Trust SECURITY PLUS-LINE ALSIR-2000 User manual

SECURITY PLUS-LINE
ALSIR-2000
ALSIR2000 SIREN
Item 71112 Version 1.0
Visit www.trust.com
for the latest instructions
USER MANUAL
MULTI LANGUAGE

2
4
1
3
Red LED indicator
Learn button 2 sec
Arm
O
4 sec
ON button
On
O
1.5 sec

6
8
5
7
85 sec.
O
On
OFF button
4 sec
On
O
1.5 sec
Tamper switch
Tamper switch

910
11 12
Learn button
2 sec
6 sec
1 sec

1
ALSIR-2000 SIREN
1. Place batteries
Open the Siren by unscrewing the two screws beneath the light cap. When the screws are removed
the cap of the Siren can be slid open. When the cap of the Siren is slid open place 4x Alkaline D type
1.5V battery in the Siren. Observe the correct polarity of the batteries. When the battery is low the
Siren will give 1 beep every 5 seconds while entering arm/disarm mode for the duration of 3 minutes.
2. LED indicator
The Siren has a LED indicator in the light cap. The LED behaviour is as followed.
Confirm pair: LED will blink 5 times
Confirm unpair: LED will blink 5 times
Learn mode: LED will blink for 15 sec.
3. Learn mode
When the Siren is disarmed slide open the cap and press and hold the Siren learn button for about 2
seconds to enter learn mode. The LED of the Siren will be blinking (in the light cap). The learn mode
lasts 15 seconds. While in learn mode press the SET button on a sensor to pair it with the Siren (check
manual of the sensor how to pair it). The LED of the Siren will flash quickly 5 times to confirm the
pairing was successfully. Close the cap of the Siren.
4. Arm the ALSIR
To arm the Siren press and hold the ON button for 4 sec on the ALKCT-2000.
If the Siren is armed successfully the LED on the ALKCT will light up for 1.5 seconds.
5. Walk-out time
When the Siren is armed there is a 85 sec walk-out time. Within these 85 sec the system checks all
the sensors if they are responding and it is possible to leave the building without triggering the alarm.
When at the beginning of the walk-out time a window or door is open the alarm will go o for 20 sec
reminding that one of the doors or windows isn’t closed. After the window or door sensor is closed
the alarm will stop and continue in armed mode.
EN

ALSIR-2000 SIREN
2
6. Disarm ALSIR
To disarm the Siren press hold the OFF button for 4 sec on the ALKCT-2000.
If the Siren is disarmed successfully the LED on the ALKCT will light up for 1.5 seconds.
7. Tamper switch
The Siren contains a tamper switch. This is a switch that prevents the Siren from being moved when
it is armed. The tamper switch is pressed when the Siren is mounted on a wall or placed on another
flat surface. When the Siren is moved and it is armed the tamper switch will activate the alarm
immediately.
8. ALSIR placement
When placing the Siren on a wall keep attention that the tamper switch isn’t placed on a groove or
crack in the wall. Make sure that the tamper switch is placed on a location of the wall where it is firmly
pressed
9. Mount the ALSIR
To mount the Siren slide the cap o (see step 1) and screw the casing with screws on a flat surface
according to the screwholes. (Screws are included). Keep attention that the tamper switch is pressed
to the surface after mounting the Siren.
10. Close the ALSIR
Place the batteries in the Siren (see step 1) and slide the cap back on. Screw the screws back in
to secure the cap. When the Siren is triggered by a sensor it will flash and sound the alarm for
approximately 4 minutes.
11. Delete all paired devices
To delete all the devices that are paired with the Siren press the Siren learn button for 2 seconds untill
the LED is blinking. Release the button and press the button for another 6 seconds. The LED will begin
to flash quickly. Release the learn button and press it again for 1 sec to delete all paired devices.
EN

3
ALSIR-2000 SIREN
12. ALSIR flash behaviour + sound
Siren alarm: Siren will flash + sound for 4 min
Low battery: Siren will flash + sound if alarm active
Door/window open in walk-out time: Siren will flash + sound for 20 sec when the Siren is armed
EN

SECURITY PLUS-LINE
ALSIR-2000
ALSIR-2000 SIREN
IMPORTANT INFORMATION
MULTI LANGUAGE
Item 71112 Version 1.0
Visit www.trust.com
for the latest instructions

ALSIR-2000 SIREN
1
EN
Legal information
CE: Trust declares this device complies with the Directives as listed in Section 2 of this document.
WEEE: Dispose of the device at a recycling centre. More information: www.trust.com
Warranty information: www.trust.com/warranty
WIRELESS SIGNAL
• The 868 MHz signal passes through walls, windows and doors.
• Range up to 120 m (under optimal conditions).
• The range depends on local conditions, such as the presence of metals. The metal particles in for example, double
glazing (HR glass), can provide a reduction in the range of wireless signals.
• There may be restrictions on the use of this device outside the EU. Check, if applicable, whether this device meets local
regulations.
Read these simple instructions. Failure to follow these instructions can be dangerous.
Incorrect installation will void any warranty on this product.
TECHNICAL SPECIFICATIONS
• Battery
• Battery life
• Battery low indication
• Frequency
• RF Range
• Waterresistant
4x Alkaline D type 1.5V batteries (not included)
18 months stand-by
Siren will flash and beep every 5 sec while entering arm/disarm mode
868 MHz 2-way communication
Up to 120 m (under optimal conditions)
IP44
COMPATIBILITY
The Siren works with the
ALKCT-2000, ALMST-2000,
ALMDT-2000 and ICS-2000
FUNCTIONALITY
Siren for alarming purposes when a sensor is triggered.
SMARTPHONE/TABLET FUNCTIONS
By combining this product with a sensor and the OCTOPUS Control station, you can also set your alarm on / o via your
tablet and / or smartphone and receive push notifications when you are not at home.
For more information visit trust.com/71110

ALSIR-2000 SIREN
2
EN
BATTERY
Remove the battery from the device if it is not used for a
long time. Extreme temperatures reduce the capacity and
lifetime of the battery.
Siren will flash and beep every 5 sec while entering arm/
disarm mode Batteries should not be chopped into pieces or
burned. Dispose of batteries according to local regulations.
Deliver them for the possibility to reuse. Do not throw
batteries away with the normal household waste.
LIFE SUPPORT
Never use Trust SmartHome products for life support
systems or other applications where failures can have life-
threatening consequences.
INTERFERENCE
Interference can aect the operation of all
broadcast transmitters and receivers negatively. The
distance between 2 receivers or transmitters should be at
least 50 cm.
REPAIRS
Do not try to repair this product yourself. The device
contains no serviceable parts for the user.
WATER-RESISTANT
This product is IP44 water-resistant. Make sure the screws
in the light cap are fasten tight.
CLEANING
Clean this product with a dry cloth. Do not use harsh
chemicals, cleaning solvents or strong detergents.
HANDLING
Do not drop the device, bump the device against something
or shake it. Rough handling can damage internal circuit
boards and fine mechanics.
MEMORY
The Siren can save up to 16 devices in its memory
ENVIRONMENT
The product should not be exposed to extreme heat or
cold. This can damage the circuit boards and batteries or
shorten its life.
DISCLAIMER
This product is a basic deterrent against intruders.
However, it remains the responsibility of the end-user to
adequately protect their home against break-ins. Therefor
Trust cannot be held responsible or liable for any damages
resulting from break-ins, trespassing, unauthorized access
or vandalism.

ALSIR-2000 SIREN
50
EN
Declaration of conformity
Trust International B.V. declares that the
TrusT smarThome
-product:
model: ALSIR-2000 Siren
item number: 71112
intended use: Indoor/Outdoor
is in compliance with the essential requirements and other relevant provisions of the following directives:
EMC Directive (2014/30/EU), Low Voltage Directive (2014/35/EU), ROHS Directive (2011/65/EC), R&TTE
Directive (1999/5/EC). The product is compatible with the following norms/standards:
Manufacturer/Authorised representative,
H. Donker, Procurement Director
Dordrecht, April 28 2016
Trust International B.V.
LAAN VAN BARCELONA 600
3317DD DORDRECHT
NETHERLANDS
EN 300-220-1 V2.4.1 (2012)
EN 300-220-2 V2.4.2 (2012)
EN 301489-1 V1.9.2 (2011)
EN 301489-3 V1.6.1 (2013)
EN 60950-1: 2006+A11: 2009+A1 2010+A12:
2011+A2 2013
EN 55014-1 : 2006+A1 : 2009+A2: 2011
EN 55014-2: 1997+A1: 2001 +A2: 2008
EN 50581: 2012
