Tot Mate TM2264R User manual

1
#0964-3139
3594.TM2264.10/18/18
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
of small parts and sharp edges.
ATTENTION
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
When ordering parts, give the Model Number and Color of the unit.
by Stevens Industries, Inc.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TM2264R
IMPORTANT!
Assembly must be securely attached to
building structure with anchoring devices
of appropriate type, size and quantity in
accordance with applicable codes and
accepted installation practices.
TM2264R
Double-Door Tall Cabinet
3$5747<
,7(0
;;
;;
;;
;;
;;

;;
;;

;;
;;















'(6&5,37,21
(QG5
7RS%RW
(QG/
%DFN
6KHOI$GM
'RRU/
'RRU5
7.6WULQJHU
6KHOI)[G
/RFN'HDGEROW1,Z%H]HO6,$0
/RFN&RUH1,6,$0
6WULNH3/DWH/RFN
6FUHZ7DSS3K)O=LQF;
6FUHZ7DSS3K7U=LQF;
%XPSHU3UHVV,Q[PP+HDG
&DWFK3ODWH'RRU%ODFN
6FUHZ7DSS3K)O=LQF;
+LQJH%OXP)26&'RZHO
+LQJH0WJ3ODWH%OXPPP
3XOOPP$GYWJ%QWZU0W1L
6FUHZ0DFK3K7U=LQF[
&OLS6KOI&OU7ZLQ3LQ
6FUHZ&RQQ+['F1LPP[PP
6FUHZ7D
SS
3K:K=LQF;
3DUWV/LVW
HARDWARE / TOOLS INCLUDED
Door Bumper (15)
(Bumper Press-In 8x2.5mm Head)
Hex Wrench
Hinge Plate (19)
(Hinge Mtg Plate Blum 0mm)
Pull Screw (21)
(Screw Mach PhTr Zinc 8-32x1.00)
Pull (20)
(Pull 128mm Advtg Bntwr MtNi)
Hinge (18)
(Hinge Blum F/O 120 S/C Dowel)
Confirmat Bolt (23)
(Screw Conn HxDc Ni 7mmx50mm)
Lock Catch (12)
(Strike Plate Lock)
Lock Screw (13)
(Screw Tapp PhFl Zinc #7x.875)
Lock Catch Screw (14)
(Screw Tapp PhTr Zinc #8x.62)
Shelf Clip (22)
(Clip Shlf Clr Twin Pin 3/4-1")
Lock Core (11)
(Lock Core NI SIAM #001)
Lock Body (10)
(Lock Deadbolt NI w/Bezel SIAM)
deadbolt
Door Catch Plate Screw (17)
(Screw Tapp PhFl Zinc #8x.68)
Door Catch Plate (16)
(Catch Plate Door Black)
Back Screw (24)
(Screw Tapp PhWh Zinc #8x1.25)

TM2264R
STEP-BY-STEP ASSEMBLY
2#0964-3139
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2264.10/18/18
2-PERSON ASSEMBLY RECOMMENDED.
IMPORTANT!
Be sure to keep all parts supported during assembly to avoid damage. Do not over-tighten screws
or it will damage the pre-drilled holes; snug fit is adequate.
3$5747<
,7(0
;;
;;
;;
;;
;;

;;
;;

;;
;;















'(6&5,37,21
(QG5
7RS%RW
(QG/
%DFN
6KHOI$GM
'RRU/
'RRU5
7.6WULQJHU
6KHOI)[G
/RFN'HDGEROW1,Z%H]HO6,$0
/RFN&RUH1,6,$0
6WULNH3/DWH/RFN
6FUHZ7DSS3K)O=LQF;
6FUHZ7DSS3K7U=LQF;
%XPSHU3UHVV,Q[PP+HDG
&DWFK3ODWH'RRU%ODFN
6FUHZ7DSS3K)O=LQF;
+LQJH%OXP)26&'RZHO
+LQJH0WJ3ODWH%OXPPP
3XOOPP$GYWJ%QWZU0W1L
6FUHZ0DFK3K7U=LQF[
&OLS6KOI&OU7ZLQ3LQ
6FUHZ&RQQ+['F1LPP[PP
6FUHZ7D
SS
3K:K=LQF;
3DUWV/LVW
HARDWARE / TOOLS INCLUDED
Door Bumper (15)
(Bumper Press-In 8x2.5mm Head)
Hex Wrench
Hinge Plate (19)
(Hinge Mtg Plate Blum 0mm)
Pull Screw (21)
(Screw Mach PhTr Zinc 8-32x1.00)
Pull (20)
(Pull 128mm Advtg Bntwr MtNi)
Hinge (18)
(Hinge Blum F/O 120 S/C Dowel)
Confirmat Bolt (23)
(Screw Conn HxDc Ni 7mmx50mm)
Lock Catch (12)
(Strike Plate Lock)
Lock Screw (13)
(Screw Tapp PhFl Zinc #7x.875)
Lock Catch Screw (14)
(Screw Tapp PhTr Zinc #8x.62)
Shelf Clip (22)
(Clip Shlf Clr Twin Pin 3/4-1")
Lock Core (11)
(Lock Core NI SIAM #001)
Lock Body (10)
(Lock Deadbolt NI w/Bezel SIAM)
deadbolt
Door Catch Plate Screw (17)
(Screw Tapp PhFl Zinc #8x.68)
Door Catch Plate (16)
(Catch Plate Door Black)
Back Screw (24)
(Screw Tapp PhWh Zinc #8x1.25)

TM2264R
STEP-BY-STEP ASSEMBLY
3
#0964-3139
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TM2264.10/18/18
Identify Left End (3), Right End (1) and Top-
Bottoms (2). Note that routed channels along
back edges will all face interior of unit for
installation of Back (4). Note that toe kick holes on
Ends (1 & 3) are located at the bottom.
STEP
1
Lay Fixed Shelf (9) flat on floor, with side having
holes facing up. Attach Lock Catch (12) with two
Lock Catch Screws (14).
STEP
2
With front edge of Left End (3) resting on floor,
insert dowels on Top-Bottoms (2) and Fixed
Shelf (9) into holes on Left End (3), making sure
channels are oriented correctly. Also, make sure
tab on Lock Catch (12) from Step 2 is facing
toward bottom of Left End (3). Press firmly into
place.
STEP
3
channels
toe kick
holes
bottom
edge
bottom
edge
channels
channel
Secure Top-Bottoms (2) and Fixed Shelf (9) to
Left End (3) with two Confirmat Bolts (23) each,
using the included Hex Wrench.
STEP
4

TM2264R
STEP-BY-STEP ASSEMBLY
4#0964-3139
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2264.10/18/18
Slide Back (4) into channels on Top-Bottoms (2)
and Left End (3). Make sure pre-drilled holes on
Back (4) align with Fixed Shelf (9). If they do not
align, remove Back (4), rotate 180°, reinsert and
check alignment. Seat firmly into place.
STEP
6
pre-drilled
holes
channel
channel
channel
Insert dowels on TK-Stringers (8) into upper and
lower holes on Left End (3). Top Stringer (8) will
be at upper back of unit; bottom Stringer (8) will
be at lower front of unit (for toe kick). Press firmly
into place.
STEP
7
Bottom
Stringer
To p
Stringer
Position Right End (1) on top of assembly, so
holes on Right End (1) align with dowels on Top-
Bottoms (2), Fixed Shelf (9) and Stringers (8)
AND Back (4) fits into channel on Right End (1).
Press firmly into place.
STEP
8
Carefully position assembly with Left End (3) flat
on floor, and dowels on Top-Bottoms (2) and
Fixed Shelf (9) facing up.
STEP
5

TM2264R
STEP-BY-STEP ASSEMBLY
5
#0964-3139
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TM2264.10/18/18
Secure Right End (1) to Top-Bottoms (2) and
Fixed Shelf (9) with six Confirmat Bolts (23).
STEP
9
Carefully stand unit upright.
STEP
10
Secure Back (4) to Fixed Shelf (9) with two Back
Screws (24). (Phillips screwdriver not included.)
IMPORTANT! Make sure Back Screws are
centered on Fixed Shelf and inserted straight
into Shelf. This is necessary to prevent Back
Screws from protruding through and damaging
Shelf surface.
STEP
11
Attach Hinge Plates (19) to inside face of both
Ends (1 & 3), making sure front edge of each
Hinge Plate (19) is facing front edge of unit
(reference DETAIL A).
STEP
12
facing toward
front edge DETAIL A

TM2264R
STEP-BY-STEP ASSEMBLY
6#0964-3139
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2264.10/18/18
Mount Lock Body (10) to inside of Right Door (7)
with four Lock Screws (13), making sure deadbolt
is facing toward top of Right Door (7).
STEP
16
top
edge
Mount Door Catch Plate (16) to Left Door (6)
with two Door Catch Plate Screws (17).
STEP
17
With Hinges (18) fully extended into the open
position, insert them into routed cutouts on Doors
(6 & 7), using a soft mallet and striking over the
screw heads. IMPORTANT! Take care not to
remove hinge once it is started; otherwise, pre-
drilled holes may become damaged.
STEP
15
Mount Doors (6 & 7) to Hinge Plates (19). NOTE:
Hinges need to be opened when attaching doors
to mounting plates. Starting with bottom Hinge
(18), press hinge in from front to back. Pop back
edge of hinge in, while holding other hinges close
to matching Hinge Plates (19). Repeat for other
Hinges (18).
STEP
18
Insert Door Bumpers (15) into small holes on
inside corners of each Door (6 & 7), two per door.
STEP
14
Lay Doors (6 & 7) on floor, with side having the
most holes facing up.
STEP
13

TM2264R
STEP-BY-STEP ASSEMBLY
7
#0964-3139
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TM2264.10/18/18
Insert Adjustable Shelves (5) into Shelf Clips
(22) by putting into unit diagonally and resting one
end on one set of clips, then lowering other end
into place on other set of clips.
STEP
21
Mount Pulls (20) to Doors (6 & 7) with two Pull
Screws (21) each.
STEP
19
Insert Shelf Clips (22) into aligning holes on each
End (1 & 3).
STEP
20
Insert Lock Core (11) through front of Right Door
(7) and into Lock Body (10).
STEP
22

TM2264R
STEP-BY-STEP ASSEMBLY
8#0964-3139
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2264.10/18/18
Ensure that all joints, bolts and screws are tight.
STEP
23
This completes the assembly.
