Trojan TITAN 330 User manual

USER MANUAL
TITAN 330
TREADMILL LEG WORKOUT CARDIO
Visit facebook.com/trojanhealth
www.trojanhealth.co.za
www.instagram.com/trojanhealth
CAUTION
READ ALL PRECAUTIONS AND
INSTRUCTIONS IN THIS MANUAL
BEFORE USING THIS EQUIPMENT.
KEEP THIS MANUAL FOR
FUTURE REFERENCE.

2
INDEX
• Important Safety Instructions ________________________________ 3
• Pre Assembly Check List _____________________________________ 5
• Hardware & Tool List _________________________________________ 6
• Parts List ___________________________________________________ 7
• Exploded Drawing ___________________________________________ 9
• Assembly Steps _____________________________________________ 10
• Console Functions ___________________________________________ 13
• Pre-set Programs ____________________________________________ 16
• Exercise Instructions ________________________________________ 18
• Fitness Tips & Techniques ____________________________________ 20
• Conditioning Guidelines ______________________________________ 21
• Warm Up & Cool Down _______________________________________ 22
• Maintenance ________________________________________________ 23
• Troubleshooting _____________________________________________ 25
• 2 Year Limited Warranty ______________________________________ 26
• Repairs Procedure ___________________________________________ 27

3
IMPORTANT SAFETY INSTRUCTIONS
It is the sole responsibility of the purchaser of Trojan products to read the owner’s manual, warning labels and
instruct all individuals, on proper usage of the equipment. Understanding each and every warning to the fullest
is important. If any of these instructions or warnings are unclear please contact Trojan Customer Services on
0861 TROJAN (0861 876526), within the Republic of South Africa. Customers residing outside South Africa
can contact us on [phone].
The equipment is only intended for home use and is not intended for commercial, institutional and/or studio
facilities use.
Contact Trojan with any questions regarding this classication. It is recommended that all users of Trojan be
informed of the following information prior to use.
HEALTH WARNING
• Before starting any exercise or conditioning program you should consult with your personal physician to
see if you require a complete physical exam. This is especially important if you are inactive, pregnant or
suffer from any illness.
• If at any time during exercise you feel faint, dizzy or experience pain, stop exercising immediately and
consult your physician.
• To avoid muscular pain and strain, begin each workout by stretching and warming up and end each session
by cooling down and stretching.
INSTALLATION
Trojan recommends that all equipment:
• Be secured to or set up on a solid, level surface to stabilise and eliminate rocking or tipping over
during training.
• Be set up inside your home away from moisture and dust (the equipment is not designed for outdoor use).
• Be set up with sufcient ventilation to ensure proper operation.
• Be set up with sufcient space around the equipment so that all exercises can be completed safely. It is
recommended that there should be at least 1 m of space around the equipment where access is required
to exercise.
PROPER USAGE
• Do not use the equipment in any way other than as designed or intended by the manufacturer. It is
imperative that Trojan equipment is used properly to avoid injury.
• Injuries may result from exercising improperly or excessively.
• Your Trojan equipment should only be used by 1 person at a time.
• Be careful to maintain your balance while using, mounting, dismounting or assembling your Trojan
equipment to avoid injury.
• Servicing other than the procedures in this manual should be performed by an authorised service
representative only.

4
ACCESS CONTROL
• Trojan recommends that all tness equipment be used in a supervised area. It is recommended that
the equipment be located in an access controlled area. Control is the responsibility of the owner.
Keep children away from all equipment.
• Parents or other supervising adults must provide close supervision of children if the equipment is used
in the presence of children.
INSPECTION
• Do not use or permit use of any equipment that is damaged, or has worn or broken parts. For all Trojan
equipment use only replacement parts supplied by Trojan.
• Always make sure that all nuts and bolts are tightened prior to each use.
• Maintain labels and nameplates – do not remove labels for any reason. They contain
important information.
• Equipment maintenance – preventative maintenance is the key to smooth operating equipment. Please
ensure that you follow our maintenance tips to ensure the continued correct function of your
Trojan equipment.
• Before any use, examine all accessories approved for use with the Trojan equipment for damage or wear.
• Should your Trojan equipment appear damaged or worn, do not attempt to use or repair the
equipment yourself.
• Please contact our service department on 0861 TROJAN (0861 876526) to arrange a repair.
Customers residing outside South Africa can contact us on [phone].
OPERATING WARNINGS
• It is the purchaser’s responsibility to instruct all users as to the proper operating procedures of all
Trojan equipment.
• Keep children away from all moving parts. Parents must provide close supervision of children if the
equipment is used in the presence of children.
• Do not wear loose tting clothing or jewellery when using the equipment. It is also recommended that
users tie up long hair to avoid contact with moving parts.
• Ensure that anyone not using the equipment stays clear of the user, accessories and moving parts while
the machine is in operation.
USER WEIGHT LIMITATIONS
• This Trojan Titan 330 Treadmill may not be used by persons weighing more than 110 kg.
SAVE THIS INSTRUCTION MANUAL FOR FUTURE USE AND REFERENCE.
If any of these instructions or warnings are unclear please contact Trojan Customer Services on
0861 TROJAN (0861 876526) within the Republic of South Africa or visit www.trojanhealth.co.za.
Customers residing outside South Africa can contact us on [phone].
IMPORTANT SAFETY INSTRUCTIONS

5
PRE ASSEMBLY CHECK LIST
Thank you for choosing the Trojan Titan 330 Treadmill. We take great pride in producing this product and
hope it will provide many hours of quality exercise to make you feel better, look better and enjoy life to its
fullest. Yes, it’s a proven fact that a regular exercise program can improve your physical and mental health. Too
often, our busy lifestyles limit our time and opportunity to exercise. The Trojan Titan 330 Treadmill provides a
convenient and simple method to begin your assault on getting your body in shape and achieving a healthier
lifestyle. Before reading further, please review the drawing below and familiarise yourself with the parts that
are labelled.
Read this manual carefully before using the Trojan Titan 330 Treadmill.
Console
Display
Safety Key
Hand Rail
Heart Rate
Sensor
Running
Deck
Power
Switch
Side Cover
Upright
Tube
Programs 9 Pre-set
Function Time / Speed / Pulse / Calories / Speed / Incline / Body Fat / Step Calculation
Set-up Size 1615 mm (l) x 680 mm (w) x 12750 mm (h)
Running deck 1240 mm (l) x 400 mm (w)
User Weight 110 kg (maximum)

6
HARDWARE & TOOL LIST
INSTRUCTIONS FOR ASSEMBLY
• Before you start to assemble, please check the hardware packaging to make sure all parts are included.
• Basic tools, such as spanners will be provided for assembly.
33. Left Upright
Tube Cover
34. Right Upright
Tube Cover
12. Allen Wrench
(5 mm)2. Main Frame
55. Washer 8
39. Allen Screw
(M8 x 15 mm)
11. Wrench W / Screw
Driver (S=13, 14, 15)

7
PARTS LIST
No. Description Qty
1 Base Frame 1
2 Main Frame 1
3 Console Bracket 1
4 Left Upright 1
5 Right Upright 1
6 Motor Bracket 1
7 Fixing Pin 2
8 Turning Bushing 2
9 Front Roller 1
10 Rear Roller 1
11 Wrench W/Screw Driver (S=13, 14, 15) 1
12 Allen Wrench (5 mm) 1
13 Cylinder 1
14 Console Top Cover 1
15 Motor Top Cover 1
16 Motor Bottom Cover 1
17 Left Rear Cover 1
18 Right Rear Cover 1
19 Side Rail 2
20 Running Belt 1
21 Motor Belt 1
22 Console Board 1
23 Blue Cushion 2
24 Square Cushion 4
25 Ring Protecting Wire Plug 2
26 Moving Wheel 2
27 Power Wire Buckle 1
28 Foot Pad 4
No. Description Qty
29 Adjustable Foot Pad 2
30 End Cap 2
31 Foam 2
32 Incline Bushing 2
33 Left Upright Tube Cover 1
34 Right Upright Tube Cover 1
35 Bolt (M6) 2
36 Bolt (M8) 8
37 Bolt (ST 4.2 x 12 mm) 12
38 Bolt (M8 x 35 mm) 1
39 Bolt (M8 x 15 mm) 12
40 Bolt (M8 x 20 mm) 4
41 Bolt (M8 x 30 mm) 1
42 Bolt (M8 x 40 mm) 2
43 Bolt (M8 x 40 mm) 4
44 Bolt (M8 x 45 mm) 1
45 Bolt (M10 x 30 mm) 2
46 Bolt (M6 x 55 mm) 2
47 Bolt (M6 x 45 mm) 1
48 Bolt (M6 x 35 mm) 6
49 Screw (ST 4.2 x 20 mm) 4
50 Screw (M5 x 8 mm) 16
51 Screw (ST 2.9 x 8 mm) 2
52 Screw (ST 4.2 x 12 mm) 18
53 Screw (ST 4.2 x 25 mm) 2
54 Washer 3
55 Washer 6
56 Washer 7

8
PARTS LIST
No. Description Qty
57 Washer 8 16
58 Washer (Ø10 mm x Ø26 mm x 2 mm) 2
59 Control Board 1
60 Handpulse With Incline 1
61 Console Upper Wire 1
62 Console Middle Wire 1
63 Console Lower Wire 1
64 Speed Sensor 1
65 DC Motor 1
66 Safety Accessory 1
67 AC Single Line Blue 1
68 AC Single Line Brown 2
69 Power Wire 1
70 Running Board 1
71 Square Switch 1
72 Overload Protector 1
73 Magnetic Ring 1
No. Description Qty
74 Magnetic Core 1
76 Bolt (M8 x 35 mm) 2
77 Inner Cap 2
78 Speaker Net 2
79 Silica Gel Pad 4
80 Oval Button 2
81 Function Button 1
82 Start Button 1
83 Stop Button 1
84 Filter 1
85 Inductance 1
86 Bolt (M10) 4
87 Lock Washer (10 mm) 2
88 Bolt (M10 x 45 mm) 3
89 Bolt (M10 x 100 mm) 1
90 Handpulse With Speed 1
91 Incline Motor 1

9
EXPLODED DRAWING

10
ASSEMBLY STEPS
1. PREPARATION
• Before assembling make sure that you will have enough space around the item.
• Use the supplied parts and hardware for the assembly.
• Before assembling, please check whether all the required parts have been supplied as per the exploded
drawing on the opposite page.
STEP 1:
Open the box and remove the spare
parts. Place the Main Frame (1) on a
level ground.
STEP 2:
Lift up the Console (A) and Upright Tube
(B) as indicated in the diagram.
Note: When lifting the Console (A) and
Upright Tube (B), make sure not to pinch
the wires inside the Upright Tubes.
STEP 1
STEP 2
