Tot Mate TMW301R User manual

1
#0964-3151
3594.TMW301.10/18/18
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
of small parts and sharp edges.
ATTENTION
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
When ordering parts, give the Model Number and Color of the unit.
by Stevens Industries, Inc.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TMW301R
TMW301R
4-Compartment Wall Cabinet
IMPORTANT!
Assembly must be securely attached to
building structure with anchoring devices
of appropriate type, size and quantity in
accordance with applicable codes and
accepted installation practices.
076,QYHQWRU
\
3DUWV/LVW
3DUWV/LVW
3$5747<,7(0
;;
;;
;;
;;
;;
;;
;;
;;

















'(6&5,37,21
7RS%RW
%DFN
6KHOI$GM
'RRU/
'RRU5
6WULQJHU
'LYLGHU
(QG8
6FUHZ&RQQ+['F1LPP[PP
6FUHZ7DSS3K:K=LQF;
+LQJH%OXP)26&'RZHO
+LQJH0WJ3ODWH%OXPPP
3XOOPP$GYWJ%QWZU0W1L
6FUHZ0DFK3K7U=LQF[
%XPSHU3UHVV,Q[PP+HDG
&OLS6KOI&OU7ZLQ3LQ
/RFN'HDGEROW1,Z%H]HO6,$0
/RFN&RUH1,6,$0
6WULNH3ODWH/RFN
6FUHZ7DSS3K)O=LQF;
6FUHZ7DSS3K7U=LQF;
&DWFK3ODWH'RRU%ODFN
6FUHZ7DSS3K)O=LQF;

TMW301R
STEP-BY-STEP ASSEMBLY
2#0964-3151
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TMW301.10/18/18
channel
channel
channel
076,QYHQWRU
\
3DUWV/LVW
3DUWV/LVW
3$5747<,7(0
;;
;;
;;
;;
;;
;;
;;
;;

















'(6&5,37,21
7RS%RW
%DFN
6KHOI$GM
'RRU/
'RRU5
6WULQJHU
'LYLGHU
(QG8
6FUHZ&RQQ+['F1LPP[PP
6FUHZ7DSS3K:K=LQF;
+LQJH%OXP)26&'RZHO
+LQJH0WJ3ODWH%OXPPP
3XOOPP$GYWJ%QWZU0W1L
6FUHZ0DFK3K7U=LQF[
%XPSHU3UHVV,Q[PP+HDG
&OLS6KOI&OU7ZLQ3LQ
/RFN'HDGEROW1,Z%H]HO6,$0
/RFN&RUH1,6,$0
6WULNH3ODWH/RFN
6FUHZ7DSS3K)O=LQF;
6FUHZ7DSS3K7U=LQF;
&DWFK3ODWH'RRU%ODFN
6FUHZ7DSS3K)O=LQF;
HARDWARE / TOOLS INCLUDED
Door Bumper (15)
(Bumper Press-In 8x2.5mm Head)
Hex Wrench
Door Catch (22)
(Catch Plate Door Black)
Door Catch Screw (23)
(Screw Tapp PhFl Zinc #8x.68)
Pull Screw (14)
(Screw Mach PhTr Zinc 8-32x1.00)
Pull (13)
(Pull 128mm Advtg Bntwr MtNi)
Hinge Plate (12)
(Hinge Mtg Plate Blum 0mm)
Hinge (11)
(Hinge Blum F/O 120 S/C Dowel)
Confirmat Bolt (9)
(Screw Conn HxDc Ni 7mmx50mm)
Lock Catch (19)
(Strike Plate Lock)
Lock Screw (20)
(Screw Tapp PhFl Zinc #7x.875)
Lock Catch Screw (21)
(Screw Tapp PhTr Zinc #8x.62)
Shelf Clip (16)
(Clip Shlf Clr Twin Pin 3/4-1")
Lock Core (18)
(Lock Core NI SIAM #001)
Lock Body (17)
(Lock Deadbolt NI w/Bezel SIAM)
deadbolt
Back Screw (10)
(Screw Tapp PhWh Zinc #8x1.25)
(Phillips screwdriver and soft mallet required but not included.)

TMW301R
STEP-BY-STEP ASSEMBLY
3
#0964-3151
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TMW301.10/18/18
Identify Ends (8) and Top-Bottoms (1) and
set them nearby for assembly. Note that routed
channels along back edges will all face interior of
unit for installation of Backs (2).
STEP
1
With front edge of one End (8) resting on floor,
insert dowels on one Top-Bottom (1) into holes
on End (8), making sure channels are oriented
correctly, as shown. Press firmly into place.
STEP
2
Secure End (8) toTop-Bottom (1) with two
Confirmat Bolts (9), using the included Hex
Wrench.
STEP
3
Insert dowels on other Top-Bottom (1) into other
set of holes on End (8), making sure channels
are oriented correctly, as shown. Press firmly into
place.
STEP
4
Secure End (8) toTop-Bottom (1) with two
Confirmat Bolts (9).
STEP
5
2-PERSON ASSEMBLY RECOMMENDED.
IMPORTANT!
Be sure to keep all parts supported during assembly to avoid damage.
Do not over-tighten screws or it will damage the pre-drilled holes;
snug fit is adequate.
channels
channels

TMW301R
STEP-BY-STEP ASSEMBLY
4#0964-3151
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TMW301.10/18/18
Carefully position assembly with End (8) flat on
floor, and dowels on Top-Bottoms (1) facing up.
STEP
8
Insert Backs (2) into channels on Top-Bottoms
(1) and End (8). Seat firmly into place. Make sure
seam between Backs (2) is centered on edge of
Divider (7) when Backs (2) are seated.
STEP
9
channel
channels
seam between
Backs (2) must be
centered on edge
of Divider (7) when
Backs (2) are seated
Insert dowels on Stringers (6) into holes on
End (8) near back edge, making sure holes in
Stringers (6) align with thru-holes in End (8).
Press firmly into place.
STEP
10
thru-hole
Secure Divider (7) to Top-Bottoms (1) with two
Confirmat Bolts (9).
STEP
7
Insert dowels on Divider (7) first into holes on one
Top-Bottom (1). Then, move other end to insert
dowels into corresponding holes on other Top-
Bottom (1). To provide enough room, one Top-
Bottom (1) can be moved slightly, but no more
than necessary. Make sure raw edge of Divider
(7) is facing toward channels on Top-Bottoms (1).
Press all parts firmly into place.
STEP
6
channels
raw edge
NOTE:
Movement of
Top-Bottom (1)
is exaggerated
in illustration, in
order to better
depict Divider (7)
installation.

TMW301R
STEP-BY-STEP ASSEMBLY
5
#0964-3151
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TMW301.10/18/18
Position other End (8) on top of assembly, so
holes in End (8) align with dowels in Top-Bottoms
(1) and Stringers (6) AND Back (2) fits into
channel on End (8). Press firmly into place.
STEP
11
Secure End (8) to Top-Bottoms (1) and Stringers
(6) with six Confirmat Bolts (9).
STEP
12
Carefully turn unit over, so other End (8) is facing
up.
STEP
13
Secure End (8) to Stringers (6) with two
Confirmat Bolts (9).
STEP
14
Carefully turn unit over, so Backs (2) are facing up.
STEP
15
Secure Backs (2) to Divider (7) with two Back
Screws (10) through seam between Backs (2).
(Phillips screwdriver not included.) IMPORTANT!
Make sure Back Screws are centered on raw
edge of Divider and inserted straight into
Divider. This is necessary to prevent Back
Screws from protruding through and damaging
Divider surface.
STEP
16

TMW301R
STEP-BY-STEP ASSEMBLY
6#0964-3151
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TMW301.10/18/18
Insert Door Bumpers (15) into small holes on
inside corners of Doors (4 & 5), two per door.
STEP
20
With Hinges (11) fully extended into the open
position, insert them into routed cutouts on Doors
(4 & 5), using a soft mallet and striking over the
screw heads. IMPORTANT! Take care not to
remove hinge once it is started; otherwise,
pre-drilled holes may become damaged.
STEP
21
Mount Lock Body (17) to inside of Right Door (5)
with four Lock Screws (20), making sure deadbolt
is facing bottom edge of door.
STEP
22
bottom
edge
deadbolt
Identify Left Door (4) and Right Door (5) and
remaining hardware as shown on page 2.
STEP
18
Carefully position unit so back is flat on floor.
STEP
17
Attach two Hinge Plates (12) to inside face of
each End (8), making sure front edge of each
Hinge Plate (12) is facing front edge of unit
(reference DETAIL A).
STEP
19
front edge
facing toward
front edge DETAIL A

TMW301R
STEP-BY-STEP ASSEMBLY
7
#0964-3151
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TMW301.10/18/18
Insert Shelf Clips (16) into aligning holes on each
End (8) and both sides of Divider (7).
STEP
27
Mount Pulls (13) to Doors (4 & 5) with two Pull
Screws (14) each.
STEP
26
Mount Door Catch (22) to inside of Left Door (4)
with two Door Catch Screws (23).
STEP
23
Mount Doors (4 & 5) to Hinge Plates (12). NOTE:
Hinges need to be opened when attaching doors
to mounting plates. Starting with top Hinge (11),
press hinge in from front to back. Pop back edge
of hinge in, while holding lower hinge close to
matching Hinge Plate (12). Repeat for lower
Hinges (11).
STEP
25
Mount Lock Catch (19) to lower Top-Bottom (1)
with two Lock Catch Screws (21) and pre-drilled
holes.
STEP
24
Insert Adjustable Shelves (3) into Shelf Clips
(16) by putting into unit diagonally and resting one
end on one set of clips, then lowering other end
into place on other set of clips.
STEP
28

TMW301R
STEP-BY-STEP ASSEMBLY
8#0964-3151
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TMW301.10/18/18
This completes the assembly.
Insert Lock Core (18) through front of Right Door
(5) and into Lock Body (17).
STEP
29
Ensure that all joints, bolts and screws are tight.
STEP
31
Carefully stand unit upright.
STEP
30
