TSSU-72-30M-B-ST
TSSU-72-30M-B-ST
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Pans
(top)
Cabinet Dimensions
(inches)
(mm)
LD
†H*
HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TSSU-72-30M-B-ST 3 19.0
538
63072
3/8
1839
341/8
867
403/8
1026
1/2
1/2
115/60/1
230-240/50/1
10.5
6.7
5-15P
▲
7
2.13
425
193
†Depth does not include 1" (26 mm) for rear bumpers. ▲Plug type varies by country.
* Height does not include 61/4"(159 mm) for castors or 6"(153 mm) for optional legs.
1/06
R
True’s salad/sandwich units are
designed with enduring quality
that protects your long term
investment.
Oversized, environmentally
friendly (134A) forced-air
refrigeration system holds 33°F
to 41°F (.5°C to 5°C).
Complies with and listed under
ANSI/NSF-7-1997-6.3.
All stainless steel front, top
and cabinet ends. Matching
aluminum finished back.
Stainless steel, patented,
foam insulated lids and
hoods maintain colder pan
temperatures, lock in freshness
and minimize condensation.
Removable for easy cleaning.
87/8" (226 mm) deep, full
length removable cutting
board included. Sanitary, high
density, NSF approved white
polyethylene provides tough
preparation surface.
Foamed-in-place, high density
polyurethane insulation (CFC
free).
Heavy duty PVC coated wire
shelves.
Food Prep Table:
Mega Top Solid Door Sandwich/Salad Unit
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TSSU-72-30M-B-ST
TSSU-72-30M-B-ST
DESIGN
• True’s commitment to using the highest
quality materials and oversized refrigeration
systems provides the user with colder
product temperatures, lower utility costs,
exceptional food safety and the best value in
today’s food service marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary
tube system using environmentally friendly
(CFC free) 134A refrigerant.
• Oversized, factory balanced refrigeration
system with guided airflow to provide
uniform temperature in food pans and
cabinet interior.
• Forced-air design holds 33°F to 41°F (.5°C to
5°C) product temperature in food pans and
cabinet interior. Complies with and listed
under ANSI/NSF-7-1997-6.3.
• Sealed, cast iron, self-lubricating evaporator
fan motors and larger fan blades give True
sandwich/salad units a more efficient low
velocity, high volume airflow design.
• Condensing unit access in back of cabinet,
slides out for easy maintenance.
CABINET CONSTRUCTION
• Exterior - stainless steel front, top and
cabinet ends. Matching aluminum
finished back.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor
with coved corners.
• Insulation - entire cabinet structure and
solid doors are foamed-in-place using high
density, CFC free, polyurethane insulation.
• 5" (127 mm) diameter stem castors - locks
provided on front set. 36" (915 mm) work
surface height.
DOORS
• Stainless steel exterior with white aluminum
liner to match cabinet interior.
• Each door fitted with 12" (305 mm) long
recessed handle that is foamed-in-place with
a sheet metal interlock to insure permanent
attachment.
• Positive seal self-closing doors with 90° stay
open feature (excludes center door). Doors
swings within cabinet dimensions.
• Magnetic door gaskets of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Six (6) adjustable, heavy duty PVC coated
wire shelves. Two (2) left and two (2) right
door shelf dimensions are 219/16"L x 16"D
(548 mm x 407 mm), two (2) center door
shelf dimensions are 231/2"L x 16"D (597 mm
x 407 mm). Four (4) chrome plated shelf clips
included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
• 87/8" (226 mm) deep, full length removable
cutting board. Sanitary, high-density, NSF
approved white polyethylene provides tough
preparation surface.
• Stainless steel, patented, foam insulated lids
and hoods keep pans’ temperature colder,
lock in freshness and minimize condensation.
Removable for easy cleaning.
PAN CAPACITY
• Comes standard with 30 (1/6size)
67/8"L x 61/4"W x 4"D (175 mm x 159 mm x
102 mm) clear polycarbonate, NSF approved,
food pans in countertop prep area. Also
accommodates 6" (153 mm) and 8" (204 mm)
deep food pans.
• Countertop pan opening designed to
fit varying size pan configurations with
available pan divider bars. Varying size pans
supplied by others.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord and
plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230 - 240V / 50 Hz.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/flanged legs.
❒ 21/2" (64 mm) diameter castors.
❒ Additional shelves.
❒ Single utility shelf.
❒ Double utility shelf.
❒ Sneezeguard.
❒ 87/8" (226 mm) deep, 1/2" (13 mm) thick,
composite cutting board.
❒ Crumb catcher. Requires crumb catcher
cutting board for proper installation.
❒ Pan dividers.
❒ ADA compliant models with 34" (864 mm)
work surface height.
❒ Remote cabinets available (condensing unit
supplied by others), consult factory technical
service department for BTU information.
115/60/1
NEMA-5-15R
ELEVATION RIGHT VIEW PAN LAYOUT
Food Prep Table:
Mega Top Solid Door Sandwich/Salad Unit
725/16"
(1837 mm)
131/32"
(51 mm)
271/2"
(699 mm)
125/8"
(321 mm)
111/4"
(286 mm)
1"
(26 mm)
159/32"
(389 mm)
341/16"
(866 mm)
257/32"
(641 mm)
77/8"
(201 mm)
5215/16"
(1345 mm)
293/4"
(756 mm)
517/32"
(1301 mm)
3515/16"
(913 mm)
63/16"
(158 mm)
4615/32"
(1181 mm)
409/32"
(1024 mm)
1017/32"
(268 mm)
1/2"
(13 mm)
177/8"
(455 mm)
25/16"
(59 mm)
37/8"
(99 mm)
401/2"
(1029 mm)
127/32"
(47 mm)
