Regency ONRTSCD6224 User manual

Organize your parts and hardware. You will need (2) people, a Phillips head screwdriver and rubber mallet.
IMPORTANT NOTICE:
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
Check to be sure that you have all parts and hardware.
Remove all wrapping materials, including staples & packing straps before you start to assemble.
Do not tighten all screws/bolts until completely assembled.
Keep all hardware parts out of reach of children.
Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
62” Storage Cabinet Return • ONRTSCD6224 • INSTRUCTIONS
CARTONS: TT6224, MP2412, PSC3624, SCD3624
HS-A: Back Panel
(34” x 23.75” x 1”)
Quantity: 1
HS-D: Foot Bracket
(23.5”D)
Quantity: 2
HS-E: Top Bracket
(23.5”D)
Quantity: 2
Parts :
HS-C: Top Panel
(35.5” x 23.5” x 1”)
Quantity: 1
HS-B: Base Panel
(34” x 23” x 1”)
Quantity: 1
HS-F: Shelf
(34” x 19.75” x 1”)
Quantity: 1
HS-H: Right Side
(23.75” x 23.5” x 1”)
Quantity: 1
HS-G: Left Side
(23.75” x 23.5” x 1”)
Quantity: 1
(34” x 23.75” x 1”)
Quantity: 1
(34” x 23” x 1”)
(35.5” x 23.5” x 1”)
(23.75” x 23.5” x 1”)
Quantity: 1
Cam Lock Assembly:
To open Cam, point arrow
toward Cam Pin hole. To
lock Cam, turn clockwise.
Figure 1:
Parts List continued on back.
HS-C
HS-D
DR-A
HS-G
TT-C HS-E
DR-B
HS-B
HS-H
MP-F
62” Storage Cabinet Return
Page 1

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
Hardware :
NOTE : PRODUCT IS REVERSIBLE.
SOME STEPS INCLUDE BOTH RIGHT AND LEFT ORIENTATIONS.
Please examine all parts before assembly. Hardware placement is critical.
Parts continued:
TT-C: Return Top
(61” x 23” x 1”)
Quantity: 1
MP-F: Return Modesty
(25.5” x 12” x 1”)
Quantity: 1
J: Allen Key
Quantity: 1
M: Wood Cam Pins
Quantity: 12
O: 3/4” Wood Screws
(19mm)
Quantity: 35
N: Shelf Pins
Quantity: 4
R: Glides
Quantity: 4
Q: Cam Caps
Quantity: 9
K: 1.5” Long Bolts
(38mm)
Quantity:12
L: 3/4” Short Bolts
(19mm)
Quantity: 28
S: Washers
Quantity: 6
P: Insert Covers
Quantity: 8
T: Flat Bracket
Quantity: 4
V: Fine threaded
Cam Pins
Quantity: 2
U: Corner Bracket
Quantity: 2
DR-B: Right Door
(23” x 17” x 1”)
Quantity: 1
DR-A: Left Door
(23” x 17” x 1”)
Quantity: 1
W: Handles
Quantity: 2
X: Hinge
Quantity: 4
Y: Hinge
Bracket
Quantity: 4
Z: Set of Keys
Quantity: 1
AA: Latch Screw
(15mm)
Quantity: 2
BB: Lock Latch
Quantity: 1
CC: Door Stop
Quantity: 1
62” Storage Cabinet Return
Page 2
62” Storage Cabinet Return • ONRTSCD6224 • INSTRUCTIONS
CARTONS: TT6224, MP2412, PSC3624, SCD3624

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
STEP 1 : Insert 2 Wood Cam Pins(M) into Back Panel(HS-A).
Attach Base Panel(HS-B) to Back Panel by inserting Cam
Pins into Cam Locks. Lock Cams(Figure 1).
NOTE: Cam Locks on Base Panel face away from Back Panel.
STEP 2 : Insert 4 Wood Cam Pins(M) into Left Side(HS-G)
and Right Side(HS-H).
HS-A
HS-B
MM
HS-G
MM
M
M
HS-H
MM
M
M
STEP 3 : Attach Left Side(HS-G) and Right Side(HS-H) to
Back Panel(HS-A) and Base Panel(HS-B) by inserting Cam
Pins into Cam Locks. Lock Cams (Figure 1).
STEP 4 : Insert 2 Glides(R) into each Foot Bracket(HS-D).
HS-G HS-H
RR HS-D
HS-A
HS-B
STEP 5 : Attach each Foot Bracket(HS-D) by placing 1 Washer(S) between the base and each wood screw hole on Legs (Figure 2).
Then, insert 6 Long Bolts(K) and 6 Wood Screws(O) to attach to Base Panel(HS-B).
O
K
K
K
K
K
K
O
O
O
OKO
KO
KO
S
S
S
Figure 2
HS-D
HS-B
HS-D
O
62” Storage Cabinet Return
Page 3
62” Storage Cabinet Return • ONRTSCD6224 • INSTRUCTIONS
CARTONS: TT6224, MP2412, PSC3624, SCD3624

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
STEP 8 : Open Storage Component is Reversible. Decide on an orientation(Left and Right). According to the orientation that you
choose, remove 2 Cam Pin Covers in the location shown below. Then insert a Fine threaded Cam Pin(H) into each of the revealed
inserts.
H
H
STEP 6 : Insert 5 Wood Cam Pins(M) into Top Panel(HS-C). STEP 7 : Attach Top Panel(HS-C) to Back Panel(HS-A),
Left Side(HS-G) and Right Side(HS-H) by inserting Cam
Pins into Cam Locks. Lock Cams (Figure 1).
HS-C
M
M
M
M
M
HS-A
HS-C
HS-H
HS-G
STEP 9 : Attach Top Brackets(HS-E) to Return Top(TT-C). Use 6 Short Bolts(L) to attach each bracket.
Do not tighten bolts until all are started.
HS-E
TT-C
H
H
Right ReturnLeft Return
62” Storage Cabinet Return
Page 4
62” Storage Cabinet Return • ONRTSCD6224 • INSTRUCTIONS
CARTONS: TT6224, MP2412, PSC3624, SCD3624

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
STEP 10 : According to the orientation that you choose, Attach Open Storage Cabinet to Return Top(TT-C) using 6 Long Bolts(K).
TT-C
KK
STEP 11 : Attach Modesty(MP-F) to the Open Storage Cabinet
by inserting and locking cam pins into locks (Figure 1).
MP-F
TT-C
KK
Cam Pin Location
Cam Pin Location
Cam Pin Location
Cam Pin Location
Right ReturnLeft Return
STEP 13: Attach the Lock Latch(BB) with 2 Latch
Screws(AA) and Door Stop(CC) with 1 Wood Screw(O).
CC BB
STEP 12 : Insert 4 Shelf Pins(N) at desired height. Place
Shelf(HS-F).
AA AAO
62” Storage Cabinet Return
Page 5
62” Storage Cabinet Return • ONRTSCD6224 • INSTRUCTIONS
CARTONS: TT6224, MP2412, PSC3624, SCD3624

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
STEP 14 : Use 2 Wood Screws(O) to attach each Hinge
Bracket(Y) to the sides. The hinge adjustment screw on each
bracket should face toward the back of the unit.
Y
Y
STEP 15 : Attach 1 Handle(W) to the Left Door(DR-A) and
Right Door(DR-B).
DR-A
W
STEP 16 : Attach 4 Hinges(X) to the Left Door(DR-A) and Right Door(DR-B) with 8 Wood Screws(O).
O
O
X
DR-B
W
STEP 17A : Connect 4 Hinges(X) to Hinge Brackets(Y).
STEP 17B: The screw(EA) located on Hinge Bracket(Y) interlocks with the opening on Hinges(X) just as screw(EB) located on
Hinges(X) interlocks with the Hinge Bracket(V) opening. Tighten screw(EA) to secure door.
Note: The screw EB is an adjustment for the door position. Turn right to adjust door to center and left to adjust toward the side.
EA EB
Y
X
Y
Y
Y
Hinge
Adjustment
Screw
62” Storage Cabinet Return
Page 6
62” Storage Cabinet Return • ONRTSCD6224 • INSTRUCTIONS
CARTONS: TT6224, MP2412, PSC3624, SCD3624

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
YOU WILL NEED A SECOND PERSON TO SUPPORT RETURN MODESTY AND RETURN TOP FOR THIS STEP.
STEP 18 : Attach Return Modesty(MP-F) to Desk Leg with 2 Flat Brackets(T) using 4 Short Bolts(L) per bracket. Then, attach
Return Top(TT-C) to Desk Top with 2 Flat Brackets(T) using 4 Short Bolts(L) per bracket.
TT-C
MP-F
STEP 19 : For extra support, attach Corner Brackets(U) to the Modesty(MP-F) and Storage Cabinet with 6 Wood Screws(O) per
Bracket. Finish by concealing Cam Locks with Cam Caps(Q) & Insert Covers(P).
62” Storage Cabinet Return
Page 7
