Tot Mate TM9300R User manual

1
#0964-3183
3594.TM9300/9301.9/25/18
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
of small parts and sharp edges.
ATTENTION
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
When ordering parts, give the Model Number and Color of the unit.
by Stevens Industries, Inc.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TM9300R
TM9301R
TM9300R
TM9301R
Rectangular Table
2-PERSON ASSEMBLY RECOMMENDED.
IMPORTANT!
Be sure to keep all parts supported
during assembly to avoid damage.
Do not over-tighten screws or it will
damage the pre-drilled holes;
snug fit is adequate.
HARDWARE INCLUDED
Leg Screw (6)
NOTE:
Illustration of table top and leg
shown at right is representative of
all table top shapes and both leg styles.
TM9300R
TM9301R
NOTE: Phillips screwdriver required but not included.
(other hardware is pre-installed)

STEP-BY-STEP ASSEMBLY
2#0964-3183
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM9300/9301.9/25/18
TM9300R – TM9301R
Lay Table Top (1) face down on floor. Note that
there are two pre-mounted Table Leg Clips (4) for
each leg. Each Table Leg Clip (4) has three pre-
installed Clip Screws (5).
STEP
1
2-PERSON ASSEMBLY RECOMMENDED.
IMPORTANT!
Be sure to keep all parts supported during assembly to avoid damage.
Do not over-tighten screws or it will damage the pre-drilled holes;
snug fit is adequate.
Each adjustable table leg is made up of an Upper
Leg (2) and Lower Leg (3). Upper Leg (2) has
a mounting bracket that will be attached to a pair
of Table Leg Clips (4) and the table top. The set
screw is used to secure Lower Leg (3) at the
desired height. Lower Leg (3) has a series of
pre-drilled holes for height adjustment, as well as
a leveler.
STEP
2
Slide mounting bracket on one Upper Leg (2)
under lip of both Table Leg Clips (4). The bracket
should slide all the way in to the second step. If
necessary, loosen the Clip Screws (5) to allow the
mounting bracket to slide completely into place.
When Upper Leg (2) is correctly positioned, the
two holes in the mounting bracket will align with
the pre-drilled holes in the table top, as shown.
STEP
3
side view
mounting
bracket
pre-drilled holes
for height adjustment
leveler
set screw
second
step
leg mounting bracket
slides under lip of
table leg clip and rests
against second step

STEP-BY-STEP ASSEMBLY
3
#0964-3183
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TM9300/9301.9/25/18
TM9300R – TM9301R
Tighten the three Clip Screws (5) in each Table
Leg Clip (4). Secure mounting bracket to table top
with two Leg Screws (6).
STEP
4
Insert Lower Leg (3) into Upper Leg (2). Position
Lower Leg (3) at desired height, making sure
appropriate pre-drilled hole is aligned with the set
screw. Tighten set screw.
STEP
5
Carefully position table upright and adjust levelers
as needed for stable positioning on floor.
STEP
7
This completes the assembly.
Repeat Steps 3-5 for remaining legs.
STEP
6
set screw
pre-drilled holes
for height adjustmen
t
leveler
TM9300R:
LEG HEIGHTS range from 13" to 22"
TABLE HEIGHTS range from 14" to 23"
TM9301R:
LEG HEIGHTS range from 20" to 29"
TABLE HEIGHTS range from 21" to 30"
