Trinity TLS-0209 User manual

OWNER’S MANUAL
TRINITY STAINLESS STEEL TABLE
Model # TLS-0209 (60”)
/ TLS-0210 (72”)

© 2018 TRINITY - 800.985.5506
1

Your TRINITY Stainless Steel Table should include the following parts. Please inspect box contents to
ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via our “Contact Us” section at www.trinityii.com.
PARTS LIST
TABLE TOP (1)
A
SHELF (1)
BC
HEX KEY (1)
DE
LEG (4)
Feet Leveler comes pre-installed
HEX SCREW (8)
F
SCREW CAP (8)
© 2018 TRINITY - 800.985.5506 2

ASSEMBLY INSTRUCTIONS
With another person’s help, slide the SHELF (B) over
each LEG (C) to the desired height. Using HEX KEY (F),
tighten the HEX SCREW (D) clockwise into SHELF (B),
until HEX SCREW (D) is securely in place.
Repeat step to ensure each HEX SCREW (D) is properly
installed.
Place a SCREW CAP (E) over each HEX SCREW (D).
Lay the TABLE TOP (A) upside-down on a smooth flat
surface. Insert LEGS (C) into the round slots on the
bottom of the TABLE TOP (A). Make sure LEGS (C) are
fully inserted into the TABLE TOP (A).
You will insert and tighten the HEX SCREWS (D) in
Step 3.
Do NOT tighten HEX SCREWS (D) in Step 1.
STEP 1
STEP 2
A (1) C (4)
E (4) F (1)
D (4)
C
A
B (1)
B
DE
© 2018 TRINITY - 800.985.5506
3

ASSEMBLY INSTRUCTIONS
Using HEX KEY (F), tighten HEX SCREW (D)
clockwise into TABLE TOP (A), until HEX
SCREW (D) is securely in place.
Repeat step to ensure each HEX SCREW (D) is
properly installed.
Place a SCREW CAP (E) over each HEX SCREW
(D).
Turn the Table right-side up and adjust Feet
Levelers until the Table is stable and level.
STEP 3
E (4) F (1)
D (4)
DE
© 2018 TRINITY - 800.985.5506 4
A

SERVICE PARTS LIST –TLS-0209 (60”) / TLS-0210 (72”)
Part Number Description Part Number Description
1) XBS-06-007-6024 60” Table Top 6) XSV-98-004-3283 Feet Leveler
2) XBS-06-007-7224 72” Table Top 7) XXX-97-001-0001 Hex Key
3) XBS-03-012-5617 60” Table Shelf 8) ZSV-01-015-0812 Hex Screw
4) XBS-03-069-6817 72” Table Shelf 9) XBK-23-005-0914 Screw Cap
5) XGL-04-010-3200 Leg
TRINITY Customer Service provides the following replacement parts:
3
5
4
2
9
1
8
© 2018 TRINITY - 800.985.5506
5
6
7

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
5. Table must be used with at least one shelf installed for stability. Additional shelves can be
purchased and are available on www.trinityii.com.
6. Do NOT overload the product.
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do not use scouring pad for cleaning.
•Keep dry and avoid damp environments.
•Use a quality stainless steel cleaner and follow instructions that come with the cleaner.
Wipe ALONG the grain (NOT against).
Weight capacity per 60” table shelf 200 lb (evenly distributed)
Weight capacity per 72” table shelf 250 lb (evenly distributed)
Total weight capacity on feet levelers of 60” table 1000 lb (evenly distributed)
Total weight capacity on feet levelers of 72” table 1100 lb (evenly distributed)
© 2018 TRINITY - 800.985.5506 6
