least 30 p.s.i.. If the
system pressure is not 30 p.s.i., make sure that the hose
is not kinked or obstructed, the water supply is turned
on, and the water filter is not plugged.
Do not operate the engine while bleeding the filter
head.
Caution
5. Reach under the fuel tank and press the bleed button on
top of the water filter head (Fig. 10). Hold the bleed
button down until all air is purged from the filter and
water comes out of the opening.
1
2
Figure 10
1. Main water filter head 2. Bleed button

20
6. Reach under the hood and open the bleed valve on the
main valve at the rear of the machine (Fig. 11). Bleed
the system until a steady flow of water comes from the
outlet; then close the valve.
1
2
Figure 11
1. Main valve 2. Bleed valve
7. If desired, the valve on the pre-filter (Fig. 12) may be
opened slightly (cracked) to provide continuous
flushing during operation of the machine.
1
2
Figure 12
1. Pre-filter 2. Valve
8. Start the engine; refer to Starting and Stopping the
Engine, page 18. Move the throttle to the FAST position
and disengage the parking brake.
9. Engage the traction bail and approach the area to be
aerated. Make sure that there are no obstructions
between the aerator and water supply.
10. Engage and hold the transport/aerate toggle switch to
fully lower the machine onto the rollers. Release the
switch when the machine is fully lowered; then press
the engagement button to start water injection.
Note: The injection operation starts approximately 4–5
seconds after the pump engages. Also, the injection system
will automatically stop if the traction bail is not engaged
within 3–4 seconds after starting the water system.
11. When aerating, work moving perpendicular from the
water supply to avoid running over the garden hose.
Use the front edge of the hood or rear corner of the
frame to align rows, if desired. When at the end of a
row, make an “S” maneuver and reverse the direction of
the aerator. Do not make sharp turns on a green or
scuffing from the tire may occur.
12. Regulate the roller spray wash, if required, to remove
debris from the rollers.
Note: A small amount of water from the regulator bypass
may come out of the spray wash nozzles even with the
spray wash in the “OFF” position.
13. In areas where greater hole depth or more frequent
holes are desired, the engage button can be held down
to allow multiple shots while machine is stopped.
Important Hole depths can reach 20 inches or more
when making multiple shots, so be aware of what is buried
below the turf. Also, an excessive amount of holes and
muddy turf conditions may occur when making multiple
shots.
14. To stop water injection, press the red button. The
system continues for a few seconds after the button is
pressed. Raise the machine to the transport position,
disconnect the supply hose, and move to the next
location.
Checking the Interlock System
If safety interlock switches are disconnected or
damaged the machine could operate unexpectedly,
causing personal injury.
•Do not tamper with the interlock switches.
•Check the operation of the interlock switches
daily and replace any damaged switches before
operating the machine.
Caution
The purpose of the safety interlock system is to prevent the
engine from cranking or starting unless the traction bail is
in NEUTRAL and prevents the water system from
engaging if the machine is in the transport (raised) position.
It also stops aeration if the traction bail is released while
operating or if the machine is raised to the transport
position.
