Trojan IRONMAN 520 Installation guide

TROJAN
MY SPACE MY TIME
®
CAUTION
READ ALL PRECAUTIONS AND
INSTRUCTIONS IN THIS MANUAL
BEFORE USING THIS EQUIPMENT.
KEEP THIS MANUAL FOR
FUTURE REFERENCE

10283-3

10283-4

10283-5
SPECIFICATIONS
Motor: 1.5 hp continuous / 3.0 hp peak
Speed: 1-16 kph
Functions: Speed / distance / time / calories / incline / pulse
Programs - 7 pre-set / 1 manual / 3 heart rate control / 4 user
Elevation: Electronic incline 0-12%
Running deck (mm): 1230 (l) x 630 (w)
Set-up size (mm): 1800 (l) x 880 (w) x 1325 (h)
User weight: 130 kg (maximum)

10283-6
ITEM Description Qty
A Frame 1
B Computer Consol 1
C Left Upright 1
D Right Upright 1
E Left Decoration Cover 1
F Right Decoration Cover 1
G MP3 sound wire 1
ITEM Description Qty
a Truss Hex Screw M8 x P1.25 x 15 16
b Truss Philips Self Tapping Screw M5 x 15 6
c Hex Wrench + Screwdriver 5 mm (70 mm x 70 mm) 1
d Safety Key 1
e SILICON 1
f Hex Wrench 6 mm 1

10283-7
Recheck
all bolts and nuts are
tightened securely
before using the machine
CAUTION:
Ensure that cables are not damaged
during assembly or when tightening screws.
CAUTION:
Ensure that cables are not damaged
during assembly or when tightening screws.
CAUTION:
Ensure that cables are not damaged
during assembly or when tightening screws.
!

10283-8

10283-9
Speed Interval
6 KM / hr. Below 1 year
6~12 KM / hr. 6 months
12 KM / hr. Above 3 months

10283-10

10283-11

10283-12
HEART RATE TRANING ZONES
LOW FAT BURN AEROBIC HIGH

10283-13

10283-14

10283-15

10283-16

10283-17

10283-18

10283-19

10283-20
SPEED AND
ELEVATION
CHANGES
9 HOLE (P1) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
Level 1 ELEVATION 0.0 1.0 1.0 1.0 1.0 1.0 2.0 1.0 1.0 1.0 1.0 2.0 1.0 1.0 1.0 1.0 2.0 1.0 1.0 1.0 1.0 2.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 2 ELEVATION 0.0 1.0 1.0 1.0 1.0 1.0 2.0 1.0 1.0 1.0 1.0 2.0 1.0 1.0 1.0 2.0 3.0 1.0 1.0 1.0 1.0 2.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 3 ELEVATION 0.0 1.0 1.0 1.0 1.0 1.0 3.0 1.0 1.0 1.0 1.0 3.0 1.0 1.0 1.0 2.0 3.0 1.0 1.0 1.0 1.0 3.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 4 ELEVATION 0.0 1.0 1.0 1.0 1.0 1.0 3.0 1.0 1.0 1.0 1.0 3.0 1.0 1.0 1.0 3.0 4.0 1.0 1.0 1.0 1.0 3.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 5 ELEVATION 0.0 1.0 1.0 1.0 1.0 1.0 4.0 1.0 1.0 1.0 1.0 4.0 1.0 1.0 1.0 3.0 4.0 1.0 1.0 1.0 1.0 4.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 6 ELEVATION 0.0 1.0 1.0 1.0 1.0 1.0 4.0 1.0 1.0 1.0 1.0 4.0 1.0 1.0 1.0 4.0 5.0 1.0 1.0 1.0 1.0 4.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 7 ELEVATION 0.0 1.0 1.0 1.0 1.0 1.0 5.0 1.0 1.0 1.0 1.0 5.0 1.0 1.0 1.0 4.0 5.0 1.0 1.0 1.0 1.0 5.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 8 ELEVATION 0.0 1.0 2.0 2.0 2.0 2.0 5.0 2.0 2.0 2.0 2.0 5.0 2.0 2.0 2.0 5.0 6.0 2.0 2.0 2.0 2.0 5.0 2.0 2.0 2.0 2.0 2.0 2.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 9 ELEVATION 0.0 1.0 2.0 2.0 2.0 2.0 6.0 2.0 2.0 2.0 2.0 6.0 2.0 2.0 2.0 5.0 6.0 2.0 2.0 2.0 2.0 6.0 2.0 2.0 2.0 2.0 2.0 2.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
Level 10 ELEVATION 0.0 1.0 2.0 2.0 2.0 2.0 6.0 2.0 2.0 2.0 2.0 6.0 2.0 2.0 2.0 6.0 7.0 2.0 2.0 2.0 2.0 6.0 2.0 2.0 2.0 2.0 2.0 2.0 1.0 0.0
(MPH) 1.0 1.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.5 1.0
(KPH) 1.6 2.4 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 3.2 2.4 1.6
