TP-Link TD-VG3631 User manual

1
If you currently use a modem, disconnect it now - the Modem Router will
replace your current modem.
Connect your computer to the port labeled “LAN 1~4” on the Modem Router
with an Ethernet cable.
Connet the LINE port on the splitter to the wall jack using a telephone line.
Then use the other telephone line to connect the MODEM port on the
splitter to the ADSL port on the Modem Router, also have the PHONE port
on the splitter connected to the LINE port of the Modem Router.
Note Please use only wired network connections to configure the Modem Route
r
.
Installation

2
Connect your telephone to the port labeled “PHONE 1~2” on the Modem
Router with a telephone line.
Connect your USB device to the USB port labled “USB 1~2” on the Modem
Router.
Plug the provided Power Adapter into the Power jack on the back of the
Modem Router and the other end to a standard electrical wall socket.
Power on all your network devices and then check to see if the LEDs of the
Modem Router display normally as the diagram below describes.
If the LEDs display abnormally, please check to see if all the cable
connectors (power adapter, phone line and Ethernet cable) are well
connected to your device. With the phone line well connected, if the
ADSL LED turns off after flashing, please contact your ISP to ensure that
your Internet connection is active.
Note
WLAN: Solid
light or flashing
USB: Solid
light or flashing
Note If you want to share files or use the USB Voice Mail function, please plug
an external USB hard drive/USB flash disk into the USB port. To use the
printer function, please connect a USB printer to the USB port.
Line: Solid light
or flashing
LAN: Solid light
or flashing
ADSL: Solid
light or flashing
Power: Solid
li
g
ht
Note To use USB Voice Mail function, please make sure the free space of the
plugged external USB hard drive/USB flash disk is more than 4MB.

3
Insert the provided Resource
CD into your CD-ROM drive.
The Setup Wizard will
automatically pop up on
your computer’s screen.
To configure the device, TP-LINK strongly recommends that Windows users
run the setup CD, Mac OS\Linux\Windows\Android\iOS user who can not
run the mini CD, please refer to Appendix to run the web-based Quick
Setup Wizard.
Note
Please select your product
model and click Start Setup

4
After the configuration has been completed, please skip to Step 3 “Testing the
Internet Connection”.
Then the configuration wizard will
pop up and show you how to
connect your devices. After that,
the Easy Setup Assistant will
start.
Please enter a Profile Name
to identify this account and
other parameters provided
by your ISP
When it comes to Setup the SIP
Account for VoIP, you need to
enter the SIP account information
provided by your ISP.
Click NEXT, and then follow
the step-by-step instructions
Please make sure an external USB
hard drive/USB flash disk has been
plugged into the USB port on the
Modem Router before running
Setup Wizard. Otherwise, you may
be unable to configure USB Voice
Mail function on this page.
USB Voice Mail can only be configured through the Easy Setup
Assistant. For advanced settngs, please refer to 4.7.8 USB Voice Mail
on User Guide.
Note
Please tick these two boxes
Click NEXT
Click NEXT

5
The basic settings for your Modem Router are completed. Please open the web
browser and try to log on to some popular website to test your Internet
connection, for example:
http://www.tp-link.com
http://www.google.com
If the above websites can be accessed, it indicates that your Modem Router has
been configured successfully and you can start to enjoy the Internet. If the
websites cannot be accessed, please refer to “T4. What can I do if I cannot
access the Internet?” in the Troubleshooting guide.
For the advanced configurations, please refer to the User Guide on the
Resource CD provided.
Note
Note The above configurations only need to be set once. If you want other
computers in your LAN to access the Internet, please connect the
desired computer to the Modem Router directly. If the additional
computer can not access the Internet, please set that computer referring
to “T3. What can I do if I cannot access the web-based configuration
page?” in the Troubleshooting guide.

6
Local Storage Sharing
Local Storage Sharing allows you to share
your USB drive or HDD with other computers,
tablets or smart phones that are connected to
the Modem Router. You can create multiple
shares and control the permission by setting
different accounts.
Please refer to 4.8.3 Storage Sharing on User
Guide.
Remote Storage Sharing
Remote Storage Sharing turns your USB drive
or HDD into a FTP server, which enables your
access anywhere you have an Internet
connection.
Please refer to 4.8.4 FTP Server on User
Guide.
Media Server
Media Server let you play videos, photos and
music stored on your USB drive or HDD on
any DLNA connected to TV, game console or
media player.
Please refer to 4.8.5 Media Server on User
Guide.
Print Server
Print Server shares your printer to multiple
computers which are connected to the Modem
Router. No worry for the printer sharing any
more.
Please refer to 4.8.6 Print Server on User
Guide.
Application
Guide for USB Features
You can get the User Guide on Resource CD. Or log on to www.tp-link.com
Śselect your regionŚsearch for the product ŚUser Guide can be found
under the “Download” tab on the product page.
Note

7
Note
T1. How do I restore my Modem Router’s configuration to its factory default
settings?
T2. What can I do if I don’t know or forget my password?
1) Restore the Modem Router’s configuration to its factory default settings. If
you don’t know how to do that, please refer to section T1.
2) Use the default user name and password: admin, admin.
3) Try to configure your Modem Router once again by following the instructions
in the previous steps of the QIG.
T3. What can I do if I cannot access the web-based configuration page?
1) Configure your computer’s IP Address.
Once the Modem Router is reset, the current configuration settings will be
lost and you will need to re-configure the router.
With the Modem Router powered
on, press and hold the RESET
button on the front panel for 8 to 10
seconds before releasing it.
Troubleshooting
Press it for 8 to 10 seconds

8
For Windows 7 OS
Go to Start > Settings > Control
Panel, and then you will see the
following page.
Click Change adapter settings
Click View network
status and tasks
Right-click Local
Area Connection
Click Properties

9
Double-click Internet Protocol
Version 4 (TCP/IPv4)
Click OK
Select Obtain an IP
address automatically
Select Obtain DNS server
address automatically

10
For Windows XP OS
Go to Start > Control Panel,
you will then see the following
page.
Click Properties
Right-click Local
Area Connection
Click Network
Connections
Click Network and
Internet Connections

11
Double-click Internet
Protocol (TCP/IP)
Select Obtain an IP
address automatically
Select Obtain DNS server
address automatically
Click OK

12
Click OK

13
For Windows Vista OS
Go to Start > Settings > Control
Panel, and then you will see the
following page.
Click Properties
Click View status
Click View network
status and tasks

14
ࡇᇙƽ
Double-click Internet
Protocol Version 4
(TCP/IPv4)
Select Obtain an IP
address automatically
Select Obtain DNS server
address automatically
Click OK

15
2) Configure your IE browser.
Open your IE browser, click
Tools tab and you will see
the following screen.
Select Never dial
a connection
Click OK
Click Internet Options
Now, try to log on to the Web-based configuration page again after the above
settings have been configured. If you still cannot access the configuration page,
please restore your Modem Router’s factory default settings and reconfigure
your Modem Router following the instructions of this QIG. Please feel free to
contact our Technical Support if the problem persists.

16
Note
T4. What can I do if I cannot access the Internet?
1) Check to see if all the connectors are connected well, including the telephone
line, Ethernet cables and power adapter.
2) Check to see if you can log on to the web management page of the Modem
Modem Router. If you can, try the following steps. If you cannot, please set
your computer referring to T3 then try to see if you can access the Internet. If
the problem persists, please go to the next step.
3) Consult your ISP and make sure all the VPI/VCI, Connection Type, account
username and password are correct. If there are any mistakes, please correct
the settings and try again.
4) If you still cannot access the Internet, please restore your Modem Router to
its factory default settings and reconfigure your Modem Router by following
the instructions of this QIG.
5) Please feel free to contact our Technical Support if the problem still exists.
For more details about Troubleshooting and Technical Support contact
information, please log on to our Technical Support Website:
http://www.tp-link.com/en/support

17
Login
A
dialog box will prompt you for the
User name and Password. Ente
r
the default values and click OK.
Note
The web management page will
display after a successful login.
If the dialog box does not pop up, please refer to T3 in the Troubleshooting
guide and T2 will give you some help if you forget the password.
Appendix
Click Quick Setup
User name: admin
Password: admin
Click OK
Open your web browser and
type 192.168.1.1 in the address
bar and press Enter

18
Internet Parameters Configuration
A. Configuration for PPPoE/PPPoA
This page will then display.
Bridge mode is not recommended because multiple computers are not
permitted to share Internet access in this mode.
This page will then display.
Note
Click Next
Note If you did not get the VPI, VCI and WAN Type information, please contact
your ISP for this information.
Choose the WAN Type given by
your ISP.
If PPPoE/PPPoA is selected,
please proceed to A;
If Dynamic IP is selected, please
skip to B;
If Static IP/IPoA is selectedLjplease
skip to C;
If Bridge Mode is selected, please
skip to D.
Enter the VPI and VCI
values given by your ISP
Click Next
Enter the Username and
Password provided by
your ISP
Click Next
Click Next

19
B. Configuration for Dynamic IP
C. Configuration for Static IP/IPoA
D. Configuration for Bridge Mode
Wireless Settings Configuration
This type doesn't need to be configured.
This page will then display.
This type doesn't need to be configured.
A
fter completing the above configuration, please proceed to Wireless
Settings Configuration
This page will then display.
If you are using the modem on a new DSL line and have not completed
your DSL provider’s online registration, you may be using a generic
username and password. When registration is completed, you will need to
update the username and password if you have created a new one.
Note
Enter the Static IP information
provided by your ISP manually
Click Next
Keep the default setting: Enable. If
you want to disable WIFI Function,
please select Disable
Create a unique and
easy-to-remember name for your
wireless network. You can also
keep default settings without the
device being affected
Select a Mode type
Enter a Security Key using
8-64 characters
Click Next

20
Voice Settings Configuration
Quick Setup Complete
Note Disable Security is not recommended.
To continue, the following page will
be displayed.
Now, your Modem Router has been configured.
A
fter completing the above configuration, please proceed to
V
oice Settings
Configuration.
Save page will be displayed. Please confirm all parameters. Click Previous to
modify or click the Save button to make the configuration take effect.
Click Finish
This page will then display.
A
fter completing the above configuration, please proceed to Quick Setup
Complete.
Enter a profile name to
identify this account
Enter the Voice
information provided
by your ISP manually
Note For advanced settings, check the box before More Setup.
