Tot Mate TMS101R User manual

1
#0964-3196
3594.TMS101.11/1/18
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
of small parts and sharp edges.
ATTENTION
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
When ordering parts, give the Model Number and Color of the unit.
by Stevens Industries, Inc.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TMS101R
076,QYHQWRU
\
3DUWV/LVW3DUWV/LVW
3$5747<,7(0
;;
;;
;;
;;

'(6&5,37,21
(QG8
7RS%RW
%DFN
%DFN
6FUHZ&RQQ+['F1LPP[PP
TMS101R
School Age Shelf Storage – Double Sided
edgebanding
seam
Confirmat Bolt (5)
(Screw Conn HxDc Ni 7mmx50mm)
Hex Wrench
HARDWARE / TOOLS INCLUDED
2-PERSON ASSEMBLY RECOMMENDED.
IMPORTANT!
Be sure to keep all parts supported
during assembly to avoid damage.
Do not over-tighten screws or it will
damage the pre-drilled holes;
snug fit is adequate.

TMS101R
STEP-BY-STEP ASSEMBLY
2#0964-3196
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TMS101.11/1/18
Lay one End (1) flat on floor, with side having the
most holes facing up.
STEP
1
Insert dowels on Top-Bottoms (2) into the upper,
lower and two middle sets of holes on End (1).
Press firmly into place.
STEP
2
Insert dowels on Upper Backs (3) and Lower
Back (4) into the remaining holes on End (1),
between Top-Bottoms (2). Press firmly into place.
STEP
3
Position other End (1) on top of assembly, so
dowels on Top-Bottoms (2) and Backs (3 & 4)
align with holes on End (1). Press firmly into place.
STEP
4
Secure End (1) to Top-Bottoms (2) and Backs
(3 & 4) with eleven Confirmat Bolts (5), using the
included Hex Wrench.
STEP
5

TMS101R
STEP-BY-STEP ASSEMBLY
3
#0964-3196
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TMS101.11/1/18
Secure upper and lower Top-Bottoms (2) to
Upper Back (3) and Lower Back (4) with two
Confirmat Bolts (5).
STEP
6
Repeat Step 5 to secure End (1) to Top-Bottoms
(2) and Backs (3 & 4).
STEP
8
Carefully stand unit upright. Make sure
edgebanding seams on Ends (1) are on bottom of
unit.
STEP
9
Ensure that all joints and bolts are tight.
STEP
10
This completes the assembly.
Carefully turn unit over, so other End (1) is facing
up.
STEP
7
edgebanding
seam
