Trojan ELLIPTI-CYCLE 210 Installation guide

www.trojanhealth.co.za
#1
HOME
FITNESS
SOUTH AFRICA’S
SINCE
1981
0861 876526
0861 TROJAN
WARRANTY
TROJAN
MY SPACE MY TIME
®
CAUTION
READ ALL PRECAUTIONS AND
INSTRUCTIONS IN THIS MANUAL
BEFORE USING THIS EQUIPMENT.
KEEP THIS MANUAL FOR
FUTURE REFERENCE
ELLIPTI-CYCLE210
ELLIPTICALTRAINER
ELLIPTICALTRAINERASSEMBLY,CARE
ANDINSTRUCTIONSMANUAL

10212-3

10212-4

10212-5

10212-6

10212-7
#51

10212-8

10212-9
CAUTION:
Ensure that cables are not damaged
during assembly or when tightening screws.

10212-10
Recheck
all bolts and nuts are
tightened securely
before using the machine
CAUTION:
Ensure that cables are not damaged
during assembly or when tightening screws.

10212-11
FUNCTIONS AND OPERATIONS:
AUTO ON /OFF: Start to exercise or press the MODE button on the computer to turn the computer on.
If you leave the equipment for 4 minutes, the power will turn off automatically.
SCAN Press the MODE button until the arrow points to SCAN; the computer will
automatically scan the function every 5 seconds.
TIME: Press the MODE button until the arrow points to TIME; the computer will display your
elapsed workout time in minutes and seconds.
SPEED: Press the MODE button until the arrow points to SPEED; the computer will display the
current training speed.
CAL (CALORIES) Press the MODE button until the arrow points to CAL; the computer will display the
total accumulated calories burned during workout.
(PULSE)
Press MODE button until the arrow points to PULSE and then hold both hands on
the handlebar grip sensors and the screen will display your current heart rate figures
and a heart symbol.To ensure the pulse readout is more precise, always hold onto the
handlebar grip sensors with both hands instead of just with one hand.
DIST (DISTANCE) Press the MODE button until the arrow points to DIST; the computer will display the
accumulated distance traveled during the workout.
ODO (ODOMETER) Press the MODE button until the arrow points to ODO; the computer will display the
total accumulated distance of all workouts.
RESET Press and hold the MODE button for 4 seconds, all data values will clear to zero except
the ODO (ODOMETER) values.

10212-12
Diagram 1
Diagram 2

10212-13

10212-14

10212-15
1
2
3
4
5

10212-16

10212-17
No. Description Qty
1 End Cap 8
2 Foam Grips 2
3 Right Handlebar 1
4 Left Handlebar 1
5 Plastic Bushing 4
6 Knob 4
7 Bolt 2
8 Spring Washer 2
9 D Washer 2
10 Powder Metal Bushing 10
11 Adjustable Washer 1
12 Connecting Tube 1
13 Left Coupler Bar 1
14 Right Coupler Bar 1
15 End Cap 2
16 Fan Wheel 1
17 Fan Wheel Axle 1
18 Nut 3
19 Sensor 1
20 Bolt 4
21 Pedal 2
22 Right Pedal Bolt 1
23l Left Pedal Tubing 2
23r Right Pedal Tubing
24 Chain 1
25 Bolt 2
26 Powder Metal Bushing 4
27 Square Tube Pl ug 2
28 Spring Nut 6
29 Nut 2
30 Adjustable Bolt 2
31 U Bracket 2
32 Spring Washer 2
33 Nut 2
68 Cap S16 4
69 Cap S13 2
70 Foam Grip 2
71 Hand Pulse Sensor With Wire 2
72 Screw ST4.2 x 20 1
73 Middle Handlebar 2
74 Bolt M10 x 35 S6 2
75 Washer 2
76 Square Cap 1
77 Handlebar Post 3
78 Nut M8 2
79 Bolt M8 x 38 S6 1
80 Bolt M8 x 63 S6 1
81 Rear Shaft Post 3
82 Plug 2
83 Bearing 2
84 Cap Nut M5 2
85 Nut M4 1
No. Description Qty
34 Main Frame
35 Handlebar End Cap
36 Spring Nut 2
37 Wheel 2
38 Bolt 2
39 Spring Washer 2
40 Right Spring Nut 1
41 Train Wheel 1
42 Crank 1
43 Left Spring Nut 1
44 Computer 1
45 Knob 1
46 Left Pedal Bolt 1
47 Nut 4
48 Curve Washer 4
49 Bolt 4
50 Front Cylindrical Base 1
51 Back B ottom Tube 1
52 Ring 1
53 Axle Sleeve 15/16” 1
54 Axle Bush 2
55 Ball Bearing 2
56 Axle Sleeve 7/8” 1
57 Ring 1
58 Nut 1
59 Right Chain Cover 1
60 Left Chain Cover 1
61 Seat Post 1
62 Decoration Cover 2
63 Screw ST4.8 x 20 2
64 Screw ST4.8 x 40 7
65 Plastic Sleeve 1
66 Seat Cushion DD-982AT 1
67 Cap S18 2
86 Bushing
87 Washer 2
88 Right Spacer 1
89 Left Spacer 1
90 Wave Washer 2
91 Brake Plate 1
92 Brake Clamp Plate 1
93 Screw M5 x 30 2
94 Screw M4 x 12 2
95 Knob 1
96 Washer 3
97 Cap 3
98 Screw M5 x 12 4
99 Middle Wire 3
100 Tube Assembly 2
101 Middle Post 1
102 Front Shaft Post 1

10212-18

10212-19

10212-20
