Toshiba TOSVERT VF-AS3 User manual

E6582171
Resolver option Instruction Manual
NOTICE
1. Make sure that this instruction manual is delivered to the end user of Resolver option.
2. Read this manual before installing or operating the option. Keep it in a safe place for
reference.
3. All information contained in this manual will be changed without notice.

1
E6582171
The items described on the inverter, the resolver option and their instruction manuals are very important so that you can use
safely the inverter and resolver option, prevent injury to yourself and other people around you as well as to prevent damage
to properly in the area.
Read the instruction manual (E6582062) attached to the inverter to understand the safety precautions, thoroughly
familiarize yourself with the symbols and the indications completely and then continue to read the manual. Make sure that
you observe all warnings given.
Explanation of markings
Meanings of symbols
Safety precautions
Marking Meaning of marking
WARNING
Indicates that errors in operation will lead to death or serious injury.
CAUTION
Indicates that errors in operation will lead to injury*1 to people or that these errors will cause
damage to physical property*2.
*1 Such things as injury, burns or electric shock that will not require hospitalization or long periods of outpatient treatment.
*2 Physical property damage refers to wide-ranging damage to assets and materials.
Marking Meaning of marking
Indicates an inhibition (Don't do it).
Detailed information on the inhibition is described in illustration and text in or near the symbol.
Indicates a mandatory action that must be followed.
Detailed information on the mandatory action is described in illustration and text in or near the
symbol.
Indicates a warning or caution.
Detailed information on the warning or caution is described in illustration and text in or near
the symbol.

2
E6582171
■ Limitation of use
■ Handling in general
WARNING
Prohibited
• Never use the option with any device other than applicable TOSVERT series inverters.
This will result in accident.
WARNING
Disassembly
inhibited
• Never disassemble, modify or repair the option.
This can result in electric shock, fire or other injury. Please call your Toshiba distributor for repairs.
Prohibited
• Do not place or insert any kind of objects (electrical wire cuttings, rods, wires etc.) inside the option.
This can result in damage or fire.
• Do not allow water or any other fluids come in contact with the option.
This can result in damage or fire.
Mandatory
action
• Immediately turn the power off the inverter with the option begin to emit to smoke, an unusual odor,
unusual sounds or blind display.
Continuous use of the inverter and the option in such state will cause fire. If the inverter and the option
are left to be turned on in that state, it can cause fire. Please call your Toshiba distributor for repairs.
CAUTION
Prohibited
• Do not apply shock (falling, etc.) on the option.
This can result in damage or malfunction.
• Do not touch the connector to the inverter (refer to Names of the Parts).
This can result in damage or accident.
Mandatory
action
• Operate under the environmental conditions prescribed in this manual.
Operations under any other condition can result in malfunction.

3
E6582171
■ Installation & Wiring
■ Operation
WARNING
Prohibited
• Do not install and operate the option if it is damaged or any of its component is missing.
This will result in fire or accident. Please call your Toshiba distributor for repairs.
Mandatory
action
• The following steps must be performed before wiring and installation.
Turn off all input power, wait at least 15 minutes, and confirm that the charge lamp of the inverter is no
longer lit.
If steps above are not properly performed, this will result in electric shock.
• Use an emergency stop device and an additional safety device in your system to prevent serious
accident due to the option malfunctions.
Usage without any emergency stop device or any additional safety device can result in accident or
injury.
CAUTION
Prohibited
• Do not touch the metal part of the power circuit terminals when connecting the interconnection cable to
the option.
This can result in injury.
• Do not connect any wire other than applicable wire to the option.
This can result in malfunction or accident.
• Do not pull the cable and the connector connected to the option.
This can result in damage or malfunction.
Mandatory
action
• Use the resolver according to the specification described in this manual.
Improper resolver usage can result in accident and malfunction.
• Use Multi-layer shielded cable and connect the shield to housing of D-subminiature connector (for
option side cable end shield) and housing of resolver (for resolver side cable end shield).
Use of unshielded cable or improper shield grounding can result in malfunction or accident.
CAUTION
Prohibited
• Do not unplug the option from inverter under operation.
This will result in the damage or accident.
Mandatory
action
• Confirm the rotational direction of motor before start driving your system with this option.
Mismatch rotational direction of motor and that indicated by resolver signal will cause malfunction or
accident.
• Set the correct parameter in accordance with your resolver.
The wrong setting between this option and the resolver can result in damage or accident.

4
E6582171
■ Disposal
*1 Persons who specialize in the processing of waste and known as “industrial waste product collectors and transporters” or “industrial waste disposal
persons”. Please observe any applicable law, regulation, rule or ordinance for industrial waste disposal.
CAUTION
Mandatory
action
• If you dispose of this option, have it done by a specialist in industry waste disposal*1.
If you dispose of this option by yourself, this can result in production of noxious gases, resulting in injury.

5
E6582171
Thank you for purchasing the Resolver option for TOSVERT VF-AS3 series inverter. This option is applicable as an
interface for resolver.
This manual contains instructions of this option.
<Description of the Encoder option>
Introduction
CAUTION
Mandatory
action
• Use the resolver with the specification described in this manual.
Improper resolver usage can result in accident and malfunction.
Important
Firmware compatibility
• VF-AS3 of CPU1 version “V106” or successor is applicable for this option.
Refer to inverter instruction manual for the check method of the CPU version.
VEC 010 Z 0
Revision number
Without cable
Encoder option type number
010: Resolver
Vector control with sensor compatible

6
E6582171
- Table of contents -
1. Names of the Parts....................................................................................................................................................................7
2. Installation and wiring................................................................................................................................................................8
2.1 Installation to the Inverter .................................................................................................................................................8
2.2 Wiring ...............................................................................................................................................................................9
2.2.1 Connector..............................................................................................................................................................9
2.2.2 Pin assignment......................................................................................................................................................9
2.2.3 Signaling .............................................................................................................................................................10
2.2.4 Wiring with resolver.............................................................................................................................................11
3. Functional Description .............................................................................................................................................................12
3.1 Performance of vector control with resolver ...................................................................................................................12
3.1.1 Parameter setting for vector control with resolver...............................................................................................12
3.1.2 Monitoring method for feedback amount.............................................................................................................15
3.1.3 Confirmation of resolver's rotational direction .....................................................................................................15
3.1.4 Abnormal speed detection function.....................................................................................................................15
3.1.5 Accuracy of speed control...................................................................................................................................16
3.1.6 Easy positioning PID control ...............................................................................................................................16
4. Specification ............................................................................................................................................................................17
5. Warranty ..................................................................................................................................................................................18
6. Disposal...................................................................................................................................................................................19

7
E6582171
Appearance of the Resolver option are described in this section together with the names of parts.
■ Appearance and names of parts on the option
1. Names of the Parts
Tab for release option
Terminal connector
(D subminiature connector: DE-9)
Connector (to inverter)
Female screw
(4-40 UNC)

8
E6582171
Install the Resolver option to the inverter according to the procedures below.
2.1 Installation to the Inverter
■ Mounting
■Removing
2. Installation and wiring
Insert the option straightly
and slowly so that it fixes with
the guide inside option slot.
Insert the option into the slot B.
Keep the option from hitting other parts near slot.
1)
The option should be inserted until
the body is totally covered by the slot.
(Refer to the picture above)
2)
Remove the option in the direction of arrow while
pushing the "PUSH" tab by a screw driver.
1)

9
E6582171
2.2 Wiring
2.2.1 Connector
9pin D subminiature connector (DE-9) is prepared in this option. Pin numbers of connector are shown the figure in
below. Prepare the same type male connector separately for the cable end of interconnection cable.
Fig.2 - Resolver interface connector (D subminiature)
2.2.2 Pin assignment
Table 2-1. Pin assignment
Important
• This option is applicable with the feedback signal dedicated to resolver.
• Do not connect/disconnect the cable when the power on. it can damage the option.
No. Symbol Input/output Function / Electrical specifications Internal circuit
1- -(NC) -
2 - - (don’t use) -
3 S4 Input Sinusoidal signal from resolver (–), pair
with S2 signal Refer to (a)
4 S1 Input Sinusoidal signal from resolver (+), pair
with S3 signal Refer to (a)
5 R2 Output Excitation voltage (+)
Carrier frequency 3 to 12kHz Refer to (b)
6 - - (don’t use) -
7 S2 Input Sinusoidal signal from resolver (+), pair
with S4 signal Refer to (a)
8 S3 Input Sinusoidal signal from resolver (–), pair
with S1 signal Refer to (a)
9 R1 Output Excitation voltage (–)
Carrier frequency 3 to 12kHz Refer to (b)
Housing Shield -
Cable shield (metal housing of connector)
This part is connected to PE terminal
inside the inverter
-
1SHIELD
6
789
2345
Female screw (4-40 UNC)

10
E6582171
Table 2-2. Internal circuit
2.2.3 Signaling
Following type resolver is applicable for this option.
- Excitation frequency: 3 to 12 kHz
- Transformation ratio: 0.5
- Pole number: 2
Recommended resolver is RTD4A4Y2 P1 7 10 0.5 D2SR12 12 (Baumer).
As for the resolver signals, connect S1-S4 and R1, R2 with the same terminal on your resolver.
The signal feedback from the resolver should have the waveform shown in Fig.1 (S2-S4 should have
90degree phase difference from S3-S1) in terms of the motor rotation direction. The resolver installation
direction and signal wiring should be done accordingly.
Fig.1 - Resolver format signal
Circuit diagram
(a)
(b)
CAUTION
Mandatory
action
• Use the resolver with the specification described in this manual.
Improper resolver usage can result in accident and malfunction.
• Forward rotation or reverse rotation is judged from the resolver feedback signals of S2-S4 and S3-S1.
Make sure that the connection correctly. Wrong connection can cause an accident due to unintended
rotation of the motor.
S1
S2
S3
S4
50k
50k
VCC
VCC
ADC
R2
VDD
4.7
4.7
R1 Controller
Reference
oscillator
Gain
controller
0º
R2 – R4
S3 – S1
S2 – S4
90º 180º 270º 360º

11
E6582171
2.2.4 Wiring with resolver
When wiring, follow the instructions below.
- Use multi-layer shielded cable
- Use twisted pair for S1/S3, S2/S4 and R1/R2 each
- For R1/R2 pins, parameter set-up according to your resolver is also needed (See 3.1.1)
- Do not connect any wire to unused pins
- Recommended wire size is 0.25 mm2 (AWG23) for signal line (S1,S2,S3,S4), 0.5 mm2 (AWG20) for excitation
voltage (R1 and R2)
- The cable length is 100 m at maximum.
Fig.3 - Example of wiring for Resolver (Speed/Torque switching operation)
CAUTION
Mandatory
action
• Use Multi-layer shielded cable and connect the shield to housing of 15pin D subminiature connector.
Use of unshielded cable or improper shield grounding can result in malfunction or accident.
Important
• Separate the interconnection cable between your resolver and this option 20cm or more away from
power (Power supply and motor) cable to prevent from the signal disruption by noise immunity.
• Do not connect/disconnect the cable when the power on. it can damage the option.
• When prohibition on reverse rotation is set by the inverter parameter <F311: Reverse inhibited> = “1”
and when the motor is rotating to reverse direction due to an external force, the inverter starts with
reverse operation in accordance with the motor's rotation direction for a time and the motor will be able
to shift to the forward rotation and the smooth startup becomes possible.
Torque control with ON and reduce speed
and stop with OFF.
Set <F114 : Terminal S1 function 1> to “112”.
*1 Assign ST (standby) function to arbitrary terminals.
Forward rotation with ON and
reduce speed and stop with OFF
With OFF, free-run stop VEC010Z
VF-AS3
Resolver
*
2
*2 Ground the shield at the
cable end of resolver side.
M
S1
S3S2 S4R1
R2
S1
S3
S2
S4
R1
R2
Housing
U
V
W
PE
R
S
T
PE
*
1
ST
F
S1
CC

12
E6582171
3.1 Performance of vector control with resolver
Using the sinusoidal wave feedback signal from the resolver installed on the motor shaft or load rotation shaft, vector
control with sensor can be conducted.
Speed control operation: 0 speed to 150% torque,
speed control range: 1:1000
speed accuracy: ±0.02% (50Hz base digital input)
Torque control operation: Torque control accuracy: ±10%
(torque control range: -100% to 100%)
3.1.1 Parameter setting for vector control with resolver
During operation with vector control with sensor, it would be necessary to set the following parameters shown
below.
■ Set V/f pattern
Table 3-1. parameter of control pattern
When conducting vector control with sensor (speed/torque control) with this board option, <Pt> = “10”, “11”, “12” should
be set.
For torque control operation, it is necessary to allocate control switching (torque/position) to one of the terminal function
selection <F111> to <F118> (input terminal function selection 1 to 8) (when <CMOd> =“0”) or to allocate to
communication control switching (when <CMOd> =“2” to “5”), in addition to the above parameters.
For details of adjustment methods by the speed control command and torque control command, refer to the Function
manual for torque control (E6582106).
3. Functional Description
Title Function
Name Parameter Setting Default Setting
Pt V/f Pattern
0: V/f constant
1: Variable torque
2: Automatic torque boost
3: Vector control 1
4: Energy savings
5: Dynamic energy savings (for fan and pump)
6: PM motor control
7: V/f 5-point setting
8: -
9: Vector control 2 (speed / torque)
10: PG feedback control
11: PG feedback vector control (speed / torque)
12: PG feedback PM motor control (speed / torque)
0

13
E6582171
■ Set parameters of resolver
Table 3-2. Parameters of resolver
(1) <F397: Resolver carrier frequency> is the excitation carrier frequency of resolver signal.
(2) Set <F376: PG select> to “3” when polarity is positive, or “13” when polarity is negative.
(3) <F377: PG option disconnection detection>=“1” : in case resolver is not connected, or resolver at least one phase is
missed, “E-12” trip occurs. (<F376> should be set for Resolver)
It is necessary to reset the inverter power to enable the changes.
(4) Use resolver with transformation ratio = 0.5
(5) Use resolver with 2 poles
Title Function Name Parameter Setting Default Setting
F376 PG select
0: PTI (Command) – PTI (FB)
1: PTI (Command) – Digital option (FB)
2: -
3: PTI (Command) - Resolver option (FB)
4 - 5: -
6: Digital option (Command) - Non FB
7 - 9: -
10: PTI (Command) - PTI (FB inversion)
11: PTI (Command) - Digital option (FB inversion)
12: -
13: PTI (Command) - Resolver option (FB inversion)
14 - 15: -
16: Digital option (Command inversion) - Non FB
0
F377 PG option disconnection
detection
0: Disabled
1: Enabled 0
F397 Resolver carrier frequency 3 - 12 10

14
E6582171
■ Set motor parameters
Table 3-3. Motor parameters
The motor parameters require setting according to the motor used. For details, refer to the inverter instruction manual.
Title Function Name Parameter Setting Default Setting
F400 Offline auto-tuning
0: -
1: Reset motor parameters (0 after execution)
2: Auto-tuning at run command (0 after execution)
3: Auto-tuning at TB ON
4: Motor parameters auto calculation (0 after execution)
5: 4+2 (0 after execution)
6: Auto-tuning at run command during TB is ON
7: Auto-tuning F402 only at run command during TB is
ON
0
F401 Slip frequency gain 0 – 250% 70
F405 Motor rated capacity
(motor name plate) 0.10 – 315.0kW
Depends
on type.
F415 Motor rated current
(motor name plate) Depend on capacity
F417 Motor rated speed
(motor name plate) 100 – 64000min-1
F402 Automatic torque boost 0.01 – 30.00%
F416 Motor no load current 10 – 90%
F412 Leakage inductance 0.0 – 25.0%

15
E6582171
3.1.2 Monitoring method for feedback amount
Motor rotation speed can be monitored.
The motor is equipped with status monitor which is displayed on the panel and analog monitor which used analog
output terminals ([FM], [AM] terminals)
Set items (1) or (2) for motor speed monitoring.
(1) Speed feedback (real-time value) with sign(+/-) (Unit: Hz/free unit)
The real-time display of motor speed can be made (Monitor display setting: “153”).
(2) Speed feedback (one-second filter) with sign(+/-) (Unit: Hz/free unit)
The filtered motor speed (feedback value) is displayed. (Monitor display setting: “154”).
The monitoring for the above (1) or (2) is possible also in cases except for <Pt> = “10, 11, 12 (PG feedback vector
control operation)”. For example, the monitoring can be used for confirmation of the initial PG feedback amount in
open loop (V/f operation and the like).
<Setting method for status monitoring>
In order to monitor motor rotation speed in condition monitoring, it is necessary to change the setting for extended
parameters (<F710> to <F718>).
Refer to Monitoring Operating Condition section of the inverter manual.
<Setting method for analog monitoring>
In order to monitor motor rotation speed by the analog output terminal, it is necessary to change the setting for basic
parameters (<FMSL>, <FM>).
Refer to Meter Setting and Calibration section of the inverter manual.
3.1.3 Confirmation of resolver's rotational direction
Resolver’s connection in Sin, Cos waves and rotational direction of motor can be confirmed as follows.
Set the parameters changed back to the original values following confirming the rotational direction.
(1) Set parameter <Pt: V/f pattern> = “0: constant torque characteristics”.
(2) Set parameter <F711: status monitor 1 display selected> = “153: Signed speed feedback (real-time value)”.
(3) Enter an operating command for positive rotation and command frequency of 1-10Hz to the inverter.
(4) Confirm the motor be turning in the positive direction.
(5) Display status monitor “1” by using the status monitor indication of inverter.
(6) Monitor display, when resolver signal input is determined positive turn 3Hz, “+3.0” is indicated into the display.
When it is determined negative turn 3.0Hz, “-3.0” is indicated. When determined negative rotation, resolver's
Sin, Cos waves connections and motor wiring are not correct. They must be corrected.
3.1.4 Abnormal speed detection function
■ Parameter
Table 3-4. Parameters for abnormal speed detection
Title Function Name Adjustment Range Default Setting
F622 Abnormal speed detection time 0.01 – 100.00sec 0.01
F623 Abnormal speed increase band 0.0: Disabled, 0.01 – 30.00Hz 0.00
F624 Abnormal speed decrease band 0.0: Disabled, 0.01 – 30.00Hz 0.00

16
E6582171
■ Functions
If speed feedback (Estimated speed) > (Output frequency + <F623>) or speed feedback (Estimated speed) < (Output
frequency - <F624>), and a certain period of time set with <F622: Abnormal speed detection time>, a trip occurs.
You can provide range for a detection level of a trip with a setting of <F623: Abnormal speed increase band> and <F624:
Abnormal speed decrease band>.
During torque control, if speed feedback (Estimated speed) > (Speed upper limit + <F623>) or > (Speed lower limit
- <F624>) a certain period of time set with <F622: Abnormal speed detection time>, “E-13” trip occurs.
3.1.5 Accuracy of speed control
The accuracy of speed control with the PG feedback can be obtained by the following formulae.
Accuracy of speed control = Command frequency accuracy + feedback detection accuracy
Command frequency accuracy =
(using digital command)
Feedback detection accuracy =
FC: Inverter output frequency
P : Number of motor poles
PG : 2048
PH : 4
RT: Speed response, see the value in the table below as a reference
3.1.6 Easy positioning PID control
■ Functions
This function, which is aimed at a retaining the load at standstill at its normal stop position, is used along with the speed
sensor vector control function to prevent the position of an elevator at standstill from shifting.
Switching to position control takes place when the load is at a standstill.
The settings of these parameters take effect only in sensor speed control mode.
Please refer to E6582112 in detail.
Motor capacity Speed response RT
- 2.2 kW 300 rad/s
3.7 kW - 7.5 kW 180 rad/s
11 kW - 90 rad/s
Output frequency [Hz]
Time [s]
<F622>
<F624>
<F623>
<F622>
0
Output frequency
Feedback speed
“E-13” Trip (speed error)
±0.01 (Hz)
F
c (Hz) ×100× 1
2
[%]
±
(FC / (P / 2)) × PG × PH × (1 / R
T
)
1
× 100 × 1
2[%]

17
E6582171
4. Specification
Item Specification
Type form VEC010Z
Product name Resolver option
Function Resolver interface
Applicable Resolver
Pole number: 2
Transformation ratio: 0.5
Excitation carrier frequency: 3 to 12 kHz
Recommended Cable
Multi-layer shielded cable
Size: 0.25 mm2 (AWG23) for signal line
0.5 mm2 (AWG20) for excitation voltage
Length: 100 m or less
Connector D subminiature connector (DE-9)
Applicable model VF-AS3
(Applicable on slot B)
Full-vector
operation with sensor
Speed control operation: 150% torque at zero speed
Speed control range: 1:1000
Speed accuracy: ± 0.02% (50 Hz base digital input)
Torque control operation: Torque control accuracy: ± 10%
Torque control range: -100 to 100%
Operation Environment Inverter operating temperature is limited to 50°C or less.
In accordance with inverter for other operation environment.
Storage temperature -25 to 70°C

18
E6582171
■ Warranty period
This product’s warranty period is 12 months after the purchase, or 18 months from the date of manufacture, whichever
precedes the other.
The warranty period of repaired products will not exceed the warranty period before the repair takes place.
■ Scope of warranty
If a product failure is found during the warranty period due to our negligence, please return the product to Toshiba
distributor of purchase, for a replacement or repair of the defective component.
The warranty shall only cover the purchased or delivered product itself.
The following circumstances will incur paid service even before the warranty period expires.
- Product replacement or repair when the product is not returned.
- Product failure or damage due to misuse, inappropriate repair or modification of the product.
- Product failure or damage for reasons such as but not limited to a fall after purchase, an accident during transport, or
handling (e.g. smoking) during transport.
- Product failure or damage by natural disasters or unforeseeable external causes such as but not limited to fire, salt
exposure, gas exposure, earthquakes, storms, floods, lightning and abnormal voltage.
- Product failure or damage by use under inappropriate circumstances, environments or use not suggested in the
product catalog or instruction manual, or use not complying with the original use intended for the product.
- Product failure or damage by the lack of proper maintenance or replacement of expiring parts suggested in the
instruction manual.
- In case the product is embedded in your equipment, product failure or damage by causes irrelevant to the product,
such as the design of your equipment and software.
- In case the product is embedded in your equipment, product failure that could have been avoided if your equipment
had featured a safety device in compliance with the law that governs your equipment, or any feature or structure that
is considered the norm by the industry standard.
- Any product failure or damage by accidents that were unforeseeable with the technological standard at shipment.
■ Warranty exemptions
Irrespective of the warranty period, the warranty shall not cover the following conditions.
- Compensation for any damage not attributed to our negligence.
- Compensation for any loss of business opportunity or income caused by failure of the product.
- All liabilities and compensations for any damage, secondary damage, accidents, damage to any entity that is not the
product and damage to any other operations that arise from special circumstances, that we may or may not foresee.
- Any compensations for the results of your product replacement, readjustment of the local equipment after
replacement, launch test, inspections, or any other operations.
■ Service after the stop production
Please ask Toshiba distributor of purchase about the stop of production and repair work for each product.
5. Warranty
