OWNER’S MANUAL
TRINITY 4-TIER NSF 48” x 24” x 72”
WIRE SHELVING RACK –BLACK
Model # TBFPB-0916
Everything in its place.®

© 2017 TRINITY - 800.985.5506
Your TRINITY EcoStorage™ 4-Tier NSF 48” X 24” Wire Shelving Rack – Black should include the following
parts. Please inspect box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
at www.trinityii.com (Help & More, Contact Us).
You will need no additional tools for assembly.
PARTS LIST
SHELF (4) SLIP SLEEVE
(32) + (2) extra
Please inspect box contents to ensure you have received all components.
Note: The black circular plastic tops in between the shelves are used only for packaging purposes. They
are NOT NEEDED. Please discard.
TOP POLE (4)
End Cap (4) and
Pole Connector (4)
are pre-installed
BOTTOM POLE (4)
Threaded Insert (4) and
Feet Leveler (4)
are pre-installed
1
AB C D

© 2017 TRINITY - 800.985.5506
ASSEMBLY INSTRUCTIONS
STEP 1: SLIP SLEEVES
STEP 2: INSTALLING BOTTOM SHELF
* For safety and stability, the lowest shelf should be lower than the 3rd notch from the bottom.
** Note: There will be a very small gap in-between the SLIP SLEEVES (D)—this is normal.
2
A (4) D (8)
C (1)
Place SHELF (C) on its side and slide the (4)
BOTTOM POLES (A) through the holes in the
SHELF (C). Make sure that the SHELF (C)
corner cylinders are positioned over the SLIP
SLEEVES (D).
Stand the unit upright.
*Note: The level side of the SHELF (C) is the
TOP side (the TRINITY logo on the corner
cylinders should be right-side up.)
**Use a rubber mallet, if needed, to secure
the SHELF (C).
For easiest assembly, do not attach the TOP (B) and
BOTTOM (A) POLES until instructed. Once connected,
these will be the posts for the rack.
Note that each POLE (A+B) has slight horizontal line
indentations at 1” intervals. Each SLIP SLEEVE (D) has
raised horizontal lines inside designed to lock them in
place on the POLE (A+B).
On the BOTTOM POLE (A), place 1 pair of SLIP SLEEVES (D)
at the desired level. Please make sure the arrow faces up
and that the word “TOP” is right side up. Do this for each
BOTTOM POLE (A) and make sure that the heights are
identical for BOTTOM POLE (A).
Slide the pair of SLIP SLEEVES (D) until you hear a click to
confirm the pair is locked onto the BOTTOM POLE (A). DO
NOT place more than one pair on each POLE (A) at a time.

© 2017 TRINITY - 800.985.5506
ASSEMBLY INSTRUCTIONS
STEP 4: INSTALLING TOP POLES
3
Screw the TOP POLE (B) into the BOTTOM POLE
(A). The tops of these poles are indicated by the
BLACK END CAP.
B (4)
STEP 3: INSTALLING SHELVES
On POLE (A), place 1 pair of SLIP SLEEVES (E) at the desired
distance between SHELVES (C). Please make sure the arrow
faces up and that the word “TOP” is right side up. Do this for
each POLE (A), and make sure that the heights are identical
for each POLE (A).
Lower SHELF (C) over the BOTTOM POLES (A) so that the
corner cylinders of the SHELF (C) are positioned over the SLIP
SLEEVES (D).
Repeat Step 3 to install other SHELVES (C) as desired.
**Use a rubber mallet, if needed, to secure the SHELVES (C).
D (8) C (1)

© 2017 TRINITY - 800.985.5506 4
ASSEMBLY INSTRUCTIONS
The Feet Levelers are already screwed into the
BOTTOM POLES (A) and you can adjust as needed to
ensure your shelving rack is level.
STEP 6: FEET LEVELERS
STEP 5: INSTALLING SHELVES
D (16) C (2)
On POLE (A+B), place 1 pair of SLIP SLEEVES (D) at the desired
distance between SHELVES (C). Please make sure the arrow
faces up and that the word “TOP” is right side up. Do this for
each POLE (A+B), and make sure that the heights are
identical for each POLE (A+B).
Lower SHELF (C) over the TOP POLES (B) so that the corner
cylinders of the SHELF (C) are positioned over the SLIP
SLEEVES (D).
Repeat Step 5 to install other SHELVES (C) as desired.
**Use a rubber mallet, if needed, to secure the shelves.

© 2017 TRINITY - 800.985.5506
5
TRINITY Customer Service provides the following replacement parts:
SERVICE PARTS LIST –TBFPB-0916
Part Number Description Part Number Description
1) XBK-01-011-2543 Slip Sleeve 5) XBK-98-003-2538 Feet Leveler
2) PBK-04-006-3600 Top Pole 6) XBK-23-004-2517 End Cap
3) ZSV-01-013-2523 Pole Connector 7) PBK-03-007-4824 Shelf
4) PBK-04-008-3600 Bottom Pole
2
1
3
4
5
6
7

© 2017 TRINITY - 800.985.5506 6
WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
4. Check for damaged parts.Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
5. Do NOT overload the product.
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals
•This item is not certified for outdoor use
Weight capacity per shelf 800 lb (evenly distributed)
Total weight capacity of Shelving Rack 3200 lb (evenly distributed)

© 2017 TRINITY - 800.985.5506
7

Thank you for purchasing a TRINITY 4-Tier NSF 48” X 24” Wire Shelving Rack –Black. In
order to register your product and receive streamlined customer service, please fill out the
following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the
Product Registration Form online at www.trinityii.com or (3) scan and email the form to
[e-mail]. Include a copy of your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TBFPB-0916 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
PRODUCT REGISTRATION
© 2017 TRINITY - 800.985.5506 8

© 2017 TRINITY - 800.985.5506
9

1 YEAR LIMITED WARRANTY
TRINITY 4-Tier NSF 48” X 24” Wire Shelving Rack – Black
Model # TBFPB-0916
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the
TRINITY 4-Tier NSF 48” X 24” Wire Shelving Rack — Black (“Product”) that each Product shall be free from
defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s
obligation under this warranty shall be limited to repair or replacement of, or adequate compensation for the
Product which shall not be greater than the amount of the purchase price of the Product, at the option of
Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must
be returned to Trinity.
This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising
from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or
alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by
the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is
limited in duration to one year from the date of purchase and is subject to the same conditions and
limitations as is provided for our express warranty.
Except as set forth herein, and to the extent of applicable there are no warranties on this Product either
express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of
merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any
person, firm, or corporation with respect to this product shall be binding on Trinity.
If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service toll-
free at [phone], between 8:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased,
the date of the purchase, and the problem with your Product. A copy of your original purchase receipt must
accompany your service request.
LIMITATION OF REMEDIES AND LIABILITY
Trinity (and its employees, officers, members, managers, affiliates an assigns) shall not be liable for any
incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty,
express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and
attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of
contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As
noted above, to the extent damages are allowed by our express warranty or by applicable law, those
damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser
assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others
and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall
not extend to anyone other than the original purchaser of this product, is nontransferable and states your
exclusive remedy.
Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive
damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific
legal rights, and you may have other rights which vary from state to state.
