Trinity TLS-1901 User manual

OWNER’S MANUAL
TRINITY 24” STAINLESS STEEL TABLE
Model # TLS-1901
Everything in its place.®

© 2016 TRINITY - 800.985.5506
1

Your TRINITY 24” Stainless Steel Table should include the following parts. Please inspect box
contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact
TRINITY Customer Service: 800.985.5506 or customerserv[email protected]. Parts can also be
requested online via our “Contact Us” section at www.trinityii.com.
PARTS LIST
TABLE TOP (1)
A
SHELF (1)
B C
HEX KEY (1)
D E
LEG (4)
Feet Levelers come pre-installed
HEX SCREW (8)
F
SCREW CAP (8)
© 2016 TRINITY - 800.985.5506 2

ASSEMBLY INSTRUCTIONS
Slide the SHELF (B) over each LEG (C)
to the desired height. Using the provided
HEX KEY (F), tighten the HEX SCREW
(D) into the SHELF (B).
Turn the HEX KEY (F) as far clockwise
as possible, take out the HEX KEY (F),
reposition, reinsert, and turn as far
clockwise as possible again until the
HEX SCREW (D) is securely in place.
Place the SCREW CAP (E) over each
HEX SCREW (D).
Lay the TABLE TOP (A) upside-down on
a smooth flat surface. Insert LEGS (C)
into the round slots on the bottom of the
TABLE TOP (A). Make sure LEGS (C)
are fully inserted into the TABLE TOP
(A).
You will insert and tighten the HEX
SCREWS (D) in Step 3.
STEP 1
STEP 2
A (1) C (4)
E(4) F(1)
D (4)
C
A
B(1)
B
DE
© 2016 TRINITY - 800.985.5506
3

ASSEMBLY INSTRUCTIONS
Use the HEX KEY (F) to tighten the HEX
SCREW (D) for each LEG (C) into the
TABLE TOP (A).
Turn the HEX KEY (F) as far clockwise
as possible, take out the HEX KEY (F),
reposition, reinsert, and turn as far
clockwise as possible again until the HEX
SCREW (D) is securely in place. Place
the SCREW CAP (E) over each HEX
SCREW (D).
Turn the Table right-side up and adjust
Feet Levelers until the Table is stable
and level.
STEP 3
E(4) F(1)
D (4)
DE
© 2016 TRINITY - 800.985.5506 4

SERVICE PARTS LIST –TLS-1901
Part Number Description Part Number Description
1) XBS-06-007-2424 Table Top 5) XXX-97-001-0001 Hex Key
2) XBS-03-012-2017 Shelf 6) XBK-23-005-0914 Screw Cap
3) XGL-04-010-3200 Leg 7) ZSV-01-015-0812 Hex Screw
4) XSV-98-004-3283 Feet Leveler
TRINITY Customer Service provides the following replacement parts:
3
54
7
2
6
1
© 2016 TRINITY - 800.985.5506
5

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result
in injury and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot
cover all possible conditions or situations that may occur. The user must
always be aware of their environment and ensure that they use the product in a safe
and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
4. Check for damaged parts. Before using this product, carefully check that all parts
are in good condition, and that the product will operate properly and perform its
intended function. Check for damaged parts and any other conditions that may affect
the operation of this product. Replace damaged or worn parts, and never use this
product with a damaged part.
5. Do NOT overload the product.
6. Table must be used with at least one shelf installed for stability. Additional shelf
can be added and is available on trinityii.com.
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do not use scouring pad for cleaning.
•Keep dry and avoid damp environments.
•Use a quality stainless steel cleaner and follow instructions that come with the
cleaner. WipeALONG the grain (NOT against).
Weight capacity per shelf 100 lb (evenly distributed)
Total weight capacity on feet levelers 200 lb (evenly distributed)
